QISU5200UMTS/GPRS/GSM Mobile Phone with BT

1 Copyright ............................................................................. 1 2 Getting Started ..................................................................... 3 Your Phone at a Glance ..................................................... 3 Keys and Functions ........................................................... 4 Inserting the USIM Card and the Battery ........................... 6 Inserting the MicroSD Card ............................................... 7 Charging the Battery ......................................................... 7 Status Icons ...................................................................... 8 3 Text Entry ........................................................................... 11 Entering Spanish ............................................................. 11 Entering English .............................................................. 11 Smart English Input Method .................................................. 11 Traditional English Input Method ........................................... 11 Entering a Digit ............................................................... 12 4 Contacts ............................................................................ 13 Adding a Contact ............................................................ 13 Searching for a Contact ................................................... 13 5 Voice Services ..................................................................... 14 Making a Call .................................................................. 14 Dialing via Keypad ................................................................ 14 Dialing via Contacts .............................................................. 14 Dialing via Call Log ............................................................... 14 Answering a Call ............................................................. 14 6 Direct Connect (DC) and DC Group ..................................... 16 Making a DC Call ............................................................ 16 Dialing a DC Number ............................................................ 16 Last call notification .............................................................. 17 Making a DC call from Contacts ............................................ 17 Making a DC call from the Call Log ....................................... 17 Alert ............................................................................... 17 Sending a Alert ..................................................................... 18 DC Group ....................................................................... 18 Creating a DC Group ............................................................ 18 Making a DC Group Call ....................................................... 18 Adding Members to a DC Call ............................................... 19 Joining a DC Call After it has Started ..................................... 19 Sending an Interrupt Request .......................................... 20 Converting a DC Call to a Voice Call ................................ 20 Concurrency ................................................................... 20 Other Operations ............................................................ 22 7 Messaging .......................................................................... 24 SMS & MMS ................................................................... 24 Writing and Sending a Text Message ..................................... 24 Reading a Message ............................................................... 24 Email ............................................................................... 24 Creating an Email Account .................................................... 24 Creating and Sending an Email .............................................. 25 Receiving an Email ................................................................ 25 8 Media Applications ............................................................. 27 Camera ........................................................................... 27 Taking a Photo ...................................................................... 27 Recording a Video ................................................................ 27 Music Player .................................................................... 27 Starting the Music Player ....................................................... 27 Adding a Playlist ................................................................... 28 Playing music ........................................................................ 28 Playing a Video ............................................................... 28 Picture Viewer ................................................................. 29 FM Radio ........................................................................ 29 Switching on the FM Radio ................................................... 29 Switching off the FM Radio ................................................... 30 Recorder ......................................................................... 30 9 Browser.............................................................................. 31 Surfing the Internet ......................................................... 31 Other Browser Options ................................................... 31 10 Connectivity ..................................................................... 32 Connecting via USB ......................................................... 32 Installing PC Suite ................................................................. 32 USB-based Internet Access .................................................... 33 Bluetooth ........................................................................ 34 Bluetooth-based Data Transfer .............................................. 34 Using a Bluetooth Headset ......................................…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISU5200 to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

HUAWEI U5200 Mobile Phone with Bluetooth SECRET Page1, Total 3 Label Location HUAWEI U5200 HUAWEI U5200 Mobile Phone with Bluetooth SECRET Page2, Total 3

HUAWEI U5200 Mobile Phone with Bluetooth SECRET Page1,Total 4 Internal Photos of HUAWEI U5200 HUAWEI U5200 Mobile Phone with Bluetooth SECRET Page2,Total 4 HUAWEI U5200 Mobile Phone with Bluetooth SECRET Page3,Total 4 HUAWEI U5200 Mobile Phone with Bluetooth SECRET Page4,Total 4

