R33KPZ10B11Wireless LCD Keypad Model KPZ-10B1-(Color)

Wireless LCD Keypad Installation Guide Supported Models KPZ-10B1-W White LCD KeypadKPZ-10B1-B Black LCD KeypadKPZ-10B1-A Almond LCD Keypad Graphical Symbols in this GuideThe following symbols and their descriptions draw your attention to safe practices and additional information that can help you avoid injury, death, or loss of material or time. WARNING! This indicates a potentially hazardous situation that, if not avoided, may result in death or serious injury. DO NOT IGNORE A WARNING! CAUTION! This indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury. DO NOT IGNORE A CAUTION! IMPORTANT! This indicates information that will help you avoid damage to your equipment, loss of materials, or loss of time. PAY ATTENTION TO THESE IMPORTANT STATEMENTS! NOTE: This indicates a note on related information about the current topic. TIP: This indicates a tip that might save you time or effort. Important Safety Instructions1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Protect the power cords, if applicable, from being walked on or pinched particularly at plugs, convenience rec eptacles, and the point where they exit from the apparatus. 10. Only use attachments/accessories specified by the manufacturer.11. If applicable, unplug this apparatus during lightning storms or when unused for long periods of time. 12. Refer all servicing to qualified service perso nnel. Servicing is required when the appa- ratus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. WARNING! To reduce the risk of fire or elec trical shock, do not expose this apparatus to rain or moisture. WARNING! To avoid bodily harm, always contact a Control4-authorized reseller for assistance if any repair or adjustment is required. WARNING! Improper use or installation can cause LOSS/DAMAGE OF PROPERTY. CAUTION! Do not place unit near sources of heat or expose to direct sunlight on the screen. Store in a cool and dry place. General DescriptionAn essential component in every home c ontrol system is a navigation device that allows users to communicate with the Control4 system. Along with the Wireless LCD Keypad, Control4 offers a variety of navigation options for every room, including the System Remote Control, the On-screen (television), the Mini Touch Screen, and the 10.5” Wireless Touch Screen, etc. NOTE: For a complete list of Control4 devices, see “Products” at http:// www.Control4.com The LCD Keypad offers complete system control in an elegant, compact design. It is equipped with a backlit, intera ctive LCD screen that provides status information and feedback. The LCD Keypad uses ZigBee IEEE 802.15.4 wireless technology for communication to a Control4 Controller, such as the a Home Theater Controller or a Media Controller. It has eight navigation buttons, an intuitive Select Dial, and a unique programmable shortcut button. It gets its power from an AC power source close to the LCD Keypad installation location. This power source requires both hot and neutral connections. See Figure 1. FIGURE 1. LCD Keypad - Requires AC power to LCD Keypad Placement: Place at a convenient location comfortable for users to view displays and choose menu options, typically at eye level , (approximately 57 to 61 inches from the floor) and near the entrance of a room. Wall Box Kit OptionsThere are four wall-box options to in stall the LCD Keypad. Metal and plastic wall boxes are available in new or retr ofit versions. The following diagrams show the available wall-mounting kits. FIGURE 2. Mini Touch Screen/LCD Keypad Wall Box Kits - New Construction FIGURE 3. Mini Touch Screen/LCD Keypad Wall Box Kit - Retrofit (includes wall-box template) What’s in the BoxCarefully unpack the contents from the box and make sure the following items were included. If any item is miss ing or damaged, please contact your Control4-authorized reseller immediately. • Control4 LCD Keypad • Two sheet-metal screws (1/2-inch) fo r attachment to a plastic wall box. (Metal wall boxes require machine screws. These screws are included with the Metal Wall Box Kit.) • Three wire caps • Warranty card • LCD Keypad Installation Guide (this document) • LCD Keypad User Guide Requirements • Home Theater Controller or Media Controller fully installed and config-ured with a Control4 project. • Control4 Mini Touch Screen/LCD Keypad custom wall-box kit. See “Wall Box Kit Options.” • Access to in-wall AC power source . (A neutral connection is required.) • 14 AWG electrical wire that is long enough to pull between LCD Key- pad and power source. Front and Rear Panel DescriptionsFront View 1. User Control Buttons (soft keys): For navigation and control of the Control4 system. 2. Select Dial: For identifying the device during initial setup. Once setup is complete, for scrolling through displays. 3. Shortcut Button: For custom programming to initiate an action or sequence of actions. 4. Front Dimension: 6 1/2” (W) x 4 3/8” (H) x 1/5-2/5” (D) 5. Software: LCD Navigator (pre-installed) 6. Display: 3” viewing area FSTN LCD, 240x120 pixels, Grey on white with white LED backlight Back View1. Power Supply: 100-240 VAC 60150 Hz (less than 6W) 2. AC Wires: For connecting the black (hot) and white (neutral) wires on the back to the hot and neutral wires from the wall. 3. Power Consumption: 240x120 4. In-Wall Dimension: 5 7/8” (W) x 3 5/8” (H) x 1 1/2” (D) 5. Network Support: ZigBee IEEE 802.15.4 LCD Keypad AC Outlet Plastic model # AC-NWB3.8-G Met…

