QNP915PAD2WDEVICE CONTROLLER

SW‐ATT‐PAD2W RTL 41809 Installation Instructions Product Description The AT&T model number SW-ATT-PAD2W is a proprietary 915MHz wireless keypad that enables control of all system functions. The keypad also features a built-in sounder that annunciates system status information, alarms and troubles. They keypad sounds a predefined “chirp” and “beep” sound when a button is pressed on the keypad. For example, the system can be configured so that the keypad chirps when an entry/exit door is opened and closed. The keypad annunciates different sounds for fire and intrusion alarms. Installing/Replacing Batteries The keypad has four (4) AA batteries that provide twenty-four (24) hour battery backup. The batteries can be replaced by opening the battery compartment located on the rear of the unit. Installing the Keypad Connect the wires from the AC/DC power adapter to the terminals on the back side of the keypad, as depicted in Figure 40. And install four AA batteries. Plug the AC/DC power adapter into AC power outlet. When powered up, it is ready to be discovered. Figure 40: Keypad Connection to the AC/DC Adapter and Installation of AA Batteries Discovering and Registering the Keypad (Digital Life Direct) Follow these steps to discover and register the keypad using DLD: Step 1. Power up the keypad. Step 2. Access the “Devices” page. Step 3. Place the DLC in Discovery Mode (Initializing Process) Step 4. Enroll the keypad. SW‐ATT‐PAD2W RTL 41809 Installation Instructions Step 5. Review the DLC in Discovery Mode (Discovery in Process) Step 6. Confirm device discovery Regulatory Statements This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.  Reorient or relocate the receiving antenna  Increase the separation between the equipment and receiver  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected  Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. exploitation est autorisée aux deux conditions suivantes: (1) appareil ne doit pas produire de brouillage, et (2) utilisateur de appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible en compromettre le fonctionnement. FCC Compliance Statement This device complies with FCC Rules and Regulations as Part 15 devices as well as Industry Canada license exempt RSS Rules and Regulations. Operation is subject to the following two (2) conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. LISTED

LINEAR LLC 1950 CAMINO VIDA ROBLE, SUITE 150, CARLSBAD, CA 92008-6517 PHONE (760) 438-7000 ● (800) 421-1587 ● ENG. FAX (760) 438-7043 MAIL: P.O. BOX 9003 ● CARLSBAD, CA 92018-9003 01 February 2012 Federal Communications Commission Authorization and Evaluation Division FCC ID: QNP915PAD2W Authority to Act as Agent On our behalf, I appoint Tom Tidwell of Nemko USA Inc., 802 N. Kealy Ave., Lewisville, TX 75057-3136, USA to act as our agent in the preparation of this application for equipm ent certification. I certify that subm itted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit m anufactured, imported or marketed, as defined in Federal Communication Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nem ko Canada Inc, still resides with Linear L:LC, 1950 Cam ino Vida Roble, Suite 150, Carlsbad, CA. 92008-6517, USA. This appointment is in effect until December 31, 2013. Sincerely, John W. Kuivinen, P.E. Regulatory Compliance Engineer

LINEAR LLC 1950 CAMINO VIDA ROBLE, SUITE 150, CARLSBAD, CA 92008-6517 PHONE (760) 438-7000 ● (800) 421-1587 ● ENG. FAX (760) 438-7043 MAIL: P.O. BOX 9003 ● CARLSBAD, CA 92018-9003 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QNP915PAD2W Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram BlockDiagram_Keypad.pdf Theory of Operation Theory of Operation_Keypad.pdf Schematic and BOM Schematic_Keypad.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, John W. Kuivinen, P.E. Regulatory Compliance Engineer

LABEL, FCC/DOC, SW-ATT-PAD2W LINEAR P/N: 187-1747 B1X MANUFACTURING PROCESS: PRINTED LABEL OR PAD PRINTING LABEL MATERIAL: 60LB. WHITE COATED, ADHESIVE BACKED LABEL INK: PERMANENT BLACK PAD PRINTING INK; BLACK, LINEAR P/N 213337-002 MUST BE RoHS COMPLIANT SCALE: 1-1 2.300" 1.000" MADE IN CHINA 187-1747 BX1 This device complies with Part 15 of the FCC and Industry Canada license exempt RSS Standard Rules and Regulations. Operation subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. SECURE WIRELESS, INC. MODEL: SW-ATT-PAD2W FCC ID: QNP915PAD2W I.C.: 4676A-915PAD2W Le présent appareil est conforme aux CNR d ́Industrie Canada applicables aux appareils radio exempts de licence. L ́exploitation est autorisée aux deus conditions suivantes: (1) l ́appareil ne doit pas produire de brouillage, et (2) l ́utilisateur de l ́appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d ́en compromettre le fonctionnement. For installation instructions refer to Manual Number 234733 supplied with this product. Label location

