RIYEL2640Hand Held Security TX

EL-2640 The EL-2640 is a wireless keypad designed for use with the infiniti control panel. This keypad includes three arming keys that activate Full, Part or Perimeter arming modes. Pressing the Full and Perimeter buttons simultaneously generates an SOS panic alarm. Additionally, two Home Automation keys allow remote control over Home Automation modules. Registration To register the EL-2640: 1. Set the control panel to Registration mode. 2. Press a button on the keypad making sure that the LED lights up when the button is pressed. 3. Wait for five seconds and press the same button again. Battery Replacement Every time a key is pressed, the battery status LED is lit. When the battery needs to be replaced, the LED flashes. To replace the battery: 1. Remove the battery cover located at the rear of the unit. To do so, press the release tab using a small screwdriver and lift the cover away from the EL-2640’s plastic housing. 2. Observing correct polarity, replace the 9V alkaline battery. 3. Replace the battery cover making sure that it clicks shut. Wall Mounting To mount the EL-2640 to the wall: 1. Place the mounting bracket in position against the wall and mark the two mounting holes. 2. Install wall anchors in the appropriate positions and mount the bracket to the wall. 3. Place the EL-2640 in the bracket and slide it down until you hear a click. 4. To release the EL-2640, press the release tab in the direction of the wall and remove the unit. Technical Specifications Antenna: Built-in Whip Frequency: 418MHz FM Current Consumption: 25mA (transmission), 3μA (standby) Power: 9V Alkaline Battery (Eveready 522) RFI Immunity: 40V/m Operating Temperature: 32-140°F (0 to 60°C) Dimensions: 5”H X 1.9”W X 1.1”D (128 x 49 x 27mm) FCC ID: RIYEL2640 Figure 2: EL-2640 Mounting Bracket Figure 1: EL-2640 (front and rear view with battery cover removed) 9V Top Mounting Hole Bottom Mounting Hole Release Tab Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequenc y energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna, 2. Increase the separation between the equipment and the receiver, 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected, 4. Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Electronics Line 3000 Ltd.) could void the user’s authority to operate the equipment. Electronics Line 3000 Ltd.: 2 Granit Street, Kiryat Arieh, POB 3253, Petah Tikvah 49130 Israel. Tel: (972-3) 918-1333, Fax: (972-3) 922-0831 USA: 5637 Arapahoe Avenue, Boulder, Colorado 80303. Tel: (800) 683-6835, Fax: (303) 938-8062 UK: Unit 7, Leviss Trading Estate, Station Road, Stechford, Birmingham B33 9AE. Tel: (44-121) 789-8111, Fax: (44-121) 789-8055 France: ZI-61, rue du Marché Rollay, 94500 Champigny-Sur-Marne. Tel: (33-1) 45.16.19.20, Fax: (33-1) 45.16.19.29 ZI0313A (11/03) All data is subject to change without prior notice. In no event shall Electronics Line 3000 Ltd. (EL3K) be liable for an amount in excess of EL3K.’s original selling price of this product, for any loss or damage whether direct, indirect, incidental, consequential or otherwise arising out of any failure of the product.

EL 2640 Remote Control Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on Pu sh Bu t t on 418 MHz Logic & control RF TX Voltage Conditioner Voltage regulator Battery

