QISY560-L23Smart Phone

Quick Start Guide Y5 1 Getting to know your phone Thank you for choosing the HUAWEI smartphone. First, let's take a look at a few basics. Press and hold the power button to power on your phone. After your phone is powered up, you can use the power button to turn the screen off and on. 2 Preparing your phone To i ns ert the SIM card, the battery and a microSD card, please perform the few steps shown in the following figures. Your phone is shipped with the battery partially charged. It is recommended that you fully charge the battery before using it for the first time. HUAWEI Y560-L03: HUAWEI Y560-U03: 3 HUAWEI Y560-L23: HUAWEI Y560-U23: 4 Locking and unlocking the screen When you are not using your phone, press the power button to turn off the screen. After being idle for a specified period of time, your phone locks its screen automatically. Follow the onscreen instructions and slide to unlock the screen. 5 Making a call On the home screen, touch . You can dial a phone number directly. You can also touch a phone number in places like messages, email and webpages to make a call. 6 Sending messages On the home screen, touch . Adding a photo or audio clip to a text message turns it into a multimedia message. You can also save attachments from multimedia messages. 7 Taking a photo or video On the home screen, touch . Flick left or right to switch between photo and video capture modes. When the screen is turned off, double-press the volume down button to take a snapshot. 8 Listening to music On the home screen, touch . You can copy songs to your phone and immerse yourself with extraordinary audio experience anytime. You can also mark your songs to add them to the playlist. 9 Internet connection Flick down from the status bar to open the notification panel. Touch to turn on the mobile network. Touch and hold to go to the Wi-Fi settings screen. Turn on Wi-Fi and follow the onscreen instructions to connect your phone to a Wi-Fi network. 10 Personal information and data security The use of some functions or third-party applications on your device could result in your personal information and data being lost or becoming accessible to others. Several measures are recommended to help you protect personal and confidential information.  Place your device in a safe area to prevent it from unauthorized use.  Set your device screen to lock and create a password or unlock pattern to open it.  Periodically back up personal information kept on your SIM/USIM card, memory card, or stored in your device memory. If you change to a different device, be sure to move or delete any personal information on your old device.  If you are worried about viruses when you receive messages or emails from a stranger, you can delete them without opening them.  If you use your device to browse the Internet, avoid websites that might pose a security risk to avoid theft of your personal information.  If you use services such as Wi-Fi tether or Bluetooth, set passwords for these services to prevent unauthorized access. When these services are not in use, turn them off.  Install or upgrade device security software and regularly scan for viruses.  Be sure to obtain third-party applications from a legitimate source. Downloaded third-party applications should be scanned for viruses.  Install security software or patches released by Huawei or third-party application providers. 11  Some applications require and transmit location information. As a result, a third-party may be able to share your location information.  Your device may provide detection and diagnostic information to third-party application providers. Third party vendors use this information to improve their products and services.  If you have concerns about the security of your personal information and data, please contact [email protected]. For more help Please visit http://consumer.huawei.com/en/support/hotline/ for recently updated hotline and email address in your country or region. 