QISY530-U00HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth

Quick Start Guide Y530 1 Getting to know your phone Thank you for choosing the HUAWEI smartphone. First, let's take a look at a few basics: Press and hold the power button to power on your phone. After your phone is powered up, you can use the power button to turn the screen off and on. Headset jack Power Volume key Status indicator Front camera Earpiece Back Home Menu Charger/Data port 2 Preparing your phone To insert a SIM card, the battery and a microSD card please perform the few steps shown in the following figures. Remove the battery cover Insert the microSD card (optional) 1 3 Insert the SIM card 2 3 Your phone is shipped with the battery partially charged. It is recommended that you fully charge the battery before using it for the first time. 4 5 Insert the battery Charge the battery 6 Close the battery cover a b 4 Locking and unlocking the screen When you are not using your phone, press the power button to turn off the screen. After being idle for a specified period of time, your phone automatically locks its screen. Follow the onscreen instructions and drag to unlock the screen or open an application. 5 Managing contacts Touch to open People. From the contact list, touch > Manage contacts to import contacts from the SIM card, microSD card, or another Bluetooth device. Touch the Groups tab page to group your contacts for easier management. Create contact 6 Making a call Touch to open the dialer. You can dial a phone number directly or touch to choose a contact. You can also touch a phone number in places like messages, email and webpages to make a call. To answer an incoming call, drag to . ********** 7 Sending messages Touch to open Messaging. Adding a photo or audio clip to a text message turns it into a multimedia message. You can also save attachments from multimedia messages. Happy birthday! Attach file 8 Taking a photo or video Touch to open Camera. In photo mode, let your camera focus automatically or touch the screen to focus the camera. Then touch to take a photo. In video mode, frame the scene and touch to record a video. View photos and videos taken A Switch betwe photo and video modes 9 Listening to music Touch to open Play Music. You can copy songs to your phone and immerse yourself with extraordinary audio experience anytime. You can play songs by name, artist, album and more. Progress bar Playlist screen Music player controls Back 10 Surfing the web Touch to open Browser. You can start surfing the web right away using your phone's browser and stay on ball with up-to-date news and information. Your browser supports multi-page browsing. Touch to switch between pages. consumer.huawei.com/en 11 For more help Want to obtain the user guide? Search for and download the User Guide from http://consumer.huawei.com/en/. 12 Safety information This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment • Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device where prohibited. • Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more information. • Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Protecting your hearing when using a headset • To prevent possible hearing damage, do not listen at high volume levels for long periods. • Using a headset at high volumes may damage your hearing. To reduce this risk, lower the headset volume to a safe and comfortable level. • Exposure to high volumes while driving may cause distraction and increase your risk of an accident. 13 Areas with flammables and explosives • Do not use the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols. • Do not store or transport the device in containers with flammable liquids, gases, or explosives. Traffic security • Observe local laws and regulations while using the device. To reduce the risk of accidents, do not use your wireless device while driving. • Concentrate on driving. Your first responsibility is to drive safely. • Do not hold the device while driving. Use hands-free accessories. • When you must make or answer a call, pull off the road safely and park the vehicle first. • RF signals may affect the electronic systems of motor vehicles. For more information, consult the vehicle manufacturer. • Do not place the device over the air bag or in the air bag deployment area in a motor vehicle. Doing so may hurt you because of the strong force when the air bag inflates. • Do not use your device while flying in an aircraft or immediately before boarding. Using wireless devices in an aircraft may disrupt wireless networks, present a hazard to aircraft operation, or be illegal. Operating environment • Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions. • Do not use your device during thunderstorms to protect your device against any danger caused by lightning. 14 • Ideal operating temperatures are 0 °C to 35 °C. Ideal storage temperatures are -20 °C to 70 °C. Extreme heat or cold may damage your device or accessories. • Do not expose your device to direct sunlight (such as on a car dashboard) for prolonged periods. • To protect y…

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd. Federal Communications Commission 2013-11-30 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISY530-U00 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2014-04-28: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755-89650226 Tel: 0086-0755-28970299

HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page1,Total 5 External Photos of HUAWEI Y530-U00, Y530-U00 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page2,Total 5 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page3,Total 5 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page4,Total 5 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page5,Total 5

