RXZ-WCB61RL-001802.11 b/g Wireless LAN Cardbus

0 Wireless LAN Cardbus Adapter User’s Manual February, 2004 1 FCC Warning This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Your device contains a low power transmitter. When device is transmitted it sends out RadioFrequency (RF) signal. 2 CE Warning European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range 2.400-2.4835GHz; In France, the equipment must be restricted to the 2.4465-2.4835GHz frequency range and must be restricted to indoor use. For the following equipment: WCB61RL ! 0984 Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC), Low-voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC), the procedures given in European Council Directive 99/5/EC and 89/3360EEC. The equipment was passed. The test was performed according to the following European standards: z EN 300 328 V.1.4.1 (2003-04) z EN 301 489-1 V.1.3.1 (2001-09) / EN 301 489-17 V.1.1.1 (2000-09) z EN 50371: 2002 EN 60950: 2000 Trademarks: All trade names and trademarks are the properties of their respective companies. 3 Contents 1 Introduction ...................................................................... 3 1.1 Features ............................................................................................. 4 1.2 Specifications .....................................................................................4 1.3 Package Contents ............................................................................... 5 2 Software Installation .......................................................... 6 2.1 Install Device Driver ............................................................................ 6 3 Configuration Utility ........................................................... 9 3.1 Ralink Configuration Utility .................................................................. 9 3.1.1 Site Survey ......................................................................................... 9 3.1.2 Profile ............................................................................................... 10 3.1.3 Link Status ........................................................................................ 13 3.1.4 Statistics ............................................................................................ 14 3.1.5 Advance ............................................................................................. 14 3.1.6 ........................................................................................................... 15 3.2 Microsoft Wireless Utility ..................................................................... 16 3.2.1 ........................................................................................................... 17 3.2.2 ........................................................................................................... 18 3.2.3 ............................................................................................................ 19 3.2.4 ............................................................................................................ 19 4 1. Introduction This Wireless LAN Cardbus Adapter is designed to comply with IEEE 802.11g Wireless LAN standard and easy to carry with the compact size. It is suitable for any laptop computers and provides maximum data transfer rate up to 54 Mbps. This Cardbus Adapter supports WEP, WPA and AES high level WLAN security features the guarantee the best security for users. It also supports Windows OS Plug & Play and Cardbus Hot Swap which allows user plug in or remove it without rebooting the system. Wireless LAN Cardbus Adapter operates with Microsoft Windows operating systems such as Windows XP/2000/ME/98SE, it is capable to operate with Ad-hoc mode (pier to pier without an Access Point) or Infrastructure mode (computer to access point, an access point is required). Ad-hoc Mode: An Ad-hoc network is a local area network with wireless or temporary plug-in connections which some of the network devices are part of the network only for the duration of a communication session. Users in the network can share files, network printer and access the Internet with a shared modem. In this kind of network, new devices can be quickly added; however, users can only communicate with other wireless LAN computers that …

Text truncated - open the document above for the full version.