February 25, 2004 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 USA Subject: Request for confidentiality for wireless portable keypad, model number EL2640, FCC ID:RIYEL2640 Dear Gentlemen, We apply to you with request to withhold Electronics Line 3000 Ltd. trade secrets in Application for Certification for wireless portable keypad, model number EL2640, FCC ID:RIYEL2640. These trade secrets can be found in the schematic_EL2640_15673 diagram (1 page of this Application). Many thanks in advance. Shaul Aviezer Q.A & Approvals manager Electronics Line 3000 Ltd.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 9, 2004 RE: Electronics Line 3000 Ltd. FCC ID: RIYEL2640 I have a few comments on the above referenced Application. EMC Report 1) The device appears to contain a daughter board. Please provide additional photographs of both sides of the daughter board and also the area underneath the daughter board located on the main board. 2) The operational description provided is simply a TX attestation. Please provide an exhibit for the operational description. 3) It is uncertain how this device transmits. Does it transmit for each key pressed (for example when each number is pressed)? Note that for each key pressed, this is actually considered sending data. Please explain what types of control signals are being sent to meet the expected requirements of 15.231(a). Note that it appears that maybe a control signal is not necessary to be sent with each button press. Please explain. Note that it may be best to place this device under 15.231(e) as it does appear to meet these limits. Please review. 4) Please provide information to show/support compliance to 15.231(a)(1), ie .- test data. Please note that historically the FCC always request test data to show the device shuts off properly, regardless of an attestation. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 23, 2004 RE: Electronics Line 3000 Ltd. FCC ID: RIYEL2640 I have a few comments on the above referenced Application. EMC Report 1) It appears that the devices intent may be to only send data (keys entered) to a receiver. Note that devices intended strictly for data transmission only must be approved under 15.231(e). Note that device does appear to meet the limits of 15.231(e) as given in the test report. Approval to 15.231(a)(1) or 15.231(a)(2) may only be done if the RF packet includes control signals (see next page for a description from recent FCC Report and Order). It is uncertain what is contained in the RF interface transmission for this device. For instance, does it transmit a packet with data only for the entered code, or send data each time a key is pressed or wait and send data with a control signal (arm/disarm), etc. Note that a control code must be sent with every transmission for use under 15.231(a)(1) or 15.231(a)(2). If data only is sent for certain types of transmissions, then compliance must be shown under 15.231(e). Please confirm if the device is being approved under 15.231(e) or alternatively, please explain what types of control signals are being sent to meet the expected requirements of 15.231(a). A theory of operation describing the information contained in each type of packet may be necessary to adequately show compliance to 15.231(a). 2) We have not received the plots referenced to show/support compliance to 15.231(a)(1). This information should support the information in #3 below. Please provide. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

March 25, 2004 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 Attn: Mr. T. Johnson, Examining Engineer RE: your e-mail dated March 23, 2004; Electronics Line Ltd. FCC ID:RIYEL2640 Dear Mr. Johnson, Please find below the answer to your question. 2) a) The test data, file "Test data_15673_EL2640" , were uploaded on March 25, 2004 via "Additional information" folder. b) The test report ELERAD_FCC.15673_EL2640_rev1 was uploaded on March 25, 2004 via "Test report" folder. Please send your comments to the following e-mail address: [email protected]. Sincerely, Marina Cherniavsky, certification engineer Hermon Laboratories To: "'Timothy R. Johnson'" <[email protected]> Subject: RE: FCC ID: RIYEL2640 Page 1 of 1In 3/25/2004Printed for "Timothy R. Johnson" <[email protected]>

FCC ID:RIYEL2640 Date: February 2004 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs FCC ID:RIYEL2640 Date: February 2004 Page 2 of 3 Photograph No.1 Wireless portable keypad Front view FCC ID:RIYEL2640 Date: February 2004 Page 3 of 3 Photograph No.2 Wireless portable keypad Rear side view

FCC ID:RIYEL2640 WIRELESS PORTABLE KEYPAD LABEL LABEL LOCATION Label

FCC ID:RIYEL2640 Date: March 2004 Page 1 of 8 INTERNAL PHOTOGRAPHS This document contains 7 photographs FCC ID:RIYEL2640 Date: March 2004 Page 2 of 8 Photograph No.1 Wireless portable keypad Internal view FCC ID:RIYEL2640 Date: March 2004 Page 3 of 8 Photograph No.2 Wireless portable keypad PCB front view FCC ID:RIYEL2640 Date: March 2004 Page 4 of 8 Photograph No.3 Wireless portable keypad PCB rear side view FCC ID:RIYEL2640 Date: March 2004 Page 5 of 8 Photograph No.4 Wireless portable keypad Internal view FCC ID:RIYEL2640 Date: March 2004 Page 6 of 8 Photograph No.5 Wireless portable keypad PCB without daughter board view FCC ID:RIYEL2640 Date: March 2004 Page 7 of 8 Photograph No.6 Wireless portable keypad Daughter board view FCC ID:RIYEL2640 Date: March 2004 Page 8 of 8 Photograph No.7 Wireless portable keypad Daughter board second side view

EL2620/2640 EL2620: 16-button W/L keypad used for activating/deactivating security system and various auxiliary functions. Includes tx that transmits CONTROL CODES in a frequency of 418MHZ modulated FSK EL2640: Same as EL2620 (same tx, same CONTRO CODES) but comprises 15 buttons. Each press on any button send a Control codes of 800msec burst Control code is a burst of pulses include indentification of the device and control command to the receiver For 15.231 (a)(2) compliant refer to test plot