12 Legal notice Copyright © Huawei Technologies Co., Ltd. 2015. All rights reserved. Trademarks and permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Android™ is a trademark of Google Inc. LTE is a trade mark of ETSI. The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Huawei Technologies Co., Ltd. is under license. Other trademarks, product, service and company names mentioned may be the property of their respective owners. Third-Party software statement Huawei does not own the intellectual property of the third-party software and applications that are delivered with this product. Therefore, Huawei will not provide any warranty of any kind for third party software and applications. Neither will Huawei provide support to customers who use third-party software and applications, nor be responsible or liable for the functions or performance of third-party software and applications. Third-party software and applications services may be interrupted or terminated at any time, and Huawei does not guarantee the availability of any content or service. Third-party service providers provide content and services through network or transmission tools outside of the control of Huawei. To t he greatest extent permitted by applicable law, it is explicitly stated that Huawei shall not compensate or be liable for services provided by third-party service providers, or the interruption or termination of third-party contents or services. Huawei shall not be responsible for the legality, quality, or any other aspects of any software installed on this product, or for 13 any uploaded or downloaded third-party works in any form, including but not limited to texts, images, videos, or software etc. Customers shall bear the risk for any and all effects, including incompatibility between the software and this product, which result from installing software or uploading or downloading the third-party …

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Huawei Technologies Co.,Ltd Address: Administration Building, Headquarters of Huawei, Technologies Co., Ltd., Bantian, Longgang District City: Shenzhen Country: China Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: Smart Phone Type designation: HUAWEI Y560-L23; Y560-L23 Trademark: HUAWEI on our behalf. Date: 2015-06-09 City: Shenzhen Name: Zhang Xinghai Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 10-Aug-09 RF_501, Issue 5 Page 1 of 1 Company Name: Huawei Technologies Co.,Ltd Address: Administration Building, Headquarters of Huawei, Technologies Co., Ltd., Bantian, Longgang District City: Shenzhen Country: China To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: QISY560-L23 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: These documents contain detailed system and equipment description considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitor unfair advantage in the market. Planned Release Date STC: 180 days from date of grant (notes 2, 3, 4, 5) Date: 2015-06-09 Name and signature of applicant: Zhang Xinghai Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! FCC, Request for non-disclosure Date: 10-Aug-09 RF_501, Issue 5 Page 1 of 1 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Project No.: 1505C241 Page 2 of 19 Project No.: 1505C241 Page 3 of 19 Project No.: 1505C241 Page 4 of 19 Project No.: 1505C241 Page 5 of 19 Project No.: 1505C241 Page 6 of 19 Project No.: 1505C241 Page 7 of 19 Project No.: 1505C241 Page 8 of 19 Project No.: 1505C241 Page 9 of 19 Project No.: 1505C241 Page 10 of 19 Project No.: 1505C241 Page 11 of 19

HUAWEI Y560-L23,Y560-L23 Smart Phone Secret 2015-6-30 Page1, Total1 Label and Label Location:

Project No.: 1505C241 Page 12 of 19 Project No.: 1505C241 Page 13 of 19 Project No.: 1505C241 Page 14 of 19 Project No.: 1505C241 Page 15 of 19 Project No.: 1505C241 Page 16 of 19 Project No.: 1505C241 Page 17 of 19 Project No.: 1505C241 Page 18 of 19 Project No.: 1505C241 Page 19 of 19

