QISU8666EHUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with BT

Welcome to HUAWEI Quick Start Guide HUAWEI Ascend Y 201 Pro Phone at a Glance All the pictures in this guide are for your reference only. Your phone’s actual display features may be different to those described here, depending on its software version. 1Earpiece2Menu key 3Home key4Back key 5Speaker6 Volume control keys 7Camera8Headset jack 9 Power key 10 Charging/Data interface 1 10 2 3 4 7 8 9 6 5 Key Functions at Your Fingertips Installing the SIM Card There are two steps to install the SIM card: 1. Remove the battery cover. 2. Insert the SIM card. • Press and hold to power on your mobile phone. • When your mobile phone is powered on, press and hold the button to display the options menu from where you can power the mobile phone off or perform some shortcut operations. • Press to lock the screen when your mobile phone is active. • Touch to return to the previous screen or exit the application you are running. • Touch to hide the keyboard. Touch to open the menu on an active screen. • Touch to return to the Home screen. • Touch and hold to display recently used applications. 1 Removing a SIM Card 1. Pull out the card holder. 2. Carefully remove the SIM card. (Optional) Installing the microSD Card Your mobile phone is already equipped with a large-volume built-in embedded MultiMediaCard (eMMC). If you want to expand your phone memory, you can also insert a microSD card. 1. Remove the battery cover. 2. Insert the microSD card into the card slot as shown in the diagram. 1 2 1 Installing the Battery 1. Angle the edge labeled a (with the contacts) into the bottom end of the battery compartment. 2. Push the edge labeled b into the compartment until the battery clicks firmly into place. Charging the Battery Before charging the battery, ensure that it has been properly installed on your phone. 1. Connect the USB cable that came with your mobile phone to the charger. 2. Connect the other end of the USB cable to your mobile phone. Then, to start charging, plug the charger into an electrical outlet. If you charge your mobile phone while it is powered on, the battery icon on the notification bar indicates the charging status. When the battery icon changes to , your mobile phone is fully charged. a b Status Indicator The color of the status indicator tells you the status of your mobile phone’s battery. Touchscreen Actions Using your finger on the touchscreen, you can operate your phone conveniently. Status Indicator Green: Fully charged (when connected to charger). Orange: Charging in progress (when connected to charger). Red: Battery low. Drag TouchTouch & holdDouble touch RotateFlick Home Screen You can set up the Home screen according to your own preferences, for example by adding a shortcut or a widget to your Home screen, or changing the wallpaper. To return to the Home screen from any of its extensions, press . When a new notification icon appears on the notification bar, place your finger on the notification bar and flick down to open the notification panel. Adding a New Home Screen Item 1. On the Home screen, touch to display the application list. 2. Press and hold an application icon, and then drag the icon to a blank area on the Home screen. Removing an Icon from the Home Screen 1. Touch and hold an item on the Home screen that you want to remove until your mobile phone vibrates. 2. Without lifting your finger, drag the item to the cross sign . Wait until the item and the turn red. 3. Release the item. Flick your finger left or right across the Home screen. 10:23 Importing Contacts from a SIM Card 1. In the contacts list, touch > Manage contacts. 2. Touch Copy from SIM card. 3. Wait for the SIM card contents to be loaded. Touch one contact to import that contact individually to your mobile phone, or touch SELECT ALL to import all contacts to your mobile phone. 4. Touch COPY. 5. If you have more than one account on your phone, touch the account into which you want to import the contacts. Adding a Contact 1. In the contact list, touch . 2. From the screen displayed, create a contact in your mobile phone, SIM card or your account. Add a new account if you do not have one. 3. Enter the contact's name, and then add detailed information such as phone numbers and address. 4. Touch DONE to save the contact information. Making a Call with the Phone Application 1. On the Home screen, touch > Phone. If the dialer is not displayed, touch . 2. Enter the phone number. 3. Touch to initiate the call. Creating and Sending a Multimedia Message You can use multimedia messages to make everyday communications very special. You can record a message and send it as an audio file, for example, sing "Happy Birthday" and send it to a friend, or send a slideshow of photographs of a special event. The possibilities are enormous. 1. Touch > Messaging, then . 2. Enter a phone number in the To field, or touch to select a contact from People. 3. Touch the composition text box to start composing your message. 4. When you are ready to send the message, touch . 10:23 Connecting Internet Get online using your phone’s Wi-Fi to save your money. Turning On Wi-Fi 1. Touch > Settings. 2. Under WIRELESS & NETWORKS, touch the button next to Wi-Fi. Basic Operations Touch > Browser to open the home page. When known or open Wi-Fi networks and mobile data networks are available at the same time, your phone will preferably select a Wi-Fi network for Internet access. Touch on the upper section of the screen, and all web pages currently open are displayed. You can: • Touch one page to enlarge it. • Touch the cross sign (X) to close that page. • Touch (+) to open a new browser window. Opening a Webpage 1. In a browser window, touch the URL field at the top of the screen. 2. Use the keyboard to enter a webpage address. You can touch to enter the web page address by voice. 3. As you enter the address, matching webpage addresses will appear on the screen. If you see the address you want, touch it and go directly to that webpage or complete ente…

