QLN-VA2410A802.11 b/g Outdoor Microcell

1Copyright © 2005, Vivato, Inc. VA2410 802.11b/g Outdoor Microcell User Guide Manual P/N: 770-01376-01 Release 3.0 August 29, 2005 ® Copyright © 2005, Vivato, Inc.2 Copyright © 2005, Vivato, Inc. All rights reserved. No part of this document may be reproduced in any form or by any means, electronic or mechanical, including photocopying, recording, or by any information storage and retrieval system, without written permission from Vivato, Inc. “Vivato” is a U.S. registered trademark of Vivato, Inc. The content of this manual is furnished for informational use only, and is subject to change without notice. Vivato, Inc. assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Documentation Updates The most current documentation and firmware for this Vivato product is available on the Vivato Customer Support website. See “Contact Information” on page 14. VA2410 802.11b/g Outdoor Microcell User Guide 3 Copyright © 2005, Vivato, Inc. VIVATO, INC. END USER LIMITED WARRANTY AND LICENSE TERMS Limited Warranty Vivato, Inc. ("Vivato") warrants that the hardware of the Vivato products ("Product") will be free from defects in material and workmanship under normal use for a period of one (1) year (i) if purchased directly from Vivato, from the date of shipment by Vivato to End User, or (ii) if purchased from a Vivato authorized reseller ("Reseller"), from the date of shipment by Reseller to End User. Vivato warrants that the media upon which software (“Software”) is provided will be free from defects in material and workmanship under normal use for a period of ninety (90) days (i) if purchased directly from Vivato, from the date of shipment by Vivato to End User, or (ii) if purchased from a Reseller, from the date of shipment by Reseller to End User. Except for the forgoing, the Software is provided "AS IS" with all faults and without warranty of any kind. This limited warranty extends only to the End User who is the original purchaser of the Product and licensee of the Software and may not be transferred to any other party. The date of original shipment of Product and Software shall be determined by the information on file at Vivato regarding End User in accordance with Vivato's then current procedures. REMEDY End User's sole and exclusive remedy, and Vivato's entire liability under this Limited Warranty in the event that Product or Software does not perform as warranted above, will be, at Vivato's or its service center's option, to repair or replace such Product or Software or to refund the purchase price paid for such Product or Software. Vivato's obligations hereunder are conditioned upon the return, freight pre-paid of the alleged affected Product or Software in accordance with Vivato's or its service centers then current Return Material Authorizations ("RMA") procedure. All warranty claims shall be directed to Vivato’s technical assistance center as designated by Vivato’s web site (www.vivato.net). Vivato or its authorized repair center shall have the right to inspect the Product or Software claimed as not performing as warranted. This warranty is conditioned upon receipt by Vivato of notice of any alleged covered manufacturing defect in material or workmanship within thirty (30) days after discovery, subject to the warranty period. In no event shall Vivato be responsible for any costs associated with the removal (or re-installation) of Product or Software from (or into) items into which such Product or Software have been integrated by Buyer (or other third parties), or costs associated with other products into which the Product or Software may have been integrated or used. After receiving an RMA for Product or Software, End User shall ship such Product, Software or component thereof, clearly identifying it with its RMA, to Vivato’s designated repair facility in its original shipping cartons or equivalent, freight prepaid. Damage to Product or Software that occurs during return shipment will not be covered by this warranty. Upon receipt of the Product or Software returned in accordance with Vivato's then current RMA procedure, Vivato, at its option, shall (i) repair or replace such Product, Software or component thereof with equivalent or better, new or refurbished Product, Software or parts, and shall return the repaired or replaced Product or Software to End User freight prepaid by Vivato, or (ii) refund the purchase price of such Product or Software. The remainder of the original warranty coverage shall apply to such repaired or replacement Product or Software. LIMITATIONS OF WARRANTY This warranty does not apply to Product or Software which fails to perform as warranted due to: (a) improper handling, installation, removal, repair, maintenance, abuse or improper use; (b) damage caused by vandalism, severe weather, lightning, chemical hazards, fire, contact with high-voltage power lines or other electrical stress; (c) repairs, modifications, or any alterations performed or attempted by End User or any third party, unless authorized by Vivato as stated below; (d) use in conjunction with equipment which is not compatible with Product or Software; (e) documentation errors; (f) software errors; or (g) Product or Software provided to End User for evaluation, testing, demonstration or other purposes for which Vivato does not receive payment of purchase price or license fee. VA2410 802.11b/g Outdoor Microcell User Guide Copyright © 2005, Vivato, Inc.4 Vivato does not warrant or accept any responsibility for Product or Software, which has been repaired or altered by anyone other than Vivato, or a Vivato authorized service center. In the event of any such unauthorized repairs or alterations, this warranty shall become void. No agent, distributor, Reseller or representative is authorized to make any warranties or to assume any liabilities on behalf of Vivato. Vivato shall make the final determination as to the existence and cause of any alleged defect of Prod…

Text truncated - open the document above for the full version.

