QISS7-721WHUAWEI MediaPad 7 Youth 2

2 Quick Start 1 Congratulations on your purchase of the HUAWEI MediaPad 7 Youth2. Press and hold the power key to power on or off your device or restart it. Press the power key once to turn on or off the screen. HUAWEI MediaPad 7 Youth2 at a Glance 2 Charging the Battery Installing the SIM and microSD Cards 3 This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment  Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device where prohibited.  Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more information.  Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Protecting your hearing when using a headset  To prevent possible hearing damage, do not listen at high volume levels for long periods.  Using a headset at high volumes may damage your hearing. To reduce this risk, lower the headset volume to a safe and comfortable level.  Exposure to high volumes while driving may cause distraction and increase your risk of an accident. Areas with flammables and explosives  Do not use the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using Safety information 4 your device in these environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols.  Do not store or transport the device in containers with flammable liquids, gases, or explosives. Traffic security  Observe local laws and regulations while using the device. To reduce the risk of accidents, do not use your wireless device while driving.  Concentrate on driving. Your first responsibility is to drive safely.  Do not hold the device while driving. Use hands-free accessories.  When you must make or answer a call, pull off the road safely and park the vehicle first.  RF signals may affect the electronic systems of motor vehicles. For more information, consult the vehicle manufacturer.  Do not place the device over the air bag or in the air bag deployment area in a motor vehicle. Doing so may hurt you because of the strong force when the air bag inflates.  Do not use your device while flying in an aircraft or immediately before boarding. Using wireless devices in an aircraft may disrupt wireless networks, present a hazard to aircraft operation, or be illegal. Operating environment  Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions.  Do not use your device during thunderstorms to protect your device against any danger caused by lightning.  Ideal operating temperatures are 0°C to 35°C. Ideal storage temperatures are –20°C to 60°C. Extreme heat or cold may damage your device or accessories.  Do not expose your device to direct sunlight (such as on a car dashboard) for prolonged periods. 5  To protect your device or accessories from fire or electrical shock hazards, avoid rain and moisture.  Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water heater, radiator, or candle.  Do not place sharp metal objects, such as pins, near the earpiece or speaker. The earpiece may attract these objects and result in injury.  Stop using your device or applications for a while if the device is overheated. If skin is exposed to an overheated device for an extended period, low temperature burn symptoms, such as red spots and darker pigmentation, may occur.  Do not touch the device's antenna. Otherwise, communication quality may be reduced.  Do not allow children or pets to bite or suck the device or accessories. Doing so may result in damage or explosion.  Observe local laws and regulations, and respect the privacy and legal rights of others. Child's safety  Comply with all precautions with regard to child's safety. Letting children play with the device or its accessories may be dangerous. The device includes detachable parts that may present a choking hazard. Keep away from children.  The device and its accessories are not intended for use by children. Children should only use the device with adult supervision. Accessories  Using an unapproved or incompatible power adapter, charger or battery may cause fire, explosion or other hazards.  Choose only accessories approved for use with this model by the device manufacturer. The use of any other types of accessories may void the warranty, may violate local regulations and laws, and may be dangerous. Please contact your retailer for information about the availability of approved accessories in your area. 6 Charger safety  For pluggable devices, the socket-outlet shall be installed near the devices and shall be easily accessible.  Unplug the charger from electrical outlets and the device when not in use.  Do not drop or cause an impact to the charger.  If the power cable is damaged (for example, the cord is exposed or broken), or the plug loosens, stop using it at once. Continued use may lead to electric shocks, short circuits, or fire.  Do not touch the power cord with wet hands or pull the power cord to disconnect the charger.  Do not touch the device or the charger with wet hands. Doing so may lead to short circuits, malfunctions, or electric shocks.  If your charger has been exposed to water, other liquids, or excessive moisture, take it to an …

Text truncated - open the document above for the full version.

Date (06/05/2014) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Huawei Technologies Co., Ltd. Bantian, Longgang District, Shenzhen, 518129, China hereby authorize TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Felix Li Phone: +86-755-88286998-3243 e-mail: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to denial of U.S. Federal benefits, which include FCC benefits, pursuant to section 5301 of Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. This authorization is application to following FCC ID application: FCC ID: QISS7-721W This authorization is valid until further written notice from Huawei Technologies Co., Ltd. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhangxinghai EMC Laboratory Manager

Huawei Technologies Co.,Ltd. Federal Communications Commission 2014-05-09 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISS7-721W To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure PCB Diagram Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2014-07-30: User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755- 28970299

Justification Letter Date (14/05/2014) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Huawei Technologies Co., Ltd. Bantian, Longgang District, Shenzhen, 518129, China hereby to do the Justification on original FCC application: HUAWEI MediaPad 7 Youth2, S7-721w, FCC ID: QISS7-721W as following: S7-721w is a MediaPad, it is support 2.4G wlan and bluetooth function. S7-722u is a MediaPad, it is supporting GSM850, PCS1900, WCDMA850, WCDMA1900, 2.4G wlan and bluetooth function. The difference between S7-722u (Product Type: HUAWEI MediaPad 7 Youth2; Model No.:S7-722u; FCC ID: QISS7-722U, Grant date: 2014-03-31) and S7-721w: 1) S7-722u delete the GSM850, PCS1900, WCDMA850, WCDMA1900 four bands. The PCB is the same. 2) With different model no. The followed table is show the different between the 2 Models. S7-722u S7-721w PCB the same The same WIFI/BT 2.4G the same The same GSM 850/1900 Support Not support WCDMA 1900/850 Support Not support So in FCC application for S7-721w (FCC ID: QISS7-721W), Test data for bluetooth is from report “SYBH(Z-RF)040022014-2002 ” in FCC application for S7-722u (FCC ID: QISS7-722U, Grant date: 2014-03-31), and this data according to Part 15C remains valid and applicable and they are representative of the compliance of S7-721w. Test data for WIFI is from report “SYBH(Z-RF)046042014-2001” in FCC application for S7-722u (FCC ID: QISS7-722U, Grant date: 2014-03-31), and this data according to Part 15C remains valid and applicable and they are representative of the compliance of S7-721w. New 15B Test report “SYBH(Z-EMC)105042014” demonstrate S7-721w comply with the 15B requirement. New SAR Test report “SYBH(Z-SAR)041042014-2” demonstrate S7-721w comply with the SAR requirement. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhangxinghai EMC Laboratory Manager

