QISY520-U03WCDMA Digital Mobile Phone

1 Gett ing to know your phone Thank you for choosing the HUAWEI smartphone. First, let's take a look at a few basics. Press and hold the power button to power on your phone. After your phone is powered up, you can use the power button to turn the screen off and on. 2 Preparing your phone To insert the SIM card, the battery and a microSD card please perform the steps shown in the following f igures. Your phone is shipped with the battery part ially charged. It is recommended that you fully charge the battery before using it for the f irst t ime. When fastening the battery cover, fasten its upper part f irst and then press down the lower part unt il completely fastened. 3 Locking and unlocking the screen When you are not using your phone, press the power button to turn off the screen. After being idle for a specif ied period of t ime, your phone automat ically locks its screen. Follow the onscreen instruct ions and drag to unlock the screen or open an applicat ion. 4 Making a call Touch to open the dialer. You can dial a phone number directly or touch to choose a contact. You can also touch a phone number in places like messages, email and webpages to make a call. To answer an incoming call, drag to . 5 Sending messages Touch to open Messaging. Adding a photo or audio clip to a text message turns it into a mult imedia message. You can also save attachments from mult imedia messages. 6 Taking a photo or video Touch to open Camera. In photo mode, touch to take a photo. In video mode, frame the scene and touch to record a video. Your phone does not support autofocus and may not be able to properly scan QR codes. 7 Listening to music Touch > to open Play Music. You can copy songs to your phone and immerse yourself with extraordinary audio experience anytime. You can play songs by artist, album and more. 8 Surf ing the web On the home screen, touch > to open Browser. You can start surf ing the web right away using your phone's browser and stay on ball with up-to-date news and informat ion. Your browser supports mult i-page browsing. Touch to switch between pages. 9 Wi-Fi hotspot Your phone can also funct ion as a Wi-Fi hotspot for other devices, sharing its mobile data connect ion. 1. Touch > More... > Tethering & portable hotspot. 2. Touch Wi-Fi hotspot to turn on hotspot. 3. Touch Wi-Fi hotspot > Set up Wi-Fi hotspot, you can name the Wi-Fi hotspot, select an encryption mode, set the key to the Wi-Fi hotspot. 4. On the device you want to use, search for and connect to your phone's Wi-Fi network. By default, the Wi-Fi hotspot turns off after being idle for 5 minutes. 10 Others In certain locat ions or weather condit ions, GPS posit ioning informat ion may not be accurate. Your phone may experience lag when there is insuff icient memory or there are too many applicat ions running in the background. 11 Personal Informat ion and Data Security The use of some functions or third-party applications on your device could result in your personal information and data being lost or becoming accessible to others. Several measures are recommended to help you protect personal and confidential information.  Place your device in a safe area to prevent it from unauthorized use.  Set your device screen to lock and create a password or unlock pattern to open it.  Periodically back up personal informat ion kept on your SIM/USIM card, memory card, or stored in your device memory. If you change to a different device, be sure to move or delete any personal informat ion on your old device.  If you are worried about viruses when you receive messages or emails from a stranger, you can delete them without opening them.  If you use your device to browse the Internet, avoid websites that might pose a security risk to avoid theft of your personal informat ion.  If you use services such as Wi-Fi tether or Bluetooth, set passwords for these services to prevent unauthorized access. When these services are not in use, turn them off.  Install or upgrade device security software and regularly scan for viruses.  Be sure to obtain third-party applicat ions from a legit imate source. Downloaded third-party applicat ions should be scanned for viruses.  Install security software or patches released by Huawei or third-party applicat ion providers. 12  Some applicat ions require and transmit location informat ion. As a result, a third-party may be able to share your locat ion informat ion.  Your device may provide detect ion and diagnost ic informat ion to third-party applicat ion providers. Third party vendors use this informat ion to improve their products and services.  If you have concerns about the security of your personal informat ion and data, please contact [email protected]. For more help Search for and download the User Guide from http://consumer.huawei.com/en/. Please visit http://consumer.huawei.com/en/support/hotline for recent updated hotline and email address in your country. Safety informat ion This sect ion contains important informat ion about the operat ion of your device. It also contains informat ion about how to use the device safely. Read this informat ion carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment  Follow rules and regulat ions set forth by hospitals and health care facilit ies. Do not use your device where prohibited. 13  Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more informat ion.  Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potent ial interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Protect ing your hearing when using a headset  To prevent p…

Text truncated - open the document above for the full version.