Copyright © 2004-2005, Vivato, Inc.VA2210/2410 Installation1 VA2210/2410 802.11 Outdoor Microcell Installation Supplement P/N 720-01777-03 Supplement to the VA2200 and VA2410 User Guides. Please refer to the User Guide on the product’s CD-ROM for information on configuring that Microcell. ® 2VA2210/2410 InstallationCopyright © 2004-2005, Vivato, Inc. Copyright © 2004-2005, Vivato, Inc. All rights reserved. No part of this document may be reproduced in any form or by any means, electronic or mechanical, including photocopying, recording, or by any information storage and retrieval system, without written permission from Vivato, Inc. “Vivato” is a U.S. registered trademark of Vivato, Inc. The content of this manual is furnished for informational use only, and is subject to change without notice. Vivato, Inc. assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Copyright © 2004-2005, Vivato, Inc.VA2210/2410 Installation3 Safety Information You must heed any and all safety precautions and warnings in this document or indicated on the Vivato Outdoor Microcell whenever you are operating or servicing this product. Failure to comply with all precautions and warnings found in this document violates the design, manufacture, and intended use requirements of the product. Vivato, Inc. assumes no liability for the operator’s failure to obey these warnings and cautions. The person installing the Vivato Outdoor Microcell must be qualified by Vivato, Inc. or by a Vivato authorized reseller. This product must only be serviced by qualified Vivato personnel or its certified agent. Power Supply: The Microcell includes a pre-installed direct current (DC) power supply. Do not attempt to use a substitute power supply unless it has been approved by Vivato for use with this product. Do not operate this product in an explosive atmosphere or in the presence of flammable gases or fumes, or in the presence of unshielded blasting caps. To protect against fire, replace any fuses in the product with those of the same voltage, current rating, and type. Never short-circuit fuse holders or use modified fuses. Keep away from energized circuits. Only qualified Vivato service personnel or its certified agent may remove the outer covers of the product. Hazardous voltages may be present any time a cover is removed, even if the product is not turned on. Do not operate this product if damage is indicated. Refer servicing or repair to qualified Vivato personnel or its certified agent. Do not service or adjust this product by yourself. It is recommended that someone else is present who can render first aid in the event that electrical shock or other injury occurs. Do not substitute any parts or modify the product. Any unauthorized changes to the product could result in compromising the safety features or the correct operation of the product. Refer any service or repair to authorized Vivato personnel or its certified agent. Maintenance There are no user serviceable components or adjustments in Vivato equipment. The normal course of care and maintenance for electrical equipment should be followed for all Vivato equipment. The following should be performed on a semi-annual basis: 1. Inspection of housing for signs of external damage, such as a torn radome, dented or breached housing, or other external damage. 2. Inspection of mounting hardware for missing fasteners, loose fasteners, excessive corrosion, or changes in mounting orientation. 3. Inspection of ventilation holes for blockage. 4VA2210/2410 InstallationCopyright © 2004-2005, Vivato, Inc. 4. Inspection of cables for proper stress/strain relief and drip loop (if required). 5. Inspection of cables for any signs of fraying, wear, or damage. Any of the above conditions could lead to failure or reduced performance and should be rectified as soon as possible. Operation With Antennas Not Included With The Microcell The antennas listed in the following table have been tested with the Vivato Outdoor Microcells and comply with FCC Part 15 rules. FCC Part 15, paragraph 15.204 (c) 4, addresses the use of other antennas than those specifically used during compliance testing of the Microcell. Generally stated, antennas of the same type (omni, Yagi, patch) and of the same or lower gain for that type of approved antenna may be substituted in place of those used during compliance testing. Please refer to that FCC document for the full text of the ruling. Antenna connections on the Microcell are RP-TNC (f) jacks. Therefore, antenna leads must be terminated with an RP-TNC (m) plug connector. Be sure to specify this type of connector when ordering antennas and any extension cables and adapters that may be needed to reach from the antenna’s mounting point to the connectors on the bottom of the electrical enclosure. See Figure 6— Example Antenna Mounting on page 16. Table 1— Tested Antennas PatternGain (dBi) Polarization Omni11Vertical Omni8.5Horizontal Panel8.5Horizontal/Vertical Ya g i10Horizontal/Vertical Copyright © 2004-2005, Vivato, Inc.VA2210/2410 Installation5 Conventions Used in This Document The following conventions are used in this document: Contact Information For customer support: For technical support, contact your Vivato reseller or visit the Vivato Customer Support website. Go to www.vivato.net and select the Customer Support link. Enter the required information for setting up a user account. A support password is e-mailed to you (typically within one business day) after validating the information, . You can then search the online knowledge base for information by clicking on “Find Answers / Questions”. You can also access the latest firmware downloads and user documents from the support site. To provide feedback on our documentation: Feedback on the documentation shipped with the Vivato Microcell is greatly appreciated, and will always be reviewed by our Technical Publications department. Please send your suggestions to manuals_feed…