Nemko USA, Inc. 2210 Faraday Avenue, Suite 150 Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC Part 15 Subpart C, 15.249 : 22 January 2013 CERTIFICATION TEST REPORT Report Number: 2012 10221063 EMC Project Number: 10231197 Nex Number: 221063 Applicant: L INEAR LLC 1950 CAMINO VIDA ROBLE Carlsbad, CA 92008 Equipment Under Test (EUT): KEYPAD Model: SW-ATT-PAD2W FCC ID: QNP915PAD2W IC: 4676A-915PAD2W In Accordance With: FCC Part 15 Subpart C, 15.249 IC RSS-210 Issue 8 December 2010 IC RSS-Gen Issue 3 December 2010 Tested By: Nemko USA Inc. 2210 Faraday Avenue, Suite 150 Carlsbad, CA 92008 Authorized By: Alan Laudani, EMC/RF Test Engineer Date: O CTOBER 5, 2012 Total Number of Pages: 27 Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915PAD2W Report Number: 2012 10221063 EMC IC: 4676A-915PAD2W Specification: FCC Part 15 Subpart C, 15.249 Page 2 of 27 1 Applicant Affirmation John Kuivinen representing Linear LLC hereby affirms: a) That he/she has reviewed and concurs that the test shown in this report are reflective of the operational characteristics of the device for which certification is sought; b) That the device in this test report will be representative of production units; c) That all changes (in hardware and software/firmware) to the subject device will be reviewed. d) That any changes impacting the attributes, functionality or operational characteristics documented in this report will be communicated to the body responsible for approving (certifying) the subject equipment. John Kuivinen Printed name of official Signature of official 1950 Camino Vida Roble October 5, 2012 Address Date 760-438-7138 [email protected] Telephone number Email address of official NOTE—This affirmation must be signed by the responsible party before it is submitted to a regulatory body for approval. Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915PAD2W Report Number: 2012 10221063 EMC IC: 4676A-915PAD2W Specification: FCC Part 15 Subpart C, 15.249 Page 3 of 27 Section1: Summary of Test Results General All measurements are traceable to national standards These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15; Subpart C and IC RSS-210. Radiated tests were conducted is accordance with ANSI C63.4-2003. Radiated emissions are made in a 10m semi-anechoic chamber. A description of the test facility is on file with the FCC and IC. The assessment summary is as follows: Apparatus Assessed: Keypad Model: SW-ATT-PAD2W Specification: FCC Part 15 Subpart C, 15.249 IC RSS-210 Issue 8 December 2010 Date Received in Laboratory: September 24, 2011 Compliance Status: Complies Exclusions: None Non-compliances: None Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915PAD2W Report Number: 2012 10221063 EMC IC: 4676A-915PAD2W Specification: FCC Part 15 Subpart C, 15.249 Page 4 of 27 1.1 Report Release History REVISION DATE COMMENTS - October 5, 2012 Prepared By: Mark Phillips - October 5, 2012 Initial Release: Alan Laudani Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko USA Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. TESTED BY: _ Date: October 5, 2012 Mark Phillips, EMC Test Engineer Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC ID: QNP915PAD2W Report Number: 2012 10221063 EMC IC: 4676A-915PAD2W Specification: FCC Part 15 Subpart C, 15.249 Page 5 of 27 TABLE OF CONTENTS 1 Applicant Affirmation ............................................................................................. 2 Section1: Summary of Test Results ................................................................................ 3 1.1 Report Release History ..................................................................................... 4 Section 2: Equipment Under Test ................................................................................... 6 2.1 Product Identification ........................................................................................ 6 2.2 Samples Submitted for Assessment ................................................................. 6 2.3 Theory of Operation .......................................................................................... 7 2.4 Technical Specifications of the EUT ................................................................. 7 Section 3: Test Conditions .............................................................................................. 8 3.1 Specifications .................................................................................................... 8 3.2 Deviations From Laboratory Test Procedures ................................................... 8 3.3 Test Environment .............................................................................................. 8 3.4 Test Equipment ................................................................................................. 9 Section 4: Observations ................................................................................................ 10 4.1 Modifications Performed During Assessment .......................................…