Mike Kuo From: [email protected] Sent: April30 2004 Friday 2:02 AM To: Mike Kuo Cc: Lai, Harris (E-mail); Scott Wang; CCS-Taiwan, Ting (E-mail) Subject: FW: PRO-NETS TECHNOLOGY CORPORATION, FCCId:RXZ-WCB61RL-001, AN04 T3876 5/7/2004 Hi Mike, Here are our replies to your questions. Notice_content ------------- Question #1: Page 57 of EMC test report with peak reading above average limits. Please provide average measurement. Ans #1: The average measurement data is provided. Please refer to the revised test report. Question #2: section 7.7 ( page 59) indicates the EUT was plug-in Host PC via USB port. This device is equipped with PCMCIA interface, how the device is able to plug into USB portion of Host computer. Ans #2: There are typos in Sec. 7.7 (Page 59). Revision is made. Please refer to the revised test report. Sar portion : Question #3: System validation ( page 14 ) , body liquid was used vs body sar but the head simulating liquid was indicated. Please make necessary correction. Ans #3: Correction is made. Please refer to Page 14 of the revised SAR test report. Question #4: Page 17 and 18 of SAR data summary , what is antenna " 1 " for 802.11g OFDM modulation. Is it Antenna A or B ? Ans #3: Antenna A and Antenna B are specified. Please refer to Pages 17 & 18 of the revised SAR test report. Question #5: Page 57 , 63 of SAR data plots indicate the frequency is tuned to 2472MHz which does not agree with SAR test data summary and the highest channel investigated. Please submit SAR test data for these two configuration with channel tuned to 2462MHz. Ans #3: SAR test data are re-submitted. Please refer to the revised SAR test report. User Manual : Question #6: Page 9 of user manual provides the option for the end user to select the country which may cause this device to be operated in the unauthorized frequency channels. Product compliance to operate within authorized channel shall not depend on the user selection. Please address this issue. Ans #3: The option of "Country Selection" is removed. Please refer tothe revised user manual. Best Rgds, WK -----Original Message----- From: CERTADM Sent: Monday, April 26, 2004 6:57 PM To: Mike Kuo Subject: PRO-NETS TECHNOLOGY CORPORATION, FCC Id:RXZ-WCB61RL-001, AN04T3876 Notice_content ------------- Question #1: Page 57 of EMC test report with peak reading above average limits. Please provide average measurement. Question #2: section 7.7 ( page 59) indicates the EUT was plug-in Host PC via USB port. This device is equipped with PCMCIA interface, how the device is able to plug into USB portion of Host computer. Sar portion : Question #3: System validation ( page 14 ) , body liquid was used vs body sar but the head simulating liquid was indicated. Please make necessary correction. Question #4: Page 17 and 18 of SAR data summary , what is antenna " 1 " for 802.11g OFDM modulation. Is it Antenna A or B ? Question #5: Page 57 , 63 of SAR data plots indicate the frequency is tuned to 2472MHz which does not agree with SAR test data summary and the highest channel investigated. Please submit SAR test data for these two configuration with channel tuned to 2462MHz. User Manual : Question #6: Page 9 of user manual provides the option for the end user to select the country which may cause this device to be operated in the unauthorized frequency channels. Product compliance to operate within authorized channel shall not depend on the user selection. Please address this issue. Best Regards Mike Kuo <[email protected]> 2004/04/27 09:57 AM "CCS-Taiwan, Ting (E-mail)" <[email protected]>, "CCS-Taiwan, Wklo (E-mail)" <[email protected]> "Lai, Harris (E-mail)" <[email protected]>, Scott Wang <[email protected]> 5/7/2004 Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. 5/7/2004

Compliance Certification Services Inc. Report No: B40204403 Date of Issue: March 23, 2004 Page 1 of 4 EXTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40204403 Date of Issue: March 23, 2004 Page 2

PANTONE 2695 CVC Down 20%

Compliance Certification Services Inc. Report No: B40204403 Date of Issue: March 23, 2004 Page 3 INTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: B40204403 Date of Issue: March 23, 2004 Page 4

ACX Adv anced Ceram ic X AT7020 Series Multilayer Chip Antenna Features ™ Monolithic SMD with small, low-profile and light-weight type. ™ Wide bandwidth Applications ™2.4GHz WLAN, Home RF, Bluetooth Modules, etc. Specifications Part Number Frequency Range (MHz) Peak Gain (dBi typ.) Average Gain (dBi typ.) VSWR Impedance AT7020 -B2R4HAA_ 2400~2500 2.0 (XZ-V) 0.5 (XZ-V) 2 max. 50 Ω Q’ty/Reel (pcs) : 1,000 pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : -40 ~ +85 o C Power Capacity : 3W max. Part Number AT 7020 - B 2R4 HAA ‡ ghfe dc c Type AT : Antenna d Dimensions ( L × W ) 7.0× 2.0 mm e Material Code B f Frequency Range 2R4=2400MHz g Specification Code HAA h Packaging T: Tape & Reel B: Bulk Terminal Configuration No. Terminal Name No. Terminal Name c Feeding Point d NC d c ACX Adv anced Ceram ic X Dimensions and Recommended PC Board Pattern Unit : mm a W T Mark L W T a Dimensions 7.00.2 2.00.2 1.2+ 0.1/-0.2 0.50.3 *Line width should be designed to match 50Ω characteristic impedance, depending on PCB material and thickness. Typical Electrical Characteristics (T=25 o C) ™ Test Board * * * 2.0 5.5 8.0 1.0 (Matching circuit and component values will be different, depending on PCB layout) Antenna No Ground Ground 20mm 19mm 40mm 9.5mm L 50Ω Feed Line ACX Adv anced Ceram ic X ™Return Loss ACX Adv anced Ceram ic X ™ Radiation Patterns XY cut @2.45GHz Vertical Horizontal XZ cut @2.45GHz Vertical Horizontal XY-V/XY-H XZ-V/XZ-H Z 270 o 0 o X Y XY-cut scanning direction Y Z 0 o 270 o X 180 180 o 90 o 90 o XZ-cut scanning direction Z Y X 90 o 0 o 270 180 YZ-V/YZ-H YZ cut @2.45GHz Vertical Horizontal YZ-cut scanning direction