Text truncated - open the document above for the full version.

Date: 9/9/2005 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Testing Division of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS on our behalf shall have the same effect as acts of our own. In authorizing CCS Testing Division as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jeffrey Gilbert RF Test Engineer Vivato, Inc.

8/15/2005 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: The following information is to be held confidential pursuant of 47 CFR Part 0 §0.457 and Section 552(b) (4) of the Freedom of Information Act, because the information provided contains trade secrets and proprietary information. If made public, the information might be used to the disadvantage of the applicant in the market place. • Block Diagrams • Schematics • Technical Product Description Sincerely, Jeff Gilbert RF Test Engineer Vivato, Inc.

PROPOSED FCC ID LABEL AND LOCATION VIVATO, INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: QLN-VA2410A FCC ID LABEL LOCATION

Figure 1 - Digital Board Bottom Figure 2 - Digital Board Top Figure 3 - Heat Sink & Filter Left Figure 4 - Heat Sink & Filter Right Figure 5 - Digital Board with Radios, Heat Sink, & Filters Figure 6 - Radio Top Figure 7 - Radio Bottom Figure 8 - Heater Resistors Figure 9 - Data Surge Board Bottom Figure 10 - Data Surge Board Top

2.4 GHz ISM Enclosed Yagi Antenna Series The MYP directional yagis can be used as bridge antennas between two networks or for point-to-point communications. They are field adjustable for vertical or horizontal polarization with matched principal plane beamwidths for optimum performance in either orientation. This design also provides improved front-to-back ratio and sidelobe suppression that reduces interference. All models feature a robust mounting structure for consistent performance regardless of weather conditions. General Specifications: 2.4 GHz ISM enclosed yagi antenna series Polarization: Vertical or horizontal, linear (user adjustable) Nominal Impedance: 50 Ohms Mounting Method: Heavy duty yagi mounting bracket (included) permits mast mounting on masts up to 2” O.D. MYK18 adjustable wall/pipe mount allows 180°(included angle) azimuth and elevation adjustment (sold separately.) Stacking harnesses available to stack two yagis (sold separately.) Termination: N, female is standard Consult factory for other connector options Features and Benefits: •Field adjustable to allow vertical or horizontal polarity. Eliminates co-channel interference from neighboring radiators. Polarity markings molded on the antenna ensure installation in the correct orientation. •Optional, articulating mount. Allows precise adjustment of the antenna both vertically and horizontally. •All antennas include a robust mast mount bracket designed to withstand 125 mph wind. •Matched principal plane beamwidths with excellent sidelobe suppression and cross-polarization rejection of more than 20 dB. Provides superior signal quality with enhanced gain performance and minimal interference from neighboring radiators. •30 dB front-to-back ratio permits less physical separation on the tower thus adding mounting flexibility at installation sites where space is limited. •Attractive weather-proof radome constructed of UV resistant material. Provides robust and trouble-free use in harsh outdoor environments. XtremeWave™ MYP Series The MYP24015PT (above) provides 15 dBi of gain and covers frequencies between 2400 and 2485 MHz. A broadband version (model MYPB24015PT) covering frequencies from 2400 - 2686 MHz is also available. The MYP24010PT (below) provides 10 dBi gain and 23 dB front-to-back in a very compact radome. The MYK18 adjustable azimuth and elevation mounting bracket is optional with all yagis in this series. 