SECRET Page1, Total28 Photo documentation of external of product SECRET Page2, Total28 SECRET Page3, Total28 SECRET Page4, Total28 SECRET Page5, Total28 SECRET Page6, Total28 SECRET Page7, Total28 SECRET Page8, Total28 SECRET Page9, Total28 SECRET Page10, Total28 SECRET Page11, Total28 SECRET Page12, Total28 SECRET Page13, Total28 SECRET Page14, Total28 SECRET Page15, Total28 SECRET Page16, Total28 SECRET Page17, Total28 SECRET Page18, Total28 SECRET Page19, Total28 SECRET Page20, Total28 SECRET Page21, Total28 SECRET Page22, Total28 SECRET Page23, Total28 SECRET Page24, Total28 SECRET Page25, Total28 SECRET Page26, Total28 SECRET Page27, Total28 SECRET Page28, Total28

HUAWEI MediaPad 7 Youth2 SECRET Page1, Total 1

HUAWEI MediaPad 7 Youth2 SECRET Page1, Total 1 HUAWEI MediaPad 7 Youth2 SECRET Page2, Total 1

HUAWEI MediaPad 7 Youth 2 SECRET Page1, Total20 Photo documentation of interior of product HUAWEI MediaPad 7 Youth 2 SECRET Page2, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page3, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page4, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page5, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page6, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page7, Total20 5V2A HK HUAWEI MediaPad 7 Youth 2 SECRET Page8, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page9, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page10, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page11, Total20 5V2A BYD HUAWEI MediaPad 7 Youth 2 SECRET Page12, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page13, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page14, Total20 5V1A HK HUAWEI MediaPad 7 Youth 2 SECRET Page15, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page16, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page17, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page18, Total20 5V1A BYD HUAWEI MediaPad 7 Youth 2 SECRET Page19, Total20 HUAWEI MediaPad 7 Youth 2 SECRET Page20, Total20

EMC Test Report Product Name: HUAWEI MediaPad 7 Youth2 Model Number: S7-721w Report No:SYBH(Z-EMC)105042014 FCC ID：QISS7-721W Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 Security Level: secret Report No: SYBH(Z-EMC)105042014 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total18 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has passed the accreditation by The American Association for Laboratory Accreditation (A2LA). The accreditation number is 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 7. The test report is invalid if there is any evidence of erasure and/or falsification. 8. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 9. Normally, the test report is only responsible for the samples that have undergone the test. 10. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. Security Level: secret Report No: SYBH(Z-EMC)105042014 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total18 Applicant: Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Date of Receipt Test Item: May.1, 2014 Start Date of Test: May.4, 2014 End Date of Test: May.8, 2014 Test Result: Pass Approved By 2014-05-09 Liuchunlin (Lab Manager) Date Name Signature Operator 2014-05-09 Haozy He (Test Engineer) Date Name Signature Security Level: secret Report No: SYBH(Z-EMC)105042014 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total18 Modification Record No. Last Report No. Modification Description 1 NA First report Security Level: secret Report No: SYBH(Z-EMC)105042014 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total18 TABLE OF CONTENT 1 General Information ............................................................................................................................. 6 1.1 EUT Description ........................................................................................................................... 6 1.2 Differences Description ................................................................................................................ 7 1.3 Test Site Information .................................................................................................................... 7 1.4 Applied Standards ........................................................................................................................ 7 2 Summary of Results ............................................................................................................................. 8 3 System Configuration during EMC Test .............................................................................................. 9 3.1 Test Mode ..................................................................................................................................... 9 3.2 Test System Configuration ........................................................................................................... 9 3.3 Cables Used during Test ............................................................................................................ 10 3.4 Associated Equipment Used during Test .................................................................................. 10 4 Electromagnetic Interference (EMI) ................................................................................................... 11 4.1 Radiated Disturbance 30MHz to 18GHz ................................................................................... 11 4.2 Conducted Disturbance 0.15 MHz to 30MHz ............................................................................ 13 5 Main Test Instruments ........................................................................................................................ 14 6 System Measurement Uncertainty .................................................................................................... 15 7 Test Data and Graph .......................................................................................................................... 16 7.1 Radiated Disturbance ................................................................................................................. 16 7.2 Conducted Disturbance .............................................................................................................. 18 Security Level: secret Report No: SYBH(Z-EMC)105042014 Confidential Information of Huawei. No Distribution without Written Permission Page6, Total18 1 General Information 1.1 EUT Description EUT Description Product Name HUAWEI MediaPad 7 Youth2 Model Number S7-721w Serials Number L4Z0114409000023 Working Voltage 5Vdc TX Frequency Bluetooth:2402MHz To 2480MHz WIFI:2412MHz To 2462MHz RX Frequency Bluetooth:2402MHz To 2480MHz WIFI:2412MHz To 2462MH…
