Make the most of now. Vodafone 716 Mobile Phone User Guide Notice Copyright  2007 Huawei Technologies Co. Ltd.All Rights Reserved 1 Your Vodafone 716 is made exclusively for Vodafone by Huawei Technologies. 2 No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co. Ltd. 3 Trademarks 4 Vodafone 2007. Vodafone and the Vodafone logos are trade marks of the Vodafone Group. 5 Notice 6 The information in this manual is subject to change without notice. Every effort has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information, and recommendations in this man-ual do not constitute a warranty of any kind, expressed or implied. 7 Read the safety precautions carefully to ensure that you use wireless device in a correct and safe manner. For details, see the section "Warn-ings and Precautions". Huawei Technologies Co. Ltd.Branch Address: 8 Huawei Technologies Deutschland GmbH, 9 Am Seestem 24, Dusseldorf, Germany 10 Postal Code: 40547 Head Office Address: 11 Administration Building, Huawei Technologies Co. Ltd.,  Bantian, Longgang District, 12 Shenzhen, P. R. China 13 Postal Code: 518129 Website: http://www.huawei.com 14 Read the Safety Information section ofthis user guide on page 66. Do not use hand-held while driving.For body-worn operation maintain a separation of 15 mm.Small parts may cause a choking hazard.This device may produce a loud sound.Keep away from pacemakers and other personal medical devices.Switch off when instructed in hospitals and medical facilities.Switch off when instructed in aircrafts and airports. Do not use while re-fuelling.This device may produce a bright or flashing light.Do not dispose of in a fire.Avoid contact with magnetic media.Avoid Extreme TemperaturesAvoid contact with liquid, keep dry.Do not try and disassemble.Do not rely on this device for emergency communications. Safety Precautions 1516 Specific Absorption Rate (SAR) 17 Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organisation ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health. 18 The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when tested at the ear was 1.04 W/kg*. As mobile devices offer a range of functions, they can be used in other positions, such as on the body as described in this user guide**. 19 As SAR is measured utilising the device's highest transmitting power, the actual SAR of this device while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum power required to communicate with the network. 20 * The tests are carried out in accordance with IEC standard PT62209-1. 21 ** Please see page 66 about body worn operation. 22 Please read the safety precautions carefully to ensure the correct and safe use of your wireless device. For detailed information, refer to the 23 section “Warnings and Precautions”. 2425 Switch off in explosive environments.Only use approved accessories. . 1 1 Table of Contents Table of Contents 1Getting to Know Your Phone 1 Packing List ................................................1Your Phone ................................................2 Getting Started 6 Loading the Battery ....................................6Unloading the Battery .................................6Charging the Battery ..................................7Loading/Removing the SIM Card ...............8Loading/Removing a Memory Card............9Powering On/Off .........................................9 Call Service 11 Making or Answering Calls .......................11Operations During a Voice  Call ...............12 Operations During a Video  Call ...............13 Text Input 15 T9 Input Method .......................................15Traditional Input Method ..........................16"123" Numeric Input Method ....................16Symbol Input Method ...............................16Input Different Languages ........................17 Contacts 18 Making Calls from the Contacts ...............18Searching for a Contact............................18Other Operations ......................................19Groups......................................................19 Call Log 21 Making Calls from Call Log ...................... 21Other Operations ..................................... 21 Messaging 22 Text Messages......................................... 22Multimedia Messages .............................. 25Creating Live!Postcards ........................... 29Email ........................................................ 29Push Inbox ............................................... 34Broadcast Inbox ....................................... 34Voice Mail number ................................... 35Common Phrases .................................... 35 Music 36 My Music .................................................. 36Playlist...................................................... 37 Organiser & Tools 38 SIM ToolKit .............................................. 38Alarms ...................................................... 38Calendar .................................................. 38Task ......................................................... 39Memo ...................................................... 40Synchronise ............................................. 40Calculator ................................................. 41Unit Converter .......................................... 41Currency Converter.................................. 42Voice Recorder ........................................ 42Wor…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. AddressHuawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP518129 Page 1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com SubjectLetter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISU121 to be kept confidential: 1. Schematic diagram & PCB layout. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

V716/Vodafone 716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page1,Total 4 External Photo of V716/Vodafone 716/U121 V716/Vodafone 716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page2,Total 4 V716/Vodafone 716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page3,Total 4 V716/Vodafone 716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page4,Total 4

V716/Vodafone 716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page1, Total 1 Label Location_ V716/Vodafone 716/U121