235 PCTEL Antenna Products Group, Inc. ORDER (800) 323-9122 http://www.maxrad.com MYK18 Mechanical Specifications Electrical Specifications 236 PCTEL Antenna Products Group, Inc. ORDER (800) 323-9122 http://www.maxrad.com Specifications Model # Wind Survival Lateral Thrust at Rated Wind Equivalent Flat Plate Area CableLengthWeight MYP24010PT125 mph5.8 lbs 0.060 ft 2 3’ (914.4 mm) coax4.5” L x 3” OD (114 mm L x 76 mm OD)1 lb (0.5 kg) MYP24014PT125 mph18.3 lbs 0.20 ft 2 36” (914 mm) coax14” x 3” OD (356 mm L x 76 mm OD)1 lb (0.5 kg) MYP24015PT125 mph18.3 lbs 0.20 ft 2 18” (457 mm) coax14” x 3” OD (356 mm L x 76 mm OD)1 lb (0.5 kg) MYPB24015PT125 mph18.3 lbs 0.20 ft 2 12” (305 mm) LMR19514” x 3” OD (356 mm L x 76 mm OD)1 lb (0.5 kg) Model #Frequency RangeVSWR Front-to- Back RatioNominal Gain Vertical Beamwidth @ 1/2 Power Horizontal Beamwidth @ 1/2 Power MYP24010PT2400-2485 MHz< 1.5:123 dB10 dBi55°55° MYP24014PT2400-2485 MHz< 1.5:130 dB14 dBi30°30° MYP24015PT2400-2485 MHz< 1.5:130 dB15 dBi30°30° MYPB24015PT2400-2686 MHz< 1.5:130 dB15 dBi30°30° Model #Description MSK2450MNStacking harness for two 2.4 GHz MYP directional yagis. N male connector. MSK2450MSMAStacking harness for two 2.4 GHz MYP directional yagis. Male SMA connector. Accessories Maximum Power 5 Watts 5 Watts 5 Watts 5 Watts 237 PCTEL Antenna Products Group, Inc. ORDER (800) 323-9122 http://www.maxrad.com MYP24015PT Elevation Cut MYP24015PT Azimuth Cut Patterns 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 2020 1515 1010 5500551 010 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 2020 1515 1010 5500551 010 MYPB24015PT Elevation Cut MYPB24015PT Azimuth Cut Patterns 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 2020 1515 1010 5500551 010 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 2020 1515 1010 5500551 010 238 PCTEL Antenna Products Group, Inc. ORDER (800) 323-9122 http://www.maxrad.com Patterns 239 PCTEL Antenna Products Group, Inc. ORDER (800) 323-9122 http://www.maxrad.com MYP24014PT Elevation Cut MYP24014PT Azimuth Cut 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 2020 1515 1010 5500551 010 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 2020 1515 1010 5500551 010 MYP24010PT Elevation Cut MYP24010PT Azimuth Cut 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 3535 3030 2525 2020 1515 1010 55 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 3535 3030 2525 2020 1515 1010 55 Patterns 240 PCTEL Antenna Products Group, Inc. ORDER (800) 323-9122 http://www.maxrad.com

2.4GHz 8.5dBi Horizontal Polarized Omni-directional antennahttp://www.superpass.com/SPHSG6O.html 1 of 29/12/2005 9:05 AM Home Overview Products/Price OEM Design News Release Contact us 2.4GHz 8.5dBi Horizontal Polarized Omni-directional antenna SPHSG6OSPHSG6OP Technical Specifications NoITEMTYPICALREMARKS 1Frequency Range 2400  2483 MHz 2Impedance 50 Ω 3VSWR (or Return Loss) < 1.5:1 ( or > 14dB) 4Gain>8.5dBi 5PolarizationHorizontal, Linear 6X-Pol<-20dB 73dB Horizontal Beamwidth 360 Degrees 83dB Vertical Beamwidth 12 Degrees 9Max. Power Input20W 10 ConnectorN female, Bottom FeedOr Custom Design 11 AppearancePipe Type 12 Size 36 x2 [inch] 14 Radom MaterialPVC 15 Radom ColorGray 16 Case DesignWater Resistance 17 Weight3 Lb 18 Wind Loading (Frontal) > 12Kg200km/h 2.4GHz 8.5dBi Horizontal Polarized Omni-directional antennahttp://www.superpass.com/SPHSG6O.html 2 of 29/12/2005 9:05 AM 19 Temperature Range-45 to +75 Degrees 20 Storage Temperature-30 to +75 Degrees 21 Lighting ProtectionDirect Grounding 22 Mounting HardwareClamp Set 23 Life Expectancy20 years

