RFLUVB-N82DVOIP & BLUETOOTH DONGLE

Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 1 Page 2007-09-05 UVB-Nx2x Spec. & Quick Manual Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 2 Page 2007-09-05 History Revision Date AuthorDescription 0.1 2007-05-08 HAES 0.2 2007-05-15 HAES Spec Added. 0.3 2007-08-30 EKPARKSpec Revision. Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 3 Page 2007-09-05 Table of Contents 1. Product Overview...............................................................................................................4 1.1. Model specification...................................................................................................4 1.2. Functional Features...................................................................................................5 1.3. Product’s combination of 3-Components....................................................................6 1.3.1. Dongle component.................................................................................................6 1.3.2. UBManager component..........................................................................................6 1.3.3. Dialer component...................................................................................................7 2. Quick Start Manual.............................................................................................................8 2.1. PC PLUG-IN..............................................................................................................9 2.2. MRU SELECT............................................................................................................9 2.3. SEARCH....................................................................................................................9 2.4. CONNECT...............................................................................................................11 2.5. ENJOY....................................................................................................................14 2.6. DISCONNECT..........................................................................................................14 2.7. Setting....................................................................................................................15 2.8. PC PLUG-OUT.........................................................................................................16 Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 4 Page 2007-09-05 1. Product Overview 1.1. Model specification Model Name Ear jack Bluetooth NAND Flash USB UVB-N52S X 2.0 512MB 2.0 UVB-N52D O 2.0 512MB 2.0 UVB-N62S X 2.0 1024MB 2.0 UVB-N62D O 2.0 1024MB 2.0 UVB-N72S X 2.0 2048MB 2.0 UVB-N72D O 2.0 2048MB 2.0 UVB-N82S X 2.0 4096MB 2.0 UVB-N82D O 2.0 4096MB 2.0 UVB-Nx2x ① USB H/W Spec. PC Interface USB 2.0 Plug and play ( Easy installation ) Power Consumption < 1000 mW Voltage 5.0 V ±10 % VDC ( USB Bus POWERD ) Operating Temp -10 °C ~ 60 °C Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 5 Page 2007-09-05 Functional Features ② Plug and Play: No need Driver and Installation ③ Bluetooth USB Dongle „ Chipset : CSR Bluecore 4–ROM (Bluetooth 2.0) „ Class II : range 10[meter] „ Frequency : 2.2 ~ 2.4835 GHZ ISM Band „ Bluetooth Stack : A2DP, HFP, HSP, AVRCP supported, (Bluetooth 2.0) ④ USB 2.0, NAND Flash Memory : can be used as a flash storage ⑤ VoIP : Skype Software Autorun support ⑥ Wired Ear-jack(Stereo) interface for Skype (UBV-Nx2D only) ⑦ Mono & Stereo Switching (High Quality Bluetooth headset only) „ VoIP Call : Mono sound Music Play : Stereo sound ⑧ Windows XP(preferred), 2000, Vista(later) supported Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 6 Page 2007-09-05 1.2. Product’s combination of 3-Components. 1.2.1. Dongle component ① Definition „ Hardware component with USB 2.0 interface. ② Function „ Removable Disk „ Bluetooth 1.2 ‹ Audio source for A2DP profile supported ‹ Audio gateway for HFP & HSP profile supported ‹ AVRCP profile supported. „ Wired Stereo Ear-jack interface(UVB-N52D only) 1.2.2. UBManager component ① Definition „ Software component for windows „ When plug-in PC, it will be automatically executed „ When plug-out PC, it will be automatically terminated ② Function „ It will control the Interface between UBDongle and Skype „ It will provide the Bluetooth-related functions such as searching, connecting, and disconnecting of Bluetooth Headset. Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 7 Page 2007-09-05 1.2.3. Dialer component ① Definition „ Software component for PC „ Skype is used for Dialer „ It will be automatically executed „ When plug-out PC, it will be automatically terminated ② Function „ It will provide VoIP function. Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 8 Page 2007-09-05 2. Quick Start Manual Operation flow diagram is below. NO MRU SELECT NEW SEARCH CONNECT PLUG-IN YES ENJOY PLUG-OUT DISCONNECT Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 9 Page 2007-09-05 2.1. PC PLUG-IN ① Plug UBDongle in PC via USB ② UBManager will be executed automatically ③ UBManager executes Skype Dialer when connecting Bluetooth headset ④ UBManager supports a tray menu 2.2. MRU SELECT ① MRU means the abbreviation of “Most Recently Used” ② Icon list means Bluetooth headsets which have been used previously. ③ User will choice whether try to connect new device or not. ‹ New device connection goes to “Search” ‹ Previously used device connection goes to “Connect” 2.3. SEARCH ① Bluetooth headset must be in paring mode for this procedure. ② Click “Search” button. Model UVB-Nx2x Version 0.3 Title UVB-Nx2x Spec. & Quick Manual CONFIDENTIAL 10 Page 2007-09-05 ③ User can set the max Search Time in setting menu. (default : 10 sec). ④ After searching new Bluetooth devices and then found device is added…

Text truncated - open the document above for the full version.

