QNP915DCDEVICE CONTROLLER

Product Description The AT&T model number SW-ATT-DC is a 915MHz Wireless Device Controller that is used to control AC power to small appliances, such as a lamp. The unit is plugged directly into one socket of an AC power outlet. Then install the retaining screw into the plastic tab located at the top of the unit to secure the unit to the AC outlet. This Device Controller can be utilized to control turning lamps and other small appliances on and off. Follow these steps to install the Device Controller: 1. Plug the Device Controller into an AC power outlet. 2. Plug the lamp or other small appliance into the unit. Discovering and Registering the Device Controller Follow these steps to discover and register the device controller: Step Action 1. Place the DLC into Discovery Mode in DLD. 2. Make the Device Controller discoverable by pressing the Learn button located on the side of the unit. 3. Confi rm that the Device Controller has been discovered in DLD. 4. Label the Device Controller in DLD. This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures. • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. exploitation est autorisée aux deux conditions suivantes: (1) appareil ne doit pas produire de brouillage, et (2) utilisateur de appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible en compromettre le fonctionnement. Copyright © 2013 Linear LLC. 234730X1 FCC Compliance Statement This device complies with FCC Rules and Regulations as Part 15 devices as well as Industry Canada license exempt RSS Rules and Regulations. Operation is subject to the following two (2) conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. LISTED SW-ATT-DC RTL 41807 Installation Instructions

LINEAR LLC 1950 CAMINO VIDA ROBLE, SUITE 150, CARLSBAD, CA 92008-6517 PHONE (760) 438-7000 ● (800) 421-1587 ● ENG. FAX (760) 438-7043 MAIL: P.O. BOX 9003 ● CARLSBAD, CA 92018-9003 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QNP915DC Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram DC_BlockDiagram.pdf Theory of Operation DC_Theory of Operation_X1.pdf Schematic and BOM Schematic_DeviceController.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, John W. Kuivinen, P.E. Regulatory Compliance Engineer

LINEAR LLC 1950 CAMINO VIDA ROBLE, SUITE 150, CARLSBAD, CA 92008-6517 PHONE (760) 438-7000 ● (800) 421-1587 ● ENG. FAX (760) 438-7043 MAIL: P.O. BOX 9003 ● CARLSBAD, CA 92018-9003 01 February 2012 Federal Communications Commission Authorization and Evaluation Division FCC ID: QNP915DC Authority to Act as Agent On our behalf, I appoint Tom Tidwell of Nemko USA Inc., 802 N. Kealy Ave., Lewisville, TX 75057-3136, USA to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Federal Communication Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Linear L:LC, 1950 Camino Vida Roble, Suite 150, Carlsbad, CA. 92008-6517, USA. This appointment is in effect until December 31, 2012. Sincerely, John W. Kuivinen, P.E. Regulatory Compliance Engineer

LABEL,UL, MARK, SW-ATT-DC LINEAR P/N: 234751 X4 MFG. PROCESS: PRINTED LABEL OR PAD PRINTING LABEL INK: PERMANENT BLACK LABEL MATERIAL: 60 LB. WHITE COATED, ADHESIVE BACKED SCALE: 1-1 NOTE: ALL MATERIALS MUST BE UL GRADE AND PRINTER MUST BE UL RECOGNIZED LISTED WIRELESS RECEIVER 19WP Complies with FCC Rules and Regulations 234751 X4 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN MADE IN CHINA 454 2.000” 1.800” MODEL: SW-ATT-DC INPUT: 120V 60 Hz 3 WATTS FCC ID: QNP915DC IC: 4676A-915DC OUTPUT: 120VAC 15A MAX. This device complies with Part 15 of the FCC and Industry Canada license exempt RSS Standard Rules and Regulations. Operation subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d ́Industrie Canada applicables aux appareils radio exempts de licence. L ́exploitation est autorisée aux deus conditions suivantes: (1) l ́appareil ne doit pas produire de brouillage, et (2) l ́utilisateur de l ́appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d ́en compromettre le fonctionnement. For Installation Instructions refer to manual number 234730 supplied with product.

