R33C4THERMTHERMOMETER

™ ™ Thermostat with Humidity or Ventilation Control User Guide ii Disclaimer Control4® makes no representations or warranties with respect to any Control4 hardware, software, or the contents or use of this publication, and specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose. Control4 reserves the right to make changes to any and all parts of Control4 hardware, software, and this publication at any time, without any obligation to notify any person or entity of such changes. Trademarks ©2014 Control4. All rights reserved. All rights reserved. Control4, the Control4 logo, the Control4 iQ logo and the Control4 certified logo are registered trademarks or trademarks of Control4 Corporation in the United States and/or other countries. All other names and brands may be claimed as the property of their respective owners. Pricing and specifications are subject to change without notice. Warranty Control4 Corporation 11734 S. Election Road, Suite 200 Salt Lake City, UT 84020 USA http://www.control4.com Thermostat with Humidity or Ventilation Control User Guide Part Number: 90-1883 Rev A, 3/26/2014 Model Number: C4-THERM-WH For complete warranty information, including details on consumer legal rights as well as warranty exclusions, visit www.control4.com/warranty, or refer to the Thermostat with Humidity or Ventilation Control User Guide on the Control4 website, Resources > Documentation page at http://www.control4.com/residential/products/resources/. iii Contents About your new thermostat ................................................1 Supported model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Thermostat features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Quick reference to controls and display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Operation ...............................................................2 Select system mode (Em Heat /Heat /Off/Cool /Auto) . . . . . . . . . . . . . . . . . . . . . .2 Change temperature set point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Select fan setting (On /Auto /Circ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Maintenance reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Screen lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Power and battery replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Indoor Air Quality functions ...............................................3 Event-Based ™ air cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Humidifier control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Automatic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Manual mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Dehumidifier control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 If dehumidification is installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 If dehumidification is done with the air conditioner . . . . . . . . . . . . . . . . . . .4 Fresh air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Program schedule and holds ...............................................5 Understanding program schedules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Progressive recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Program schedule holds 2 Hour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Permanent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Next Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Timed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 1 Quick reference to controls and display Thermostat features • Up to 4 stage heat and 2 stage cool operation. • Indoor air quality control. • Humidification (automatic or manual control). • Dehumidification. • Event-Based™ air cleaning. • Ventilation with temperature and humidity limits. • Temperature control. • Message center provides feedback and instructions. • Dual power option (24VAC or battery). • Programmable fan control with fan circulation mode. • Easy-to-use temperature control can override program schedule at any time. • Progressive recovery ensures proper temperature at the start of a program event. • Built-in compressor protection prevents damage to your equipment. • System test mode. Control4 thermostat with humidity or ventilation control User guide Quick reference to controls and display Home screen Note: Backlight is activated with the first button press and automatically turns off. Equipment status System Mode setting System Mode buttonHold buttonFan Mode button Indoor Air Quality button (optional) Setpoint Adjust buttons Temperature setting Fan Mode setting Presets button Hold status Radio signal strength indicator Low battery indicator Message centerIndoor Air Quality settingCurrent indoor temper…

Text truncated - open the document above for the full version.

11734 South Election Road, Ste. 200 | Salt Lake City, Utah 84020 | www.control4.com | 801.523.3100 phone | 801.523.3199 fax Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: R33C4THERM To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until February 10, 2015: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Roger Midgley Sr. Regulatory Compliance Engineer

SCALE 1:1DO NOT SCALESHEET 1 OF 2 REVSIZEPART # AC.0 1. MATERIAL: COLOR: WHITE PREMIUM COATED, THERMAL TRANSFER POLYESTER PAPER LABEL STOCK SEE PART NUMBER 211-00023 FOR MATERIAL SPECIFICATION AND APPROVED MANUFACTURERS 2. PRINTING: PRINT COLOR: PANTONE 426C BLK (Black) TEXT USE SHEET 2 FOR LABEL PLACEMENT REFERENCE PDF DOCUMENT IS FOR REFERENCE ONLY 3. DOCUMENT SCHEDULE: SHEET 1: ARTWORK SHEET 2: LABEL PLACEMENT THE INFORMATION CONTAINED IN THIS DRAWING AND THE ASSOCIATED CAD DATA IS CONFIDENTIAL, AND IS THE SOLE PROPERTY OF CONTROL4. ANY USE, REPRODUCTION, OR DISCLOSURE - IN WHOLE OR IN PART - WITHOUT WRITTEN PERMISSION FROM CONTROL4 IS PROHIBITED 11734 S. Election Road, Suite 200 Draper, UT 84020 Phone: 801-523-3100 Fax: 801-523-3199 TITLE 210-40001 NO.REVISIONSDATEBY LABEL, REGULATORY THERMOSTAT COPYRIGHT 2014 CADD FRENCH SAFETY STATEMENT01/07/15CJK NOTES (UNLESS OTHERWISE SPECIFIED): 210-40001 Made in China MODEL: C4-THERM FCC ID: R33C4THERM IC: 7848A-C4THERM 24V ~ 50-60 Hz, 0.1A This device complies with part 15 of the FCC rules and CAN ICES-3(B)/NMB-3(B). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MODELE 45.00 mm 28.00 mm DECIMAL: ± 0.508 2 DECIMAL: ± 0.254 3 DECIMAL: ± 0.127 RAD/CHAM: ± 0.508 ANGLE: ± 1.00° TOLERANCES: (ALL DIMENSIONS ARE IN MM) FOR REFERENCE ONLYNOT TO SCALESHEET 2 OF 2 REVSIZEPART # AC.0 11734 S. Election Road, Suite 200 Draper, UT 84020 Phone: 801-523-3100 Fax: 801-523-3199 TITLE 210-40001 LABEL, REGULATORY THERMOSTAT COPYRIGHT 2014 210-40001 Made in China MODEL: C4-THERM FCC ID: R33C4THERM IC: 7848A-C4THERM 24V ~ 50-60 Hz, 0.1A This device complies with part 15 of the FCC rules and CAN ICES-3(B)/NMB-3(B). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MODELE