文档名称 文档密级 2014-08-05 华为保密 信息,未经授权禁止扩散 第1页, 共1页 To whom it may concern, Letter of Agency I, an officer of HUAWEI TECHNOLOGIES CO.,LTD do hereby authorize Intertek Testing Services (Mr. Shawn Xing) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 22&24 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2007) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Zhang xinghai EMC Laboratory Manager

Huawei Technologies Co.,Ltd. Federal Communications Commission 2014-08-05 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QIS Y520-U03 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Block Diagram Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2014-12-30: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C E- mail: [email protected] Tel: 0086-0755-28970299 Fax: 0086-0755-89650226

文档名称 文档密级 2014-8-12 华为保密信息,未经授权禁止扩散 第1页, 共1页 Declaration Manufacturer/Application:Huawei Technologies Co.,Ltd FCC ID: QISY520-U03 I declare that the shielded USB cable used in the test will be marketed with the EUT. Yours sincerely, Product Manager: Email: [email protected]

External photos

HUAWEI Y-U03 WCDMA Digital Mobile Phone 文档密级 2014-8-6 华为保密信息,未经授权禁止扩散 第1页, 共1页 Statement We, Huawei Technologies Co.,Ltd., states that our device, FCC ID: QISY520-U 03, The label is put inside the battery compartment But the battery will not be placed in the battery compartment when delivery, the label is visible to the users as they purchase the products and install the battery. For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C E-mail: [email protected] Tel: 0086-0755-28970299 Fax: 0086-0755-89650226

SIZE：48 (mm)* 56(mm)

Internal photos

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. TRF No.: FCC 15C_PC_b I ntertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Website: www.china.intertek-etlsemko.com Huawei Technologies Co., Ltd Application F or Certification FCC ID: QISY520-U03 WCDMA Digital Mobile Phone M odel: HUAWEI Y520-U03 Class B Personal Computer Peripherals Report No.: 140710013SZN-005 Prepared and Checked by: Approved by: Si gn on file Jenner Liu Assistant Engineer Andy Yan Se nior Project Engineer Date: August 15 , 2014 INTERTEK TESTING SERVICES TRF No.: FCC 15C_PC_b FCC ID: QISY520-U03 Report No.: 140710013SZN-005 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labeling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information EXHIBIT 9: Confidentiality Request EXHIBIT 10: Test Equipment List INTERTEK TESTING SERVICES TRF No.: FCC 15C_PC_b FCC ID: QISY520-U03 Report No.: 140710013SZN-005 ii MEASUREMENT / TECHNICAL REPORT Huawei Technologies Co., Ltd MODEL: HUAWEI Y520-U03 FCC ID: QISY520-U03 This report concerns (check one:) Original Grant X Class II Change Equipment Type: JBP-Part 15 Class B Computing Device/Peripherals Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart B for unintentional radiator − the new 47 CFR [10-01-13 Edition] provision. Report prepared by: Jenner Liu Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road Nanshan District, Shenzhen, P. R. China Phone: (86 755) 8614 0639 Fax: (86 755) 8601 6751 INTERTEK TESTING SERVICES TRF No.: FCC 15C_PC_b FCC ID: QISY520-U03 Report No.: 140710013SZN-005 iii Table of Contents 1.0 General Description .............................................................................................. 2 1.1 Product Description ........................................................................................ 2 1.2 Related Submittal(s) Grants ........................................................................... 2 1.3 Test Methodology ........................................................................................... 3 1.4 Test Facility .................................................................................................... 3 2.0 System Test Configuration .................................................................................. 5 2.1 Justification .................................................................................................... 5 2.2 EUT Exercising Software ............................................................................... 5 2.3 Special Accessories ....................................................................................... 5 2.4 Equipment Modification .................................................................................. 5 2.5 Measurement Uncertainty .............................................................................. 6 2.6 Support Equipment List and Description ........................................................ 6 3.0 Emission Results .................................................................................................. 8 3.1 Field Strength Calculation .............................................................................. 9 3.2 Radiated Emission Configuration Photograph ............................................. 11 3.3 Radiated Emission Data ............................................................................... 11 3.4 Conducted Emission at Mains Terminal ....................................................... 13 3.5 Conducted Emission Configuration Photograph .......................................... 13 3.6 Conducted Emission Data ............................................................................ 13 4.0 Equipment Photographs .................................................................................... 17 5.0 Product Labelling ............................................................................................... 19 6.0 Technical Specifications .................................................................................... 21 7.0 Instruction Manual .............................................................................................. 23 8.0 Miscellaneous Information ...........................…

Text truncated - open the document above for the full version.

Radiated photos

Conducted photos
