QISY625-U13UMTS Mobile Phone

Quick Start Guide Y625 1 Getting to know your phone Thank you for choosing the HUAWEI smartphone. First, let's take a look at a few basics. Press and hold the power button to power on your phone. After your phone is powered up, you can use the power button to turn the screen off and on. 2 Preparing your phone To i ns ert a micro SIM card, the battery and a microSD card, please perform the few steps shown in the following figures. Your phone is shipped with the battery partially charged. It is recommended that you fully charge the battery before using it for the first time. 3 Locking and unlocking the screen When you are not using your phone, press the power button to turn off the screen. After being idle for a specified period of time, your phone locks its screen automatically. Follow the onscreen instructions and slide to unlock the screen or open an application. 4 Managing contacts On the home screen, touch to open People. Touch the Contacts tab page to group your contacts for easier management. 5 Making a call On the home screen, touch to open the dialer. You can dial a phone number directly. You can also touch a phone number in places like messages, email and webpages to make a call. To answer an incoming call, drag to. 6 Sending messages On the home screen, touch to open Messaging. Adding a photo or audio clip to a text message turns it into a multimedia message. You can also save attachments from multimedia messages. 7 Taking a photo or video On the home screen, touch to open Camera. Touch to take a photo. Frame the scene and touch to record a video. When the screen is turned off, double-press the volume down button to take a snapshot. 8 Listening to music On the home screen, touch to open Music. You can copy songs to your phone and immerse yourself with extraordinary audio experience anytime. You can also mark your songs to add them to the playlist. 9 Surfing the web On the home screen, touch to open Browser. You can start surfing the web right away using your phone's browser and stay on ball with up-to-date news and information. Your browser supports multi-page browsing. Touch to switch between pages. 10 Magic Touch On the home screen, touch > to enable the Magic To u c h function. When the screen is turned off, you can double-touch the screen to wake it up, or slide your finger to different directions to open specified applications. 11 For more help Want to obtain the user guide? Search for and download the User Guide from http://consumer.huawei.com/en/. Please visit http://consumer.huawei.com/en/support/hotline/ for recently updated hotline and email address in your country or region. Personal information and data security The use of some functions or third-party applications on your device could result in your personal information and data being lost or becoming accessible to others. Several measures are recommended to help you protect personal and confidential information.  Place your device in a safe area to prevent it from unauthorized use.  Set your device screen to lock and create a password or unlock pattern to open it.  Periodically back up personal information kept on your USIM card, memory card, or stored in your device memory. If you change to a different device, be sure to move or delete any personal information on your old device.  If you are worried about viruses when you receive messages or emails from a stranger, you can delete them without opening them.  If you use your device to browse the Internet, avoid websites that might pose a security risk to avoid theft of your personal information.  If you use services such as Wi-Fi tether or Bluetooth, set passwords for these services to prevent unauthorized access. When these services are not in use, turn them off.  Install or upgrade device security software and regularly scan for viruses. 12  Be sure to obtain third-party applications from a legitimate source. Downloaded third-party applications should be scanned for viruses.  Install security software or patches released by Huawei or third-party application providers.  Some applications require and transmit location information. As a result, a third-party may be able to share your location information.  Your device may provide detection and diagnostic information to third-party application providers. Third party vendors use this information to improve their products and services.  If you have concerns about the security of your personal information and data, please contact [email protected]. Legal notice Copyright © Huawei Technologies Co., Ltd. 2015. All rights reserved. Trademarks and permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Android™ is a trademark of Google Inc. The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Huawei Technologies Co., Ltd. is under license. Other trademarks, product, service and company names mentioned may be the property of their respective owners. Third-Party software statement Huawei does not own the intellectual property of the third-party software and applications that are delivered with this product. Therefore, Huawei will not provide any warranty of any kind for third party software and applications. Neither will Huawei provide support to customers who use third-party 13 software and applications, nor be responsible or liable for the functions or performance of third-party software and applications. Third-party software and applications services may be interrupted or terminated at any time, and Huawei does not guarantee the availability of any content or service. Third-party service providers provide content and services through network or transmission tools outside of the control of Huawei. To the greatest extent permitted by applicable law, it is explicitly stated that Huawei shall not compensate or be liable for services provided by third-party service providers, or the interruption or termination of t…

Text truncated - open the document above for the full version.

