RVVBSLIMPF1The BLUE SLIM FAMILY is a tag used for advertising through an antenna

Specifications could be modified without any notification. Non-contractual document. www.elainnovation.com Copyright © 2018 ELA Innovation RVVBSLIMPF1_User Man_v2.docx SLIM FAMILY Ref. IDF03XXX Ultra slim format: 2.4 mm adhesive face Very high range: up to 300 meters (open field) Lifecycle: up to 2 years with 10 seconds transmission period Integrated NFC chipset TECHNICAL SPECIFICATIONS Battery power supply 3 VDC - Lithium internal battery Frequency 2,4 GHz range Operating mode Periodic data transmission Power output Up to +4dBm (programmable) Transmission range Up to 300 meters (open field / + 4dBm) Transmission period 0,1 to 10 second (programmable) Lifecycle 2 years (Beacon rate = 10s with 0dBm power) Radio frame format ID: 15 characters name Unique 48 bits MAC address ID (ELA) compliant Settings & configuration Interface/Protocol: NFC (type 2) Device Manager software or Device Manager Mobile Android App Operating temperature -20°C to +55°C Battery level management 15% remaining battery warning Housing ABS Material 56 x 30,6 x 2,4mm - 2 housing 4mm holes, space 43mm Weight 6gr - High adhesive back side Standards CE (Europe)*: EN 300 328/ EN 300 330/ EN 301 489 & EN 55032 / EN 62368-1 FCC (USA): FCC PART 15 ISED/IC (Canada): RSS-247 / ICES-003 RoHS certified FCC ID RVVBSLIMPF1 IC 20429-BSLIMPF1 Specifications could be modified without any notification. Non-contractual document. www.elainnovation.com Copyright © 2018 ELA Innovation RVVBSLIMPF1_User Man_v2.docx FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference; and 2. This device must accept any interference received, including interference that may cause undesired operation. § 15.21 Information to user The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. Sample RF exposure test exclusion Given that the calculation of the RF exposure was performed with a 20cm value, test exclusions are applicable as the minimum test separation distance is ≤ 50 mm, and the transmission frequencies between 100 MHz and 6 GHz. Industry Canada Statement This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d’ISED applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. Le dispositif ne doit pas produire de brouillage préjudiciable, et 2. Ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.

ELA Innovation S.A. au capital de 396.822 € - RCS de Montpellier - 432 799 278 00036 – TVA FR78432799278 297, rue Maurice Béjart, 34080 MONTPELLIER, France - Tél. 33 (0)4 67 47 60 60 - www.ela.fr BLUE SLIM Confidentiality request letter_v2.docx 1 Federal Communications Commission Authorization and Evaluation Division Montpellier, France, January 28, 2020 Subject: Confidentiality Request regarding application for certification of FCC ID: RVVBSLIMPF1 Applicant: ELA Innovation S.A. Product: BLUE SLIM FAMILY To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Parts List RVVBSLIMPF1_BlkDia.pdf RVVBSLIMPF1_Schem.pdf RVVBSLIMPF1_OpDes.pdf RVVBSLIMPF1_PartsLst.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. If you have any queries, please do not hesitate to contact us. Yours faithfully, Pierre Bonzom, January 28, 2020

ELA Innovation S.A. au capital de 396.822 € - RCS de Montpellier - 432 799 278 00036 – TVA FR78432799278 297, rue Maurice Béjart, 34080 MONTPELLIER, France - Tél. 33 (0)4 67 47 60 60 - www.ela.fr RVVBSLIMPF1 _Cover letter_v2.docx 1 Montpellier, France, January 28, 2020 Subject: Certification of the BLUE SLIM FAMILY Applicant: ELA Innovation S.A. Product: BLUE SLIM FAMILY FCC ID: RVVBSLIMPF1 IC ID: 20429-BSLIMPF1 To Whom It May Concern: We would like to submit the above product for Certification concerning FCC and ISED certification. Please review all required documents enclosed. The BLUE SLIM FAMILY meets the industrial requirements of people and equipment indoor location. This tracking system also makes possible movement tracking of handling machines in real time and thus facilitate fleet management inside buildings. Compliance for RF exposure requirement was demonstrated in the test report. If you have any queries, please do not hesitate to contact us. Yours faithfully, Pierre Bonzom, January 28, 2020