September 3, 2007 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : UBISTAR CO.,LTD. FCC ID : RFLUVB-N82D Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (File name: [RFLUVB-N82D] SCH.pdf), Parts list(File name: [RFLUVB-N82D] PL.pdf), Block diagram (File name: [RFLUVB-N82D] BLK.pdf), and Operational description (File name: [RFLUVB-N82D] OpDes.pdf). The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, __________________________ Eun-Kyung Park Assistant Manager 4F, Onse Bldg., 192-2, Gumi-Dong, Bundang-Gu, Sungnam-Si, Gyounggi-Do, 463-782, Korea

Model No.: UVB-N82D FCC ID: RFLUVB-N82D Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 2 Model No.: UVB-N82D FCC ID: RFLUVB-N82D Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 2

FCC ID: RFLUVB-N82D Copyright Ⓒ 2007, LTA Co., Ltd. SAMPLE LABEL & LOCATION Note: 1. Because The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual. M/N: UVB-N82D FCC ID: RFLUVB-N82D Made in Korea

Model No.: UVB-N82D FCC ID: RFLUVB-N82D Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 2 Model No.: UVB-N82D FCC ID: RFLUVB-N82D Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 2

Ref. No.: LR500190708E Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 29 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: August 14 ~ 20, 2007 Test Report S/N: LR500190708E Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT FCC Classification : FHSS Sequence Spread Spectrum (FHSS) Manufacturing Description : VoIP & Bluetooth Dongle Manufacturer : UBISTAR CO.,LTD. Model name : UVB-N82D, UVB-N72D, UVB-N62D, UVB-N52D Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2402 ~ 2480MHz RF power Class : 0.002 W - Conducted Data of issue : August 22, 2007 This test report is issued under the authority of: The test was supervised by: Dong –Min JUNG, Technical Manager Kyung-Taek LEE, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 RFLUVB-N82D UBISTAR CO.,LTD. Ref. No.: LR500190708E Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 29 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 TTANSMITTER OUTPUT POWER ---------------------------------------------------------- 3.2.6 BAND – EDGE ----------------------------------------------------------------------------------- 3.2.7 FIELD STRENGTH OF HARMONICS ------------------------------------------------------ 3.2.8 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 6 6 7 7 9 12 14 16 18 23 25 28 Ref. No.: LR500190708E Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 29 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2007-09-30 ECT accredited Lab. RRL KOREA KR0049 2009-06-20 EMC accredited Lab. FCC U.S.A 610755 2008-03-28 FCC filing VCCI JAPAN R2133, C2307 2008-06-22 VCCI registration IC CANADA IC5799 2008-04-23 IC filing Ref. No.: LR500190708E Copyright ○ c 2007, LTA Co., Ltd. Page 4 of 29 2. Information’s about test item 2-1 Applicant Company name : UBISTAR CO.,LTD. Address : 4F, Onse Bldg., 192-2, Gumi-Dong, Bundang-Gu, Sungnam-Si, Gyounggi-Do, 463-782, Korea Tel / Fax : +81-1688-6226 / +81-31-738-6400 2-2 Manufacturer List Company name : UBISTAR CO.,LTD. Address : 4F, Onse Bldg., 192-2, Gumi-Dong, Bundang-Gu, Sungnam-Si, Gyounggi-Do, 463-782, Korea 2-3 Equipment Under Test (EUT) Trade name : VoIP & Bluetooth Dongle FCC ID : RFLUVB-N82D Model name : UVB-N82D Variant Model name : UVB-N72D, UVB-N62D, UVB-N52D (Æ Refer to the Model Description) Serial number : Identical prototype Flash memory : 4GByte / 2GByte/ 1GByte / 512MByte Date of receipt : August 07, 2007 EUT condition : Pre-production, not damaged Antenna type : Chip antenna, Max Gain 0.65dBi Frequency Range : 2402 ~ 2480MHz Bluetooth version : V2.0 Æ The BlueCore 4-rom is a single-chip radio and baseband IC for Bluetooth systems including EDR. Æ But This device is not used EDR mode by manufacturer. RF output power Range : 0.002 W - Conducted Number of channels : 79 Channel spacing : 1MHz Channel Access Protocol : Frequency Hopping Type of Modulation : GFSK Power Source : 5VDC by USB Port of Main PC 2-4 Tested frequency LOW MID HIGH Frequency (MHz) 2402 2441 2480 Ref. No.: LR500190708E Copyright ○ c 2007, LTA Co., Ltd. Page 5 of 29 2-5 Ancillary Equipment Equipment Model No. Serial No. Manufacturer PC dx2200Microtower CNG6500RX9 HP Monitor VS11353 E060T4021/1-1 View Sonic Keyboard SK-8115 641-OEWW DELL Mouse MO56UO 510022473 DELL Print Deskjet 600K SG7631B1XX HP - - - - 2-6 Model Description Model Name Memory Size UVB-N82D 4 GBytes UVB-N72D 2 GBytes UVB-N62D 1 GBytes UVB-N52D 512 MBytes Ref. No.: LR500190708E Copyright ○ c 2007, LTA Co., Ltd. Page 6 of 29 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) Carrier Frequency Separation > 25 kHz C 15.247(a) Number of Hopping Frequencies > 15 hops C 15.247(a) 20 dB Bandwidth - C 15.247 Dwell Time < 0.4 seconds C 15.247(b) Transmitter Output Power < 1Watt C 15.247(d) Conducted Spurious emission > 20 dBc C 15.247(d) Band Edge > 20 dBc Conducted C 15.249 / 15.209 Field Strength of Harmonics < 54 dBuV (at 3m) C 15.109 Field Strength - Radiated C 15.207 /15.107 AC Conducted Emissions EN 55022 Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this t…