文档名称 文档密级 2014-10-22 华为保密信息,未经授权禁止扩散 第1页, 共1页 To whom it may concern, Letter of Agency I, an officer of HUAWEI TECHNOLOGIES CO.,LTD do hereby authorize Intertek Testing Services (Mr. Shawn Xing) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 22/24 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2007) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Zhang xinghai EMC Laboratory Manager

Huawei Technologies Co.,Ltd. Federal Communications Commission 2014-08-05 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. QISY625-U13 2015-4-30: Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C E- mail: [email protected] Tel: 0086-0755-28970299 Fax: 0086-0755-89650226

文档名称 文档密级 2014-10-22 华为保密信息,未经授权禁止扩散 第1页, 共1页 Declaration Manufacturer/Application:Huawei Technologies Co.,Ltd FCC ID: I declare that the shielded USB cable used in the test will be marketed with the EUT. Yours sincerely, Product Manager: Email: [email protected] QISY625-U13

OR Label Size: 40mm x 75mm

Date: 10/22/2014 To whom it may concern, Label Location Justification FCC ID: QISY625-U13 Request is hereby submitted by Huawei Technologies Co., Ltd. to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925 (f) of the FCC Rules. The FCC identifier for HUAWEI Y625-U13, Y625-U13 will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches: * Marketing the device without the battery installed, or * Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Sincerely, For and Behalf of: HUAWEI Technologies Co, Ltd. Zhang Xinghai EMC Laboratory Manager

Report No.: RXA1411-0268SAR01R3 Page 1 of 208 TESTING No. L2264 SAR TEST REPORT Product Name UMTS Mobile Phone Model Name HUAWEI Y625-U13, Y625-U13 Brand Name HUAWEI FCC ID QISY625-U13 Applicant Huawei Technologies Co., Ltd. Manufacturer Huawei Technologies Co., Ltd. Date of issue January 19, 2015 TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1411-0268SAR01R3 Page 2 of 208 GENERAL SUMMARY Reference Standard(s) FCC 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices ANSI C95.1, 1992: Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz.(IEEE Std C95.1-1991) IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01r03: SAR Measurement Requirements for 100 MHz to 6 GHz KDB 447498 D01 Mobile Portable RF Exposure v05r02: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB 648474 D04 Handset SAR v01r02: SAR Evaluation Considerations for Wireless Handsets. KDB 941225 D01 SAR test for 3G devices v03: SAR Measurement Procedures CDMA 20001x RTT, 1x Ev-Do, WCDMA, HSDPA/HSPA KDB 941225 D06 Hotspot Mode SAR v02: SAR Evaluation Procedures for Portable Devices with Wireless Router Capabilities KDB 248227 D01 SAR meas for 802 11 a b g v01r02: SAR Measurement Procedures for 802.11a/b/g Transmitters. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards for the tested bands only. General Judgment: Pass Comment The test result only responds to the measured sample. Approved by Kai Xu Director Revised by Jiangpeng Lan SAR Manager Performed by JIan Qi SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1411-0268SAR01R3 Page 3 of 208 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the Test Report ....................................................................................................... 5 1.2. Testing Laboratory ................................................................................................................ 5 1.3. Applicant Information ............................................................................................................ 6 1.4. Manufacturer Information ...................................................................................................... 6 1.5. Information of EUT ................................................................................................................ 7 1.6. EUT Antenna Locations ........................................................................................................ 9 1.7. The Maximum Reported SAR 1g .......................................................................................... 10 1.8. Test Date ............................................................................................................................ 11 2. SAR Measurements System Configuration ................................................................................ 12 2.1. SAR Measurement Set-up .................................................................................................. 12 2.2. DASY5 E-field Probe System ............................................................................................. 13 2.2.1. EX3DV4 Probe Specification ....................................................................................... 13 2.2.2. E-field Probe Calibration .............................................................................................. 14 2.3. Other Test Equipment ......................................................................................................... 14 2.3.1. Device Holder for Transmitters .................................................................................... 14 2.3.2. Phantom ...................................................................................................................... 15 2.4. Scanning Procedure ........................................................................................................... 15 2.5. Data Storage and Evaluation .............................................................................................. 17 2.5.1. Data Storage ................................................................................................................ 17 2.5.2. Data Evaluation by SEMCAD ...................................................................................... 17 3. Laboratory Environment ............................................................................................................. 19 4. Tissue-equivalent Liquid ............................................................................................................ 20 4.1. Tissue-equivalent Liquid Ingredients ................................................................................... 20 4.2. Tissue-equivalent Liquid Properties .................................................................................... 22 5. Sy stem Check ............................................................................................................................ 23 5.1. Description of System Check .............................................................................................. 23 5.2. System Check Results ........................................................................................................ 24 6. Operational Conditions during Test ............................................................................................ 26 6.1. General Description of …

