RIYEL2635Repeater for Wireless Sensors

Introduction The EL-2635 is a wireless repeater designed to extend the range of wireless devices registered to the infiniti control panel. Up to four repeaters can be registered to the control panel with eight transmitters registered to each repeater. The repeater is powered by either 9VAC (via a 110VAC plug-in step down transformer) or 12VDC with a 6V rechargeable backup battery pack. Registration and maintenance tests are performed using a plug-in LCD programming keypad that provides a comprehensive interface to the repeater. Installation 1. Register all wireless devices to the infiniti control panel as explained in the infiniti installation manual. 2. On the control panel, define the detection devices that are intended to transmit via the repeater as follows: • From the Programming menu, select Devices, Zones [911]. • Select the zone you want to program (1-32). • From the zone’s sub-menu, select Repeater [#9]. • Select “Use Repeater”. Note: It is not necessary to define, at the control panel, the keypads and keyfobs that are registered to the repeater. 3. Open the EL-2635’s plastic housing. To do so, remove the two cover screws and lift the front cover away from the base. Figure 2: EL-2635 (cover removed) 4. Connect the antenna provided to the antenna connector. 5. Connect the backup battery pack to the Battery connector. 6. Connect 9VAC (via a 110VAC plug-in step down transformer) or a 12VDC transformer to the Power Input terminal block. 7. All registration and test functions, described in the following sections, are performed from the LCD programming keypad shown in Figure 3. Connect the programming keypad to the Programming Keypad connector. Note: The programming keypad is not able to operate on battery power only. 8. Test the repeater from the required mounting location before permanently mounting the unit. 9. Mount the base to the wall using four screws and replace the front cover. When the tamper switch is open, the bi-color LED provides indication regarding repeater transmission and reception as an aid during the installation procedure – see Table 1. When the tamper switch is closed, the bi-color LED provides indication regarding power status – see Table 2. Registering the Repeater to the Control Panel For the control panel to recognize the repeater, you must register the repeater to the control panel. To register the repeater to the control panel: 1. Set the control panel to Registration mode as follows: • From the Programming menu, select Devices, Repeaters [914]. • Select the repeater you want to register (1-4). • From the repeater’s sub-menu, select Register [#1]. 2. Send two Status transmissions from the repeater as follows: • On the programming keypad, press  until 5. STS Transmit appears on the display. • Press . • Press  again. 3. Confirm registration to the control panel as follows: • When Save? appears on the control panel’s LCD display, press . Antenna Connecto r Programming Keypad Connector Lower Mounting Hole Upper Mounting Hole Lower Mounting Hole LED Indicator Receiver Tamper Switch AC Power Protection Fuse Upper Mounting Hole Transmitter Flash Programming Connector Power Input Terminals Wiring Hole Figure 3: LCD Programming Keypad Figure 1: Typical Single Repeater Application LED Indication Description Flashing Green Signal Reception Flashing Red Signal Transmission Table 1: LED Indication (Tamper Open) LED Indication Description Steady Green AC & Battery OK Flashing Red AC Loss Flashing Orange Low Battery Table 2: LED Indication (Tamper Closed) Backup Battery Pack Battery Connector Registering Transmitters to the Repeater You can register up to eight transmitters to the EL-2635 repeater. Note: Do not register the same transmitter to more than one repeater. To register transmitters to the repeater: 1. On the LCD programming keypad, press  until 4. TX Register appears on the display. 2. Press ; New Device appears on the display. 3. Press  again; Transmit 1 appears on the display. 4. Send two transmissions from the device you want to register. 5. When the transmitter number and Save? appear on the display, press  to confirm registration. Note: The EL-2635 repeater automatically allocates a transmitter number to each newly registered device. Write this number and the zone number on the sticker provided with the sensor and stick it inside the transmitter’s cover for future reference. 6. After you have confirmed registration, the display returns to New Device. Press  to register another device or  to exit Registration mode. Deleting Registered Transmitters To delete transmitters from the repeater’s register: 1. On the LCD programming keypad, press  until 3. TX Delete appears on the display. 2. Press ; the first transmitter in the list appears on the display. 3. Use the arrow navigation keys (/) to scroll to the transmitter you want to delete. 4. Press  to select the transmitter. 5. Press again for confirmation; the transmitter is deleted. 6. Select another transmitter to delete or press  to exit. Installer Utilities The EL-2635 repeater offers two installer utilities that serve as a valuable aid during installation and maintenance. TX List The TX List is a scrollable inventory of all registered transmitters and their last reported signal strength. To view the TX list: 1. Press  until 1. TX List appears on the display. 2. Press ; the first transmitter in the list is displayed. 3. Use the arrow navigation keys (/) to scroll through the list. 4. Press  to exit the list. TX Test TX Test is a utility that enables you to identify registered transmitters and test their signal strength. To perform a TX test: 1. Press  until 2. TX Test appears on the display. 2. Press . 3. Activate a transmitter; the transmitter number, type and signal strength are displayed. 4. Press  to exit TX Test mode. Technical Specifications Frequency: 868.35MHz, 433.92MHz or 418MHz FM Antenna: External Whip Operating Voltage: 9VAC (1332 plug-in transformer) or 12VDC Backup Bat…

Text truncated - open the document above for the full version.