Report No.: BTL-FCC-SAR-1505C241 Page 1 of 117 FCC SAR Test Report FCC ID: QISY560-L23 Project No. : 1505C241 Equipment : Smart Phone Model Name : HUAWEI Y560-L23, Y560-L23 Applicant : Huawei Technologies Co., Ltd. Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen,518129, P.R.C Date of Receipt : May 22, 2015 Date of Test : May 22, 2015~ Jun. 18, 2015 Issued Date : Jun. 18, 2015 Tested by : BTL Inc. Testing Engineer : ( Super Jiang) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3,Jinshagang 1st Road, Shixia,Dalang Town, Dongguan, China. TEL: +86-769-8318-3000FAX: +86-769-8319-6000 Report No.: BTL-FCC-SAR-1505C241 Page 2 of 117 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML), or National Institute of Standards and Technology (NIST) . BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCC-SAR-1505C241 Page 3 of 117 Table of Contents Page 1 . GENERAL SUMMARY 6 2 . RF EMISSIONS MEASUREMENT 7 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 STATEMENT OF COMPLIANCE 8 3.2 GENERAL DESCRIPTION OF EUT 9 3.3 LABORATORY ENVIRONMENT 11 3.4 MAIN TEST INSTRUMENTS 12 4 .SAR MEASUREMENTS SYSTEM CONFIGURATION 13 4.1 SAR MEASUREMENT SET-UP 13 4.2 DASY5E-FIELDPROBESYSTEM 14 5 . SYSTEM VERIFICATION PROCEDURE 22 5.1 TISSUE VERIFICATION 22 5.2 SYSTEM CHECK 24 5.3 SYSTEM CHECK PROCEDURE 25 6 .SAR MEASUREMENT VARIABILITY AND UNCERTAINTY 26 6.1 SAR MEASUREMENT VARIABILITY 26 6.2 SAR MEASUREMENT UNCERTAINTY 26 7 . OPERATIONAL CONDITIONS DURING TEST 27 7.1 SAR TEST CONFIGURATION 27 7.1 .1 GSM TEST CONFIGURATION 27 7.1.2 UMTS TEST CONFIGURATION 28 7.1.3 LTE TEST CONFIGURATION 34 7.1.4 2.4G WIFI TEST CONFIGURATION 36 7.2 TEST POSITION 37 7.2.1 HEAD 37 7.2.2 BODY 37 8 .TEST RESULT 38 8.1 CONDUCTED POWER RESULTS 38 8.2 SAR TEST RESULTS 53 Report No.: BTL-FCC-SAR-1505C241 Page 4 of 117 Table of Contents Page 8.3 MULTIPLE TRANSMITTER EVALUATION 74 APPENDIX 79 1. TEST LAYOUT 79 2. SYSTEM CHECK PLOTS 81 3.SAR MEASUREMENT PLOTS 95 4. CALIBRATION CERTIFICATE 117 Report No.: BTL-FCC-SAR-1505C241 Page 5 of 117 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCC-SAR-1505C241 Original Issue. Jun. 18, 2015 Report No.: BTL-FCC-SAR-1505C241 Page 6 of 117 1. GENERAL SUMMARY Equipment Smart Phone Brand Name HUAWEI Model Name HUAWEI Y560-L23, Y560-L23 Model difference Only differ in model name. Manufacturer Huawei Technologies Co., Ltd. Address Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen,518129, P.R.C Standard(s) ANSI Std C95.1-1992Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz – 300 GHz.( IEEE Std C95.1-1991) IEEE Std 1528-2003Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques IEEE Std 1528a-2005IEEE Recommended Practice for Determining the Peak Spatial-AvSpecific Absorption Rate (SAR) in the Human Head from WirelessCommunications Devices: Measurement Techniques Amendment 1: CAD File for Human Head Model (SAM Phantom) KDB941225 D01 3G SAR Procedures v03 KDB941225 D05 SAR for LTE Devices v02r03 KDB941225 D06 Hotspot Mode V02 KDB447498 D01 General RF Exposure Guidance v05r02 KDB648474 D04 SAR Handsets Multi Xmiter and Ant v01r02 KDB248227 D01 802. 11 Wi-Fi SAR v02 KDB865664 D01 SAR measurement 100 MHz to 6 GHz v01r03 KDB865664 D02 SAR Reporting v01r01 KDB690783 D01 SAR Listings on Grants v01r03 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCC-SAR-1505C241) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCC-SAR-1505C241 Page 7 of 117 2. RF EMISSIONS MEASUREMENT 2.1 TEST FACILITY The test facilities used to collect the test data in this report is SAR room at the location of No.3,Jinshagang 1st Road, ShiXia, Dalang Town,Dong Guan, China.523792 2.2 MEASUREMENT UNCERTAINTY Note: Per KDB865664 D01 SAR Measurement 100 MHz to 6 GHz v01r03,when the highest measured 1-g SAR within a frequency band is < 1.5 W/kg, the extensive SAR measurement uncertainty analysis described in IEEE Std 1528-2003 is not required in SAR reports submitted for equipment approval. The equivalent ratio (1.5/1.6) is applied to extremity and occupational exposure conditions. Report No.: BTL-FCC-SAR-150…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-4-1505C241 Page 1 of 61 FCC Radio Test Report FCC ID: QISY560-L23 This report concerns (check one): Original Grant Class II Change Project No. : 1505C241 Equipment : Smart Phone Model Name : HUAWEI Y560-L23, Y560-L23 Applicant : Huawei Technologies Co., Ltd. Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen,518129, P.R.C Date of Receipt : May 22, 2015 Date of Test : May 22, 2015~Jun.18, 2015 Issued Date : Jun.19, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-4-1505C241 Page 2 of 61 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement b y NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-4-1505C241 Page 3 of 61 Table of Contents Page REPORT ISSUED HISTORY 5 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 . TEST RESULT 12 4.1 RADIATED RF OUTPUT POWER MEASUREMENT 12 4.1.1 LIMIT 12 4.1.2 MEASURING INSTRUMENTS AND SETTING 12 4.1.3 TEST PROCEDURE 12 4.1.4 TEST SETUP LAYOUT 13 4.1.5 TEST DEVIATION 13 4.1.6 EUT OPERATION DURING TEST 13 4.1.7 EUT TEST CONDITIONS 13 4.1.8 TEST RESULTS 13 4.2 99% OCCUPIED BANDWIDTH MEASUREMENT 14 4.2.1 LIMIT 14 4.2.2 MEASURING INSTRUMENTS AND SETTING 14 4.2.3 TEST PROCEDURE 14 4.2.4 TEST SETUP LAYOUT 14 4.2.5 TEST DEVIATION 14 4.2.6 EUT OPERATION DURING TEST 14 4.2.7 EUT TEST CONDITIONS 14 4.2.8 TEST RESULTS 15 4.3 SPURIOUS EMISSIONS AT ANTENNA TERMINALS MEASUREMENT 16 4.3.1 LIMIT 16 4.3.2 MEASURING INSTRUMENTS AND SETTING 16 4.3.3 TEST PROCEDURES 16 4.3.4 TEST SETUP LAYOUT 16 4.3.5 TEST DEVIATION 16 4.3.6 EUT OPERATION DURING TEST 16 4.3.7 EUT TEST CONDITIONS 17 Report No.: BTL-FCCP-4-1505C241 Page 4 of 61 Table of Contents Page 4.3.8 TEST RESULTS 17 4.4 SPURIOUS RADIATED EMISSIONS MEASUREMENT 18 4.4.1 LIMIT 18 4.4.2 MEASURING INSTRUMENTS AND SETTING 18 4.4.3 TEST PROCEDURES 18 4.4.4 TEST SETUP LAYOUT 19 4.4.5 TEST DEVIATION 19 4.4.6 EUT OPERATION DURING TEST 19 4.4.7 EUT TEST CONDITIONS 19 4.4.8 TEST RESULTS 19 4.5 BAND EDGE MEASUREMENT 20 4.5.1 LIMIT 20 4.5.2 MEASURING INSTRUMENTS AND SETTING 20 4.5.3 TEST PROCEDURES 20 4.5.4 TEST SETUP LAYOUT 20 4.5.5 TEST DEVIATION 20 4.5.6 EUT OPERATION DURING TEST 20 4.5.7 EUT TEST CONDITIONS 20 4.5.8 TEST RESULTS 21 4.6 FREQUENCY STABILITY MEASUREMENT 22 4.6.1 LIMIT 22 4.6.2 MEASURING INSTRUMENTS AND SETTING 22 4.6.3 TEST PROCEDURES 22 4.6.4 TEST SETUP LAYOUT 22 4.6.5 TEST DEVIATION 22 4.6.6 EUT OPERATION DURING TEST 22 4.6.7 EUT TEST CONDITIONS 23 4.6.8 TEST RESULTS 23 5. LIST OF MEASUREMENT EQUIPMENTS 24 ATTACHMENT A - RADIATED RF OUTPUT POWER 26 ATTACHMENT B - 99% OCCUPIED BANDWIDTH 28 ATTACHMENT C - SPURIOUS EMISSIONS AT ANTENNA TERMINALS 35 ATTACHMENT D - SPURIOUS RADIATED EMISSION 38 ATTACHMENT E - BAND EDGE 55 ATTACHMENT F - FREQUENCY STABILITY 59 Report No.: BTL-FCCP-4-1505C241 Page 5 of 61 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-4-1505C241 Original Issue. Jun.19, 2015 Report No.: BTL-FCCP-4-1505C241 Page 6 of 61 1. CERTIFICATION Equipment : Smart Phone Brand Name : HUAWEI Model Name : HUAWEI Y560-L23, Y560-L23 Applicant : Huawei Technologies Co., Ltd. Manufacturer : Huawei Technologies Co., Ltd Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen,518129, P.R.C Date of Test : May 22, 2015~Jun.18, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : 47 CFR FCC Part 22 Subpart H & ANSI/ C63.4 : 2009 47 CFR FCC Part 2 & ANSI/TIA-603-C-2004 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-4-1505C241) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Test result included in this report is only for the GSM 850MHz approval part of the product. Report No.: BTL-FCCP-4-1505C241 Page 7 of 61 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part 22 Subpart H &…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-8-1505C241 Page 1 of 52 FCC Radio Test Report FCC ID: QISY560-L23 This report concerns (check one): Original Grant Class II Change Project No. : 1505C241 Equipment : Smart Phone Model Name : HUAWEI Y560-L23, Y560-L23 Applicant : Huawei Technologies Co., Ltd. Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen,518129, P.R.C Date of Receipt : May 22, 2015 Date of Test : May 22, 2015~Jun.18, 2015 Issued Date : Jun.19, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-8-1505C241 Page 2 of 52 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement b y NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-8-1505C241 Page 3 of 52 Table of Contents Page REPORT ISSUED HISTORY 5 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 . TEST RESULT 12 4.1 RADIATED RF OUTPUT POWER MEASUREMENT 12 4.1.1 LIMIT 12 4.1.2 MEASURING INSTRUMENTS AND SETTING 12 4.1.3 TEST PROCEDURE 12 4.1.4 TEST SETUP LAYOUT 13 4.1.5 TEST DEVIATION 13 4.1.6 EUT OPERATION DURING TEST 13 4.1.7 EUT TEST CONDITIONS 13 4.1.8 TEST RESULTS 13 4.2 99% OCCUPIED BANDWIDTH MEASUREMENT 14 4.2.1 LIMIT 14 4.2.2 MEASURING INSTRUMENTS AND SETTING 14 4.2.3 TEST PROCEDURE 14 4.2.4 TEST SETUP LAYOUT 14 4.2.5 TEST DEVIATION 14 4.2.6 EUT OPERATION DURING TEST 14 4.2.7 EUT TEST CONDITIONS 14 4.2.8 TEST RESULTS 15 4.3 SPURIOUS EMISSIONS AT ANTENNA TERMINALS MEASUREMENT 16 4.3.1 LIMIT 16 4.3.2 MEASURING INSTRUMENTS AND SETTING 16 4.3.3 TEST PROCEDURES 16 4.3.4 TEST SETUP LAYOUT 16 4.3.5 TEST DEVIATION 16 4.3.6 EUT OPERATION DURING TEST 16 4.3.7 EUT TEST CONDITIONS 17 Report No.: BTL-FCCP-8-1505C241 Page 4 of 52 Table of Contents Page 4.3.8 TEST RESULTS 17 4.4 SPURIOUS RADIATED EMISSIONS MEASUREMENT 18 4.4.1 LIMIT 18 4.4.2 MEASURING INSTRUMENTS AND SETTING 18 4.4.3 TEST PROCEDURES 18 4.4.4 TEST SETUP LAYOUT 19 4.4.5 TEST DEVIATION 19 4.4.6 EUT OPERATION DURING TEST 19 4.4.7 EUT TEST CONDITIONS 19 4.4.8 TEST RESULTS 19 4.5 BAND EDGE MEASUREMENT 20 4.5.1 LIMIT 20 4.5.2 MEASURING INSTRUMENTS AND SETTING 20 4.5.3 TEST PROCEDURES 20 4.5.4 TEST SETUP LAYOUT 20 4.5.5 TEST DEVIATION 20 4.5.6 EUT OPERATION DURING TEST 20 4.5.7 EUT TEST CONDITIONS 20 4.5.8 TEST RESULTS 21 4.6 FREQUENCY STABILITY MEASUREMENT 22 4.6.1 LIMIT 22 4.6.2 MEASURING INSTRUMENTS AND SETTING 22 4.6.3 TEST PROCEDURES 22 4.6.4 TEST SETUP LAYOUT 22 4.6.5 TEST DEVIATION 22 4.6.6 EUT OPERATION DURING TEST 22 4.6.7 EUT TEST CONDITIONS 23 4.6.8 TEST RESULTS 23 5. LIST OF MEASUREMENT EQUIPMENTS 24 ATTACHMENT A - RADIATED RF OUTPUT POWER 26 ATTACHMENT B - 99% OCCUPIED BANDWIDTH 28 ATTACHMENT C - SPURIOUS EMISSIONS AT ANTENNA TERMINALS 35 ATTACHMENT D - SPURIOUS RADIATED EMISSION 38 ATTACHMENT E - BAND EDGE 47 ATTACHMENT F - FREQUENCY STABILITY 51 Report No.: BTL-FCCP-8-1505C241 Page 5 of 52 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-8-1505C241 Original Issue. Jun.19, 2015 Report No.: BTL-FCCP-8-1505C241 Page 6 of 52 1. CERTIFICATION Equipment : Smart Phone Brand Name : HUAWEI Model Name : HUAWEI Y560-L23, Y560-L23 Applicant : Huawei Technologies Co., Ltd. Manufacturer : Huawei Technologies Co., Ltd Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen,518129, P.R.C Date of Test : May 22, 2015~Jun.18, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : 47 CFR FCC Part 22 Subpart H & ANSI/ C63.4 : 2009 47 CFR FCC Part 2 & ANSI/TIA-603-C-2004 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-8-1505C241) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Test result included in this report is only for the WCDMA Band V approval part of the product. Report No.: BTL-FCCP-8-1505C241 Page 7 of 52 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part 22 Subpart H…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-5-1505C241 Page 1 of 6 5 FCC Radio Test Report FCC ID: QISY560-L23 This report concerns (check one): Original Grant Class II Change Project No. : 1505C241 Equipment : Smart Phone Model Name : HUAWEI Y560-L23, Y560-L23 Applicant : Huawei Technologies Co., Ltd. Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen,518129, P.R.C Date of Receipt : May 22, 2015 Date of Test : May 22, 2015~Jun.18, 2015 Issued Date : Jun.19, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-5-1505C241 Page 2 of 6 5 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement b y NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedure…

Text truncated - open the document above for the full version.
