Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 17, 2011
Application Purpose: Original Equipment
Date of Application: May 17, 2011
Equipment Note: HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with BT
Frequency Range: 2412.00000000 - 2462.00000000
Company: Huawei Technologies Co.,Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

What is in Your Box Phone at a Glance All the pictures in this guide are for your reference only. The actual appearance and display features depend on the mobile phone you purchase. • Mobile phone • Charger • USB cable • Battery • Quick Start Guide • Safety Information 1Power key 2Earpiece 3Menu key4Back key 5Microphone6Home key 7Search key8Volume control keys 1 2 3 5 4 9 10 7 6 8 11 12 13 Key Functions at Your Fingertips 9Wrist strap hole10Headset jack 11Camera12Speaker 13 Charging/Data interface • Press to power on your mobile phone. • Press and hold to open the Phone options menu. • Press to lock the screen when your mobile phone is active. • Touch to return to the previous screen. • Touch to exit any application you are running. • Touch to hide the keyboard. Touch to open the menu on an active screen. • Touch to open Google search for searching your mobile phone and the web. • Touch and hold to open Google search by voice. • Press to return to the Home screen. • Press and hold to show the most recently used applications. Before getting started 1 Removing battery cover 2 Installing SIM card 3 Installing *micro SD card 4 Installing battery 5 Installing battery cover *micro SD card is optional Charging the Battery If your mobile phone is charged when it is powered on, the battery icon on the Notification bar shows the charging status. When the battery icon changes to , it indicates that your mobile phone is fully charged. Powering On Your Mobile Phone Press . The first time you power on your phone, you will be asked to sign in to your account and set up your mobile phone. Powering Off Your Mobile Phone 1. Press and hold to open the Phone options menu. 2. Touch Power off. 3. Touch OK. Using the Touchscreen Touchscreen Actions •Touch: Use the touch of your finger to select an item, confirm a selection, or start an application. • Touch and hold: Touch an item with your finger and continue to press down until your mobile phone responds. For example, to open the options menu for the active screen, touch the screen and hold down until the menu appears. • Flick: Move your finger either vertically or horizontally across the screen. • Drag: Touch and hold the desired item with your finger. To move an item, drag the item to any part of the screen. You can drag an icon to move or delete it. Home Screen Touch and hold one of the shortcuts until the mobile phone vibrates, you can drag it to your desired location or move it to the trash. You can also drag a screen item to the shortcut position. 10:23 Touch to view all your applications. Shortcuts Notifications bar: Displays the reminders and status icons of your phone. Flick down to open the notifications panel. Display area: Shows the operation and display areas of your phone. Indicate the serial number of current screens Touch to view thumbnails of the Home screen and its extensions. Viewing Other Parts of the Home Screen Touch > Home settings > Advanced settings > Screen number to set the screen number. Locking the Screen • When your phone is on, press to lock the screen. When the screen is locked, you can still receive messages and calls. • If your phone is idle for a while, the screen will lock automatically. Unlocking the Screen 1. Press or to wake up the screen. 2. Drag the lock icon from left to right to unlock the screen. Flick your finger left or right across the Home screen. Press to view thumbnails of the Home screen and its extensions. Touch a thumbnail to open the screen. 10:23 10:23 Adding a New Screen Item 1. Touch and hold a blank area on the Home screen until the Select action menu is displayed. 2. Select an item to add it to the Home screen. Importing Contacts from a SIM Card 1. In the contact list, touch > Manage contacts. 2. Touch Copy from SIM card. 3. Wait for the SIM card contents to be loaded. Select the contacts you want to import or touch Select all to select all contacts. 4. Touch Copy. 5. If you have more than one account on your phone, touch the account into which you want to import the contacts. Adding a Contact 1. In the contact list, touch > Create contact. 2. If you have more than one account with contacts, touch the account to which you want to add the contact. 3. Enter the contact's name, and then add detailed information such as phone number or address. 4. When you are finished, touch Done to save the contact information. Making a Call To make a call, you can use the Dialer application, or select a number from Contacts orCall log. When you are on a call, you can press to return to the Home screen and use other functions. To return to the calling screen, flick the notification bar down and touch Current call. Do not block the microphone at the bottom of your phone if you want your voice heard. Making a Call with the Phone Application 1. Touch > Dialer to display the dialer. 2. Touch the appropriate numeric keys to enter the phone number. 3. Touch to initiate the call. Answering an Incoming Call Drag the to the right to answer the call. Rejecting an Incoming Call Drag the to the left to reject the call. Ending a Call During a call, touch End to hang up. Displaying the Keyboard Panel To enter text, use the onscreen keyboard. Some applications open the keyboard automatically. In others, touch a text field to open the keyboard. Touch the space where you want to write text to display the keyboard. Touch to hide the keyboard. Touch and hold the space where you usually write your text to open the options menu. Choosing an Input Method 1. Touch and hold the space where you enter your text until the Edit text menu is displayed. 2. Touch Input method. 3. Select the input method. The keyboard panel will be displayed automatically. Creating and Sending a Multimedia Message 1. Touch > Messaging > New message. 2. Enter a phone number in the To field. 3. Touch the composition text box to start entering your message. 4. Touch to display the options panel. • Touch Add subject to add the message subject. Your mobile phone is now in …