Huawe i Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28785513 Fax: +86 755 36834474 FCC SAR Compliance Test Report Project Name: _______________________ Model : _______________________ FCC ID : _______________________ Report No. : _______________________ APPROVED CHECKED PREPARED BY DATE 2011-08-02 2011-08-02 2011-08-02 The test results of this test report relate exclusively to the item(s) tested , The HUAWEI does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of HUAWEI. Reliability Laboratory of Huawei Technologies Co., Ltd. HSUP A/HS DPA/UMTS/GSM/GPRS/ ED GE Mobile Phone with Bluetooth HUAWEI U5200 QISU5200 SYBH (Z-SAR)011072011-2 Report No.: SYBH (Z-SAR)011072011-2 FCC ID:QISU5200 2011-08-02 Page 2 of 32 Table of Contents 1 General Information ............................................................................................................................................................................... 4 1.1 Statement of Compliance........................................................................................................................................................... 4 1.2 RF expos ure limits ........................................................................................................................................................................ 4 1.3 EUT Descri ption ............................................................................................................................................................................ 5 1.3.1 General Description ............................................................................................................................................................ 5 1.4 Test specification(s) .................................................................................................................................................................... 6 1.5 Testing laboratory ......................................................................................................................................................................... 6 1.6 Applicant and Manufacturer ...................................................................................................................................................... 6 1.7 Application details......................................................................................................................................................................... 6 1.8 Ambient Condition ....................................................................................................................................................................... 6 2 SAR Measurement System .............................................................................................................................................................. 7 2.1 SAR Measurement Set-up........................................................................................................................................................ 7 2.2 Test envi ronment .......................................................................................................................................................................... 8 2.3 Data Acquisition Electronics description.............................................................................................................................. 8 2.4 Probe description .......................................................................................................................................................................... 9 2.5 Phantom description .................................................................................................................................................................. 10 2.6 Device hol der description......................................................................................................................................................... 10 2.7 Test Equipment List ................................................................................................................................................................... 11 3 SAR Measurement Procedure....................................................................................................................................................... 12 3.1 Scanning procedure ................................................................................................................................................................... 12 3.2 Spatial Peak SAR E valuation ................................................................................................................................................. 13 3.3 Data Storage and E val uation.................................................................................................................................................. 14 4 System Verification Procedure......................................................................................................................................................... 16 4.1 Tissue Verificati on ...................................................................................................................................................................... 16 4.2 System Check .............................................................................................................................................................................. 17 4.3 Validation Procedure ................................................................................................................................................................. 17 5 Measureme…

Text truncated - open the document above for the full version.

Report No:SYBH (Z-SAR) 011072011-2 FCC ID:QISU5200 Appendix A. System Check Plots Table of contens SystemPerformanceCheck-D900-EX-Head SystemPerformanceCheck-D900-EX-Body SystemPerformanceCheck-D1800-EX-Head SystemPerformanceCheck-D1800-EX-Body SystemPerformanceCheck-D1900-EX-Head SystemPerformanceCheck-D1900-EX-Body Date/Time: 2011-8-1 9:37:28, Date/Time: 2011-8-1 9:44:26 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D900-EX-Head DUT: Dipole 900 MHz D900V2; Type: D900V2; Serial: D900V2 - SN:1d112 Communication System: CW; Frequency: 900 MHz Medium parameters used: f = 900 MHz; σ = 0.933 mho/m; ε r = 41.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=15mm, Pin=250mW/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.64 mW/g Configuration/d=15mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 52.6 V/m; Power Drift = -0.00471 dB Peak SAR (extrapolated) = 3.98 W/kg SAR(1 g) = 2.59 mW/g; SAR(10 g) = 1.66 mW/g Maximum value of SAR (measured) = 2.8 mW/g 0 dB = 2.8mW/g Date/Time: 2011-7-30 8:31:40, Date/Time: 2011-7-30 8:38:33 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D900-EX-Body DUT: Dipole 900 MHz D900V2; Type: D900V2; Serial: D900V2 - SN:1d112 Communication System: CW; Frequency: 900 MHz Medium parameters used: f = 900 MHz; σ = 1.02 mho/m; ε r = 52.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.07, 9.07, 9.07); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=15mm, Pin=250mW/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.84 mW/g Configuration/d=15mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51.8 V/m; Power Drift = 0.049 dB Peak SAR (extrapolated) = 4.24 W/kg SAR(1 g) = 2.79 mW/g; SAR(10 g) = 1.8 mW/g Maximum value of SAR (measured) = 3.01 mW/g 0 dB = 3.01mW/g Date/Time: 2011-8-1 17:58:41, Date/Time: 2011-8-1 18:02:52 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D1800-EX-Head DUT: Dipole 1800 MHz D1800V2; Type: D1800V2; Serial: D1800V2 - SN:2d184 Communication System: CW; Frequency: 1800 MHz Medium parameters used: f = 1800 MHz; σ = 1.44 mho/m; ε r = 39.2; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(8.25, 8.25, 8.25); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=10mm, Pin=250mW/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 9.2 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 82.9 V/m; Power Drift = 0.052 dB Peak SAR (extrapolated) = 17.6 W/kg SAR(1 g) = 9.17 mW/g; SAR(10 g) = 4.71 mW/g Maximum value of SAR (measured) = 10.3 mW/g 0 dB = 10.3mW/g Date/Time: 2011-7-30 21:30:54, Date/Time: 2011-7-30 21:35:05 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D1800-EX-Body DUT: Dipole 1800 MHz D1800V2; Type: D1800V2; Serial: D1800V2 - SN:2d184 Communication System: CW; Frequency: 1800 MHz Medium parameters used: f = 1800 MHz; σ = 1.56 mho/m; ε r = 51.7; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.48, 7.48, 7.48); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=10mm, Pin=250mW/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 10.7 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 82.3 V/m; Power Drift = 0.00111 dB Peak SAR (extrapolated) = 18.1 W/kg SAR(1 g) = 9.81 mW/g; SAR(10 g) = 5.08 mW/g Maximum value of SAR (measured) = 11 mW/g 0 dB = 11mW/g Date/Time: 2011-7-22 11:45:23, Date/Time: 2011-7-22 11:49:35 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D1900-EX-Head DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d018 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.36 mho/m; ε r = 39.3; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.9, 7.9, 7.9); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=10mm, Pin=250mW/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 7.47 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 74 V/m; Power Drift = 0.084 dB Peak SAR (extrapolated) = 16.9 W/kg SAR(1 g) = 9.07 mW/g; SAR(10 g) = 4.72 mW/g Maximum value of SAR (measured) = 10.2 mW/g 0 dB = 10.2mW/g Date/Time: 2011-7-20 22:31:55, Date/Time: 2011-7-20 22:36:06 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D1900-EX-Body DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - …