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd Bantian, Longgang District, Shenzhen, 518129 Guangdong, P.R.China Tel: +86-755-2878-1879 ; Fax: +86-755-2878-1889 Date: August 16, 2012 Statement We, Huawei Technologies Co.,Ltd, states that our device, FCC ID: U8666E, has a battery, But the battery will not be placed in the battery compartment when delivery, it is visible to the users as they purchase the products and install the battery. For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISU8666E to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co., Ltd. Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. +86 755 28780808 www.huawei.com Huawei internal reference RCT-US-01-01 USA FCC Short Term Confidentiality Request template Effective date: 2007-01-06 Version 1.1 Short Term Confidentiality Request 2012-08-16 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality Request for FCC ID: QISU8666E Product Name: HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; To whom maybe concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, Huawei Technologies Co., Ltd requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 days: 1. External Photos 2. Internal Photos 3. Test Setup Photos 4. Users Manual The applicant also acknowledges that they will also provide appropriate notice to CETECOM should either of the following occur: A) If the applicant requires additional 45 day extension periods they will notify CETECOM with a new request letter at least 7 days prior to the short-term confidentiality expiration date-[Note: up to maximum of 3 extensions only are allowed], or b) Immediately notify CETECOM in the event the information regarding the product of the product is made available to the public. CETECOM will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page1,Total 7 External Photos of HUAWEI U8666E, U8666E HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page2,Total 7 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page3,Total 7 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page4,Total 7 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page5,Total 7 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page6,Total 7 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page7,Total 7

Label&Label Location of U8666E Secret 2012-9-17 华为保密信息,未经授权禁止扩散 第1页, 共3页 Dear FCC, I bring more picture of U8666E here to show you that the label's dimension and location would not interfere with the SIM card and the microSD card, if you have any problem, please just let me know, i will do my best fot it, thank you very much! Sincerely Mike Label&Label Location of U8666E Secret 2012-9-17 华为保密信息,未经授权禁止扩散 第2页, 共3页 Label&Label Location of U8666E Secret 2012-9-17 华为保密信息,未经授权禁止扩散 第3页, 共3页

HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page1,Total 9 Internal Photos of HUAWEI U8666E, U8666E HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page2,Total 9 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page3,Total 9 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page4,Total 9 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page5,Total 9 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page6,Total 9 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page7,Total 9 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page8,Total 9 HUAWEI U8666E,U8666E HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; SECRET Page9,Total 9

TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 201 of 255 802.11b Back Side High (Battery 3, 10mm) Date/Time: 7/30/2012 10:43:19 PM Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 1.92 mho/m; ε r = 51.7; ρ = 1000 kg/m 3 Ambient Temperature:22.3 °C Liquid Temperature: 21.5°C Phantom section: Flat Section DASY5 Configuration: Probe: ES3DV3 - SN3189; ConvF(3.96, 3.96, 3.96); Calibrated: 6/22/2012 Electronics: DAE4 Sn1317; Calibrated: 1/23/2012 Phantom: SAM2; Type: SAM; Serial: TP-1524 Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 59 Back Side High/Area Scan (61x111x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.032 mW/g Back Side High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.07 V/m; Power Drift = 0.124 dB Peak SAR (extrapolated) = 0.065 W/kg SAR(1 g) = 0.031 mW/g; SAR(10 g) = 0.015 mW/g Maximum value of SAR (measured) = 0.034 mW/g TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 202 of 255 Figure 140 Body, Back Side, 802.11b Channel 11 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 203 of 255 802.11b Back Side High (Battery 4, 10mm) Date/Time: 7/30/2012 11:07:22 PM Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 1.92 mho/m; ε r = 51.7; ρ = 1000 kg/m 3 Ambient Temperature:22.3 °C Liquid Temperature: 21.5°C Phantom section: Flat Section DASY5 Configuration: Probe: ES3DV3 - SN3189; ConvF(3.96, 3.96, 3.96); Calibrated: 6/22/2012 Electronics: DAE4 Sn1317; Calibrated: 1/23/2012 Phantom: SAM2; Type: SAM; Serial: TP-1524 Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 59 Back Side High/Area Scan (61x111x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.034 mW/g Back Side High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.09 V/m; Power Drift = 0.021 dB Peak SAR (extrapolated) = 0.061 W/kg SAR(1 g) = 0.029 mW/g; SAR(10 g) = 0.013 mW/g Maximum value of SAR (measured) = 0.033 mW/g Figure 141 Body, Back Side, 802.11b Channel 11 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 204 of 255 802.11b Back Side High (Battery 5, 10mm) Date/Time: 8/7/2012 5:33:05 PM Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 1.92 mho/m; ε r = 51.7; ρ = 1000 kg/m 3 Ambient Temperature:22.3 °C Liquid Temperature: 21.5°C Phantom section: Flat Section DASY5 Configuration: Probe: ES3DV3 - SN3189; ConvF(3.96, 3.96, 3.96); Calibrated: 6/22/2012 Electronics: DAE4 Sn1317; Calibrated: 1/23/2012 Phantom: SAM2; Type: SAM; Serial: TP-1524 Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 59 Towards Ground High/Area Scan (61x111x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.031 mW/g Towards Ground High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 2.8 V/m; Power Drift = -0.081 dB Peak SAR (extrapolated) = 0.061 W/kg SAR(1 g) = 0.030 mW/g; SAR(10 g) = 0.014 mW/g Maximum value of SAR (measured) = 0.034 mW/g Figure 142 Body, Back Side, 802.11b Channel 11 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 205 of 255 802.11b Back Side High (Battery 6, 10mm) Date/Time: 8/7/2012 5:02:05 PM Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 1.92 mho/m; ε r = 51.7; ρ = 1000 kg/m 3 Ambient Temperature:22.3 °C Liquid Temperature: 21.5°C Phantom section: Flat Section DASY5 Configuration: Probe: ES3DV3 - SN3189; ConvF(3.96, 3.96, 3.96); Calibrated: 6/22/2012 Electronics: DAE4 Sn1317; Calibrated: 1/23/2012 Phantom: SAM2; Type: SAM; Serial: TP-1524 Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 59 Towards Ground High/Area Scan (61x111x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.032 mW/g Towards Ground High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 2.94 V/m; Power Drift = 0.186 dB Peak SAR (extrapolated) = 0.051 W/kg SAR(1 g) = 0.029 mW/g; SAR(10 g) = 0.017 mW/g Maximum value of SAR (measured) = 0.031 mW/g Figure 143 Body, Back Side, 802.11b Channel 11 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 206 of 255 802.11b Back Side High (Battery 1, 10mm, hotspot mode closed) Date/Time: 7/30/2012 8:39:15 PM Communication System: 802.11b; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 1.92 mho/m; ε r = 51.7; ρ = 1000 kg/m 3 Ambient Temperature:22.3 °C Liquid Temperature: 21.5°C Phantom section: Flat Section DASY5 Configuration: Probe: ES3DV3 - SN3189; ConvF(3.96, 3.96, 3.96); Calibrated: 6/22/2012 Electronics: DAE4 Sn1317; Calibrated: 1/23/2012 Phantom: SAM2; Type: SAM; Serial: TP-1524 Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 59 Back Side High/Area Scan (61x111x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.036 mW/g Back Side High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.33 V/m; Power Drift = 0.034 dB Peak SAR (extrapolated) = 0.068 W/kg SAR(1 g) = 0.033 mW/g; SAR(10 g) = 0.015 mW/g Maximum value of SAR (measured) = 0.040 mW/g Figure 144 Body, Back Side, 802.11b Channel 11 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 207 of 255 ANNEX D: Probe Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 208 of 255 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 209 of 255 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 210 of 255 TA Technology (Shanghai) Co., …