An ISO-9001:2000 Registered Company XtremeWave MFB Series XtremeWave Models 25007 (MMDS), MFB58009 (5.8 GHz ISM) and MFB19008A (PCS), MFB24006 and MFB24008 (2.4 GHz ISM) Antennas XtremeWave MFB24011 General Specifications: Radome Material: UV resistant pultruded fiberglass Polarization: Vertical Lightning Protection: Not standard, but all models can be ordered with DC grounding. Add a “DC” suffix to the part number to choose the DC grounded version of the antenna. Nominal Impedance: 50 Ohms Mounting Base Diameter: 1.25 inches (all models except MFB24011) 1.5 inches (model MFB24011) Mounting Method (sold separately): MMK1924 – L-bracket mount for wall or pipe mount (all models, except MFB24010 and MFB24011) MMK8 - Aluminum extruded bracket for mast mounting (all models, except model MFB24011) MMK11 - Ceiling mount bracket (for MFB24004, MFB24006 and MFB24008 only) MMK12 - Heavy duty bracket for mast mounting the MFB24011 MMK14 - Light duty mounting clamp for MFB24011 Termination: N female standard with all models, except MFB24011 and MFB58009PTNM N female, reverse polarity and reverse threaded connectors optional 16” RG-213 pigtail with N female connector for model MFB24011 only 5’ LMR400 pigtail with N male connector for model MFB58009PTNM only N male connector option available with models MFB58009, MFB24010, MFB24008, MFB24006 and MFB19008. To order, add “NM” to part number. Features and Benefits: •UV stable, pultruded fiberglass radome. Allows outdoor installation even in harsh climates. Vented system design. Provides reliable performance by protecting the electrical design against extreme moisture and/or tempera- tures. •Thread relief on connector (all models, except MFB24011 and MFB58009PTNM which have pigtails). Improved accessibility for taping reduces installation time and improves overall effectiveness. •Internal o-ring seal in the base of the antenna with integrated connector at the base. Assures a watertight seal to prevent water from migrating into the antenna connector (all models, except MFB24011 which has a pigtail). •Electrical downtilt options on select models. Provide system planners flexibility in challenging operating environments. The MAXRAD XtremeWave wireless broadband omnidirectional antennas are designed to provide maximum performance and reliability under the toughest weather conditions. These antennas feature a UV stable, vented radome that provides ultimate protection against weather elements. These antennas can be mast, wall or ceiling mounted. PCS, 2.4 GHz ISM, MMDS and 5.8 GHz ISM/UNII Omnidirectional Base Station Antenna Series Model #Frequency RangeGain Bandwidth @ 1.5:1 VSWR Vertical Beamwidth @ 1/2 Power VSWR Maximum Power Downtilt MFB19008A1850-1990 MHz8 dBi140 MHz12°< 1.5:125 WattsN/A MFB240042400-2483.5 MHz4 dBi100 MHz30°< 1.5:125 WattsN/A MFB240062400-2483.5 MHz6 dBi100 MHz20°< 1.5:125 WattsN/A MFB240082400-2483.5 MHz8 dBi100 MHz13°< 1.5:125 WattsN/A MFB24008DT32400-2483.5 MHz8 dBi100 MHz13°< 1.5:125 Watts3° MFB24008DT52400-2483.5 MHz8 dBi100 MHz13°< 1.5:125 Watts5° MFB24008DT72400-2483.5 MHz8 dBi100 MHz13°< 1.5:125 Watts7° MFB24008DT122400-2483.5 MHz8 dBi100 MHz13°< 1.5:125 Watts12° MFB240102400-2483.5 MHz10 dBi100 MHz9°< 1.5:125 WattsN/A MFB240112400-2500 MHz11 dBi100 MHz7°< 1.5:125 WattsN/A MFB250072500-2700 MHz7 dBi200 MHz13°< 1.5:125 WattsN/A MFB25007DT32500-2700 MHz7 dBi200 MHz13°< 1.5:125 Watts3° MFB515105150-5350 MHz10 dBi200 MHz7°< 1.8:125 WattsN/A MFB580095725-5875 MHz9 dBi150 MHz8°< 1.5:125 WattsN/A MFB58009PTNM5725-5825 MHz9 dBi100 MHz6°< 1.5:125 WattsN/A MFB580105725-5825 MHz10 dBi100 MHz6°< 1.5:125 WattsN/A Model # Wind Survival Equivalent Flat Plate Area Lateral Thrust @ Rated Wind Bending Moment @ Rated Wind HeightWeight MFB19008A125 mph .07 ft 2 5.9 lbs5.7 ft-lbs24.0” (609.6 mm)0.70 lbs (0.318 kg) MFB24004125 mph .02 ft 2 2.1 lbs0.7 ft-lbs8.1” (205.7 mm)0.34 lbs (0.154 kg) MFB24006125 mph .04 ft 2 3.0 lbs1.4 ft-lbs11.6” (294.6 mm)0.38 lbs (0.172 kg) MFB24008125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB24008DT3125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB24008DT5125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB24008DT7125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB24008DT12125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB24010125 mph .11 ft 2 10.1 lbs14.7 ft-lbs36.0” (914.4 mm)0.65 lbs (0.295 kg) MFB24011125 mph .25 ft 2 22.4 lbs41 ft-lbs44.0” (1,118 mm)3.00 lbs (1.400 kg) MFB25007125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB25007DT3125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB51510125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB58009125 mph .046 ft 2 4.1 lbs2.7 ft-lbs15.7” (398.8 mm)0.43 lbs (0.195 kg) MFB58009PTNM125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) MFB58010125 mph .06 ft 2 5.2 lbs4.4 ft-lbs20.2” (513.1 mm)0.50 lbs (0.226 kg) Electrical Specifications Specifications MMK1924 MFB24004 with MMK11 MMK8 Vented System MMK12 Mechanical Specifications An ISO-9001 Registered Company Patterns MFB24011 Elevation Plane Radiation Pattern