V716/Vodafone716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page1,Total 4 Internal Photo of V716/Vodafone716/U121 V716/Vodafone716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page2,Total 4 V716/Vodafone716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page3,Total 4 V716/Vodafone716/U121 WCDMA/GPRS/GSM Mobile Phone SECRET Page4,Total 4

No. 2007EEE02305 Page 2 of 77 Notes 1. . The test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 2. Copies of the test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 3. The test report shall be invalid if there are no signatures of the testing person, reviewing person and approving person on it. 4. The test report shall be invalid if it is altered. 5. Any demurral about the test shall be put forward to the testing organization within 15 days after the receiving of the test report. 6. This test report standalone dose not constitute or imply by its own an approval of the product by any Certification Authorities or Competent Bodies. 7. This report is only valid if complete, and test report shall not be reproduced except in full, without written approval of the laboratory. 8. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of Telecommunication Metrology Center of MII and the Accreditation Bodies, if it applies. Address: No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China (Telecommunication Metrology Center of MII) Post code: 100083 Telephone: +86 10 62302041 Fax: +86 10 62304793 Web site: http://www.emcite.com E-mail: [email protected] No. 2007EEE02305 Page 3 of 77 TABLE OF CONTENT 1 COMPETENCE AND WARRANTIES ................................................................................................................................5 2 GENERAL CONDITIONS ...................................................................................................................................................5 3 DESCRIPTION OF EUT ......................................................................................................................................................5 3.1 ADDRESSING INFORMATION RELATED TO EUT........................................................................................................................ 5 3.2 CONSTITUENTS OF EUT ......................................................................................................................................................... 6 3.3 GENERAL DESCRIPTION.......................................................................................................................................................... 6 4 OPERATIONAL CONDITIONS DURING TEST ..............................................................................................................7 4.1 SCHEMATIC TEST CONFIGURATION......................................................................................................................................... 7 4.2 SAR MEASUREMENT SET-UP.................................................................................................................................................. 7 4.3 DASY4 E-FIELD PROBE SYSTEM............................................................................................................................................. 8 4.4 E-FIELD PROBE CALIBRATION................................................................................................................................................. 9 4.5 OTHER TEST EQUIPMENT..................................................................................................................................................... 10 4.6 EQUIVALENT TISSUES........................................................................................................................................................... 10 4.7 SYSTEM SPECIFICATIONS...................................................................................................................................................... 11 5 CHARACTERISTICS OF THE TEST ..............................................................................................................................11 5.1 APPLICABLE LIMIT REGULATIONS......................................................................................................................................... 11 5.2 APPLICABLE MEASUREMENT STANDARDS............................................................................................................................. 11 6 LABORATORY ENVIRONMENT ....................................................................................................................................12 7 CONDUCTED OUTPUT POWER MEASUREMENT ....................................................................................................12 7.1 SUMMARY............................................................................................................................................................................ 12 7.2 CONDUCTED POWER............................................................................................................................................................ 12 8 TEST RESULTS...................................................................................................................................................................13 8.1 DIELECTRIC PERFORMANCE................................................................................................................................................. 13 8.2 SYSTEM VALIDATION............................................................................................................................................................ 13 8.3 SUMMARY OF MEASUREMENT RESULTS (PCS1900MHZ) ..................................................................................................... 14 8.4 SUMMARY OF MEASUREMENT RESULTS (WITH BLUETOOTH FUNCTION) ................................................................................ 15 8.5 CONCLUSION...............................................................................................................................................…

Text truncated - open the document above for the full version.