Compliance Certification Services Inc. Report No: B40204403-SF Date of Issue: March 26, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page1 of 22 ANSI/IEEE Std. C95.1-1992 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C TEST REPORT For PRO-NETS TECHNOLOGY CORPORATION Wireless LAN Cardbus Model: WCB61RL Trade Name: Pro-Nets, SpeedCom, JetCom, Neto Dragon Prepared for PRO-NETS TECHNOLOGY CORPORATION 10F-1, No.92, Pao-Chung Road, Hsin Tien Taipei, Taiwan, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: B40204403-SF Date of Issue: March 26, 2004 Page 3 TABLE OF CONTENTS 1. EUT DESCRIPTION ..................................................................................................... 4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC .... 5 3. DOSIMETRIC ASSESSMENT SYSTEM ................................................................... 5 3.1 MEASUREMENT SYSTEM DIAGRAM .........................................................................6 3.2 SYSTEM COMPONENTS.................................................................................................7 DASY4 Measurement Server.............................................................................................7 Data Acquisition Electronics (DAE)..................................................................................7 ET3DV6 Isotropic E-Field Probe for Dosimetric Measurements ......................................7 SAM Phantom (V4.0) ........................................................................................................8 Device Holder for SAM Twin Phantom ............................................................................8 System Validation Kits ......................................................................................................8 4. EVALUATION PROCEDURES................................................................................... 9 5. MEASUREMENT UNCERTAINTY ......................................................................... 12 6. EXPOSURE LIMIT ..................................................................................................... 13 7. MEASUREMENT RESULTS ..................................................................................... 14 7.1 SYSTEM PERFORMANCE CHECK..............................................................................14 7.2 TEST LIQUID CONFIRMATION ..................................................................................15 7.3 EUT TUNE-UP PROCEDURES......................................................................................16 7.4 SAR MEASUREMENTS RESULTS...............................................................................17 8. EUT PHOTOS .............................................................................................................. 19 9. EQUIPMENT LIST & CALIBRATION STATUS ................................................... 20 10. REFERENCES ............................................................................................................. 21 11. ATTACHMENTS ......................................................................................................... 22 Compliance Certification Services Inc. Report No: B40204403-SF Date of Issue: March 26, 2004 Page 4 1. EUT DESCRIPTION Applicant: PRO-NETS TECHNOLOGY CORPORATION 10F-1,No.92, Pao-Chung Road, Hsin Tien Taipei, Taiwan, R.O.C. Model Number: WCB61RL FCC ID: RXZ-WCB61RL-001 Device Category: PORTABLE DEVICES Exposure Category: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: 802.11b Direct Sequence Spread Spectrum 802.11g Orthogonal Frequency Division Multiplexing (OFDM) Tx Frequency: 2412 ~ 2462 MHz Max. O/P Power: (Conducted/Peak) 18.38dBm Max. SAR (1g): 0.455W/kg Application Type: Certification FCC Rule Part(s): 15C Antennas: Chip Ant. Test Host: Compaq P/N: PP2150 S/N:1V31LDL23407 Compliance Certification Services Inc. Report No: B40204403-SF Date of Issue: March 26, 2004 Page 5 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC The US Federal Communications Commission has released the report and order “Guidelines for Evaluating the Environmental Effects of RF Radiation", ET Docket No. 93-62 in August 1996 [1]. The order requires routine SAR evaluation prior to equipment authorization of portable transmitter devices, including portable telephones. For consumer products, the applicable limit is 1.6 mW/g for an uncontrolled environment and 8.0 mW/g for an occupational/controlled environment as recommended by the ANSI/IEEE standard C95.1-1992 [6]. According to the Supplement C of OET Bulletin 65 “Evaluating Compliance with FCC Guide-lines for Human Exposure to Radio frequency Electromagnetic Fields", released on Jun 29, 2001 by the FCC, the device should be evaluated at maximum output power (radiated from the antenna) under “worst-case” conditions for normal or intended use, incorporating normal antenna operating positions, device peak performance frequencies and positions for maximum RF energy coupling. 