Text truncated - open the document above for the full version.

Cover Letter(s)

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISU8180-1 to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Cover Letter(s)

Huawei Technologies Co., Ltd. Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. +86 755 28780808 www.huawei.com Huawei internal reference RCT-US-01-01 USA FCC Short Term Confidentiality Request template Effective date: 2007-01-06 Version 1.1 Short Term Confidentiality Request 04/30/2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality Request for FCC ID: QISU8180-1 Product Name: HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga Product Model: HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine To whom maybe concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, Huawei Technologies Co., Ltd requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 90 days: 1. External Photos 2. Internal Photos 3. Test Setup Photos 4. Users Manual The applicant also acknowledges that they will also provide appropriate notice to CETECOM should either of the following occur: A) If the applicant requires additional 45 day extension periods they will notify CETECOM with a new request letter at least 7 days prior to the short-term confidentiality expiration date-[Note: up to maximum of 3 extensions only are allowed], or b) Immediately notify CETECOM in the event the information regarding the product of the product is made available to the public CETECOM will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705.

Cover Letter(s)

Huawei Technologies Co., Ltd. Federal Communication Commission Equipment Authorization Devision, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 2011-08-30 TO WHOM IT MAY CONCERN Request for Supersede exhibit: FCC ID: QISU8180-1 Pursuant to KDB 546630 D01 TCB Supersede Procedures v01(2010-3-11), Huawei Technologies Co., Ltd. hereby request for supersede exhibit for its application with FCC ID: QISU8180-1 granted on 2011-05-17 Reason for supersede: We provide the wrong external photo by mistake The following new exhibits will be uploaded: External Photos Sincerely Zhang Xinghai EMC Laboratory Manager For and Behalf of: Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang, Shenzhen, P.R China 0086-755- 89650288 [email protected]

External Photos

ID Label/Location Info

HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page1, Total 8 Label Location HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page2, Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page3, Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page4, Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page5, Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page6, Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page7, Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page8, Total 8

Internal Photos

HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page1,Total 8 Internal Photos of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page2,Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page3,Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page4,Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page5,Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page6,Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page7,Total 8 HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga SECRET Page8,Total 8

