RHHPAN05In Wall Single relay (1 way) switch

PAN05-1/-2/-3 In Wall Single relay(1 way) switch module P Fig 1. Assembling This in-wall switch module is a transceiver which is a Z-WaveTM enabled device and is fully compatible with any Z-WaveTM enabled network. Mini size design let the module can easily hide itself into the wall box and that will be good for the house decoration. There are many kind of application by using the module to switch Load On and Off , one main application is the light control. If connect the com port directly to AC Line terminal ,the new smart relay calibration technology can reduce the inrush current caused by the load and let the module work perfectly with many kind of light like incandescent, fluorescent and LED light. This module can also connect to alternative power supply like DC 12V to switch on/off 12V MR-16 light as follow picture. Adding to Z-Wave TM Network In the front casing, there is an on/off button with LED indicator below which is used to toggle switch on and off or carries out inclusion, exclusion, reset or association. After being excluded, its LED flashes on and off alternately and repeatedly at 2-second in- tervals. It implies that it has not been assigned a node ID and cannot work with Z- Wave enabled devices. Auto Inclusion The function of auto inclusion will be executed as long as the in wall switch does not have Node ID and just connect the switch to main power. Note: Auto inclusion timeout is 2 minute during which the node information of explorer frame will be emitted once every 5 seconds. Unlike “inclusion” function as 1 shown in the table below, the execution of auto inclusion is free from pressing the On/Off button on the Switch. The table below lists an operation summary of basic Z-Wave functions. Please refer to the instructions for your Z-WaveTM Certificated Primary Controller to access the Setup function, and to include/exclude/associate devices FunctionDescriptionLED Indication No node IDThe Z-Wave Controller does not allocate a node ID to the Switch. 2-second on, 2-second off Inclusion1.Have Z-Wave Controller entered inclusion mode. One press one flash 2. Pressing Include button of PAN05 three times within 2 seconds will enter inclusion mode. Exclusion1.Have Z-Wave Controller entered exclusion mode. One press one flash 2.Pressing Include button of PAN05 three times within 2 seconds will enter exclusion mode. Node ID has been excluded.2-second on, 2-second off Reset1.Pressing Include button of PAN05 three times within 2 seconds will enter inclusion mode. 2.Within 1 second, press Include button of PAN05 again for 5 seconds until LED is off. 3.IDs are excluded. Association1.Have Z-Wave Controller entered association mode. Or Pressing Include button of PAN05 three times within 2 seconds will enter association mode One press one flash 2. There are only 1 group for the switch ※ Including a node ID allocated by Z-Wave Controller means inclusion. Excluding a node ID allocated by Z-Wave Controller means exclusion. ※ Failed or success in including/excluding the node ID can be viewed from the Z-Wave Controller. Sometimes people are not easy to execute exclusion or inclusion especially when PAN05 already installed in a wall box. To solve this issue, PAN05 support a special feature that can use S1 or S2 to execute “exclusion, inclusion, Reset or Association” at the first 3 minutes when first time connect to main power. LED Indication To distinguish what mode the switch is in, view from the LED for identification. State TypeLED Indication NormalWhenever we switch On and off of the PAN05 by S1 S2 or On/Off button or RF command , the LED will lights up 1 second and then 2 off. No node IDUnder normal operation, when the Switch has not been allocated a node ID, the LED flashes on and off alternately at 2-second intervals. By pressing S1 S2 or On/Off button, it will stop flashing temporarily. However, after disconnect and reconnect the Switch, the LED will flash on and off alternately at 2-second intervals. LearningWhen PAB01 is in learning mode, LED flashes on and off alternately and repeatedly at 0.5 second intervals. Choosing a Suitable Location 1.Do not locate the Switch facing direct sunlight, humid or dusty place. 2.The suitable ambient temperature for the Switch is 0°C~40°C. 3.Do not locate the Switch where exists combustible substances or any source of heat, e.g. fires, radiators, boiler etc. 4.After putting it into use, the body of Switch will become a little bit hot of which phenomenon is normal. Installation 1.Put the in wall switch into a wall box and connect the AC power wire L,N to PAN05 connector L, N. 2.Connect the wall switch to the PAN05 as Fig1 . 3.There are 3 mode PAN05 can be configured to match different kind of wall switch, please refer to 3-1 Edge / Pulse / Edge-Toggle mode which described in next section of this user manual. 4.If Edge-Toggle mode has been set, and the S1 S2 is connect to normal bi-stable switch, every time when change the state of the wall switch will also swap the state of Relay1. Programming 1. Basic Command Class / Binary Switch Command Class The Switch will respond to BASIC and BINARY commands that are part of the Z- 3 Wave system. 1-1 BASIC_GET / BINARY_SWITCH_GET Basic Get Command: [Command Class Basic, Basic Get] Basic Report Command: Report OFF: [Command Class Basic, Basic Report, Value = 0(0x00)] Report ON:[Command Class Basic, Basic Report, Value = (255)0xFF] Binary Switch Get Command:[Command Class Switch Binary, Switch Binary Get] Binary Switch Report Command: Report OFF:[Command Class Switch Binary, Switch Binary Report, Value =0(0x00)] Report ON:[Command Class Switch Binary, Switch Binary Report, Value = (255)0xFF] 1-2 BASIC_SET / SWITCH_BINARY_SET [Command Class Basic, Basic Set, Value = (255)0xFF]: the load attached to the Switch turns on. [Command Class Basic, Basic Set, Value = 0(0x00)]: the load attached to the Switch turns off. [Command Class Switch Binary, Switch Binary Set, Value = (255)0xFF]: the load attached to the Switch turn…
