RIYEL2614Hand Held Transmitter

EL-2614 The EL-2614 is a keyfob transmitter designed for use with Electronics Line 3000’s supervised wireless range of receivers. Registration To register the EL-2614: 1. Set the receiver to Registration mode. 2. Press one of the buttons, making sure that the LED lights up when the button is pressed. 3. Press the same button again to complete the registration process. Battery Replacement If the LED blinks during transmissions, this indicates that the batteries are low and need replacing. To replace the batteries: 1. Insert a small screwdriver into the pry-off slot – see Figure 2. Carefully twist the screwdriver to separate the front and back of the casing. 2. Observing correct polarity, replace the batteries. 3. Close the casing making sure that the front and back click shut. Technical Specifications Antenna: Built-in whip Frequency: 418MHz FM Power: 2 x 3V Lithium Battery, Size CR1225 (Part No. BT5099) Current Consumption: 16mA (transmission), 2μA (standby) RFI Immunity: 40V/m Operating Temperature: 32-140°F (0 to 60°C) Dimensions: 2.4”H X 1.7”W X 0.6”D (62 x 42 x 15mm) FCC ID: RIYEL2614 Figure 1: EL-2614 Figure 2: Opening the Casing Figure 3: EL-2614 Rear View (Casing Open) Battery Holders Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequenc y energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna, 2. Increase the separation between the equipment and the receiver, 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected, 4. Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Electronics Line 3000 Ltd.) could void the user’s authority to operate the equipment. Electronics Line 3000 Ltd.: 2 Granit Street, Kiryat Arieh, POB 3253, Petah Tikvah 49130 Israel. Tel: (972-3) 918-1333, Fax: (972-3) 922-0831 USA: 5637 Arapahoe Avenue, Boulder, Colorado 80303. Tel: (800) 683-6835, Fax: (303) 938-8062 UK: Unit 7, Leviss Trading Estate, Station Road, Stechford, Birmingham B33 9AE. Tel: (44-121) 789-8111, Fax: (44-121) 789-8055 France: ZI-61, rue du Marché Rollay, 94500 Champigny-Sur-Marne. Tel: (33-1) 45.16.19.20, Fax: (33-1) 45.16.19.29 ZI0311A (11/03) All data is subject to change without prior notice. In no event shall Electronics Line 3000 Ltd. (EL3K) be liable for an amount in excess of EL3K.’s original selling price o f this product, for any loss or damage whether direct, indirect, incidental, consequential or otherwise arising out of any failure of the product.

February 25, 2004 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 USA Subject: Request for confidentiality for remote control transmitter, model number EL2614, FCC ID:RIYEL2614 Dear Gentlemen, We apply to you with request to withhold Electronics Line 3000 Ltd. trade secrets in Application for Certification for remote control transmitter, model number EL2614, FCC ID:RIYEL2614. These trade secrets can be found in the schematic_EL2614_15673 diagram (2 pages of this Application). Many thanks in advance. Shaul Aviezer Q.A & Approvals manager Electronics Line 3000 Ltd.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 4, 2004 RE: Electronics Line 3000 Ltd. FCC ID: RIYEL2614 I have a few comments on the above referenced Application. EMC Report 1) The device appears to contain a daughter board. Please provide additional photographs of both sides of the daughter board and also the area underneath the daughter board located on the main board. 2) The operational description provided is simply a TX attestation. Please provide an exhibit for the operational description. 3) The fundamental appears lower than typically expected. Please confirm that the span was reduced at the fundamental in order to obtain good dynamic range during the final measurement (i.e. < 50 MHz span generally speaking). For instance, the large span used in the plots of 700 MHz has a loss of dynamic range due to the large span vs quick sweep time. The plots provide are usually sufficient to obtain areas of interest. 4) Please provide information to show/support compliance to 15.231(a)(1), ie .- test data. Please note that historically the FCC always request test data to show the device shuts off properly, regardless of an attestation. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 23, 2004 RE: Electronics Line 3000 Ltd. FCC ID: RIYEL2614 I have a few comments on the above referenced Application. EMC Report 1) The fundamental appears unusually lower than typically expected. Please confirm that the span was reduced at the fundamental in order to obtain good dynamic range during the final measurement (i.e. < 50 MHz span generally speaking). For instance, the large span used in the plots of 700 MHz has a loss of dynamic range due to the large span vs quick sweep time. The plots provide are usually sufficient to obtain areas of interest. Additionally, please confirm that the device was checked in all 3 axis as stated in the test report 2) We have not received the plots referenced to show/support compliance to 15.231(a)(1). This information should support the information in #3 below. Please provide. 3) There is contradictory information within the application that needs to be corrected: a) The test report (Section 3.1.1) describes 2 x 800 ms bursts with 1 second between, while the new operational description provided mentions 1 x 800 ms burst. Please confirm which is correct, and provide either a corrected operational description or test report as necessary. Additionally, the plot referenced in #2 above should support this information. Additional Note for compliance to 15.231(a)(1): Note that this TX may continue to TX for the duration that the button is pressed to ensure that the signals are received. For compliance purposes, we are only concerned with how much more time the TX continues to operate once the button being released (i.e. only completes current 800 ms burst, or continues to transmit for 2 more 800 ms bursts, ceases immediately with no further TX, etc.). Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