Text truncated - open the document above for the full version.

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. TRF No.: FCC 15C_TX_b Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Website: www.china.intertek-etlsemko.com Huawei Technologies Co., Ltd A p p l ication For Certification FCC ID: QISY625-U13 UMTS Mobile Phone Models: HUAWEI Y625-U13, Y625-U13 Report No.: 141112039SZN-001 2.4GHz Transceiver We h ereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-13] Prepared and Checked by: Approved by: S ign on file Hardy Suo Assistant Engineer Andy Yan S enior Project Engineer Da te: December 03, 2014 INTERTEK TESTING SERVICES TRF No.: FCC 15C_TX_b FCC ID: QISY625-U13 Report No.: 141112039SZN-001 i L I S T OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information EXHIBIT 9: Confidentiality request EXH IBIT10: Test Equipment List INTERTEK TESTING SERVICES TRF No.: FCC 15C_TX_b FCC ID: QISY625-U13 Report No.: 141112039SZN-001 ii MEASUREMENT/TECHNICAL REPORT H u a wei Technologies Co.,Ltd Model: HUAWEI Y625-U13, Y625-U13 FCC ID: QISY625-U13 This report concerns (check one:) Original Grant X Class II Change Equipment Type: DSS - Part 15 Spread Spectrum Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator − the new 47 CFR [10-1-13 Edition] provision. Report prepared by: Hardy Suo Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, Block D, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Phone: (86 755) 8614 0743 Fax: (86 755) 8601 6751 INTERTEK TESTING SERVICES TRF No.: FCC 15C_TX_b FCC ID: QISY625-U13 Report No.: 141112039SZN-001 iii Table of Contents 1.0 G eneral Description ............................................................................................ 2 1.1 Product Description ............................................................................................ 2 1.2 Related Submittal(s) Grants.....................................................................2 1.3 Test Methodology ............................................................................................... 2 1.4 Test Facility ........................................................................................................ 3 2.0 System Test Configuration ................................................................................. 5 2.1 Justification ........................................................................................................ 5 2.2 EUT Exercising Software .................................................................................... 5 2.3 Special Accessories ........................................................................................... 5 2.4 Equipment Modification ...................................................................................... 6 2.5 Measurement Uncertainty .................................................................................. 6 2.6 Support Equipment List and Description ............................................................. 6 3.0 Test Results ......................................................................................................... 8 3.1 Radiated Test Result .......................................................................................... 9 3.1.1 Field Strength Calculation ................................................................................ 9 3.1.2 Radiated Emission Configuration Photograph ................................................ 10 3.1.3 Radiated Emissions ....................................................................................... 10 3.1.4 Transimitter Spurious Emissions (Radiated) .................................................. 12 3.2 Conducted Emissions at Mains Termial ............................................................ 16 3.2.1 Conducted Emissions Configuration Photograph ........................................... 16 3.2.2 Conducted Emissions .................................................................................. 16 3.3 Peak Power ......................................................................…
