QNP-POWERMOUSE01PowerMouse

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Compliance Certification Services Inc. Date of Issue: November 4, 2004 Report No.: 41008405 FCC ID: QNP-POWERMOUSE01 Page Compliance Certification Services Inc. Date of Issue: November 4, 2004 Report No.: 41008405 FCC ID: QNP-POWERMOUSE01 Page Compliance Certification Services Inc. Date of Issue: November 4, 2004 Report No.: 41008405 FCC ID: QNP-POWERMOUSE01 Page

FCC ID LABEL FORMAT AND LOCATION Secure Wireless, Inc. FCC ID: QNP-POWERMOUSE01 FCC ID: QNP-POWERMOUSE01 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Date of Issue: November 4, 2004 Report No.: 41008405 FCC ID: QNP-POWERMOUSE01 Page Compliance Certification Services Inc. Date of Issue: November 4, 2004 Report No.: 41008405 FCC ID: QNP-POWERMOUSE01 Page Compliance Certification Services Inc. Date of Issue: November 4, 2004 Report No.: 41008405 FCC ID: QNP-POWERMOUSE01 Page

PowerMouse Operational Description The PowerMouse is a low powered, which is installed in computer integrated with transmitter function for wireless presentation . See the function descriptions in attached. The sensor is powered by a 3 volt battery. It is designed to operate on a single fixed frequency at 433.92 MHz. See the attached block diagram and schematic. There are 3 switches trigger the integrated circuit (IC1) which produces the digital control signals and will modulate the carrier signal (ASK). The carrier signal is generated by a I C oscillator/amplifier circuit comprised of a 433.92 MHz SAW(X1) . The modulated output of the RF stage is coupled to the strip antenna. The antenna is on-board soldered, around 80mm. The PowerMouse is operated by the triggered momentarily within 0.2 second and will automatically deactivate send signal to receiver. This feature is incorporated by the IC1 internally. All tuning and verification are performed by the manufacturer and there are no adjustments can be made by users.

EV-TX3 HCS300 V2 Custom 01Wednesday, August 25, 2004 EV-TX3 HCS300 V2.DSN D:\WORK\CLPAN-NEW\LASER POINT MOUSE\EV-TX3 HCS300V2.DSN Title SizeDocument NumberRev Date:Sheetof SW1 12 IC1 HCS 300 S0 1 S1 2 S2 3 S3 4 VSS 5 PWM 6 LED 7 VDD 8 X1 EPCOS/433.92MHZ 1 2 Q1 3356 2 3 1 BT1 3V 1 2 JP1 4 HEADER 1 2 3 4 C4 75P 1 2 R2 22K 12 LED1 LED 12 R1 100 12 SW2 12 SW3 12 C1 220P 1 2 R3 270 1 2 JP2 HEADER 2 1 2 C5 5.6P 1 2 ANT1 ANTENNA C6 1.8P 1 2 C2 104 1 2 L1 39nH 1 2 L2 82nH 1 2

