EV-DW433 door sensor Operational Description The EV-DW433 door sensor is a low powered, which is installed in house to detect door/window for home security and other features. See the function descriptions in attached. The sensor is powered by a 3 volt battery. It is designed to operate on a single fixed frequency at 433.92 MHz. See the attached block diagram and schematic. There are 3 switches trigger the integrated circuit (U1) which produces the digital control signals and will modulate the carrier signal(ASK). The carrier signal is generated by a I.C (U1) oscillator/amplifier circuit comprised of a 6.78 MHz crystal (X1) . The modulated output of the RF stage is coupled to the strip antenna. The antenna is off-board soldered, around 160mm. The sensor is operated by the triggered momentarily within 0.2 second and will automatically deactivate send signal to receiver. This feature is incorporated by the U1 internally. All tuning and verification are performed by the manufacture and there are no adjustments can be made by user.

Schematics

42181-433.92.DSN DOOR SENSOR SAW SW Custom 11Thursday, January 30, 2003 Title SizeDocument NumberRev Date:Sheetof VCC VCC VCC VCC VCC VCC FOR ALL SENSORS EXCEPT DATA IN PULL UP PULL UP PULL UP TXEN DATA IN PULL UP PULL UP TEST PAD JUMPER1 JUMPER2 REED SW COVER VCC PULL UP JUMPER3 PULL UP PULL UP EXT2 PULL UP EXT1 SW1 REED SW 21 SW2 COVER SW 21 R4 1M 12 R1 1M 12 R2 1M 12 BT1 3V 1 2 C2 104 1 2 R9 22K 12 JP1 JUMPER R15 1M 12 R16 100K 12 J1 TEST PAD X1 4MHZ 1 2 3 R14 1M 12 JP2 JUMPER P1 PROGRAMMING PADS 12345 U2 S-808-21(SC-82AB) VI 2 NC 3 GND 4 OUT 1 JP3 JUMPER R13 1M 12 R5 1M 1 2 U1 PIC 16F62X-SSOP RA4 3 RA5/MCLR 4 OSC2 17 OSC1 18 RB7 14 RB6 13 RB5 12 RB4 11 RB3 10 RB2 9 RB1 8 RB0 7 RA0 19 RA1 20 RA2 1 RA3 2 GND 5 VDD 16 GND 6 VDD 15 R8 100K 12 SW3 MER 21 R6 1K 1 2 D2 LED 1 2 R3 1M 12 CON1 3PIN SCREW 1 2 3 C1 104 1 2 R10 100 12 R12 100 12 D3 14V 1 2 D1 14V 1 2 C4 3P 1 2C5 2P 12 C3 10P 1 2 ANT 1 2 C8 18nH 12 L1 104 1 2 X2 433.92MHZ 1 2 C12 1P 1 2 C6 3P 1 2 C9 104 1 2 C11 1p 12 R7 22 1 2 Q1 2SC3356 3 2 1 Q2 2SC3356 3 2 1 L3 27nH 1 2 R11 68n 1 2