Text truncated - open the document above for the full version.

User Input 9 buttons, 1 rotary encoder with center button Main CPU 8.00 MHz crystal 32.768 KHz crystal KPZ-10B1-x LCD keypad Functional Blocks LCD graphics display 16.0000 MHz crystal 240 x120 pixels Radio 16.0000 MHz crystal 2.4 GHz 802.15.4 power supply Built on board, 8 watts, 115 or 230 VAC 50-60 Hz SRAM Voltage Regulators 5 Volts, 3.3 Volts FLASH

11734 South Election Drive Suite 200 Draper, Utah 84020 (801) 523-3100 To: Federal Communications Commission Date: 10/28/05 445 12 th Street, SW Washington, DC 20554 Re: Non disclosure Request for FCC ID: R33KPZ10B11 We are requesting that the following documents be held and treated as confidential and proprietary information. These materials contain technical trade secret information and should be guarded from competitors as stated under the Code of Federal Regulations Title 47 Section 0.459 (3), (4) and (5). 1) All KPZ-10B1-x Schematic diagrams Steve Coffin Senior Electrical Engineer Control4 Corporation

Front View of the EUT Back View of the EUT

Front View of the Display PCB Back View of the Display PCB Front View of the Main PCB Back View of the Main PCB

KPZ-10B1-x LCD keypad Functional Description The KPZ-10B1-x LCD keypad is low cost in wall user interface for use in Control4 home automation systems. The unit features a 240 x 120 pixel black and white graphical LCD display, a host microprocessor, and 2.4 GHZ 802.15.4 radio transceiver. It also features ten buttons and rotary encoder knob to accept input from users. The system contains an onboard universal power supply made to operate from 90-260 VAC at 50Hz-60Hz, and consumes less that 5 watts of electrical power. The host processor receives information via the wireless link from a central home controller and displays menus and data on the LCD display. User button pushes and rotary knob input is captured by the host processor and communicated back to the central home controller again via 802.15.4 wireless communication. Thus the KPZ-10B1-x functions as a user access panel to allow users to access home automation control functions.

