1 IEEE802.11 b/g Outdoor AP/Bridge （Support IEEE802.11a Client Backhaul） WDR2000 User’s Manual Version 1.2 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC ID：SCD0059 3 Table of Contents Table of Contents ...........................................................................................................3 Package Contents ...........................................................................................................5 Hardware Setup..............................................................................................................5 Ethernet & RS-232 Console Connector:................................................................5 PSE BOX : for Power Over Ethernet (POE) .........................................................6 Minimum System Requirements....................................................................................7 Introduction....................................................................................................................7 Features and Benefits .............................................................................................8 Four Operational Modes ................................................................................................9 AP Mode ................................................................................................................9 Repeater Mode .....................................................................................................10 Point to Point Mode .............................................................................................10 Point to Multi Point Mode ................................................................................... 11 Using the Configuration Menu .................................................................................... 11 Device IP Setting Æ Ethernet ..............................................................................13 AP Setting --> Wireless0 or Wireless1 ................................................................14 Encryption............................................................................................................18 Set Encryption to Open System ...................................................................19 Set Encryption to Shared Key......................................................................19 Set Encryption to Open System/Shared Key ...............................................20 Set Encryption to WPA-PSK .......................................................................20 Set Encryption to WPA-Enterprise(802.1x).................................................20 Point to Point Mode Setting Æ Wireless0 or Wireless1 ......................................21 Point to Multi Point Mode Setting Æ Wireless0 or Wireless1 ............................22 Repeater Mode Setting Æ Wireless0 or Wireless1 ..............................................24 Dual Radio Setting For Simultaneous Operation.................................................25 AP and Bridge ..............................................................................................25 AP and AP ....................................................................................................25 Bridge and Bridge ........................................................................................25 DHCP Server Setting Æ DHCP...................................................................................26 WAN Setting Æ WAN ...............................................................................................28 WAN Status Æ WAN Status ........................................................................................30 Admin setting Æ Admin ..............................................................................................31 4 Firewall setting Æ Firewall .........................................................................................33 Virtual Server setting Æ Virtual Server .......................................................................36 Connection Status ...................................…

Text truncated - open the document above for the full version.

LanReady Technologies, Inc. 3F, No.116, Sinhu 2nd Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) TEL: (02) 2796 8188 FAX: (02) 2796 8158 Date: November 17, 2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Taiwan office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS TW, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS TW on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS TW as our agent, we still recognize that we are responsible to: a) Comply with the relevant provisions of the certification program; b) Make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) Make claims regarding certification only in respect of the scope for which certification has been granted; d) Do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) Upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) Use certification only to indicate the products are certified as being in conformity with specified standards; g) Endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) Ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) Keep a record of all complaints made known to the us relating to the product compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) Take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) Document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jason / Engineer LanReady Technologies Inc. Tel: 886-2-27968188 Fax: 886-2-2796-8158 E-Mail:[email protected] REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

LanReady Technologies, Inc. 3F, No.116, Sinhu 2nd Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) TEL: (02) 2796 8188 FAX: (02) 2796 8158 Date :November 17,2006 Federal Communications Commission Authorization and Evaluation Division FCC ID: SCD0059 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Jason / Engineer LanReady Technologies Inc. Tel: 886-2-27968188 Fax: 886-2-2796-8158 E-Mail:[email protected]

1 Helen Zhao Subject: FW: FW: LanReady Technologies Inc., FCC ID: SCD0059, Assessment NO.: AN06T6379, Notice#1 From: amanda.wu [mailto:[email protected]]On Behalf Of application Sent: Monday, January 15, 2007 9:44 PM To: Helen Zhao Subject: Re:FW: LanReady Technologies Inc., FCC ID: SCD0059, Assessment NO.: AN06T6379, Notice#1 Dear Helen: Please see my reply, thank you. Best Regards, Amanda -----Original Message----- Sent: Friday, December 22, 2006 3:52 PM Subject: LanReady Technologies Inc., FCC ID: SCD0059, Assessment NO.: AN06T6379, Notice#1 Question #1: The proposed FCC ID label format does not show the FCC ID is preceded by the term "FCC ID", as required by FCC2.925(a). FCC DoC logo can not replace the term "FCC ID" here. Please revise the ID label format. Ans: The "FCC ID" had been added in the FCC ID label format. Client dec , please see the attchment. Question #2: The operational Description indicates "To implement the concurrent radio operation", two MiniPCI IEEE802.11 a/b/g radio cards are used. Please provide additional information as whether two radios can transmit/receive simultaneously or not, if so, you need to test MIMO mode, if it is for diversity, please provide mechanism to determine which antenna shall be activated. Please provide the updated operational description and block diagram. Please specify whether one radio is limited for operation at 802.11b/g mode, one is limited for operation at 802.11a mode, or not. Ans: Client revised the OpDes as enclosure. Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. WDR2000 Label Sample & Locatio... WDR2000 Theroy of operation Re...

Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 1 Total Page: 9 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 2 Rev.00 Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 3 Rev.00

Rating : 48V 1A DSC09476.JPG

Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 4 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 5 Rev.00 Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 6 Rev.00 Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 7 Rev.00 Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 8 Rev.00 Compliance Certification Services Inc. Report No.: 51028005 Date of Issue: December 1, 2006 Page 9 Rev.00

2 2 2

Compliance Certification Services Inc. Report No.: 51028005-RP1 FCC ID: SCD0059 Date of Issue: November 23, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 91 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For IEEE802.11 b/g Outdoor AP/Bridge (Support IEEE802.11a Client Backhaul) Model / Trade name: WDR2000 / LanReady WDR5084 / LanReady WDR5083 / LanReady WDR5082 / LanReady WDR5000 / LanReady WLO-2401AG / PheeNet WaveGate XTM / Digicom WLG2502 / SohoWare WLG3500 / SohoWare WLG2501 / SohoWare ESS 24562 / Essentia S.p.A. Issued to LanReady Technologies Inc. 3F, No.116, Sinhu 2nd Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 51028005-RP1 FCC ID: SCD0059 Date of Issue: November 23, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION........................................................................................................3 2. EUT DESCRIPTION..............................................................................................................................4 3. TEST METHODOLOGY.......................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................7 4. INSTRUMENT CALIBRATION...........................................................................................................8 4.1 MEASURING INSTRUMENT CALIBRATION......................................................................................8 4.2 MEASUREMENT EQUIPMENT USED.........................................................................................8 5. FACILITIES AND ACCREDITATIONS ..............................................................................................9 5.1 FACILITIES .........................................................................................................................................9 5.2 EQUIPMENT........................................................................................................................................9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.....................................................................................10 6. SETUP OF EQUIPMENT UNDER TEST...........................................................................................11 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................11 6.2 SUPPORT EQUIPMENT ...............................................................................................................11 7. FCC PART 15.247 REQUIREMENTS................................................................................................12 7.1 6 DB BANDWIDTH.............................................................................................................................12 7.2 PEAK POWER....................................................................................................................................19 7.3 A VERAGE POWER............................................................................................................................26 7.4 BAND EDGES MEASUREMENT ................................................................................................32 7.5 PEAK POWER SPECTRAL DENSITY....................................................................................................57 7.6 SPURIOUS EMISSIONS ................................................................................................................64 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................83 APPENDIX I RADIO FREQUENCY EXPOSURE ...................................................................................86 APPENDIX II PHOTOGRAPHS OF TEST SETUP ..................................................................................90 Compliance Certification Services Inc. Report No.: 51028005-RP1 FCC ID: SCD0059 Date of Issue: November 23, 2006 Page 4 Rev. 00 2. EUT DESCRIPTION Product IEEE802.11 b/g Outdoor AP/Bridge (Support IEEE802.11a Client Backhaul) Model / Trade Name WDR2000 / LanReady, WDR5084 / LanReady WDR5083 / LanReady WDR5082 / LanReady WDR5000 / LanReady WLO-2401AG / PheeNet WaveGate XTM / Digicom WLG2502 / SohoWare WLG3500 / SohoWare WLG2501 / SohoWare ESS 24562 / Essentia S.p.A. Model Discrepancy All the specification and layout are identical except they come with different model numbers for marketing purposes. Power Supply Model: F919I-4810 IP: 100-240VAC, 2A, 50-60Hz OP: 48V, 1.0A AC Power Cord Type Unshielded, 1.8m (Detachable) at POE. Frequency Range IEEE 802.11a: 5.745~5.825 GHz IEEE 802.11b/g: 2.412~2.462 GHz Transmit Power IEEE 802.11a: 19.92 dBm IEEE 802.11b: 18.37 dBm IEEE 802.11g: 19.20 dBm Modulation Technique IEEE 802.11a: OFDM (QPSK, BPSK, 16-QAM, 64-QAM) IEEE 802.11b: DSSS (CCK,…