Page 1 FCC ID: RVVBSLIMPF1 IC: 20429-BSLIMPF1

Label Location FCC ID : RVVBSLIMPF1 IC : 20429-BSLIMPF1 Label Location

Label Sample FCC ID: RVVBSLIMPF1 IC: 20429-BSLIMPF1

Page 1 FCC ID: RVVBSLIMPF1 IC: 20429-BSLIMPF1 Page 2

RR410-19-104019-2A Ed.0 Duplication of this test report is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample.  Siège Social : Emitech - 3, rue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B ACCREDITATION N° 1-2043 PORTEE DISPONIBLE SUR WWW.COFRAC.FR Test report issued under the responsibility of: EMITECH MONTPELLIER laboratory MRA US-EU Designation Number: FR0006 Canadian CAB Identifier: FR0003 RADIO TEST REPORT FCC part 15 FCC part 15.247 RSS-247_Issue 2, February 2017 ANSI C 63.10: 2013 ANSI C 63.4: 2014 Company ......................................... : ELA INNOVATION Address............................................. : 297 RUE MAURICE BEJART 34080 MONTPELLIER FRANCE Test item description. .................... : BLUE SLIM FAMILY Trade Mark. ...................................... : BLUE SLIM FAMILY Manufacturer. ................................... : ELA INNOVATION Model/Type reference. ...................... : IDF03XXX FCC ID. ............................................. : RVVBSLIMPF1 IC. ..................................................... : 20429-BSLIMPF1 Ratings.............................................. : 2,6Vdc to 3Vdc Testing Laboratory ......................... : EMITECH MONTPELLIER laboratory Address............................................. : 145 rue de Massacan 34740 VENDARGUES FRANCE Report Reference No. ..................... : RR410-19-104019-2A Test procedure. ................................ : FCC IC Certification Diffusion. ........................................... : MR LEBRUN Applicant’s name. ............................. : ELA INNOVATION Date of issue. .................................... : February 19, 2020 Total number of pages. ..................... : 68 Revision. ........................................... : 0 Modified page(s). .............................. : Creation Compiled by. ..................................... : Olivier AELBRECHT Approved by (+ signature). ............... : David MONTAULON (Technical Manager) RR410-19-104019-2A Ed.0 Page 2 on 68  REPORT INDEX: 1. GENERAL INFORMATIONS .......................................................................................................................... 3 2. REFERENCE DOCUMENT(S) ........................................................................................................................ 4 3. EQUIPMENT TECHNICAL DESCRIPTION .................................................................................................... 5 3.1. TEST CONDITIONS ................................................................................................................................... 5 3.2. EUT MARKING PLATE .............................................................................................................................. 5 3.3. EUT GENERAL VIEW ................................................................................................................................ 6 3.4. EUT ELECTRONIC BOARD ........................................................................................................................ 6 3.5. EUT MECHANICAL AND ELECTRICAL DESIGN ............................................................................................. 7 3.6. EUT INPUT/OUTPUT PORTS ...................................................................................................................... 7 3.7. EUT RADIO SPECIFICATIONS .................................................................................................................... 8 4. EUT REQUIREMENTS FOR FCC RULES ..................................................................................................... 9 4.1. SUBPART A - GENERAL ............................................................................................................................ 9 4.2. SUBPART B - UNINTENTIONAL RADIATORS .............................................................................................. 11 5. OPINION(S) AND INTERPRETATION(S)..................................................................................................... 11 6. RESULT SUMMARY ..................................................................................................................................... 12 7. RF EXPOSURE ............................................................................................................................................. 12 8. MEASUREMENT UNCERTAINTY ................................................................................................................ 13 9. TEST CONDITIONS AND RESULTS ........................................................................................................... 14 9.1. DUTY CYCLE OF TEST SIGNAL ................................................................................................................ 14 9.2. TRANSMITTER RADIATED SPURIOUS EMISSIONS AT FREQUENCIES <30MHZ ............................................... 15 9.3. TRANSMITTER RADIATED SPURIOUS EMISSIONS AT FREQUENCIES >30MHZ ............................................... 20 9.4. BAND-EDGE COMPLIANCE ....................................................................................................................... 33 9.5. MAXIMUM PEAK CONDUCTED POWER OF THE INTENTIONAL RADIATOR ....................................................... 40 9.6. 6DB BANDWIDTH FOR DIGITALLY MODULATION SYSTEMS ........................................................................ 48 9.7. POWER SPECTRAL DENSITY ...........…

Text truncated - open the document above for the full version.

FCC ID: RVVBSLIMPF1 IC: 20429-BSLIMPF1