1 MPE Calculations R33KPZ10B11 2 1.0 SCOPE_________________________________________________________3 2.0 REVISION LEVEL_______________________________________________4 3.0 REFERENCE DOCUMENTS______________________________________4 4.0 CALCULATIONS________________________________________________5 5.0 CONCLUSION___________________________________________________6 3 1.0 SCOPE: This Report Demonstrates Evaluation and Compliance for Human Exposure to Radiofrequency Electromagnetic Fields as Outlined by the Federal Communications Commission Office of Engineering and Technology Bulletin 65. 2.0 REVISION LEVEL: DATE COMMENTS REVISION 10/27/2005 Created. 1.0 3.0 REFERANCE DOCUMENTS: (A) Limits for Maximum Permissible Exposure (MPE). Code of Federal Regulations Title 47, Volume 1, Section 1.1310. (B) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields. OET Bulletin 67 Edition 97-01. 4.0 CALCULATIONS: The KPZ-10B1-x LCD keypad utilizes a low power 2.4 GHz radio located approx 2.5 cm behind the front panel plastic. The following worst case emissions are based on a PPt (Peak Power Total) measurement of 11.6 dBm. And the worst case antenna gain on axis is found to be 2.5 dBi. Total radiated power at the Transmitter: A) Pt = 11.6 dBm + 2.5 dBi = 14.1 dBm EIRP 14.1 dBm EIRP = .0257 Watts. (25.7mW) Power density at a distance of 10cm from the antenna is: B) S = EIRP/4π∙r 2 Where S is Power density in units of mW/cm2 and EIRP is Equivalent Isotropic Radiated Power in units of mW and r is distance to the center of radiation of the antenna in units of cm S = 25.7mW/(4 π (10cm) 2 ) = .0205mW/cm 2 4 5.0 CONCLUSION: Based on the FCC Limits for Maximum Permissible Exposure (MPE) given in Table 1 of reference document (A) this device falls under the required limits.

