QISU9510EHSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone

Huawei Technologies Co.,Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Aug 15, 2012
Application Purpose: Original Equipment
Date of Application: Aug 15, 2012
Equipment Note: HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone
Frequency Range: 2412.00000000 - 2462.00000000
Company: Huawei Technologies Co.,Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Guide Welcome to HUAWEI HUAWEI U9510E ContentsIntroduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 !Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8"# $ " % %&&' & $ " & ('# )* + ,-./ ( --0 , / , --1 - 2& " -') )** 3 -4 3 -4 1 . Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21, -) # 5 %* , & # # ! ** !/ 6 7Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27* & 8 8 # + ,') $ ' & '9 ' 4 : *4; . . , /*$ .Text Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32/ % < # # (= * 1 # * / ) < 9 (=/ 0 *< ! * !Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 7* 8 &8 > 8 8 / (,' Data Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40( % < ./ 3? . $ " @ / 702)8Email/Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 489':!-Managing Applications . . . . . . . . . . . . . . . . . . . . . . . . . 53/ "! )** & !6# / )** !!Security Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 # 3<"!8 ,,!8 1"!' > …

Text truncated - open the document above for the full version.

Attestation Statements

Secret 2012-8-13 华为保密信息,未经授权禁止扩散第1页, 共1页 Huawei Technologies Co.,Ltd Bantian, Longgang District, Shenzhen, 518129 Guangdong, P.R.China Tel: +86-755-2878-1879 ; Fax: +86-755-2878-1889 Date: August 13, 2012 Statement We, Huawei Technologies Co.,Ltd, states that our device, FCC ID: QISU9510E use Broadcom’s chip BCM4330, though BCM4330 support BT4.0+HS and 5.0G Wi-Fi., but 201HW doesn’t support BLE, 5 GHz client, ad-hoc, function. 201HW only support BT3.0+EDR and 2.4G Wi-Fi , Wi-Fi Direct. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Cover Letter(s)

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISU9510E to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Cover Letter(s)

Huawei Technologies Co., Ltd. Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. +86 755 28780808 www.huawei.com Huawei internal reference RCT-US-01-01 USA FCC Short Term Confidentiality Request template Effective date: 2007-01-06 Version 1.1 Short Term Confidentiality Request 2012-08-13 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality Request for FCC ID: QISU9510E Product Name: HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with Bluetooth To whom maybe concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, Huawei Technologies Co., Ltd requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 90 days: 1. External Photos 2. Internal Photos 3. Test Setup Photos 4. Users Manual The applicant also acknowledges that they will also provide appropriate notice to CETECOM should either of the following occur: A) If the applicant requires additional 45 day extension periods they will notify CETECOM with a new request letter at least 7 days prior to the short-term confidentiality expiration date-[Note: up to maximum of 3 extensions only are allowed], or b) Immediately notify CETECOM in the event the information regarding the product of the product is made available to the public. CETECOM will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely ,

External Photos

HUAWEI U9510E, U9510E SECRET Page1,Total 4 External Photos of HUAWEI U9510E, U9510E HUAWEI U9510E, U9510E SECRET Page2,Total 4 HUAWEI U9510E, U9510E SECRET Page3,Total 4 HUAWEI U9510E, U9510E SECRET Page4,Total 4

ID Label/Location Info

Document Title SECRET Page1, Total 2 Label&Label Location HUAWEI U9510E，U9510E Document Title SECRET Page2, Total 2

Internal Photos

HUAWEI U9510E, U9510E SECRET Page1,Total 4 Internal Photos of HUAWEI U9510E, U9510E HUAWEI U9510E, U9510E SECRET Page2,Total 4 HUAWEI U9510E, U9510E SECRET Page3,Total 4 HUAWEI U9510E, U9510E SECRET Page4,Total 4