Text truncated - open the document above for the full version.

Report No:SYBH (Z-SAR) 011072011-2 FCC ID:QISU5200 Appendix B. SAR Measurement Plots Table of contents GSM 850 MHz head GSM 850 MHz body GSM 1900 MHz head GSM 1900 MHz body WCDMA 1700 MHz head WCDMA 1700 MHz body WCDMA 1900 MHz head WCDMA 1900 MHz body Date/Time: 2011-8-1 15:23:00, Date/Time: 2011-8-1 15:31:29 Test Laboratory: Huawei SAR Lab U5200 GMS850 190CH Left hand touch cheek DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.902 mho/m; ε r = 42.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.11 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 12.8 V/m; Power Drift = -0.037 dB Peak SAR (extrapolated) = 1.4 W/kg SAR(1 g) = 1.08 mW/g; SAR(10 g) = 0.793 mW/g Maximum value of SAR (measured) = 1.14 mW/g 0 dB = 1.14mW/g Date/Time: 2011-8-1 16:43:31, Date/Time: 2011-8-1 16:51:59 Test Laboratory: Huawei SAR Lab U5200 GMS850 190CH Left hand tilt 15 degree DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.902 mho/m; ε r = 42.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.619 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 17.7 V/m; Power Drift = -0.057 dB Peak SAR (extrapolated) = 0.811 W/kg SAR(1 g) = 0.626 mW/g; SAR(10 g) = 0.459 mW/g Maximum value of SAR (measured) = 0.661 mW/g 0 dB = 0.661mW/g Date/Time: 2011-8-1 12:17:15, Date/Time: 2011-8-1 12:25:29 Test Laboratory: Huawei SAR Lab U5200 GMS850 190CH Right hand touch cheek DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.908 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Right Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.12 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.35 V/m; Power Drift = -0.052 dB Peak SAR (extrapolated) = 1.42 W/kg SAR(1 g) = 1.1 mW/g; SAR(10 g) = 0.816 mW/g Maximum value of SAR (measured) = 1.16 mW/g 0 dB = 1.16mW/g Date/Time: 2011-8-1 14:15:11, Date/Time: 2011-8-1 14:23:26 Test Laboratory: Huawei SAR Lab U5200 GMS850 190CH Right hand tilt 15 degree DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.902 mho/m; ε r = 42.4; ρ = 1000 kg/m 3 Phantom section: Right Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.645 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 16.7 V/m; Power Drift = -0.132 dB Peak SAR (extrapolated) = 0.795 W/kg SAR(1 g) = 0.619 mW/g; SAR(10 g) = 0.455 mW/g Maximum value of SAR (measured) = 0.656 mW/g 0 dB = 0.656mW/g Date/Time: 2011-8-1 15:51:30, Date/Time: 2011-8-1 15:59:58 Test Laboratory: Huawei SAR Lab U5200 GMS850 251CH Left hand touch cheek DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 848.8 MHz Medium parameters used: f = 849 MHz; σ = 0.925 mho/m; ε r = 42.3; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.12 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 12.8 V/m; Power Drift = -0.120 dB Peak SAR (extrapolated) = 1.4 W/kg SAR(1 g) = 1.08 mW/g; SAR(10 g) = 0.792 mW/g Maximum value of SAR (measured) = 1.13 mW/g 0 dB = 1.13mW/g Date/Time: 2011-8-1 16:15:30, Date/Time: 2011-8-1 16:23:59 Test Laboratory: Huawei SAR Lab U5200 GMS850 128CH Left hand touch cheek DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 824.2 MHz Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.9 mho/m; ε r = 42.3;…