No. 2007EEE02305 Page 51 of 77 Fig. 28 Z-Scan at power reference point (PCS 1900MHz, Body Towards Phantom with GPRS, CH661) No. 2007EEE02305 Page 52 of 77 1900 Body Toward Phantom Low with GPRS Electronics: DAE3 Sn536 Medium: Body 1900 MHz Medium parameters used (interpolated): f = 1850.2 MHz; σ = 1.48 mho/m; ε r = 52.2; ρ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: GSM 1900MHz GPRS Frequency: 1850.2 MHz Duty Cycle: 1:4 Probe: ET3DV6 - SN1736 ConvF(4.88,488, 4.88) Toward Phantom Low/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.040 mW/g Toward Phantom Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 1.41 V/m; Power Drift = 0.200dB Peak SAR (extrapolated) = 0.021 W/kg SAR(1 g) = 0.00358 mW/g; SAR(10 g) = 0.000826 mW/g Maximum value of SAR (measured) = 0.021 mW/g 0 dB = 0.021mW/g Fig. 29 PCS 1900MHz, Body, Towards Phantom with GPRS, CH512 No. 2007EEE02305 Page 53 of 77 Fig. 30 Z-Scan at power reference point (PCS 1900MHz, Body Towards Phantom with GPRS, CH512) No. 2007EEE02305 Page 54 of 77 1900 Body Toward Ground High with GPRS Electronics: DAE3 Sn536 Medium: Body 1900 MHz Medium parameters used: f = 1910 MHz; σ = 1.54 mho/m; ε r = 52; ρ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: GSM 1900MHz GPRS Frequency: 1909.8 MHz Duty Cycle: 1:4 Probe: ET3DV6 - SN1736 ConvF(4.88, 4.88, 4.88) Toward Ground High/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.076 mW/g Toward Ground High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 4.56 V/m; Power Drift = -0.156 dB Peak SAR (extrapolated) = 0.110 W/kg SAR(1 g) = 0.068 mW/g; SAR(10 g) = 0.043 mW/g Maximum value of SAR (measured) = 0.071 mW/g 0 dB = 0.071mW/g Fig. 31 PCS 1900MHz, Body, Towards Ground with GPRS, CH810 No. 2007EEE02305 Page 55 of 77 Fig. 32 Z-Scan at power reference point (PCS 1900MHz, Body Towards Ground with GPRS, CH810) No. 2007EEE02305 Page 56 of 77 1900 Body Toward Ground Middle with GPRS Electronics: DAE3 Sn536 Medium: Body 1900 MHz Medium parameters used: f = 1880 MHz; σ = 1.51 mho/m; ε r = 52.1; ρ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: GSM 1900MHz GPRS Frequency: 1880 MHz Duty Cycle: 1:4 Probe: ET3DV6 - SN1736 ConvF(4.88, 4.88, 4.88) Toward Ground Middle/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.060 mW/g Toward Ground Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 4.15 V/m; Power Drift = 0.183 dB Peak SAR (extrapolated) = 0.082 W/kg SAR(1 g) = 0.055 mW/g; SAR(10 g) = 0.036 mW/g Maximum value of SAR (measured) = 0.059 mW/g 0 dB = 0.059mW/g Fig. 33 PCS 1900MHz, Body, Towards Ground with GPRS, CH661 No. 2007EEE02305 Page 57 of 77 Fig. 34 Z-Scan at power reference point (PCS 1900MHz, Body Towards Ground with GPRS, CH661) No. 2007EEE02305 Page 58 of 77 1900 Body Toward Ground Low with GPRS Electronics: DAE3 Sn536 Medium: Body 1900 MHz Medium parameters used (interpolated): f = 1850.2 MHz; σ = 1.48 mho/m; ε r = 52.2; ρ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: GSM 1900MHz GPRS Frequency: 1850.2 MHz Duty Cycle: 1:4 Probe: ET3DV6 - SN1736 ConvF(4.88, 4.88, 4.88) Toward Ground Low/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.069 mW/g Toward Ground Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 4.02 V/m; Power Drift = 0.102 dB Peak SAR (extrapolated) = 0.066 W/kg SAR(1 g) = 0.043 mW/g; SAR(10 g) = 0.026 mW/g Maximum value of SAR (measured) = 0.046 mW/g 0 dB = 0.046mW/g Fig. 35 PCS 1900MHz, Body, Towards Ground with GPRS, CH512 No. 2007EEE02305 Page 59 of 77 Fig. 36 Z-Scan at power reference point (PCS 1900MHz, Body Towards Ground with GPRS, CH512) No. 2007EEE02305 Page 60 of 77 1900 Body Toward Ground High with Bluetooth Function Electronics: DAE3 Sn536 Medium: Body 1900 MHz Medium parameters used: f = 1910 MHz; σ = 1.54 mho/m; ε r = 52; ρ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: GSM 1900MHz GPRS Frequency: 1909.8 MHz Duty Cycle: 1:4 Probe: ET3DV6 - SN1736 ConvF(4.88, 4.88, 4.88) Toward Ground High/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.098 mW/g Toward Ground High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 4.71 V/m; Power Drift = -0.092 dB Peak SAR (extrapolated) = 0.152 W/kg SAR(1 g) = 0.071 mW/g; SAR(10 g) = 0.047mW/g Maximum value of SAR (measured) = 0.091 mW/g 0 dB = 0.091mW/g Fig. 37 PCS 1900MHz, Body, Towards Ground with Bluetooth, CH810 No. 2007EEE02305 Page 61 of 77 Fig. 38 Z-Scan at power reference point (PCS 1900MHz, Body, Towards Ground with Bluetooth, CH810) No. 2007EEE02305 Page 62 of 77 ANNEX D SYSTEM VALIDATION RESULTS 1900MHzDAE536Probe1736 Electronics: DAE3 Sn536 Medium: Head 1900 MHz Medium parameters used: f= 1900 MHz; σ = 1.38 mho/m; ε r = 40.9; ρ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: CW Frequency: 1900 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(5.4, 5.4, 5.4) System Validation/Area Scan (101x101x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 11.2 mW/g System Validation/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 92.1 V/m; Power Drift = 0.1 dB Peak SAR (extrapolated) = 16.9 W/kg SAR(1 g) = 9.91 mW/g; SAR(10 g) = 5.27 mW/g Maximum value of SAR (measured) = 11.3 mW/g 0 dB = 11.3mW/g Fig.39 validation 1900MHz 250mW No. 2007EEE02305 Page 63 of 77 ANNEX E PROBE CALIBRATION CERTIFICATE No. 2007EEE02305 Page 64 of 77 No. 2007EEE02305 Page 65 of 77 No. 2007EEE02305 Page 66 of 77 No. 2…