Compliance Certification Services Inc. Report No.: 41008405-RP FCC ID: QNP-POWERMOUSE01 Date of Issue: November 4, 2004 Page 1 of 21 Rev. 00 FCC ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR of POWERMOUSE FCC ID Number : QNP-POWERMOUSE01 Trade Name : Evolution Model Number : POWERMOUSETX Agency Series : N/A Report Number : 41008405-RP Date : November 4, 2004 Prepared to Secure Wireless, Inc. 1185 PARK CENTER DRIVE SUITE, A AND B VISTA, VISTA, CALIFORNIA, 92083 U.S.A. Issued by Compliance Certification Services Inc. Hsintien Lab. No. 165, Chunghsen Road, Hsintien City Taipei Hsien, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. Ltd. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Compliance Certification Services Inc. Report No.: 41008405-RP FCC ID: QNP-POWERMOUSE01 Date of Issue: November 4, 2004 Page 2 Rev. 00 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE......................................................3 2. PRODUCT DESCRIPTION.....................................................................4 3. TEST FACILITY.......................................................................................4 4. MEASUREMENT STANDARDS.............................................................4 5. TEST METHODLOGY............................................................................4 6. MEASUREMENT EQUIPMENT USED.................................................5 7. POWERLINE RFI LIMIT.......................................................................5 8. RADIATED EMISSION LIMITS.............................................................6 9. SYSTEM TEST CONFIGURATION.......................................................6 10. TEST PROCEDURE................................................................................7 11. EQUIPMENT MODIFICATIONS...........................................................8 12. TEST RESULT..........................................................................................9 12.1. MAXIMUM MODULATION PERCENTAGE (M%)..........................9 12.2. THE EMISSIONS BANDWIDTH.........................................................9 APPENDIX I TEST DATA............................................................................10 Compliance Certification Services Inc. Report No.: 41008405-RP FCC ID: QNP-POWERMOUSE01 Date of Issue: November 4, 2004 Page 3 Rev. 00 1. VERIFICATION OF COMPLIANCE COMPANY NAME : Secure Wireless, Inc. 1185 PARK CENTER DRIVE SUITE, A AND B VISTA, VISTA, CALIFORNIA, 92083 U.S.A. CONTACT PERSON : Jeff Christsten TELEPHONE NO. : 760-727-0601 EUT DESCRIPTION : POWERMOUSE MODEL NAME/NUMBER : POWERMOUSETX FCC ID : QNP-POWERMOUSE01 DATE TESTED : October 11, 2004 ~ November 3, 2004 REPORT NUMBER : 41008405-RP TYPE OF EQUIPMENT SECURITY EQUIPMENT (INTENTIONAL RADIATOR) EQUIPMENT TYPE 433.92 MHz POWERMOUSE MEASUREMENT PROCEDURE ANSI 63.4 / 2003 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services Inc. will constitute fraud and shall nullify the document. Approved by: Reviewed by: Compliance Certification Services Inc. Report No.: 41008405-RP FCC ID: QNP-POWERMOUSE01 Date of Issue: November 4, 2004 Page 4 Rev. 00 2. PRODUCT DESCRIPTION Fundamental Frequency 433.92 MHz Power Source 3V Battery Transmitting Time Periodic < 5 seconds Associated Receiver Model: POWERMOUSERX (DOC) 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, Taiwan, R.O.C. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/2003. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) Compliance Certification Services Inc. Report No.: 41008405-RP FCC ID: QNP-POWERMOUSE01 Date of Issue: November 4, 2004 Page 5 Rev. 00 6. MEASUREMENT EQUIPMENT USED Open Area Test Site # E Name of Equipment Manufacturer Model Serial Number Calibration Due SITE NSA CCS E Site N/A 09/10/2005 EMI TEST RECEIVER R&S DSAI-D / ESBI-RF 827832/001 82706/003 03/08/2005 ANTENNA SCHAFFNER CBL 6112B 2802 09/25/2005 AMPLIFIER H.P. 8447D A 2727A05764 04/30/2005 CABLE BELDEN 9913 N-TYPE#E2&E3 03/05/2005 THERMO- HYGRO METER TFA N/A NO.6 11/23/2004 EMC ANALYZER (100Hz-22GHz) HP 8566B 2937A06102 07/26/2005 ANTENNA (1-18GHz) EMCO 3115 5761 02/02/2005 AMPLIFIER (1-26.5GHz) HP 8449B 3008A01266 02/15/2005 CABLE (1-18GHz) JYEBAO HUBER+SUHNER LL142 SUCOFLEX 104 SMA-RS1&2 SMA-RS3 02/15/2005 Remark: Each piece of equipment is scheduled for calibration once a year. 7. POWERLINE RFI LIMIT CONNECTED TO AC POWER LINE SECTION 15.207 CARRIER CURRENT SYSTEM …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 41008405-RP FCC ID: QNP-POWERMOUSE01 Date of Issue: November 4, 2004 Page 6 Rev. 00 8. RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209 RESTRICTED BANDS OF OPERATION SECTION 15.205 PERIODIC OPERATION IN THE BAND 40.66 -40.70 MHz AND ABOVE 70 MHz. SECTION 15.231 9. SYSTEM TEST CONFIGURATION Use a block of foam and combined it with EUT wrapping rubber band around it. This way it can test X, Y and Z axis. To activate continuous transmitting & receiving, place a small plastic block between rubber band and EUT push button. Radiated Open Site Test Set-up