Text truncated - open the document above for the full version.

TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 1 of 255 TESTING No. L2264 OET 65 TEST REPORT Product Name HUAWEI Ascend Y 201 Pro;Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; Model HUAWEI U8666E, U8666E FCC ID QISU8666E Client Huawei Technologies Co., Ltd. TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 2 of 255 GENERAL SUMMARY Product Name HUAWEI Ascend Y 201 Pro;Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; Model HUAWEI U8666E, U8666E Report No. RHA1207-0057SAR01R1 FCC ID QISU8666E Client Huawei Technologies Co., Ltd. Manufacturer Huawei Technologies Co., Ltd. Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radiofrequency Electromagnetic Fields, 3 kHz to 300 GHz. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emissions. RSS-102 Issue 4 March 2010: Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) KDB 648474 D01 SAR Handsets Multi Xmiter and Ant, v01r05: SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas. KDB 941225 D03 Test Reduction GSM_GPRS_EDGE v01 Recommended SAR Test Reduction Procedures for GSM/GPRS/EDGE KDB 941225 D06 Hot Spot SAR v01 SAR Evaluation Procedures for Portable Devices with Wireless Router Capabilities KDB 447498 D01 Mobile Portable RF Exposure V04 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB 941225 D01 SAR test for 3G devices v02: SAR Measurement Procedures CDMA 20001x RTT, 1x Ev-Do, WCDMA, HSDPA/HSPA Tracking Number: PBA 659095 Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: August 31 st , 2012 Comment The test result only responds to the measured sample. Approved by Director Revised by SAR Manager Performed by SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RHA1207-0057SAR01R1 Page 3 of 255 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the Test Report.......................................................................................................5 1.2. Testing Laboratory ................................................................................................................ 5 1.3. Applicant Information ............................................................................................................ 6 1.4. Manufacturer Information ...................................................................................................... 6 1.5. Test Report Revision ............................................................................................................6 1.6. Information of EUT................................................................................................................ 7 1.7. The Maximum SAR 1g Values ................................................................................................ 9 1.8. Maximum Conducted Power of each tested Mode.............................................................. 11 1.9. Test Date ............................................................................................................................ 11 2. SAR Measurements System Configuration ................................................................................ 12 2.1. SAR Measurement Set-up .................................................................................................. 12 2.2. DASY5 E-field Probe System ............................................................................................. 13 2.2.1. ES3DV3 Probe Specification ....................................................................................... 13 2.2.2. E-field Probe Calibration .............................................................................................. 14 2.3. Other Test Equipment .........................................................................................................14 2.3.1. Device Holder for Transmitters .................................................................................... 14 2.3.2. Phantom...................................................................................................................... 15 2.4. Scanning Procedure........................................................................................................... 15 2.5. Data Storage and Evaluation .............................................................................................. 17 2.5.1. Data Storage................................................................................................................ 17 2.5.2. Data Evaluation by SEMCAD ...................................................................................... 17 3. Laboratory Environment............................................................................................................. 19 4. Tissue-equivalent Liquid ............................................................................................................ 20 4.1. Tissue-equivalent Liquid Ingredients.........................................…

Text truncated - open the document above for the full version.