STATEMENT Electronics Line herby state that the following products: EL-2600/2600PI W/L Motion Sensor EL-2645/2645PI W/L Motion Sensor EL-2620 W/l Keypad EL-2611 W/L EL-2614 W/L EL-2601 W/L Magnetic Switch EL-2602 Universal Transmitter EL-2640W/L Incorporate the TX-FM 418MHZ transmitter. All the above mention transmit data pulses for 1sec than automatically stop transmitting by software control. EL-2600/2600PI W/L Motion Sensor EL-2645/2645PI W/L Motion Sensor EL-2601 W/L Magnetic Switch EL-2602 Universal Transmitter once in 67min each of the above transmit a supervision data pulses pattern (same pattern as for the alarm messages) for 1sec (supervision signal) than stop transmitting by software control. Shaul Aviezer Q.A Manager

EL2640 Description : EACH BUTTON ACTIVATES THE TRANSMMITER FOR PERIOD OF 800 MSEC Sincerely Shaul Aviezer Q.A & Approvals

FCC ID:RIYEL2640 Date: March 2004 Page 1 of 8 EL2640 TEST DATA according to FCC part 15 §15.231 (a)(1) FCC ID:RIYEL2640 Date: March 2004 Page 2 of 8 EL2640 remote control (wireless keypad) transmitter buttons The 15 buttons of the remote control transmitter, model EL2640, are as follows: 1) Panic 2) Full 3) Perimeter 4) Light ON 5) Light OFF 6) Numbers (0 – 9) Please see the attached operational description. The transmission duration data attached below in plots No.1 to No.6. FCC ID:RIYEL2640 Date: March 2004 Page 3 of 8 Plot No.1 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2640 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Panic Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2640 Date: March 2004 Page 4 of 8 Plot No.2 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2640 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Full Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2640 Date: March 2004 Page 5 of 8 Plot No.3 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2640 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Perimeter Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2640 Date: March 2004 Page 6 of 8 Plot No.4 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2640 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Light ON Button Duration = 640 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2640 Date: March 2004 Page 7 of 8 Plot No.5 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2640 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Light OFF Button Duration = 880 ms Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04 FCC ID:RIYEL2640 Date: March 2004 Page 8 of 8 Plot No.6 Date/Time 3/16/2004 Title Periodic operation requirements EUT Model Number EL2640 Site Description Anechoic chamber Operator Name A. Troupiansky Customer Name Electronics Line 3000 Ltd. Humidity 35% Temperature 21°C Air pressure 1018 hPa Notes Number 1 Button Duration = 640 ms The transmission duration of all number buttons is the same. Test equipment: HL 0521, 1562 Manufacturer information HL Serial No. Description Name Model No. Serial No. Due Calibr. Month/Year 0521 Spectrum analyzer with RF filter section (EMI receiver 9 kHz - 6.5 GHz) Hewlett Packard 8546A 0319 9/04 1562 Oscilloscope 100 MHz, DMM Tektronix THS720A 9444 9/04