Text truncated - open the document above for the full version.

FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page1, Total4 Appendix A Modulation Characteristics According to FCC Part 2.1047 & Part24 Subpart E FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total4 TM1: GPRS/GSM Channel 512 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page3, Total4 Channel 661 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page4, Total4 Channel 810 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of HUAWEI. No Distribution without Permission Page1, Total4 Appendix B Occupied Bandwidth According to FCC Part 2.1049 & Part 24 Subpart E FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of HUAWEI. No Distribution without Permission Page2, Total4 TM1:GPRS/GSM Channel 512 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of HUAWEI. No Distribution without Permission Page3, Total4 TM1: GPRS/GSM Channel 661 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of HUAWEI. No Distribution without Permission Page4, Total4 TM1: GPRS/GSM Channel 810 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of HUAWEI. No Distribution without Permission Page1, Total3 Appendix C Band Edges Compliance According to FCC Part 2.1051 & 24.238 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of HUAWEI. No Distribution without Permission Page2, Total3 Left Edge Channel 512 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of HUAWEI. No Distribution without Permission Page3, Total3 Right Edge Channel 810 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page1, Total10 Appendix D Spurious Emission at Antenna Terminal According to FCC Part 2.1051 & 24.238 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total10 Channel 512 Att 40 dB * Offset 9 dB A LVL * RBW 1 kHz SWT 145 ms VBW 3 kHz Ref 20 dBm Start 9 kHzStop 150 kHz14.1 kHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -45.68 dBm 66.168269231 kHz D1 -13 dBm Date: 3.SEP.2007 20:49:25 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page3, Total10 A Att 40 dB * Ref 39 dBm Offset 9 dB LVL 2.985 MHz/Start 150 kHzStop 30 MHz * RBW 10 kHz SWT 300 ms VBW 30 kHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -42.96 dBm 150.000000000 kHz D1 -13 dBm Date: 3.SEP.2007 20:44:10 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page4, Total10 Att 40 dB * Offset 9 dB A LVL * RBW 1 MHz VBW 3 MHz SWT 150 msRef 39 dBm Start 30 MHzStop 26 GHz2.597 GHz/ 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] 29.58 dBm 1.819599359 GHz D1 -13 dBm Date: 3.SEP.2007 20:52:06 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page5, Total10 Channel 661 Att 40 dB * Offset 9 dB A LVL * RBW 1 kHz VBW 3 kHz SWT 145 msRef 20 dBm Start 9 kHzStop 150 kHz14.1 kHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -46.76 dBm 66.168269231 kHz D1 -13 dBm Date: 3.SEP.2007 20:54:58 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page6, Total10 Att 40 dB * Offset 9 dB A LVL Ref 39 dBm 2.985 MHz/Start 150 kHzStop 30 MHz * RBW 10 kHz VBW 30 kHz SWT 300 ms 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -43.82 dBm 150.000000000 kHz D1 -13 dBm Date: 3.SEP.2007 20:53:51 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page7, Total10 Att 40 dB * Offset 9 dB A LVL * RBW 1 MHz VBW 3 MHz SWT 150 msRef 39 dBm Start 30 MHzStop 26 GHz2.597 GHz/ 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] 29.71 dBm 1.861217949 GHz D1 -13 dBm Date: 3.SEP.2007 20:53:04 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page8, Total10 Channel 810 Att 40 dB * Offset 9 dB A LVL * RBW 1 kHz VBW 3 kHz SWT 145 msRef 20 dBm 1 PK MAXH Center 79.5 kHzSpan 141 kHz14.1 kHz/ -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -46.76 dBm 66.168269231 kHz D1 -13 dBm Date: 3.SEP.2007 20:56:14 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page9, Total10 Att 40 dB * Offset 9 dB A LVL * RBW 10 kHz VBW 30 kHz SWT 300 ms 1 PK MAXH Ref 39 dBm Start 150 kHzStop 30 MHz2.985 MHz/ -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -41.78 dBm 150.000000000 kHz D1 -13 dBm Date: 3.SEP.2007 20:59:03 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page10, Total10 Ref 39 dBmAtt 40 dB * Offset 9 dB A LVL Start 30 MHzStop 26 GHz2.597 GHz/ * RBW 1 MHz VBW 3 MHz SWT 150 ms 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] 29.68 dBm 1.902836538 GHz D1 -13 dBm Date: 3.SEP.2007 20:59:58 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page1, Total5 Appendix E Radiated Spurious Emission According to FCC Part 2.1053 & 24.238 FCC ID: QISU121 Report No: SYBH (R)184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total5 Traffic Mode (9kHz-30MHz) - -90 -80 -70 -60 -50 -40 -30 -20 -10 0 920 k 40680k 100200 600k12 5 15M 2030M Level in Frequency in Hz FCC ID: QISU121 Report No: SYBH (R)184…