FCC RF Test Report Product Name: HUAWEI Ascend Y 201 Pro; Skyline mini; HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; Model Number: HUAWEI U8666E,U8666E Report No: SYBH(Z-RF)016072012-2001 FCC ID:QISU8666E Reliability Laboratory of Huawei Technologies Co., Ltd. Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of HUAWEI U8666E,U8666E FCC ID: QISU8666E Report No: SYBH(Z-RF)016072012-2001 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total19 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 3. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 4. The test report is invalid if not marked with "exclusive stamp for the test report". 5. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 6. The test report is invalid if there is any evidence of erasure and/or falsification. 7. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 8. Normally, the test report is only responsible for the samples that have undergone the test. 9. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of HUAWEI U8666E,U8666E FCC ID: QISU8666E Report No: SYBH(Z-RF)016072012-2001 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total19 Applicant: Huawei Technologies Co., Ltd. Address: Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Date of Receipt Test Item: July., 16, 2012 Start Date of Test: July.,19, 2012 End Date of Test: Aug., 10, 2012 Test Result: Pass Approved By Senior Engineer Sep., 05, 2012 Dai Linjun Date Name Signature Reviewed By Sep., 05, 2012 Cousy Xu Date Name Signature Operated By Sep., 05, 2012 Huang Qiuliang Date Name Signature FCC Test Report of HUAWEI U8666E,U8666E FCC ID: QISU8666E Report No: SYBH(Z-RF)016072012-2001 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total19 Modification Record Last Report No. Date Modification Description SYBH(Z-RF) 010072012-2001 2012-8-14 First report. SYBH(Z-RF) 010072012-2001 2012-8-30 1. Modify the Frequency stability requirement: changed from 1.5ppm into 2.5ppm. 2. CCDF plots have been removed from Annex A. 3. Justification that HSDPA and HSUPA were not tested shall be in the test report at page 19. SYBH(Z-RF) 010072012-2001 2012-9-5 provide test setup photos of conducted measurements FCC Test Report of HUAWEI U8666E,U8666E FCC ID: QISU8666E Report No: SYBH(Z-RF)016072012-2001 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total19 Contents 1 General Information .................................................................................................................................. 6 1.1 APPLIED STANDARD............................................................................................................................... 6 1.2 TEST LOCATION ..................................................................................................................................... 6 1.3 TEST ENVIRONMENTAL CONDITION ......................................................................................................... 6 2 Summary .................................................................................................................................................... 7 3 Product Description .................................................................................................................................. 8 3.1 PRODUCT INFORMATION ........................................................................................................................ 8 4 Test Description ...................................................................................................................................... 10 4.1 SUPPORTED FREQUENCY RANGE ......................................................................................................... 10 4.2 TRANSMITTER / RECEIVER CHARACTERISTICS ....................................................................................... 10 4.3 ANTENNA GAIN .................................................................................................................................... 10 5 General Test Conditions / Configurations ............................................................................................. 11 5.1 RF CHANNELS UNDER TEST ................................................................................................................. 11 5.2 TEST MODES ....................................................................................................................................... 11 5.3 TEST ENVIRONMENT ............................................................................................................................ 11 5.4 TEST SETUP ........................................................................................................................................ 12 5.5 TEST CONDITIONS ............................................................................................................................... 16 6 Main Test Instruments ......................…