Page 1 of 4 11734 South Election Road, Ste. 200 | Salt Lake City, Utah 84020 | www.control4.com | 801.523.3100 phone | 801.523.3199 fax MPE Calculations Control4 Model: C4-THERM FCC ID: R33C4THERM IC ID: 7848A-C4THERM Page 2 of 4 11734 South Election Road, Ste. 200 | Salt Lake City, Utah 84020 | www.control4.com | 801.523.3100 phone | 801.523.3199 fax 1.0 SCOPE_________________________________________________________3 2.0 REVISION LEVEL_______________________________________________3 3.0 REFERENCE DOCUMENTS______________________________________3 4.0 CALCULATIONS________________________________________________4 5.0 CONCLUSION___________________________________________________4 1.0 SCOPE: This Report Demonstrates Evaluation and Compliance to the following standards: 1. Code of Federal Regulations Title 47, Volume 1, Section 1.1310. 2. Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) - RSS-102 Issue 3 2.0 REVISION LEVEL: DATE COMMENTS REVISION 10/10/08 Created. 1.0 08/16/10 Added RSS-102 references 2.0 3.0 REFERANCE DOCUMENTS: (A) Limits for Maximum Permissible Exposure (MPE). Code of Federal Regulations Title 47, Volume 1, Section 1.1310. (B) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields. OET Bulletin 67 Edition 97-01. (C) Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) - RSS-102 Issue 3 Page 3 of 4 11734 South Election Road, Ste. 200 | Salt Lake City, Utah 84020 | www.control4.com | 801.523.3100 phone | 801.523.3199 fax 4.0 CALCULATIONS: The following worst case emissions was calculated by using Method 2 below Method 1: Based on a PPt (Peak Power Total) measurement of the total power into the antenna, worst case antenna gain and manufacturing variance. Effective/Equivalent Isotropic Radiated Power [EIRP] dBm = Total power into the antenna [dBm] + antenna gain [dBi] + manufacturing variance/tolerance [dB] To convert the values from dBm to mW mW = 10 dBm/10 The EIRP was calculated to be 4.66 dBm (see calculation below). This is based on the worst case conducted output power as reported in UL test report 14U19506-E2 section 8.3, declared antenna gain and Control4 has declared that the maximum variation for the output power during manufacturing testing is ± 0.5 dB; therefore, +0.5 dB was added to the measured output power to calculate the MPE. Total power into the antenna [dBm] = 2.06 antenna gain [dBi] = 2.1 Tune-up procedure variance[dB] = 0.5 EIRP (dBm) = 4.66 EIRP (mW) = 2.92 EIRP (W) = 0.00292 Method 2: Based on the radiated field strength measurement at 3 meters [at a calibrated OATS site, maximizing the antenna polarity and height] After obtaining the EIRP, the Power density is calculated and compared against the FCC and IC limits. S FCC = Power density in mW/cm² for FCC S FCC = EIRP/4π∙R² EIRP = Equivalent isotropically radiated power 2.92 mW R = Distance to the center of radiation of the antenna 20 cm S FCC = 0.000582 mW/cm² S FCC Limit = 1.0 mW/cm² Page 4 of 4 11734 South Election Road, Ste. 200 | Salt Lake City, Utah 84020 | www.control4.com | 801.523.3100 phone | 801.523.3199 fax S IC = Power density in W/m² for IC S IC = EIRP/4π∙R² EIRP = Equivalent isotropically radiated power in watts 0.00292 W R = Distance to the center of radiation of the antenna 0.2 m S IC = 0.006 W/m² S IC Limit = 10 W/m² for IC 5.0 CONCLUSION: 1. Based upon the limits for Maximum Permissible Exposure (MPE) given in Table 1 of reference document (A) as 1mW/cm², this device falls under the required limits. 2. Based upon the limits given in section 4.2 of the reference document (C) as 10W/m², this device falls under the required limits.

