RXZ-WP72RLWIRELESS N PCI CARD

IEEE 802.11n Wireless LAN PCI Adapter User’s Manual March 2010 1 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not i n stalled and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the e quipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐ Connect the equipment into an outlet on a circuit different from that to which ‐ Consult th e dealer or an ex perienced radio/TV technician for help. the receiver is connected. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this devi ce must accep t any interference received, including interference that may cause undesired operation. NOTE: All Telecom and safety Tests only include this content hardware device only. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of about eight inches (20cm) between the radiator and your body. This transmitter must not be co‐located or operated in conjunction with any other an tenna or transmit ter. Modular Approval Statement: This device is intended to be used only for OEM integrator under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co‐located with any other transmitter or antenna. 2 IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co‐location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re‐evaluating the end produ ct (including the transmitter) and obtaining a separate FCC authorization. Revision History Revision History V1.0 1st release All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their respective holders. 3 Contents 1. Introduction........................................................................... 4 1.1 Features ................................................................................................... 4 1.2 Familiar with your new wireless network card ......................................... 4 1.3 Package Contents..................................................................................... 5 1.4 Before you start ....................................................................................... 5 1.5 Hardware Installation............................................................................... 6 2. Installation Procedure............................................................... 7 3. Wireless Network Configuration Utility........................................ 13 3.1 RaUI Wireless Utility & Windows Zero Configuration (WZC)................... 13 3.2 Start RaUI Utility .................................................................................... 18 3.3 Profile .................................................................................................... 25 3.3.1 Add/Edit Profile.......................................................................... 26 3.3.2 Example to Add Profile in Profile ................................................ 27 3.4 Network................................................................................................. 29 3.5 Advanced ............................................................................................... 31 3.6 Statistics................................................................................................. 33 3.7 WMM..................................................................................................... 34 3.8 WPS ....................................................................................................... 40 3.9 SSO......................................................................................................... 43 3.10 CCX....................................................................................................... 44 3.11 About ................................................................................................... 45 3.12 Link Status............................................................................................ 45 4. Soft‐AP Function.................................................................... 46 4.1 Switch to AP mode and Basic Configuration ........................................... 46 4.2 Security Settings..................................................................................... 49 4.3 Access Control........................................................................................ 50 4.4 MAC Table.............................................................................................. 51 4.5 Event Log................................................................................................ 51 4.6 Statistics...............................…

Text truncated - open the document above for the full version.

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C1 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 APPENDIX C. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C2 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C3 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C5 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C6 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C7 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255

WP72RL FCC ID:RXZ-WP72RL 38 mm 8 mm R=1 mm FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 18, 2010 FAX : 886-2-2696-2255 label location

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 18, 2010 FAX : 886-2-2696-2255 label location

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C1 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 APPENDIX C. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C2 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C3 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C5 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C6 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C7 OF C7 TEL : 886-2-2696-2468 ISSUED DATE : Apr. 15, 2010 FAX : 886-2-2696-2255

FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : A1 of A3 FCC ID : RXZ-WP72RL Appendix A. Maximum Permissible Exposure FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : A2 of A3 FCC ID : RXZ-WP72RL 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : A3 of A3 FCC ID : RXZ-WP72RL 1.3. Calculated Result and Limit Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11n: 17.38dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 3 1.995262 17.38 54.7016 0.0217

FCC TEST REPORT Report No.: FR9D1746-02AC Page No. : A1 of A3 FCC ID : PXZ-WP72RL Appendix A. Maximum Permissible Exposure FCC TEST REPORT Report No.: FR9D1746-02AC Page No. : A2 of A3 FCC ID : PXZ-WP72RL 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. FCC TEST REPORT Report No.: FR9D1746-02AC Page No. : A3 of A3 FCC ID : PXZ-WP72RL 1.3. Calculated Result and Limit Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11b/g: 17.73dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 3 1.995262 17.73 59.2925 0.0235