RF Exposure Info

Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 FCC SAR Compliance Test Report Project Name:_______________________ Model :_______________________ FCC ID : _______________________ Report No. : _______________________ APPROVED CHECKED PREPARED BY DATE 2012-08-09 2012-08-09 2012-08-09 The test results of this test report relate exclusively to the item(s) tested , The HUAWEI does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of HUAWEI. Reliability Laboratory of Huawei Technologies Co., Ltd. HUAWEI U9510E, U9510E QISU9510E SYBH(Z-SAR)018082012-2 HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/ EDGE Mobile Phone with Bluetooth Report No.:SYBH(Z-SAR)018082012-2 FCC ID:QISU9510E 2012-08-09 Page 2 of 40 Table of Contents 1 General Information ............................................................................................................................................................ 4 1.1 Statement of Compliance .......................................................................................................................................... 4 1.2 RF exposure limits...................................................................................................................................................... 4 1.3 EUT Description ......................................................................................................................................................... 5 1.3.1 General Description ........................................................................................................................................... 6 1.4 Test specification(s) .................................................................................................................................................. 7 1.5 Testing laboratory ....................................................................................................................................................... 7 1.6 Applicant and Manufacturer ...................................................................................................................................... 7 1.7 Application details ...................................................................................................................................................... 7 1.8 Ambient Condition ..................................................................................................................................................... 7 2 SAR Measurement System ............................................................................................................................................. 8 2.1 SAR Measurement Set-up ....................................................................................................................................... 8 2.2 Test environment ........................................................................................................................................................ 9 2.3 Data Acquisition Electronics description ................................................................................................................ 9 2.4 Probe description ..................................................................................................................................................... 10 2.5 Phantom description ................................................................................................................................................ 11 2.6 Device holder description ........................................................................................................................................ 11 2.7 Test Equipment List ................................................................................................................................................. 12 3 SAR Measurement Procedure ...................................................................................................................................... 13 3.1 Scanning procedure ................................................................................................................................................. 13 3.2 Spatial Peak SAR Evaluation ................................................................................................................................. 14 3.3 Data Storage and Evaluation .................................................................................................................................. 15 4 System Verification Procedure ........................................................................................................................................ 17 4.1 Tissue Verification .................................................................................................................................................... 17 4.2 System Check ........................................................................................................................................................... 19 4.3 Validation Procedure................................................................................................................................................ 20 5 Measurement Uncertainty Evaluation .......................................................................................................................... 21 5.1 Measurement uncertainty evaluation for SAR test .............................................................................................. 21 5.2 Measurement uncertainty evaluation for system validation ................................…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No.:SYBH(Z-SAR)018082012-2 FCC ID:QISU9510E Appendix A. System Check Plots Table of contents SystemPerformanceCheck-D835-EX-Head SystemPerformanceCheck-D835-EX-Body SystemPerformanceCheck-D1800-EX-Head SystemPerformanceCheck-D1800-EX-Body SystemPerformanceCheck-D1900-EX-Head SystemPerformanceCheck-D1900-EX-Body SystemPerformanceCheck-D2450-EX- Head SystemPerformanceCheck-D2450-EX-Body Date/Time: 7/31/2012 23:46:31 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D835-EX-Head DUT: Dipole 835 MHz D835V2; Type: D835V2; Serial: D835V2 - SN:4d126 Communication System: CW; Frequency: 835 MHz Medium parameters used: f = 835 MHz; σ = 0.913 mho/m; ε r = 41.43; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(9.01, 9.01, 9.01); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/d=15mm,pin=250mW/Area Scan (6x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.65 mW/g Configuration/d=15mm,pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 52.987 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 3.748 mW/g SAR(1 g) = 2.49 mW/g; SAR(10 g) = 1.62 mW/g Maximum value of SAR (measured) = 2.69 mW/g 0 dB = 2.65 mW/g = 8.46 dB mW/g Date/Time: 8/3/2012 11:05:23 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D835-EX-Body DUT: Dipole 835 MHz D835V2; Type: D835V2; Serial: D835V2 - SN:4d126 Communication System: CW; Frequency: 835 MHz Medium parameters used: f = 835 MHz; σ = 0.991 mho/m; ε r = 56.512; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 