3. DOSIMETRIC ASSESSMENT SYSTEM These measurements were performed with the automated near-field scanning system DASY4 from Schmid & Partner Engineering AG (SPEAG). The system is based on a high precision robot (working range greater than 0.9 m) which positions the probes with a positional repeatability of better than ± 0.02 mm. Special E- and H-field probes have been developed for measurements close to material discontinuity, the sensors of which are directly lo…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: B40204403-RP FCC ID: RXZ-WCB61RL-001 Date of Issue: March 22, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 63 FCC 47 CFR PART 15 SUBPART C TEST REPORT For PRO-NETS TECHNOLOGY CORPORATION Wireless LAN Cardbus Model: WCB61RL Trade Name: Pro-Nets, SpeedCom, JetCom, Neto Dragon Prepared for PRO-NETS TECHNOLOGY CORPORATION 10F-1, No. 92, Pao-Chung Road, Hsin Tien, Taipei, Taiwan, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: B40204403-RP FCC ID: RXZ-WCB61RL-001 Date of Issue: March 22, 2004 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION........................................................................................................3 2. EUT DESCRIPTION..............................................................................................................................4 3. TEST METHODOLOGY.......................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION...........................................................................................................7 5. FACILITIES AND ACCREDITATIONS ..............................................................................................8 5.1 FACILITIES....................................................................................................................................... 8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST...........................................................................................10 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................10 6.2 SUPPORT EQUIPMENT ...............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS ................................................................................................11 7.1 6DB BANDWIDTH.............................................................................................................................11 7.2 PEAK POWER....................................................................................................................................16 7.3 BAND EDGES MEASUREMENT ................................................................................................21 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................22 7.5 RADIO FREQUENCY EXPOSURE........................................................................................................32 7.6 SPURIOUS EMISSIONS.................................................................................................................36 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................58 APPENDIX 1 PHOTOGRPHS OF TEST SETUP......................................................................................62 Compliance Certification Services Inc. Report No: B40204403-RP FCC ID: RXZ-WCB61RL-001 Date of Issue: March 22, 2004 Page 4 2. EUT DESCRIPTION Product Wireless LAN Cardbus Trade Name Pro-Nets, SpeedCom, JetCom, Neto Dragon Model Number WCB61RL Model Discrepancy N/A Power Supply Powered from the host device Frequency Range IEEE 802.11b,g: 2412 ~ 2462 MHz Transmit Power IEEE 802.11b: 18.35 dBm IEEE 802.11g: 16.35 dBm Modulation Technique IEEE 802.11b: DSSS (CCK; DQPSK; DBPSK) IEEE 802.11g: OFDM Antenna Gain 2.0 dBi (Max) Antenna Designation Multilayer Chip Antenna Note: This submittal(s) (test report) is intended for FCC ID: RXZ-WCB61RL-001 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No: B40204403-RP FCC ID: RXZ-WCB61RL-001 Date of Issue: March 22, 2004 Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.247. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the TX frequency that was for the purpose of the measurements. According to it…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: B40204403-RP FCC ID: RXZ-WCB61RL-001 Date of Issue: March 22, 2004 Page 62 APPENDIX 1 PHOTOGRPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No: B40204403-RP FCC ID: RXZ-WCB61RL-001 Date of Issue: March 22, 2004 Page 63 Conducted Emission Set Up Photos