FCC CFR47 PART 15 SUBPART C INDUSTRY CANADA RSS-210 ISSUE 8 ZIGBEE CERTIFICATION TEST REPORT FOR THERMOSTAT MODEL NUMBER: C4-THERM FCC ID: R33C4THERM IC: 7848A-C4THERM REPORT NUMBER: 14U19506-E2 REVISION E ISSUE DATE: Jan 26, 2015 Prepared for CONTROL 4 CORP. 11734 S. ELECTION RD. SALT LAKE CITY, UT 84020 USA Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 2 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 12/29/14 Initial Issue P. Zhang A 1/6/15 Updated page 5,6,7,10,11,21 regarding standard version and statement P. Zhang B 1/15/15 Updated equipment list P. Zhang C 1/21/15 Updated page 12 regarding standard version P. Zhang D 1/23/15 Updated equipment list; page 10; page 25; add appendix for DC factor calculation P. Zhang E 1/26/15 Updated page 23-24 P. Zhang REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 3 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. TABLE OF CONTENTS ATTESTATION OF TEST RESULTS ................................................................................. 4 1. TEST METHODOLOGY ..................................................................................................... 5 2. FACILITIES AND ACCREDITATION ................................................................................. 5 3. CALIBRATION AND UNCERTAINTY ................................................................................ 5 4. 4.1. MEASURING INSTRUMENT CALIBRATION .............................................................. 5 4.2. SAMPLE CALCULATION ............................................................................................ 5 4.3. MEASUREMENT UNCERTAINTY ............................................................................... 5 EQUIPMENT UNDER TEST ............................................................................................... 6 5. 5.1. DESCRIPTION OF EUT .............................................................................................. 6 5.2. MAXIMUM OUTPUT POWER...................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS .............................................................. 6 5.4. WORST-CASE CONFIGURATION AND MODE .......................................................... 6 5.5. DESCRIPTION OF TEST SETUP ................................................................................ 7 TEST AND MEASUREMENT EQUIPMENT ....................................................................... 9 6. MEASUREMENT METHODS ............................................................................................10 7. SUMMARY ........................................................................................................................11 8. ANTENNA PORT TEST RESULTS ...................................................................................12 9. 9.1. 6 dB BANDWIDTH ......................................................................................................12 9.2. 99% BANDWIDTH ......................................................................................................16 9.3. OUTPUT POWER.......................................................................................................20 9.4. POWER SPECTRAL DENSITY ..................................................................................21 9.5. CONDUCTED SPURIOUS EMISSIONS .....................................................................25 RADIATED TEST RESULTS .........................................................................................32 10. 10.1. LIMITS AND PROCEDURE .....................................................................................32 10.2. TRANSMITTER ABOVE 1 GHz ...............................................................................33 10.4. WORST-CASE BELOW 1 GHz ...............................................................................46 AC POWER LINE CONDUCTED EMISSIONS ..............................................................49 11. APPENDIX TRANSMITTER DUTY CYCLE CALCULATIONS ......................................52 12. SETUP PHOTOS ...........................................................................................................53 13. END OF REPORT ....................................................................................................................58 1. REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 4 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. ATTESTATION OF TEST RESULTS COMPANY NAME: CONTROL 4 CORP. EUT DESCRIPTION: THERMOSTAT MODEL: C4-THERM SERIAL NUMBER: 2010928 DATE TESTED: December 8 to 27, 2014 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Pass INDUSTRY CANADA RSS-210 Issue 8 Annex 8 Pass INDUSTRY CANADA RSS-GEN Issue 4 Pass UL Verification Services Inc. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL Verification Services Inc. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account…

Text truncated - open the document above for the full version.

REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 53 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. SETUP PHOTOS 13. ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP ANTENNA PORT CONDUCTED PHOTO REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 54 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. RADIATED RF MEASUREMENT SETUP (BELOW 1 GHz) RADIATED FRONT PHOTO (BELOW 1 GHz) RADIATED BACK PHOTO (BELOW 1 GHz) REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 55 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. RADIATED RF MEASUREMENT SETUP (ABOVE 1 GHz) RADIATED FRONT PHOTO (ABOVE 1 GHz) RADIATED BACK PHOTO (ABOVE 1 GHz) REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 56 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. RADIATED RF MEASUREMENT SETUP FOR PORTABLE CONFIGURATION X-AXIS FRONT PHOTO Y-AXIS FRONT PHOTO REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 57 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Z-AXIS FRONT PHOTO REPORT NO: 14U19506-E2E DATE: Jan 26, 2015 EUT: THERMOSTAT MODEL: C4-THERM Page 58 of 58 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP END OF REPORT LINE CONDUCTED FRONT PHOTO LINE CONDUCTED BACK PHOTO