RF Exposure Info

Report No.: RZA1104-0508SAR01R1 TESTING No. L2264 OET 65 TEST REPORT Product Name HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga Model HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID QISU8180-1 Client Huawei Technologies Co., Ltd. TA Technology (Shanghai) Co., Ltd. GENERAL SUMMARY Product Name HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga Model HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID QISU8180-1 Report No. RZA1104-0508SAR01R1 Client Huawei Technologies Co., Ltd. Manufacturer Huawei Technologies Co., Ltd. Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radiofrequency Electromagnetic Fields, 3 kHz to 300 GHz. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emissions. RSS-102 Issue 4 March 2010: Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: May 17 th , 2011 Comment The test result only responds to the measured sample. Approved by Yang Weizhong Revised by Ling Minbao Performed by Zhang Xianjin TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1104-0508SAR01R1 Page 3 of 178 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the Test Report.......................................................................................................5 1.2. Testing Laboratory ................................................................................................................ 5 1.3. Applicant Information ............................................................................................................ 6 1.4. Manufacturer Information ...................................................................................................... 6 1.5. Information of EUT................................................................................................................ 7 1.6. The Maximum SAR 1g Values and Conducted Power of each tested band ........................... 9 1.7. Test Date .............................................................................................................................. 9 2. Operational Conditions during Test ............................................................................................ 10 2.1. General Description of Test Procedures............................................................................. 10 2.2. GSM Test Configuration ...................................................................................................... 10 2.3. WIFI Test Configuration ...................................................................................................... 12 2.4. Test Positions...................................................................................................................... 12 2.4.1. Against Phantom Head ................................................................................................ 12 2.4.2. Body Worn Configuration............................................................................................. 12 3. SAR Measurements System Configuration ................................................................................ 14 3.1. SAR Measurement Set-up .................................................................................................. 14 3.2. DASY5 E-field Probe System ............................................................................................. 15 3.2.1. EX3DV4 Probe Specification ....................................................................................... 15 3.2.2. E-field Probe Calibration .............................................................................................. 16 3.3. Other Test Equipment .........................................................................................................16 3.3.1. Device Holder for Transmitters .................................................................................... 16 3.3.2. Phantom...................................................................................................................... 17 3.4. Scanning Procedure........................................................................................................... 17 3.5. Data Storage and Evaluation .............................................................................................. 19 3.5.1. Data Storage................................................................................................................ 19 3.5.2. Data Evaluation by SEMCAD ...................................................................................... 19 3.6. System Check..................................................................................................................... 22 3.7. Equivalent Tissues ..............................................................................................................23 4. Laboratory Environment.........................................................…

Text truncated - open the document above for the full version.

Test Report

FCC Test Report Product Name: HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga Model Number: HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine Report No: SYBH(Z-RF)007042011-2005 FCC ID: QISU8180-1 Reliability Laboratory of Huawei Technologies Co., Ltd. Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: Public Report No: SYBH(Z-RF)007042011-2005 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total28 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 3. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 4. The test report is invalid if not marked with "exclusive stamp for the test report". 5. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 6. The test report is invalid if there is any evidence of erasure and/or falsification. 7. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 8. Normally, the test report is only responsible for the samples that have undergone the test. 9. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: Public Report No: SYBH(Z-RF)007042011-2005 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total28 REPORT ON FCC 47CFR part 15 subpart C Test of HUAWEI IDEOS X1; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; IDEOS X1;GAGA;Gaga M/N: HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine Report No: SYBH(Z-RF)007042011-2005 FCC ID: QISU8180-1 REGULATION FCC CFR47 Part 2: Subpart J; FCC CFR47 Part 15: Subpart C; CONCLUSION PASS Approved By Apr.26, 2011 Chenxiaohong Date Name Signature Reviewed By Apr.26, 2011 Xuguangyi Date Name Signature Operator Apr.26, 2011 Wuhua Date Name Signature FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: Public Report No: SYBH(Z-RF)007042011-2005 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total28 Contents 1 Summary .....................................................................................................................................................5 2 Product Description ...................................................................................................................................6 2.1 PRODUCTION INFORMATION ....................................................................................................................6 2.2 MODIFICATION INFORMATION ..................................................................................................................6 3 Test Site Description ..................................................................................................................................7 3.1 TESTING PERIOD ....................................................................................................................................7 3.2 GENERAL SET UP DESCRIPTION ..............................................................................................................7 4 Product Description ...................................................................................................................................8 4.1 TECHNICAL CHARACTERISTICS ................................................................................................................8 4.2 EUT IDENTIFICATION LIST .....................................................................................................................10 5 Main Test Instruments .............................................................................................................................11 6 Transmitter Measurements .....................................................................................................................12 6.1 6DB BANDWIDTH MEASUREMENT ...........................................................................................................12 6.2 PEAK OUTPUT POWER ..........................................................................................................................14 6.3 BAND EDGE SPURIOUS EMISSION ...........................................................................................................16 6.4 CONDUCTED RF SPURIOUS ...................................................................................................................18 6.5 POWER SPECTRAL DENSITY ..................................................................................................................20 6.6 RADIATED SPURIOUS EMISSION & SPURIOUS IN RESTRICTED BAND ..........................................................22 6.7 CONDUCTED EMISSION AT POWER PORT ...............................................................................................25 7 System Measurement Uncertainty .................................................................…

