RXZ-WR514RWireless Broadband Router

Wireless Broadband Router User’s Manual (For SOHO Users) 1 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC RF Radiation Exposure Statement: 1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. 1 Table of Contents 1. Introduction...........................................................................4 1.1 Features ..............................................................................5 1.2 Package Contents ..................................................................6 1.3 LEDs Indication & Connector of Wireless Router.............................7 1.4 System Requirements ............................................................8 1.5 Installation Instruction .............................................................9 2. PC Configuration ...............................................................9 2.1 TCP/IP Networking Setup ........................................................9 2.2 Setting up Internet Access ......................................................18 2.3 Configure Wireless Station ......................................................19 3. Setup Wireless Router Configurations via Web Browser............20 3.1 Start Your Web Browser............................................................20 3.2 Setup Wizard ......................................................................................21 3.2.1 Gateway..........................................................................22 3.2.2 Bridge.............................................................................25 3.2.3 Wireless IP.......................................................................28 3.3 Operation Mode.......................................................................32 3.4 Wireless.................................................................................33 3.4.1 Basic Settings................................................................................33 3.4.2 Advanced Settings.........................................................................33 3.4.3 Security..........................................................................................34 3.4.4 Access Control...............................................................................34 3.4.5 WDS Settings.................................................................................35 3.4.6 Site Survey.....................................................................................35 3.4.7 Easy Config....................................................................................36 3.5 TCP/IP Settings........................................................................43 3.5.1 LAN Interface..................................................................................43. 3.5.2 WAN Interface.................................................................................44. 3.6 Firewall... ...............................................................................45 3.6.1 Port Filtering...................................................................................45 3.6.2 IP Filtering.......................................................................................45 3.6.3 MAC Filtering...................................................................................46 3.6.4 Port Forwarding................................................................................46 3.6.5 URL Filtering....................................................................................47 3.6.6 DMZ.................................................................................................47 3.7 Route Setup.............................................................................48 2 3.8 Management............................................................................49 3.8.1 Status.............................................................................................49 3.8.2 Statistics.........................................................................................50 3.8.3 DDNS.............................................................................................50 3.8.4 Time Zone Setting..........................................................................51 3.8.5 Log..................................................................................................51 3.8.6 Upgrade Firmware...........................................................................52 3.8.7 Save/Reload Setting........................................................................52 3.8.8 Password......…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: 60214208 Date of Issue: May 3, 2006 Page 1 Total Page: 6 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 60214208 Date of Issue: May 3, 2006 Page 2 Rev.00

Corner Radius:R1.5mm 49*19 mm C4mm 2032300000113 中性15/16模WR514R安規貼紙 49*19mm，三面導角R1.5，單邊斜角C4，50#消銀龍，霧面 WR514R IEEE 802.11g FCC ID: RXZ-WR514R This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

Compliance Certification Services Inc. Report No: 60214208 Date of Issue: May 3, 2006 Page 3 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 60214208 Date of Issue: May 3, 2006 Page 4 Rev.00 Compliance Certification Services Inc. Report No: 60214208 Date of Issue: May 3, 2006 Page 5 Rev.00 Compliance Certification Services Inc. Report No: 60214208 Date of Issue: May 3, 2006 Page 6 Rev.00

DESCRIPTION : Swivel Access Point Antenna MODEL NO : RFA-02-C2H1-06-50 1.1 ELECTRICAL Frequency Range: 2400~2500 MHZ Gain: 2.0dBi (min.) VSWR: 2 Polarization: Linear, Vertical Impedance50 Connector: IPEX MHF Cable: 1.13mm 1.2 MECHANICAL ConditionNon operating during test. Material : PCABS(UL94V-0) Endurance Number of 90° rotation of the connector1000 cycles (min.) MandatoryGuaranty of functionalities after test. Bending: Number of 90at the hinge parts and bending on one direction with1 force1000 cycles MandatoryNo mechanical damage tolerated. Guaranty of functionalities after test. Antenna resistance Tests are applicable to all parts and both sides. Traction: Tractions force applied 3 times on plugs during 15 second5 MandatoryNo mechanical damage tolerated. Guaranty of functionalities after test. 1.3 ENVIROMENTAL Storage ConditionNon operating during test. Cold: -40during 72h (IEC 68-2-1 standard Ab/Ad test) Dry heat: +80during 96h (IEC 68-2-2 standard Bb/Bd test) Humidity: +40at 95%R.H. during 4 days (IEC 68-2-56 standard Cb test) MandatoryNo mechanical or visible damage tolerated. Guaranty of functionalities after test. Operation ConditionOperating during test. Cold: -10during 48h (IEC 68-2-1 standard Ab/Ad test) Dry heat: +55during 48h (IEC 68-2-2 standard Bb/Bd test) Composite: -10to +5595%R.H 4 cycles(IEC 68-2-30 standard Nb test) MandatoryNo mechanical or visible damage tolerated. Guaranty of functionalities during and after test.