11/23/2011; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM3; Type: SAM; Serial: TP-1597 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/d=15mm,pin=250mW/Area Scan (5x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.80 mW/g Configuration/d=15mm,pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.174 V/m; Power Drift = 0.04 dB Peak SAR (extrapolated) = 3.881 mW/g SAR(1 g) = 2.61 mW/g; SAR(10 g) = 1.71 mW/g Maximum value of SAR (measured) = 2.82 mW/g 0 dB = 2.80 mW/g = 8.93 dB mW/g Date/Time: 7/31/2012 09:28:50 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D1800-EX-Head DUT: Dipole 1800 MHz D1800V2; Type: D1800V2; Serial: D1800V2 - SN:2d184 Communication System: CW; Frequency: 1800 MHz Medium parameters used: f = 1800 MHz; σ = 1.456 mho/m; ε r = 40.212; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(7.94, 7.94, 7.94); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM3; Type: SAM; Serial: TP-1597 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/d=10mm, Pin=250mW/Area Scan (5x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 11.0 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 87.389 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 18.227 mW/g SAR(1 g) = 9.67 mW/g; SAR(10 g) = 4.96 mW/g Maximum value of SAR (measured) = 10.9 mW/g 0 dB = 11.0 mW/g = 20.81 dB mW/g Date/Time: 8/4/2012 21:38:08 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D1800-EX-Body DUT: Dipole 1800 MHz D1800V2; Type: D1800V2; Serial: D1800V2 - SN:2d184 Communication System: CW; Frequency: 1800 MHz Medium parameters used: f = 1800 MHz; σ = 1.547 mho/m; ε r = 52.938; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(7.43, 7.43, 7.43); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM3; Type: SAM; Serial: TP-1597 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/d=10mm, Pin=250mW/Area Scan (7x13x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 10.4 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 48.295 V/m; Power Drift = 0.19 dB Peak SAR (extrapolated) = 18.047 mW/g SAR(1 g) = 9.91 mW/g; SAR(10 g) = 5.19 mW/g Maximum value of SAR (measured) = 11.1 mW/g 0 dB = 10.4 mW/g = 20.36 dB mW/g Date/Time: 8/3/2012 0:41:41 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D1900-EX-Head DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d143 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.449 mho/m; ε r = 39.753; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(7.67, 7.67, 7.67); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/d=10mm, Pin=250mW/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 10.3 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 88.026 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 19.723 mW/g SAR(1 g) = 10.3 mW/g; SAR(10 g) = 5.25 mW/g Maximum value of SAR (measured) = 11.6 mW/g 0 dB = 10.3 mW/g = 20.30 dB mW/g Date/Time: 8/4/2012 2:38:33 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D1900-EX-Body DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d143 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.558 mho…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No.:SYBH(Z-SAR)018082012-2 FCC ID:QISU9510E Appendix B. SAR Measurement Plots Table of contents GSM 850MHz Head GSM 850MHz Body GSM 1900MHz Head GSM 1900MHz Body WCDMA 850MHz Head WCDMA 850MHz Body WCDMA 1700MHz Head WCDMA 1700MHz Body WCDMA 1900MHz Head WCDMA 1900MHz Body WiFi(802.11b) 2450MHz Head WiFi(802.11b) 2450MHz Body Date/Time: 8/1/2012 10:01:45 Test Laboratory: HUAWEI SAR Lab U9510E GSM850 190CH Left hand touch cheek DUT: U9510E; Type: HSHSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with Bluetooth; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.914 mho/m; ε r = 41.429; ρ = 1000 kg/m 3 Phantom section: Left Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(9.01, 9.01, 9.01); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.269 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.375 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 0.322 mW/g SAR(1 g) = 0.263 mW/g; SAR(10 g) = 0.200 mW/g Maximum value of SAR (measured) = 0.276 mW/g 0 dB = 0.269 mW/g = -11.40 dB mW/g Date/Time: 8/1/2012 10:28:44 Test Laboratory: HUAWEI SAR Lab U9510E GSM850 190CH Left hand tilt 15 degree DUT: U9510E; Type: HSHSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with Bluetooth; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.914 mho/m; ε r = 41.429; ρ = 1000 kg/m 3 Phantom section: Left Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(9.01, 9.01, 9.01); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.208 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.519 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 0.253 mW/g SAR(1 g) = 0.203 mW/g; SAR(10 g) = 0.155 mW/g Maximum value of SAR (measured) = 0.212 mW/g 0 dB = 0.208 mW/g = -13.63 dB mW/g Date/Time: 8/1/2012 11:25:13 Test Laboratory: HUAWEI SAR Lab U9510E GSM850 190CH Right hand touch cheek DUT: U9510E; Type: HSHSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with Bluetooth; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.914 mho/m; ε r = 41.429; ρ = 1000 kg/m 3 Phantom section: Right Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(9.01, 9.01, 9.01); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.379 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.067 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 0.490 mW/g SAR(1 g) = 0.378 mW/g; SAR(10 g) = 0.282 mW/g Maximum value of SAR (measured) = 0.398 mW/g 0 dB = 0.379 mW/g = -8.43 dB mW/g Date/Time: 8/1/2012 10:56:05 Test Laboratory: HUAWEI SAR Lab U9510E GSM850 190CH Right hand tilt 15 degree DUT: U9510E; Type: HSHSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with Bluetooth; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.914 mho/m; ε r = 41.429; ρ = 1000 kg/m 3 Phantom section: Right Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(9.01, 9.01, 9.01); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Head/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.246 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 12.521 V/m; Power Drift = -0.00 dB Peak SAR (extrapolated) = 0.297 mW/g SAR(1 g) = 0.239 mW/g; SAR(10 g) = 0.182 mW/g Maximum value of SAR (measured) = 0.251 mW/g 0 dB = 0.246 mW/g = -12.18 dB mW/g Date/Time: 8/3/2012 11:40:53 Test Laboratory: HUAWEI SAR Lab U9510E GSM850 GPRS 1TS 190CH Towards Phantom 10mm DUT: U9510E; Type: HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with Bluetooth; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.994 mho/m; ε r = 56.502; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM3; Type: SAM; Serial: TP-1597 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Body/Area Scan (8x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.461 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 19.567 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 0.560 mW/g SAR(1 g) = 0.445 mW/g; SAR(10 g) = 0.346 mW/g Maximum value of SAR (measured) = 0.466 mW/g 0 dB = 0.466 mW/g = -6.63 dB mW/g Date/Time: 8/3/2012 12:11:05 Test Laboratory: HUAWEI SAR Lab U9510E GSM850 GPRS 2TS 190CH Towards Phantom 10mm DUT: U9510E; Type: HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS…