Nemko USA, Inc. 2210 Faraday Avenue, Suite 150 Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC Part 15 Subpart C, 15.249 : 19 December 2012 CERTIFICATION TEST REPORT Report Number: 2012 10221062 EMC Project Number: 10231107 Nex Number: 221062 Applicant: L INEAR LLC 1950 CAMINO VIDA ROBLE Carlsbad, CA 92008 Equipment Under Test (EUT): DEVICE CONTROLLER Model: SW-ATT-DC FCC ID: QNP915DC IC: 4676A-915DC In Accordance With: FCC Part 15 Subpart C, 15.249 IC RSS-210 Issue 8 December 2010 IC RSS-Gen Issue 3 December 2010 Tested By: Nemko USA Inc. 2210 Faraday Avenue, Suite 150 Carlsbad, CA 92008 Authorized By: Alan Laudani, EMC/RF Test Engineer Date: O CTOBER 5, 2012 Total Number of Pages: 26 Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915DC Report Number: 2012 10221062 EMC IC: 4676A-915DC Specification: FCC Part 15 Subpart C, 15.249 Page 2 of 26 1 Applicant Affirmation John Kuivinen representing Linear LLC hereby affirms: a) That he/she has reviewed and concurs that the test shown in this report are reflective of the operational characteristics of the device for which certification is sought; b) That the device in this test report will be representative of production units; c) That all changes (in hardware and software/firmware) to the subject device will be reviewed. d) That any changes impacting the attributes, functionality or operational characteristics documented in this report will be communicated to the body responsible for approving (certifying) the subject equipment. John Kuivinen Printed name of official Signature of official 1950 Camino Vida Roble October 5, 2012 Address Date 760-438-7138 [email protected] Telephone number Email address of official NOTE—This affirmation must be signed by the responsible party before it is submitted to a regulatory body for approval. Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915DC Report Number: 2012 10221062 EMC IC: 4676A-915DC Specification: FCC Part 15 Subpart C, 15.249 Page 3 of 26 Section1: Summary of Test Results General All measurements are traceable to national standards These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15; Subpart C and IC RSS-210. Radiated tests were conducted is accordance with ANSI C63.4-2003. Radiated emissions are made in a 10m semi-anechoic chamber. A description of the test facility is on file with the FCC and IC. The assessment summary is as follows: Apparatus Assessed: Device Controller Model: SW-ATT-DC Specification: FCC Part 15 Subpart C, 15.249 IC RSS-210 Issue 8 December 2010 Date Received in Laboratory: September 24, 2011 Compliance Status: Complies Exclusions: None Non-compliances: None Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915DC Report Number: 2012 10221062 EMC IC: 4676A-915DC Specification: FCC Part 15 Subpart C, 15.249 Page 4 of 26 1.1 Report Release History REVISION DATE COMMENTS - October 5, 2012 Prepared By: Mark Phillips - October 5, 2012 Initial Release: Alan Laudani Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko USA Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. TESTED BY: Date: October 5, 2012 Mark Phillips, EMC Test Engineer Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915DC Report Number: 2012 10221062 EMC IC: 4676A-915DC Specification: FCC Part 15 Subpart C, 15.249 Page 5 of 26 TABLE OF CONTENTS 1 Applicant Affirmation ......................................................................................... 2 Section1: Summary of Test Results ............................................................................ 3 1.1 Report Release History ..................................................................................... 4 Section 2: Equipment Under Test ................................................................................ 6 2.1 Product Identification ........................................................................................ 6 2.2 Samples Submitted for Assessment ................................................................. 6 2.3 Theory of Operation .......................................................................................... 7 2.4 Technical Specifications of the EUT ................................................................. 7 Section 3: Test Conditions ........................................................................................... 8 3.1 Specifications .................................................................................................... 8 3.2 Deviations From Laboratory Test Procedures ................................................... 8 3.3 Test Environment .............................................................................................. 8 3.4 Test Equipment ................................................................................................. 9 Section 4: Observations ............................................................................................. 10 4.1 Modifications Performed During Assessment ................................................. 10 4.2 Record Of Tech…