Text truncated - open the document above for the full version.

Test Report

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

Test Setup Photos

FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: secret Report No: SYBH(Z-EMC)012042011-2 Confidential Information of Huawei. No Distribution without Permission Page1, Total6 Photos of EUT FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: secret Report No: SYBH(Z-EMC)012042011-2 Confidential Information of Huawei. No Distribution without Permission Page2, Total6 Figure1 EUT Appearance FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: secret Report No: SYBH(Z-EMC)012042011-2 Confidential Information of Huawei. No Distribution without Permission Page3, Total6 Photos of Test Setup FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: secret Report No: SYBH(Z-EMC)012042011-2 Confidential Information of Huawei. No Distribution without Permission Page4, Total6 1 Radiated Emissions Radiated Disturbance （30MHz-1GHz） Radiated Disturbance （1GHz-18GHz） FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: secret Report No: SYBH(Z-EMC)012042011-2 Confidential Information of Huawei. No Distribution without Permission Page5, Total6 2 Radiated Spurious Emissions Radiated Spurious Emission (30MHz-2GHz) Radiated Spurious Emission (2GHz-18GHz) FCC Test Report of HUAWEI U8180-1/U8180-1/HUAWEI U8180/U8180/Stockholm/ T-Mobile Rapport/ Android Edition™ StarShine FCC ID: QISU8180-1 Security Level: secret Report No: SYBH(Z-EMC)012042011-2 Confidential Information of Huawei. No Distribution without Permission Page6, Total6 Radiated Spurious Emission (18GHz -26.5GHz) 3 Conducted Emissions Conducted Emissions for AC Ports TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1104-0508SAR01 Page 170 of 178 ANNEX I: The EUT Appearances and Test Configuration a: EUT b: Battery(SN:LACA923HI3900373) Top Left Bottom Right TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1104-0508SAR01 Page 171 of 178 c: Battery(SN:UNHAA29XA4314746) c: Back View Picture 8: Constituents of EUT TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1104-0508SAR01 Page 172 of 178 Picture 9: Left Hand Touch Cheek Position Picture 10: Left Hand Tilt 15 Degree Position TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1104-0508SAR01 Page 173 of 178 Picture 11: Right Hand Touch Cheek Position Picture 12: Right Hand Tilt 15 Degree Position TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1104-0508SAR01 Page 174 of 178 Picture 13: Body, The EUT display towards ground, the distance from handset to the bottom of the Phantom is 15mm Picture 14: Body, The EUT display towards phantom, the distance from handset to the bottom of the Phantom is 15mm 15mm 15mm TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1104-0508SAR01 Page 175 of 178 Picture 15: Body with earphone, The EUT display towards ground, the distance from handset to the bottom of the Phantom is 15mm Picture 16: Body, the EUT display towards ground, the distance from handset to the bottom of the Phantom is 10mm 15mm 10mm TA T…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Zhang Xinghai

[email protected]+86-755-2897-0299Fax: +86-755-8965-0226

Test Firm

Huawei Technologies Co., LTDZhou Fengyum

[email protected]86-755-28782917Fax: 86-755-89650226

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	57.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 15 mm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. End users must be informed of the body worn requirements for satisfying RF Exposure compliance Highest measured SAR values are: Part 15: Head: 0.104 W/kg, Body: 0.149 W/kg.
