RXZ-WU71RWireless USB Dongle

USB Wireless LAN Adapter User’s Manual November 2010 1 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which - Consult the dealer or an experienced radio/TV technician for help. the receiver is connected. FCC Caution: To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of about eight inches (20cm) between the radiator and your body. This transmitter must not be co‐located or operated in conjunction with any other antenna or transmitter. CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. 2 Copyright 2010 All Rights Reserved. No part of this document can be copied or reproduced in any form without written consent from the company. Revision History Revision History V1.0 1 st Release All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their respective holders. 3 CONTENTS 1. INTRODUCTION........................................................................................................... 4 1.1 F EATURES.............................................................................................................. 4 1.2 P ACKAGE CONTENTS................................................................................................ 4 1.3 LED INDICATOR....................................................................................................... 4 1.4 M INIMUM SYSTEM REQUIREMENTS............................................................................. 5 2. INSTALL DRIVER/UTILITY............................................................................................. 6 3. WIRELESS NETWORK CONFIGURATION ..................................................................... 11 3.1 G ENERAL............................................................................................................. 11 3.2 P ROFILE............................................................................................................... 11 3.3 A VAILABLE NETWORK............................................................................................. 12 3.4 S TATUS................................................................................................................ 14 3.5 S TATISTICS........................................................................................................... 15 3.6 W I‐FI PROTECTED SETUP (WPS) .............................................................................. 15 3.7 E ASY SHARING...................................................................................................... 16 3.8 V IRTUAL WIFI....................................................................................................... 17 4. SOFT‐AP FUNCTION................................................................................................... 23 4.1 S WITCHING TO AP MODE........................................................................................ 24 4.2 G ENERAL............................................................................................................. 25 4.3 A DVANCED........................................................................................................... 26 4.4 S TATISTICS........................................................................................................... 27 4.5 ICS..................................................................................................................... 28 4 1. Introduction This is a wireless 11n USB Adapter that provides unsurpassed wireless performance for your Desktop PC or Notebook. It complies with IEEE 802.11n draft 2.0 wireless standard and is backward compatible with IEEE 802.11b/g. This USB adapter provides better wireless reception and up to 150Mbps data transfer rates in 11n mode. With this adapter, you can easily upgrade your Desktop PC or Notebook wireless connectivity. Once connected, to access the network with high‐speed Internet connection while sharing photos, files, music, video, printers, and storage. Get a better Internet experience with a faster wireless connection so you can enjoy smooth digital phone calls, gaming, downloading, and video streaming. The Wireless USB adapter provides peer‐to‐peer communication among any compatible wireless client users and no Access Point required. It also supports WEP, WPA, WPA2, WPS, 802.1x high‐level …

Text truncated - open the document above for the full version.

WU71R 0681 FCC ID: RXZ-WU71R Attention: According to FCC/CE Legislation, this label shall be adhered to the product permanently. 38 mm 14 mm

MPE Prediction FCC Rule: 15.247(b)(5) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See §1.1307(b)(1) of this Chapter. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average time (minutes) (A)Limits For Occupational / Control Exposures 30-300 61.4 0.613 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 PG S = -------------- 4πR² where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 13.70 (dBm) Maximum peak output power at antenna input terminal: 23.44229 (mW) Antenna gain(maximal): 1.26 (dBi) Prediction distance: 20 (cm) Prediction frequency: 2462 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm²) Power density at prediction frequency: 0.0470 (mW/cm²) The manual instruct the user to install and operate the device in a minimum distance of 20 cm between antenna and the users body.