COMMUNICATION CERTIFICATION LABORATORY 1940 West Alexander Street Salt Lake City, UT 84119 801-972-6146 Certification Test Report TEST OF: KPZ-10B1-x FCC ID: R33KPZ10B11 To FCC PART 15, Subpart C (15.203, 15.207, 15.247) Test Report Serial No: 73-8206 Applicant: Control4 11734 S. Election Drive, Suite 200 Draper, UT 84020 Dates of Test: October 24, 2005 Issue Date: October 25, 2005 Equipment Receipt Date: October 24, 2005 Accredited Testing Laboratory By: NVLAP Lab Code 100272-0 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-8206 FCC ID#: R33KPZ10B11 Page 2 of 51 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Communication Certification Laboratory to document compliance of the device described below with the requirements of Federal Communications Commission (FCC) Part 15, Subpart C, Sections 15.203, 15.207, and 15.247. This report may be reproduced in full, partial reproduction may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. - Applicant: Control4 - Manufacturer: Control4 - Brand Name: Control4 - Model Number: KPZ-10B1-x - FCC ID Number: R33KPZ10B11 On this 25 th day of October 2005, I, individually, and for Communication Certification Laboratory, certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. Although NVLAP has recognized that the Communication Certification Laboratory EMC testing facilities are in good standing, this report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. COMMUNICATION CERTIFICATION LABORATORY Tested by: Norman P. Hansen EMC Technician COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-8206 FCC ID#: R33KPZ10B11 Page 3 of 51 TABLE OF CONTENTS PAGE SECTION 1.0 CLIENT INFORMATION .................................4 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) ..........................5 SECTION 3.0 TEST SPECIFICATION, METHODS & PROCEDURES ...........8 SECTION 4.0 OPERATION OF EUT DURING TESTING ...................14 SECTION 5.0 SUMMARY OF TEST RESULTS ...........................16 SECTION 6.0 MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS .....17 APPENDIX 1 TEST PROCEDURES AND TEST EQUIPMENT ..................33 APPENDIX 2 PHOTOGRAPHS .........................................42 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-8206 FCC ID#: R33KPZ10B11 Page 4 of 51 SECTION 1.0 CLIENT INFORMATION 1.1 Applicant: Company Name: Control4 11734 S. Election Drive, Suite 200 Draper, UT 84020 Contact Name: Steve Coffin Title: Senior Hardware Engineer 1.2 Manufacturer: Company Name: Control4 11734 S. Election Drive, Suite 200 Draper, UT 84020 Contact Name: Steve Coffin Title: Senior Hardware Engineer COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-8206 FCC ID#: R33KPZ10B11 Page 5 of 51 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) 2.1 Identification of EUT: Brand Name: Control4 Model Name or Number: KPZ-10B1-x Serial Number: None Options Fitted: N/A Country of Manufacture: U.S.A., India, China 2.2 Description of EUT: The KPZ-10B1-x is a keypad and display for interfacing and control of other Control4 home automation products. There are 9 buttons, a dial control with center button, and an LCD display. It is powered from the AC mains of the home. An 802.15.4 (Zigbee) transceiver is used to interface other Control4 products. The “x” in the model number is a variable that indicates the color of the plastic faceplate. This report covers the 802.15.4 ZigBee transceiver and testing was performed to FCC Part 15 Subpart C. The digital and control circuitry subject to FCC Part 15 Subpart B is to be covered in a separate report. The 802.15.4 transceiver uses 15 channels in the 2400 to 2483.5 MHz band. The individual channels are shown in the following plots. dBm 0 -10 -20 -30 -40 -50 -60 -70 -80 -90 -100 Control4 Trace A Start: 2.402500 GHzStop: 2.427500 GHz Res BW: 100 kHzVid BW: 300 kHzSweep: 20 ms 10/24/2005 12:14:49 PMHP8566B Lower 5 Channels 1 1 2.405050 GHz -14.5000 dBm 2 2 2.410350 GHz -13.8000 dBm 3 3 2.415325 GHz -13.5000 dBm 4 4 2.420475 GHz -14.0000 dBm 5 5 2.425475 GHz -14.3000 dBm COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-8206 FCC ID#: R33KPZ10B11 Page 6 of 51 dBm 0 -10 -20 -30 -40 -50 -60 -70 -80 -90 -100 Control4 Trace A Start: 2.427500 GHzStop: 2.452500 GHz Res BW: 100 kHzVid BW: 300 kHzSweep: 20 ms 10/24/2005 12:12:21 PMHP8566B Middle 5 Channels 1 1 2.430050 GHz -14.5000 dBm 2 2 2.435350 GHz -14.0000 dBm 3 3 2.440325 GHz -14.2000 dBm 4 4 2.445475 GHz -14.2000 dBm 5 5 2.450475 GHz -14.0000 dBm dBm 0 -10 -20 -30 -40 -50 -60 -70 -80 -90 -100 Control4 Trace A Start: 2.452500 GHzStop: 2.477500 GHz Res BW: 100 kHzVid BW: 300 kHzSweep: 20 ms 10/24/2005 12:09:22 PMHP8566B Upper 5 Channels 1 1 2.455050 GHz -14.2000 dBm 2 2 2.460350 GHz -14.3000 dBm 3 3 2.465325 GHz -15.1000 dBm 4 4 2.470475 GHz -15.6000 dBm 5 5 2.475475 GHz -13.8000 dBm COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-8206 FCC ID#: R33KPZ10B11 Page 7 of 51 2.3 EUT and Support Equipment: The FCC ID numbers for all the EUT and support equipment used during the test (including inserted cards) are listed below: Brand Name Model Number Serial No. FCC ID Number Description Name of Interface Ports / Interface Cables BN: Control4 MN: KPZ-10B1-x (Note 1) R33KPZ10B11 Keypad and display See Section 2.4 Note: (1) EUT 2.4 Interface Ports on EUT: The only wired connection to the EUT is power over the AC mains of the home. All other interfacing is done with the Zigbee transceiver. 2.5 Modification Incorporated/Special Accessories on EUT: The following modifications were made to the KPZ-10B1-x by the Client during testing to comply with the specification. These modifications will be implemented during manufacturing. 1. The 3.3mH common mode choke was replaced with a 33mH common mode choke. 2. The drive level to the transmitter was s…

Text truncated - open the document above for the full version.

Front View Radiated Disturbance Worst Case Configuration Back View Radiated Disturbance Worst Case Configuration Front View Conducted Disturbance Worst Case Configuration Back View Conducted Disturbance Worst Case Configuration