Text truncated - open the document above for the full version.

0 dB = 0.326mW/g Date/Time: 2011-7-21 14:58:55, Date/Time: 2011-7-21 15:08:21 Test Laboratory: Huawei SAR Lab U5200 GSM1900 EGPRS 2TS 661CH Towards ground 15mm DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 2TS; Frequency: 1880 MHz Medium parameters used: f = 1880 MHz; σ = 1.55 mho/m; ε r = 52.9; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.17, 7.17, 7.17); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Body/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.569 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.8 V/m; Power Drift = 0.048 dB Peak SAR (extrapolated) = 0.828 W/kg SAR(1 g) = 0.528 mW/g; SAR(10 g) = 0.327 mW/g Maximum value of SAR (measured) = 0.568 mW/g 0 dB = 0.568mW/g Date/Time: 2011-7-21 15:27:57, Date/Time: 2011-7-21 15:37:23 Test Laboratory: Huawei SAR Lab U5200 GSM1900 EGPRS 2TS 810CH Towards ground 15mm DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 2TS; Frequency: 1909.8 MHz Medium parameters used: f = 1910 MHz; σ = 1.57 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.17, 7.17, 7.17); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Body/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.486 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.52 V/m; Power Drift = -0.096 dB Peak SAR (extrapolated) = 0.729 W/kg SAR(1 g) = 0.459 mW/g; SAR(10 g) = 0.283 mW/g Maximum value of SAR (measured) = 0.494 mW/g 0 dB = 0.494mW/g Date/Time: 2011-7-21 15:57:06, Date/Time: 2011-7-21 16:06:31 Test Laboratory: Huawei SAR Lab U5200 GSM1900 EGPRS 2TS 512CH Towards ground 15mm DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 2TS; Frequency: 1850.2 MHz Medium parameters used (interpolated): f = 1850.2 MHz; σ = 1.51 mho/m; ε r = 52.9; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.17, 7.17, 7.17); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Body/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.744 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 13.1 V/m; Power Drift = -0.070 dB Peak SAR (extrapolated) = 1.09 W/kg SAR(1 g) = 0.703 mW/g; SAR(10 g) = 0.437 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.756 mW/g 0 dB = 0.756mW/g Date/Time: 2011-7-21 16:30:37, Date/Time: 2011-7-21 16:40:03 Test Laboratory: Huawei SAR Lab U5200 GSM1900 512CH Towards ground with Headset 15mm DUT: U5200; Type: Mobile Phone ; Serial: 021BNX7N16000121 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 1850.2 MHz Medium parameters used (interpolated): f = 1850.2 MHz; σ = 1.51 mho/m; ε r = 52.9; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.17, 7.17, 7.17); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Body/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.421 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.9 V/m; Power Drift = 0.035 dB Peak SAR (extrapolated) = …