Text truncated - open the document above for the full version.

RF Exposure Info

Justification of the extended calibration of Dipole D1800V2 SN: 2d184 Per KDB 450824, we have Measured the Impedance and Return Loss as below, and the return loss is <-20dB, with 20% of prior calibration; the real or imaginary parts of the impedance is with 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole1800 Head TST Target Value Measured Value Difference Impedance transformed to feed point 49.7Ω-2.3jΩ 51.59Ω-2.16jΩ R=1.89Ω, X=0.14Ω Return Loss - 32.8dB -33.02dB -2.20% Dipole1800 Body TST Target Value Measured Value Difference Impedance transformed to feed point 45.3Ω-2.3jΩ 46.30Ω-2.57jΩ R=1.0Ω, X=-0.47Ω Return Loss - 25.2dB -25.64dB -1.75% Measured Date 2011-03-08 2012-03-07 --- Impedance Test-Head Return Loss Test-Head Impedance Test-Body Return Loss Test-Body

RF Exposure Info

Justification of the extended calibration of Dipole D2450V2 SN: 860 Per KDB 450824, we have Measured the Impedance and Return Loss as below, and the return loss is <-20dB, with 20% of prior calibration; the impedance is with 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole2450 Head TST Target Value Measured Value Difference Impedance transformed to feed point 54.0Ω+2.2jΩ 54.1Ω+2.36jΩ R=0.1Ω, X=0.16Ω Return Loss - 27.2dB -27.34dB -0.51% Dipole2450 Body TST Target Value Measured Value Difference Impedance transformed to feed point 49.0Ω+4.9jΩ 49.48Ω+5.13jΩ R=0.48Ω, X=0.23Ω Return Loss -26.0dB -26.38dB -1.46% Measured Date --- Impedance Test-Head Return Loss Test-Head Impedance Test-Body Return Loss Test-Body

Test Report

FCC RF Test Report Product Name: HSPA+/HSUPA/HSDPA/UMTS/GSM/GPRS/EDGE Mobile Phone with Bluetooth Model Number: HUAWEI U9510E, U9510E Report No: SYBH(Z-RF)005082012-2006 FCC ID: QISU9510E Reliability Laboratory of Huawei Technologies Co., Ltd. Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28780808 Fax: +86 755 89652518 Notice FCC Test Report of HUAWEI U9510E, U9510E FCC ID: QISU9510E Security Level: Public Report No: SYBH(Z-RF)005082012-2006 Confidential In…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Zhang Xinghai

[email protected]+86-755-2897-0299Fax: +86-755-8965-0226

Test Firm

Huawei Technologies Co., LTDZhou Fengyum

[email protected]86-755-28782917Fax: 86-755-89650226

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	260.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 10 mm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR for head, body-worn accessory, wireless router and simultaneous transmission use conditions are 0.21 W/kg, 0.10 W/kg, 0.15 W/kg, and 1.19 W/kg, respectively.