March 24, 2004 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 Attn: Mr. T. Johnson, Examining Engineer RE: your e-mail dated March 23, 2004; Electronics Line Ltd. FCC ID:RIYEL2614 Dear Mr. Johnson, Please find below the answers to your questions. 1) The plot presented on page 15 of the test report ELERAD_FCC.15673_EL2614_rev1 shows that there are no spurious emissions in 200 - 1000 MHz range. The final measurement of field strength of fundamental was performed at the open area test site with spectrum analyzer tuned to 418.0 MHz and zero span. The EUT was tested in tree orthogonal positions (along X, Y and Z axes). The measured result is recorded on page 7 of the same test report. 2) The test data, file "Test data_15673_EL2614" , were uploaded on March 24, 2004 via "Additional information" folder. 3) The test report ELERAD_FCC.15673_EL2614_rev1 was uploaded on March 24, 2004 via "Test report" folder. Please send your comments to the following e-mail address: [email protected]. Sincerely, Marina Cherniavsky, certification engineer Hermon Laboratories To: "'[email protected]'" <[email protected]> Subject: FCC ID: RIYEL2614 3/24/2004file://C:\DOCUME~1\TIMOTH~1.JOH\LOCALS~1\Temp\eud296.htm

FCC ID:RIYEL2614 Date: February 2004 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs FCC ID:RIYEL2614 Date: February 2004 Page 2 of 3 Photograph No.1 Remote control transmitter Front view FCC ID:RIYEL2614 Date: February 2004 Page 3 of 3 Photograph No.2 Remote control transmitter Rear side view

FCC ID:RIYEL2614 LABEL LABEL LOCATION FCC ID:RIYEL2614

FCC ID:RIYEL2614 Date: March 2004 Page 1 of 8 INTERNAL PHOTOGRAPHS This document contains 7 photographs FCC ID:RIYEL2614 Date: March 2004 Page 2 of 8 Photograph No.1 Remote control transmitter Internal view FCC ID:RIYEL2614 Date: March 2004 Page 3 of 8 Photograph No.2 Remote control transmitter PCB front view FCC ID:RIYEL2614 Date: March 2004 Page 4 of 8 Photograph No.3 Remote control transmitter PCB rear side view FCC ID:RIYEL2614 Date: March 2004 Page 5 of 8 Photograph No.4 Remote control transmitter Internal view FCC ID:RIYEL2614 Date: March 2004 Page 6 of 8 Photograph No.5 Remote control transmitter PCB without daughter board FCC ID:RIYEL2614 Date: March 2004 Page 7 of 8 Photograph No.6 Remote control transmitter Daughter board front view FCC ID:RIYEL2614 Date: March 2004 Page 8 of 8 Photograph No.7 Remote control transmitter Daughter board second side view

EL2611/2614 EL2611: 1-button W/L key-fob transmitter used for panic applications. Includes tx that transmits data in a frequency of 418MHZ, modulated FSK for 1sec. EL2614: Same as EL2614 (same tx, same data), but comprises 4 buttons for activation/deactivation of security system and other auxiliary functions. Low battery transmission: this data is not sent in a special transmit, but waits for first data transmission and will be sent together. For compliance with 15.231(a)(2) refer to test plot