Compliance Certification Services Inc. Report No.: 60214208-RP1 FCC ID: RXZ-WR514R Date of Issue: April 27, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 59 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Wireless Broadband Router Model: WR514R, WLAN170064-N, Wireless Router, WRO-01, WIPNWR514R, WT-514R, SWABRR-5400, 3340 Tr a d e Na me : PRO-NETS, SpeedCom+, JetCom, UPSPEED, DIGICOM, ASMAX, NILOX, ViewTech, ORANGE, GENX, TORNADO, SAFECOM, Leadership Encore Issued to PRO-NETS TECHNOLOGY CORPORATION 7F,No.95, Li-De St., Chung Ho City 235, Ta i p e i , Ta i w a n R . O . C . Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 60214208-RP1 FCC ID: RXZ-WR514R Date of Issue: April 27, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION....................................................................................................3 2. EUT DESCRIPTION ...........................................................................................................................4 3. TEST METHODOLOGY ....................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................7 4. INSTRUMENT CALIBRATION........................................................................................................8 4.1 MEASURING INSTRUMENT CALIBRATION......................................................................................8 4.2 MEASUREMENT EQUIPMENT USED.........................................................................................8 5. FACILITIES AND ACCREDITATIONS ..........................................................................................9 5.1 FACILITIES .........................................................................................................................................9 5.2 EQUIPMENT........................................................................................................................................9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.....................................................................................10 6. SETUP OF EQUIPMENT UNDER TEST .......................................................................................11 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................11 6.2 SUPPORT EQUIPMENT ...............................................................................................................11 7. FCC PART 15.247 REQUIREMENTS.............................................................................................12 7.1 6DB BANDWIDTH.............................................................................................................................12 7.2 PEAK POWER....................................................................................................................................16 7.3 AVERAGE POWER............................................................................................................................20 7.4 BAND EDGES MEASUREMENT ................................................................................................24 7.5 PEAK POWER SPECTRAL DENSITY....................................................................................................33 7.6 SPURIOUS EMISSIONS ................................................................................................................38 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................52 APPENDIX I RADIO FREQUENCY EXPOSURE ...............................................................................55 APPENDIX II PHOTOGRAPHS OF TEST SETUP .............................................................................57 Compliance Certification Services Inc. Report No.: 60214208-RP1 FCC ID: RXZ-WR514R Date of Issue: April 27, 2006 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: PRO-NETS TECHNOLOGY CORPORATION 7F,No.95, Li-De St., Chung Ho City 235, Taipei, Taiwan R.O.C. Equipment Under Test: Wireless Broadband Router Trade Name: PRO-NETS, SpeedCom+, JetCom, UPSPEED, DIGICOM, ASMAX, NILOX, ViewTech, ORANGE, GENX, TORNADO, SAFECOM, Leadership Encore Model: WR514R, WLAN170064-N, Wireless Router, WRO-01, WIPNWR514R, WT-514R, SWABRR-5400, 3340 Date of Test: March 3 ~ 18, 2006 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209,…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 60214208-RP1 FCC ID: RXZ-WR514R Date of Issue: April 27, 2006 Page 57 Rev. 00 APPENDIX II PHOTOGRAPHS OF TEST SETUP Conducted Emissions Setup Photos Compliance Certification Services Inc. Report No.: 60214208-RP1 FCC ID: RXZ-WR514R Date of Issue: April 27, 2006 Page 58 Rev. 00 Radiated Emissions Setup Photos Compliance Certification Services Inc. Report No.: 60214208-RP1 FCC ID: RXZ-WR514R Date of Issue: April 27, 2006 Page 59 Rev. 00 Powerline Conducted Emissions Setup Photos