Text truncated - open the document above for the full version.

FCC TEST REPORT OF Huawei WCDMA/ GPRS/ GSM Mobile Phone M/N: V716/Vodafone 716/U121 Jul. 30, 2007 Reliability Laboratory of Huawei Technologies Co., Ltd. All Right Reserved Report No: SYBH (R) 184082007EB-1 FCC ID: QISU121 Report No: SYBH (R) 184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total37 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Committee for Laboratories (CNAL), and accreditation number: L0310. 2. The laboratory has obtained the accreditation of THE AMERICAN ASSOCIATION FOR LABORATORY ACCREDITATION (A2LA), and Accreditation Council Certificate Number: 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory also has been listed by the VCCI to perform EMC measurements. The accreditation number is C1758, R1672, and T153. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. Any copy of the test report is invalid if not re-marked with the "exclusive stamp for the test report". 7. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 8. The test report is invalid if there is any evidence of erasure and/or falsification. 9. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 10. Normally, the test report is only responsible for the samples that have undergone the test. 11. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. Report No: SYBH (R) 184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page3, Total37 Huawei Technologies Co Ltd Huawei Industrial Base, Bantian Longgang Shenzhen 518128, P.R China Tel: +86 755 89651014 Fax: +86 755 89652518 REPORT ON FCC Test of Huawei WCDMA/GPRS/GSM Mobile Phone M/N: V716/Vodafone 716/U121 Report No: SYBH (R) 184082007EB-1 REGULATION FCC CFR47 Part 2: Subpart J; FCC CFR47 Part 24: Subpart E; FCC CFR47 Part 15: Subpart B; CONCLUSION There are 10 items need to be tested, 10 items have been tested. The sample of the model completely meets the requirements Final Judgement: Pass General Manager 2007.08.20 Guo Xiaoqi Date Name signature Technical Responsibility For Area of Testing 2007.08.19 Zhang Xinghai Date Name signature Test Lab Engineer 2007.08.19 HuJun Date Name signature Report No: SYBH (R) 184082007EB-1 Confidential Information of Huawei. No Distribution without Permission Page4, Total37 Contents 1 Summary.................................................................................................................................................... 5 2 Product Description................................................................................................................................6 2.1 PRODUCTION INFORMATION................................................................................................................... 6 2.2 MODIFICATION INFORMATION.................................................................................................................. 6 3 Test Site Description................................................................................................................................. 7 3.1 TESTING PERIOD................................................................................................................................... 7 3.2 SET UP DESCRIPTION............................................................................................................................ 7 4 Product Description.................................................................................................................................. 8 4.1 TECHNICAL CHARACTERISTICS......................................................................................................…