EL2635 REPEATER BLOCK DIAGRAM Controller Osc’: 8 MHz RX OSC’ : XTAL 12.728125 X 32 TX OSC’ : XTAL 13.0625 X 32 ANT’ : WEAP ANT’ TRANSMITER IN USE IS TXFM MELAXIS

March 28, 2005 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 USA Subject: Request for confidentiality for wireless repeater, model number EL2635, FCC ID:RIYEL2635 Dear Gentlemen, We apply to you with request to withhold Electronics Line 3000 Ltd. trade secrets in Application for Certification for wireless repeater, model number EL2635, FCC ID:RIYEL2635. These trade secrets can be found in two files of schematic diagrams: “Schematic_16338” and “Schematic_Melaxis_16338” (4 pages of this Application). Many thanks in advance. Shaul Aviezer Q.A & Approvals manager Electronics Line 3000 Ltd.

PROFESSIONAL INSTALLATION FOR INFINITE SYSTEM The INFINITE system must be installed by professional installer due to: 1. the system must be programmed by professional installer, installation of hardware is not enough 2. According to paragraph 1 sold by mail or directly to the end user is impossible. 3. From the above it understood that the installer need a special training to program the system 4. Electronics Line 3000 Ltd from the above reason sell the systems to dealers or distributors only. 5. Electronics Line 3000 Ltd Customer Care Department responsible for training and explanation of the system to the customers. 6. Dealers and distributor responsible to train the installers INFINITE system includes: 1. INFINITE w/l control unit 2. w/l Detectors 3. w/l Sensors 4. w/l Repeater 5. Accessories If you have any question or comments, please don’t hesitate to contact our office. Sincerely Shaul Aviezer Q.A & Approvals

FCC ID:RIYEL2635 Date: March 2005 Page 1 of 6 EXTERNAL PHOTOGRAPHS This document contains 5 photographs FCC ID:RIYEL2635 Date: March 2005 Page 2 of 6 Photograph No.1 EL2635 wireless repeater General view FCC ID:RIYEL2635 Date: March 2005 Page 3 of 6 Photograph No.2 EL2635 wireless repeater Rear side view without antenna FCC ID:RIYEL2635 Date: March 2005 Page 4 of 6 Photograph No.3 EL2635 wireless repeater with antenna removed FCC ID:RIYEL2635 Date: March 2005 Page 5 of 6 Photograph No.4 EL2635 wireless repeater Antenna connection view FCC ID:RIYEL2635 Date: March 2005 Page 6 of 6 Photograph No.5 EL2635 wireless repeater Antenna connector

FCC ID:RIYEL2635 Date: March 2005 Label location Page 1 of 1 EL2635 wireless repeater label Label location The label with FCC ID:RIYEL2635 will be located on the repeater bottom side as shown below. FCC ID:RIYEL2635

FCC ID:RIYEL2635 Date: March 2005 Page 1 of 10 INTERNAL PHOTOGRAPHS This document contains 9 photographs FCC ID:RIYEL2635 Date: March 2005 Page 2 of 10 Photograph No.1 EL2635 wireless repeater Internal view FCC ID:RIYEL2635 Date: March 2005 Page 3 of 10 Photograph No.2 EL2635 wireless repeater PCB front view FCC ID:RIYEL2635 Date: March 2005 Page 4 of 10 Photograph No.3 PCB front view without RF module, daughter PCB and battery pack FCC ID:RIYEL2635 Date: March 2005 Page 5 of 10 Photograph No.4 PCB second side view FCC ID:RIYEL2635 Date: March 2005 Page 6 of 10 Photograph No.5 RF module view FCC ID:RIYEL2635 Date: March 2005 Page 7 of 10 Photograph No.6 RF module with screen removed FCC ID:RIYEL2635 Date: March 2005 Page 8 of 10 Photograph No.7 RF module PCB second side FCC ID:RIYEL2635 Date: March 2005 Page 9 of 10 Photograph No.8 Daughter PCB front view FCC ID:RIYEL2635 Date: March 2005 Page 10 of 10 Photograph No.9 Daughter PCB second side view

Page 1 of 1 EL2535 Wireless Repeater operation description The Electronics Line 3000 Ltd. Wireless Repeater EL2635 (also known as Range Extender) is part of the Infinite® Intrusion Alarm Systsem. The EL2635 cannot function as a power amplifier for non-registered devices. That is, it will re-transmit devices that were previously registered to it during the Intrusion Alarm System installation. This is achieved by: 1. Demodulating received signals 2. Identify the devices’ unique code from the demodulated signal 3. Compare to the internal registered device list 4. Modulate and re-transmit ONLY devices that are registered The EL2635 can handle up to 8 Wireless devices, such as PIR detectors, Magnet Open/Close Door detectors. Re-transmission captures half the airtime of the original device, by using X2 clock for the re- transmission. Transmiter in use is TX FM MELAXIS ANT’ in use is WEAP Wireless device RF transmission pattern (any Electronics Line 3000 Ltd. Wireless device): EL2635 re-transmission of registered device RF transmission pattern: 250mSec 250mSec 0.5 Sec to 1.5 Sec 0.5 Sec to 1.5 Sec 500mSec 500mSec