STATEMENT Electronics Line herby state that the following products: EL-2600/2600PI W/L Motion Sensor EL-2645/2645PI W/L Motion Sensor EL-2620 W/l Keypad EL-2611 W/L EL-2614 W/L EL-2601 W/L Magnetic Switch EL-2602 Universal Transmitter EL-2640W/L Incorporate the TX-FM 418MHZ transmitter. All the above mention transmit data pulses for 1sec than automatically stop transmitting by software control. EL-2600/2600PI W/L Motion Sensor EL-2645/2645PI W/L Motion Sensor EL-2601 W/L Magnetic Switch EL-2602 Universal Transmitter once in 67min each of the above transmit a supervision data pulses pattern (same pattern as for the alarm messages) for 1sec (supervision signal) than stop transmitting by software control. Shaul Aviezer Q.A Manager

Hi Timoti The attached is corrected statement EL2611 MANUALY TX (15231(A)(1) ACTIVATE BY A BUTTON DIACTIVATE AFTER 0.8 SEC AUTOMATICALY BY SOFTWARE NO SUPERVISION SIGNAL FOR EL2611 (SEE NEW STATEMENT) EL2611 TRANSMITE 1 BURST OF 800msec El2614 Same as el2611 EL2620 MANUALY TX (15231(A)(1) ACTIVATE BY A BUTTON DIACTIVATE AFTER 0.8 SEC AUTOMATICALY BY SOFTWARE NO SUPERVISION SIGNAL FOR EL2620 (SEE NEW STATEMENT) EL2640 Same as EL2620 El2600 See statement EL2600 send supervision data once in 67 min’ Burst of twice 500msec with 1sec between ELECTRONICS LINE 3000 LTD Security & Beyond Shaul Aviezer. Q.A & Approvals Web: http://www.electronics-line.com/ Email: mailto:[email protected] Tel: +972 3 9211117 Ext': 151 Fax: +972 3 7256107 Subject: RE: Urgent!!! Your products... To: Elly Gazal <[email protected]>, [email protected], [email protected] 3/23/2004file://C:\DOCUME~1\TIMOTH~1.JOH\LOCALS~1\Temp\eudF3.htm

FCC ID:RIYEL2614 Date: March 2004 Page 1 of 6 EL2614 TEST DATA according to FCC part 15 §15.231 (a)(1) FCC ID:RIYEL2614 Date: March 2004 Page 2 of 6 EL2614 remote control transmitter buttons The 4 buttons of the remote control transmitter, model EL2614, are as follows: 1) Lock ON 2) Lock OFF 3) Light 4) Home Please see the attached operational description. The transmission duration data attached below in plots No.1 to No.4. FCC ID:RIYEL2614 Date: March 2004 Page 3 of 6 Plot No.1 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2614 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Lock ON Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2614 Date: March 2004 Page 4 of 6 Plot No.2 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2614 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Lock OFF Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2614 Date: March 2004 Page 5 of 6 Plot No.3 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2614 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Light Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2614 Date: March 2004 Page 6 of 6 Plot No.4 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2614 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Home Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04

