RHHPSE02Multi Sound Siren

Multi Sound Siren PSE02 The multi sound siren PSE02 is a wireless siren, based on Z-Wave TM technology. Z-Wave TM is a wireless communication protocol designed for home automation, specifically to remotely control applications in residential and light commercial environments. The technology uses a low-power RF radio embedded or retrofitted into home electronics devices and systems, such as lighting, home access control, entertainment systems and household appliances. This device is one component of the Z-Wave TM system and is designed to work with all other Z-Wave TM enabled devices in a home control network. The device adopt the Z-Wave TM 400 series chip, when your Z- Wave TM network system is all made by Z-Wave TM 400 series devices. The network system will have the advantages as below. •Concurrent multi-channel support reduces external interference. •Better RF range, improve about 10 meters in indoor. •Support 100 Kbps transmit speed, speed up communication. Product Overview Adding to Z-Wave TM Network There are one tamper key behind the device. It could inclusion, exclusion, reset or association from Z-Wave TM network. In the first time, add the device into the Z-Wave TM network. First, make sure the primary controller is in the inclusion mode. And then power on the device. The device will auto start the NWI (Network Wide Inclusion) mode. And it should be included in 5 seconds. You will see the LED light ON one second. Function Description Inclusion 1.Have Z-Wave TM Controller entered inclusion mode. 2.Pressing tamper key three times within 1.5 seconds will enter inclusion mode. 3.After inclusion successful, the device will wake to receive the setting command from Z-Wave TM Controller about 20 seconds. 1 Siren Tamper Key Circle Button Battery (Optional) DC Jack Exclusion 1.Have Z-Wave TM Controller entered exclusion mode. 2.Pressing tamper key three times within 1.5 seconds will enter exclusion mode. Node ID has been excluded. Reset 1.Pressing tamper key four times within 1.5 seconds and do not release the tamper key in the 4 th pressed, and the LED will turn ON. 2.After 3 seconds the LED will turn OFF, after that within 2 seconds, release the tamper key. If successful, the LED will light ON one second. Otherwise, the LED will flash once. 3.IDs are excluded and all settings will reset to factory default. Association 1.Have Z-Wave TM Controller entered association mode. 2.Pressing tamper key three times within 1.5 seconds will enter association mode. Note: The device support 6 groups. The group 1 is for receiving the report message, like tamper event. The group 2 to 6 will map to different sound, when the device got the BASIC Set 0xFF, it will check is the node in which group, and play the mapping sound. The group 2 mapping to emergency alarm. The group 3 mapping to fire alert. The group 4 mapping to ambulance sound. The group 5 mapping to police car sound. The group 6 mapping to door chime. •Including a node ID allocated by Z-Wave TM Controller means inclusion. Excluding a node ID allocated by Z-Wave TM Controller means exclusion. •Failed or success in including/excluding the node ID can be viewed from Z-Wave TM Controller. Notice 1: Always RESET a Z-Wave TM device before trying to add it to a Z-Wave TM network. Notice 2: When the device into NWI mode, any tamper key and sensor functionality will useless. The NWI will timeout after 3 minutes. Z-Wave TM Message Report * Tamper Report: When the tamper key is pressed over 5 seconds. The device will into the alarm state. In that state, if the tamper key be released, the device will unsolicited to send the “Sensor Binary Report” to the nodes in the group 1. Sensor Type: Tamper (0x08) Sensor Value: 0xFF * Siren Alarm State Report: When the siren start playing or stop the alarm sounds, the device will unsolicited to send the “Sensor Binary Report” to the nodes in the group 1. Sensor Type: General Purpose (0x01) Sensor Value: 0xFF (Start play), or 0x00 (Stop play) Power Up Procedure When the power on, the device will check is it already adding to the network? If doesn't, it will auto start the NWI mode. The LED will flash in every second and continue 3 minutes. Until timeout or the device successful to inclusion by controller. 2 Play Sound The device supports using BASIC SET or SWITCH_MULTILEVEL SET to play the sound. The sound ID is define as follow: 1: Emergency sound. 2: Fire alert. 3: Ambulance sound. 4: Police car sound. 5: Door chime. 6~99: Beep Beep. 0: means stop the sound, but will check the priority. And the 255 is a special one, if the node priority is 1 or 7, the device will play the last sound. The priority 2 will play emergency sound. The priority 3 will play fire alert. The priority 4 will play ambulance sound. The priority 5 will play police car sound. The priority 6 will play door chime. Priority Specification The association group 1 to 6, not only for report message and mapping to the play sound. It also setting the priority number too. For instance the node added in the group 3 and this node's priority number will be 3 too. And the node not find in any group, its priority will be 7. The smaller priority number will have higher priority. When the device is playing the sound ID 1, only the node with priority 1 or 2 can stop it or change playing another sound. Playing sound ID 2, stop by priority 3,2,1. Playing sound ID 3, stop by priority 4,3,2,1. Playing sound ID 4, stop by priority 5,4,3,2,1. Manual Battery Shutdown When the DC power is dropped. The system will auto switch to use the battery power. If you want to really shutdown the system, please follow instructions as below. 1.Press and hold the circle button. 2.Click the tamper 3 times in 1.5 seconds. 3.Release the circle button. 4.If shutdown successful, the LED will flash 3 times. After the battery shutdown, the system won't work anymore, unless the DC power recovery. Z-Wave Configuration Settings Notice: The data size of the configuration settings is 1. NO.NameDefaul…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT PSE02-2 Page 2 DCH-Z510 Page 3 Page 4