Huawei Technologies Co.,Ltd Bantian, Longgang District, Shenzhen, 518129 Guangdong, P.R.China Tel: 0086-0755-2897-0299 ; Fax: 0086-0755-8965-0226 Date: December 17, 2013 Statement We, Huawei Technologies Co.,Ltd, states that our device, FCC ID: QISY530-U00, has a battery, But the battery will not be placed in the battery compartment when delivery, it is visible to the users as they purchase the products and install the battery. For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page1, Total 4 Label Location HUAWEI Y530-U00, Y530-U00 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page2, Total 4 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page3, Total 4 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page4, Total 4

HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page1,Total 7 Internal Photos of HUAWEI Y530-U00, Y530-U00 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page2,Total 7 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page3,Total 7 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page4,Total 7 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page5,Total 7 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page6,Total 7 HUAWEI Y530-U00, Y530-U00 HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 SECRET Page7,Total 7

EMC Test Report Product Name: HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 Model Number: HUAWEI Y530-U00, Y530-U00 Report No: SYBH(Z-EMC)013112013-2 FCC ID: QISY530-U00 Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 EMC Test Report of Y530-U00 FCC ID: QISY530-U00 Security Level: secret Report No.: SYBH(Z-EMC)013112013-2 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total19 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has passed the accreditation by The American Association for Laboratory Accreditation (A2LA). The accreditation number is 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing and approving the test report. 7. The test report is invalid if there is any evidence of erasure and/or falsification. 8. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 9. Normally, the test report is only responsible for the samples that have undergone the test. 10. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. EMC Test Report of Y530-U00 FCC ID: QISY530-U00 Security Level: secret Report No.: SYBH(Z-EMC)013112013-2 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total19 Applicant: Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Date of Receipt Test Item: Nov.08, 2013 Start Date of Test: Nov.08, 2013 End Date of Test: Nov.16, 2013 Test Result: Pass Approved By 2013-12-03 Liu Chunlin (Lab Manager) Date Name Signature Prepared by 2013-12-03 Su Yuguang (Test Engineer) Date Name Signature EMC Test Report of Y530-U00 FCC ID: QISY530-U00 Security Level: secret Report No.: SYBH(Z-EMC)013112013-2 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total19 TABLE OF CONTENT 1 General Information .......................................................................................................................... 5 1.1 EUT Description ........................................................................................................................ 5 1.2 Test Site Information .................................................................................................................. 7 1.3 Applied Standards ..................................................................................................................... 7 2 Summary of Results ......................................................................................................................... 8 3 System Configuration during EMC Test ........................................................................................... 9 3.1 Test Mode .................................................................................................................................. 9 3.2 Test System Configuration ........................................................................................................ 9 3.3 Cables Used during Test ......................................................................................................... 11 3.4 Associated Equipment Used during Test ................................................................................ 11 4 Electromagnetic Interference (EMI) ............................................................................................... 12 4.1 Radiated Disturbance 30MHz to 18GHz ................................................................................. 12 4.2 Conducted Disturbance 0.15 MHz to 30MHz.......................................................................... 14 5 Main Test Instruments .................................................................................................................... 15 6 System Measurement Uncertainty ................................................................................................. 16 7 Test Data and Graph ...................................................................................................................... 17 7.1 Radiated Disturbance .............................................................................................................. 17 7.2 Conducted Disturbance ........................................................................................................... 19 EMC Test Report of Y530-U00 FCC ID: QISY530-U00 Security Level: secret Report No.: SYBH(Z-EMC)013112013-2 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total19 1 General Information 1.1 EUT Description EUT Description Product Name HSPA+/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth; HUAWEI Ascend Y530 Model Number HUAWEI Y530-U00, Y530-U00 Input voltage DC 3.7V from AC/DC adaptor TX Frequency GSM 850:824MHz To 849MHz GSM1900:1850MHz To 1910MHz BT: 2402MHz To 2480MHz WIFI: 2412MHz To 2462MHz RX Frequency GSM850:869MHz To 894MHz GSM1900:1930MHz To 1990MHz BT: 2402 MHz To 2480MHz WIFI: 2412MHz To 2462MHz GPS: 1…

Text truncated - open the document above for the full version.

Photos of Test Setups For GSM&WCDMA Radiated Spurious Emission (below 3GHz) Radiated Spurious Emission (3GHz to18GHz) Radiated Spurious Emission (18GHz to26.5GHz) For BT&WiFi 1 Radiated Spurious Emissions Radiated Spurious Emission (below 1GHz) Radiated Spurious Emission (1GHz to18GHz) Radiated Spurious Emission (above 18GHz) 2 Conducted Emissions Conducted Emissions for AC Ports