Model/MountMPAB7MPAB8MPAB10MPAB11MPAB12 MP19008XFPTN/AN/AN/Aincludedoptional MP19013XFPToptionaloptionalN/Aoptionaloptional MP24008XFPTN/AN/AN/Aincludedoptional MP24012CPLXFPToptionaloptionalN/Aoptionaloptional MP24013XFPToptionaloptionalN/Aoptionaloptional MP24018XFPToptionaloptionaloptionalN/AN/A MP58013XFPTN/AN/AN/Aincludedoptional MP24580809PTN/AN/AN/Aincludedoptional MP24581820PToptionaloptionaloptionalN/AN/A Mount Description Heavy duty outdoor adjustable mount with +/-35° uptilt/downtilt. If used with MP24018XFPT the mount provides +/- 18° uptilt/downtilt. Same as MPAB8 but bracket is longer. Heavy duty outdoor adjustable mount with 17° uptilt/downtilt. If used with MP24018XFPT the mount provides +/-9° uptilt/downtilt. Heavy duty outdoor adjustable mount +/-20° uptilt/downtilt and +/-90° polarity. Includes DSS satellite style house bracket. Short adjustable indoor mount. It may be used outdoors with small housing panels only. Long adjustable indoor corner mount. Small housing panels are 5/1” H x 4.7” W x 1.5” D 13 dBi panel on MPAB12 corner wall mount Small housing panel on MPAB11 wall mount MP24013XFPT on MPAB8 outdoor mount MP24018XFPT XtremeWave™ XF Series General Specifications: Directional panel antennas Radome Material: UL 94-V0 plastic Polarization: Linear, vertical/horizontal. Left hand circular (MP24012CPLXF only) Nominal Impedance: 50 Ohms Mounting Method: The XtremeWave™ directional panel antennas are designed to cover PCS, 4.9 GHz Public Safety band, 2.4 GHz and 5.8 GHz ISM frequencies, obtaining maximum gain in an attractive, low-profile package. All models provide efficient and stable performance across their specified bands and can be mounted indoors or outdoors. Multi-band models covering public safety and 802.11a/b/g standards are available. Features and Benefits: •Printed circuit board design provides the best performance-to-price ratio. •UL94-V0 plastic and PC board. Provides UL’s high flame retardant rating allowing maximum placement flexibility and meeting stringent building fire rating codes. •Attractive, low profile housing. Blends well with indoor and outdoor environments where aesthetic considerations are important. •Corner exit RG-58/U pigtail design (PCS and 2.4 GHz models), .141 semi-rigid (5.1 and 5.8 GHz models), and high p…