FCC TEST REPORT Report No.: FR9D1746-02AI SPORTON International Inc. Report Format Version: a FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : WIRELESS N PCI CARD Model No. : WP72RL Brand Name : PRO-NETS Filin g Type : New Application Applicant : PRO-NETS Technology Corporation 7F, No.95, Lide St., Chung Ho City 235, Taipei, Taiwan, R.O.C. FCC ID : RXZ-WP72RL Manufacturer : EDIMAX TECHNOLOGY CO., LTD. No.3, Wu Chuan 3rd Road, Wu-Ku Industrial Park, Taipei Hsien, Taiwan Received Date : Dec. 22, 2009 Final Test Date : Jan. 05, 2010 Statement Test result included is only for the 802.11n of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No.: FR9D1746-02AI SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC ID : RXZ-WP72RL Table of Contents 1 SUMMARY OF THE TEST RESULT ...................................................................................................................... 2 2 GENERAL INFORMATION ..................................................................................................................................... 3 2.1 Product Details ........................................................................................................................................................................................ 3 2.2 Table for Filed Antenna ........................................................................................................................................................................... 3 2.3 Table for Carrier Frequencies ................................................................................................................................................................. 4 2.4 Table for Test Modes .............................................................................................................................................................................. 4 2.5 Table for Testing Locations ..................................................................................................................................................................... 5 2.6 Table for Supporting Units ....................................................................................................................................................................... 5 2.7 Table for Parameters of Test Software Setting ....................................................................................................................................... 5 2.8 EUT Operation during Test ..................................................................................................................................................................... 5 2.9 Test Configuration ................................................................................................................................................................................... 6 3 TEST RESULT ........................................................................................................................................................ 7 3.1 AC Power Line Conducted Emissions Measurement .............................................................................................................................. 7 3.2 Maximum Conducted Output Power Measurement .............................................................................................................................. 11 3.3 Power Spectral Density Measurement .................................................................................................................................................. 13 3.4 6dB Spectrum Bandwidth Measurement ............................................................................................................................................... 19 3.5 Radiated Emissions Measurement ........................................................................................................................................................ 25 3.6 Band Edge and Fundamental Emissions Measurement ....................................................................................................................... 43 3.7 Antenna Requirements .......................................................................................................................................................................... 48 4 LIST OF MEASURING EQUIPMENTS ................................................................................................................. 49 5 TEST LOCATION .................................................................................................................................................. 51 6 TAF CERTIFICATE OF ACCREDITATION .......................................................................................................... 52 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE.................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS OF EUT ....................................................................................................... C1 ~ C7 FCC TEST REPORT Report No.: FR9D1746-02AI SPORTON International Inc. Page No. : ii of ii …

Text truncated - open the document above for the full version.

FCC TEST REPORT Report No.: FR9D1746-02AC SPORTON International Inc. Report Format Version: a FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : WIRELESS N PCI CARD Model No. : WP72RL Brand Name : PRO-NETS Filin g Type : New Application Applicant : PRO-NETS Technology Corporation 7F, No.95, Lide St., Chung Ho City 235, Taipei, Taiwan, R.O.C. FCC ID : RXZ-WP72RL Manufacturer : EDIMAX TECHNOLOGY CO., LTD. No.3, Wu Chuan 3rd Road, Wu-Ku Industrial Park, Taipei Hsien, Taiwan Received Date : Dec. 22, 2009 Final Test Date : Jan. 05, 2010 Statement Test result included is only for the 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No.: FR9D1746-02AC SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Apr. 15, 2010 FAX : 886-2-2696-2255 FCC ID : RXZ-WP72RL Table of Contents 1 SUMMARY OF THE TEST RESULT ...................................................................................................................... 2 2 GENERAL INFORMATION ..................................................................................................................................... 3 2.1 Product Details ........................................................................................................................................................................................ 3 2.2 Table for Filed Antenna ........................................................................................................................................................................... 3 2.3 Table for Carrier Frequencies ................................................................................................................................................................. 3 2.4 Table for Test Modes .............................................................................................................................................................................. 4 2.5 Table for Testing Locations ..................................................................................................................................................................... 4 2.6 Table for Supporting Units ....................................................................................................................................................................... 4 2.7 Table for Parameters of Test Software Setting ....................................................................................................................................... 4 2.8 EUT Operation during Test ..................................................................................................................................................................... 5 2.9 Test Configuration ................................................................................................................................................................................... 5 3 TEST RESULT ........................................................................................................................................................ 6 3.1 AC Power Line Conducted Emissions Measurement .............................................................................................................................. 6 3.2 Maximum Conducted Output Power Measurement .............................................................................................................................. 10 3.3 Power Spectral Density Measurement .................................................................................................................................................. 12 3.4 6dB Spectrum Bandwidth Measurement ............................................................................................................................................... 18 3.5 Radiated Emissions Measurement ........................................................................................................................................................ 24 3.6 Band Edge and Fundamental Emissions Measurement ....................................................................................................................... 42 3.7 Antenna Requirements .......................................................................................................................................................................... 47 4 LIST OF MEASURING EQUIPMENTS ................................................................................................................. 48 5 TEST LOCATION .................................................................................................................................................. 50 6 TAF CERTIFICATE OF ACCREDITATION .......................................................................................................... 51 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE.................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS OF EUT ....................................................................................................... C1 ~ C7 FCC TEST REPORT Report No.: FR9D1746-02AC SPORTON International Inc. Page No. : ii…

Text truncated - open the document above for the full version.

FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : B1 of B6 FCC ID : RXZ-WP72RL Appendix B. Test Photos FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : B2 of B6 FCC ID : RXZ-WP72RL 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : B3 of B6 FCC ID : RXZ-WP72RL SIDE VIEW FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : B4 of B6 FCC ID : RXZ-WP72RL 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : B5 of B6 FCC ID : RXZ-WP72RL For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FR9D1746-02AI Page No. : B6 of B6 FCC ID : RXZ-WP72RL For radiated emissions above 1GHz FRONT VIEW REAR VIEW