2.95cm 2.20cm

Page 5 PSE02-2 Page 6 DCH-Z510 Page 7 Page 8 Page 9 Page 10 Page 11

FCC ID: RHHPSE02 Report No.: RF140926C08 Operational Description This device is a Multi Sound Siren. The transmitter of the EUT is powered by 5Vdc (adapter) or 3.7Vdc (battery). The antenna is Monopole antenna without connector. For more detailed instruction, please take a look at the user’s manual.

Report No.: RF140926C08 1 of 27 Report Format Version 5.0.0 FCC TEST REPORT REPORT NO.: RF140926C08 MODEL NO.: PSE02-2 (Refer to item 3.1 for more details) FCC ID: RHHPSE02 RECEIVED: Sep. 26, 2014 TESTED: Oct. 08 ~ Oct. 14, 2014 ISSUED: Oct. 15, 2014 APPLICANT: Philio Technology Corporation ADDRESS: 8F., No.653-2, Zhongzheng Rd., Xinzhuang Dist., New Taipei City 24257, Taiwan (R.O.C) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140926C08 2 of 27 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD .............................................................................................................. 3 1. CERTIFICATION ......................................................................................................................... 4 2. SUMMARY OF TEST RESULTS ................................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY .............................................................................................. 5 3. GENERAL INFORMATION ......................................................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................ 6 3.2 DESCRIPTION OF TEST MODES .............................................................................................. 7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................................. 8 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................ 9 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ......................................................................... 9 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................... 10 4. TEST TYPES AND RESULTS ................................................................................................... 11 4.1 RADIATED EMISSION AND BAND EDGE MEASUREMENT .................................................. 11 4.1.1 LIMITS OF RADIATED EMISSION AND BAND EDGE MEASUREMENT ............................... 11 4.1.2 TEST INSTRUMENTS .............................................................................................................. 12 4.1.3 TEST PROCEDURES ............................................................................................................... 13 4.1.4 DEVIATION FROM TEST STANDARD ..................................................................................... 13 4.1.5 TEST SETUP ............................................................................................................................ 14 4.1.6 EUT OPERATING CONDITIONS .............................................................................................. 14 4.1.7 TEST RESULTS ........................................................................................................................ 15 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................................ 21 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ......................................................... 21 4.2.2 TEST INSTRUMENTS .............................................................................................................. 21 4.2.3 TEST PROCEDURES ............................................................................................................... 22 4.2.4 DEVIATION FROM TEST STANDARD ..................................................................................... 22 4.2.5 TEST SETUP ............................................................................................................................ 22 4.2.6 EUT OPERATING CONDITIONS .............................................................................................. 22 4.2.7 TEST RESULTS ........................................................................................................................ 23 5. PHOTOGRAPHS OF THE TEST CONFIGURATION ............................................................... 25 6. INFORMATION ON THE TESTING LABORATORIES .............................................................. 26 7. APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB .…