This report is in conformity with ISO/IEC 17025. The A2LA logo endorsement applies only to the test methods and the standards that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report must not be reproduced in any form except in full with the approval of Hermon Laboratories Ltd. Page 1 of 31 Document ID: ELERAD_FCC.15673_EL2640_rev1.doc Date of issue: March 2004 HERMON LABORATORIES Electrical Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30500, Israel Tel.+972 4628 8001 Fax.+972 4628 8277 e-mail: [email protected] RADIO TEST REPORT according to 47 CFR Part 15 subpart C §15.231 and subpart B for Electronics Line 3000 Ltd. EQUIPMENT UNDER TEST: Remote control (wireless keypad) transmitter Model: EL2640 Page 2 of 31 Document ID: ELERAD_FCC.15673_EL2640_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES Contents Contents .................................................................................................................................................................................. 2 1 Project information......................................................................................................................................................... 3 2 Summary and signatures............................................................................................................................................... 4 3 EUT description .............................................................................................................................................................. 5 3.1 GENERAL.................................................................................................................................................................... 5 4 Test results ..................................................................................................................................................................... 6 4.1 BANDWIDTH OF EMISSION ACCORDING TO ß 15.231 (C) ................................................................................................... 6 4.2 FIELD STRENGTH OF FUNDAMENTAL, ß 15.231(B)(2) ....................................................................................................... 7 4.3 FIELD STRENGTH OF SPURIOUS RADIATION, ß 15.231(B)(3) ............................................................................................. 8 4.4 UNINTENTIONAL RADIATED EMISSIONS TEST ACCORDING TO ß15.109.............................................................................. 10 Appendix A - Plots................................................................................................................................................................ 11 Appendix B - Test equipment used for tests...................................................................................................................... 21 Appendix C – Antenna factors and cable loss................................................................................................................... 22 Appendix C - General information ...................................................................................................................................... 31 TEST FACILITY DESCRIPTION................................................................................................................................................... 31 ABBREVIATIONS AND ACRONYMS............................................................................................................................................. 31 SPECIFICATION REFERENCES.................................................................................................................................................. 31 Page 3 of 31 Document ID: ELERAD_FCC.15673_EL2640_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES 1 Project information Description of equipment under test Test items Remote control (wireless keypad) transmitter Manufacturer Electronics Line 3000 Ltd. Types (Models) EL2640 Equipment FCC code DSR Applicant information Applicantís responsible person Mr. Shaul Aviezer, Quality and Approvals Manager Company Electronics Line 3000 Ltd. Address 58, Amal street P.O.Box 3253 City Petah Tikva Postal code 49130 Country Israel Telephone number +972 3921 1117 Telefax number +972 3921 2224 Test performance Project number: 15673 Location Hermon Laboratories Test performed from September 8 to October 26, 2003 Purpose of test Apparatus compliance verification in accordance with emission requirements Test specification(s) 47CFR Part 15, subpart C, ß15.231, ß15.209, ß15.205 and subpart B ß15.109 Page 4 of 31 Document ID: ELERAD_FCC.15673_EL2640_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES 2 Summary and signatures The EUT, remote control transmitter, was tested according to FCC part 15 subpart C, ßß15.231, 15.209, part 15 ß15.109 and found to comply with the standard requirements. Test description Specification reference Tested by Date tested Test report paragraph Verdict Bandwidth of emission 15.231(c) Mr. M. Nikishin, test engineer October 26, 2003 4.1 Pass Field strength of fundamental 15.231(b)(2) Mr. Y. Neuman, test engineer September 8, 2003 4.2 Pass Field strength of spurious radiation 15.231(b)(3) Mr. I. Fershtater, test engineer September 14, 21, 2003 4.3 Pass Radiated emissions 15.109 Mr. I. Fershtater, test engineer September 11, 2003 4.4 Pass Test report prepared by: Mrs. M. Cherniavsky, MScEE, certification engineer ________________ Test report approved by: Mr. Michael Nikishin, MScEE, group leader ________________ Mr. Edward Usoskin, PhD, C.E.O. _______________ Page 5 of 31 Document ID: ELERAD_FCC.15673_EL2640_rev1.doc Date of Issue: March 2004 HERMON LABORATORIES 3 EUT description 3.1 General The EUT, model number EL2640, is a wireless portable keypad transmitter operating at 418 MHz and designed for use with Electronics Lineís îInfiniteî control panel. The device…

Text truncated - open the document above for the full version.

FCC ID:RIYEL2640 Date: February 2004 Page 1 of 7 SETUP PHOTOGRAPHS This document contains 6 photographs FCC ID:RIYEL2640 Date: February 2004 Page 2 of 7 Photograph No.1 Spurious radiated emissions measurement setup in the anechoic chamber with loop antenna FCC ID:RIYEL2640 Date: February 2004 Page 3 of 7 Photograph No.2 Radiated emissions measurement setup in the anechoic chamber with biconical antenna FCC ID:RIYEL2640 Date: February 2004 Page 4 of 7 Photograph No.3 Radiated emissions measurement setup in the anechoic chamber with log periodic antenna FCC ID:RIYEL2640 Date: February 2004 Page 5 of 7 Photograph No.4 Radiated emissions measurement setup in the anechoic chamber with double ridged guide antenna FCC ID:RIYEL2640 Date: February 2004 Page 6 of 7 Photograph No.5 Radiated emissions measurement setup at the OATS with log periodic antenna FCC ID:RIYEL2640 Date: February 2004 Page 7 of 7 Photograph No.6 Radiated emissions measurement setup at the OATS with double ridged guide antenna