This report is in conformity with ISO/IEC 17025. The A2LA logo endorsement applies only to the test methods and the standards that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report must not be reproduced in any form except in full with the approval of Hermon Laboratories Ltd. Page 1 of 31 Document ID: ELERAD_FCC.15673_EL2614_rev1.doc Date of issue: March 2004 HERMON LABORATORIES Electrical Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30500, Israel Tel.+972 4628 8001 Fax.+972 4628 8277 e-mail: [email protected] RADIO TEST REPORT according to 47 CFR Part 15 subpart C §15.231 and subpart B for Electronics Line 3000 Ltd. EQUIPMENT UNDER TEST: Remote control transmitter Model: EL2614 Page 2 of 31 Document ID: ELERAD_FCC.15673_EL2614_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES Contents Contents .................................................................................................................................................................2 1 Project information ........................................................................................................................................3 2 Summary and signatures ..............................................................................................................................4 3 EUT description..............................................................................................................................................5 3.1 G ENERAL....................................................................................................................................................5 4 Test results .....................................................................................................................................................6 4.1 B ANDWIDTH OF EMISSION ACCORDING TO ß 15.231 (C) .................................................................................6 4.2 F IELD STRENGTH OF FUNDAMENTAL, ß 15.231(B)(2) .....................................................................................7 4.3 F IELD STRENGTH OF SPURIOUS RADIATION, ß 15.231(B)(3) ...........................................................................8 4.4 U NINTENTIONAL RADIATED EMISSIONS TEST ACCORDING TO ß15.109...........................................................10 Appendix A - Plots...............................................................................................................................................11 Appendix B - Test equipment used for tests ....................................................................................................21 Appendix C – Antenna factors and cable loss .................................................................................................22 Appendix C - General information .....................................................................................................................31 T EST FACILITY DESCRIPTION.................................................................................................................................31 A BBREVIATIONS AND ACRONYMS...........................................................................................................................31 S PECIFICATION REFERENCES................................................................................................................................31 Page 3 of 31 Document ID: ELERAD_FCC.15673_EL2614_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES 1 Project information Description of equipment under test Test items Remote control transmitter Manufacturer Electronics Line 3000 Ltd. Types (Models) EL2614 Equipment FCC code DSR Applicant information Applicantís responsible person Mr. Shaul Aviezer, Quality and Approvals Manager Company Electronics Line 3000 Ltd. Address 58, Amal street P.O.Box 3253 City Petah Tikva Postal code 49130 Country Israel Telephone number +972 3921 1117 Telefax number +972 3921 2224 Test performance Project number: 15673 Location Hermon Laboratories Receipt date September 4, 2003 Test completed September 21, 2003 Purpose of test Apparatus compliance verification in accordance with emission requirements Test specification(s) 47CFR Part 15, subpart C, ß15.231, ß15.209, ß15.205 and subpart B ß15.109 Page 4 of 31 Document ID: ELERAD_FCC.15673_EL2614_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES 2 Summary and signatures The EUT, remote control transmitter, was tested according to FCC part 15 subpart C, ßß15.231, 15.209, part 15 ß15.109 and found to comply with the standard requirements. Test description Specification reference Tested by Date tested Test report paragraph Verdict Bandwidth of emission 15.231(c) Mr. M. Nikishin, test engineer October 26, 2003 4.1 Pass Field strength of fundamental 15.231(b)(2) Mr. Y. Neuman, test engineer September 8, 2003 4.2 Pass Field strength of spurious radiation 15.231(b)(3) Mr. I. Fershtater, test engineer September 14, 21, 2003 4.3 Pass Radiated emissions 15.109 Mr. I. Fershtater, test engineer September 11, 2003 4.4 Pass Test report prepared by: Mrs. M. Cherniavsky, MScEE, certification engineer ________________ Test report approved by: Mr. Michael Nikishin, MScEE, group leader ________________ Mr. Edward Usoskin, PhD, C.E.O. _______________ Page 5 of 31 Document ID: ELERAD_FCC.15673_EL2614_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES 3 EUT description 3.1 General The EUT, model number EL2614, is a four-button keyfob portable transmitter operating at 418 MHz and designed for use with Electronics Lineís supervised receivers. The device utilizes integral, printed on PCB antenna and is powered by two 3 V lithium batteries; its controller clock generates 4 MHz. The EL2614 general view is shown in Photograph 3.1.1. 3.1.1 EUT compliance with §15.231(a)(1) requirements The EUT is manually activated transmitter, which sends data once for 640 ms and stops automat…

Text truncated - open the document above for the full version.

FCC ID:RIYEL2614 Date: February 2004 Page 1 of 7 SETUP PHOTOGRAPHS This document contains 6 photographs FCC ID:RIYEL2614 Date: February 2004 Page 2 of 7 Photograph No.1 Spurious radiated emissions measurement setup in the anechoic chamber with loop antenna FCC ID:RIYEL2614 Date: February 2004 Page 3 of 7 Photograph No.2 Radiated emissions measurement setup in the anechoic chamber with biconical antenna FCC ID:RIYEL2614 Date: February 2004 Page 4 of 7 Photograph No.3 Radiated emissions measurement setup in the anechoic chamber with log periodic antenna FCC ID:RIYEL2614 Date: February 2004 Page 5 of 7 Photograph No.4 Radiated emissions measurement setup in the anechoic chamber with double ridged guide antenna FCC ID:RIYEL2614 Date: February 2004 Page 6 of 7 Photograph No.5 Radiated emissions measurement setup at the OATS with log periodic antenna FCC ID:RIYEL2614 Date: February 2004 Page 7 of 7 Photograph No.6 Radiated emissions measurement setup at the OATS with double ridged guide antenna
