SCD030001802.11 b/g USB Dongle

802.11g Wireless USB Adapter Model # AWLL3028 User’s Manual Rev. 1.1 2 Table of Contents 1. Introduction................................................................................................................................. 3 1.1 Package Contents .................................................................................................................. 3 1.2 Features ................................................................................................................................. 3 2. Installation................................................................................................................................... 4 2.1 Install Driver & Utility.......................................................................................................... 4 2.2 Verify Driver Installation...................................................................................................... 8 3. Configuring the Adapter ........................................................................................................... 11 3.1 Windows 2000/XP Configuration....................................................................................... 11 3.2 Windows Vista Configuration ............................................................................................ 16 3.3 Troubleshooting .................................................................................................................. 20 4. Wireless Configuration Utility.................................................................................................. 22 4.1 General ................................................................................................................................ 22 4.2 Profile.................................................................................................................................. 24 4.3 Available Network .............................................................................................................. 26 4.4 Advanced ............................................................................................................................ 27 4.5 Status................................................................................................................................... 29 4.6 Statistics .............................................................................................................................. 30 Appendix A – Specifications ........................................................................................................ 44 Appendix B – Information ............................................................................................................ 45 Technical Support ......................................................................................................................... 47 3 1. Introduction Thank you for purchasing the 802.11g Wireless USB Adapter. This USB Adapter is designed to comply with IEEE 802.11g Wireless LAN standard and is suitable for notebook computers or desktop computers with a USB 2.0 port. This Adapter supports WiFi Protected Access (WPA2-PSK and WPA-PSK) data encryption for higher security that protects your wireless network from eavesdropping. Client users are required to authorize before accessing the APs or AP Routers, and the data transmitted through the network is encrypted/decrypted by a dynamically changing secret key, which is much safer than WEP encryption. 1.1 Package Contents Before you begin the installation, please check the items of your package. The package should include the following items: • Wireless USB Adapter • USB Cable • Quick Installation Guide • Installation CD (Driver/Utility/Manual) 1.2 Features • Compatible with IEEE 802.11g high rate standard to provide wireless transmission speeds of up to 54Mbps data rate • Maximum reliability, throughput and connectivity with automatic data rate switching • Supports wireless security WPA2, WPA, WPA2-PSK, WPA-PSK, and 64/128-bit WEP • Integrated microstrip dual diversity antenna for the multi-path environment • Drivers support Windows 2000, XP and Vista • Simple user setup & diagnostics utilities • Power Save & Turbo Mode • WOL(Wake On Lan) Support • Software AP function support 4 2. Installation 2.1 Install Driver & Utility This section provides instructions on how to install the Wireless USB Adapter. The driver is installed along with the utility. Insert the USB adapter into an available USB port and turn on your computer. Windows 2000/XP Users: After turning on the computer, Windows will launch the Found New Hardware Wizard. The Found New Hardware Wizard appears differently depending on your operating system. Click Cancel to quit the wizard and insert the Installation CD into your CD drive. Skip ahead to Step 1 Windows Vista Users: After turning on the computer, Windows will install its built in drivers for this adapter. A popup window will appear telling you that the driver was installed correctly. 5 Once you see this message, continue to Step 1. Step 1 The Autorun screen will pop up. Select Install Utility and Driver from the menu. Note: If the Autorun screen doesn’t appear automatically, or if you get a blank white screen, go to Start, Run, and type D:\Utility\Setup.exe (where D is the letter of your CD drive) and click OK. Windows Vista Users: At this point, you may get a warning message like the one below. Make sure that you click Allow to continue with the installation. 6 Step 2 Click Next at the welcome screen. 7 Windows 2000/XP Users: Click Continue Anyway at the Windows Logo Screen. (For Windows 2000, click Yes at the Digital Signature Not Found prompt). Windows Vista Users: When the Windows Security box appears click Install this driver software anyway. Step 3 Click Finish to complete the installation. 8 2.2 Verify Driver Installation To verify if the driver has been installed successfully, please perform the following steps. Step 1 Right-click…

Text truncated - open the document above for the full version.

LanReady Technologies, Inc. 3F, No.166, Sinhu 2nd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. TEL: (02) 2796 8188 FAX: (02) 2796 8158 Http://www.lanready.com Date: June 13, 2007 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Taiwan office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS TW, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS TW on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS TW as our agent, we still recognize that we are responsible to: a) Comply with the relevant provisions of the certification program; b) Make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) Make claims regarding certification only in respect of the scope for which certification has been granted; d) Do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) Upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) Use certification only to indicate the products are certified as being in conformity with specified standards; g) Endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) Ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) Keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) Take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) Document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

http://mail.google.com/mail/?ik=2a69a1bf8a&view=cv&search=inbox&th=113999c554b070e4&ww=1131&cvap=4&qt=&zx=zrlqi-529vpd LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 Inbox Reply "[email protected]" to Seven show details Jul 3 (3 days ago) Dear Seven, The application review is complete. The only review item is that the statements in the user manual need to be revised as shown below. If you have questions, please ask. Q1: Please revise the user manual RF exposure statement to include statements suitable for a portable category device with SAR evaluation. The statement on page is suitable for mobile category devices where separation distance is > 20 cm. Some examples can be seen in the user manuals at the following URL's https://gullfoss2.fcc.gov/prod/oet/forms/blobs/retrieve.cgi?attachment_id=750342&native_or_pdf=pdf https://gullfoss2.fcc.gov/prod/oet/forms/blobs/retrieve.cgi?attachment_id=808206&native_or_pdf=pdf Best regards, Tim Dwyer CCS Technical Reviewer The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Reply Reply to all Forward Invite [email protected] to Gmail Reply from "gina.lo" <[email protected]> hide details Jul 3 (3 days ago) to [email protected] date Jul 3, 2007 11:41 PM subject Re:LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 Dear Sir, We asked FCC to change the client's address. When we get the revised address, we'll reply the following questions to you. Pls wait kindly! Best Regards, Gina <[email protected]> 2007/07/04 10:47 AM "Seven Chen" <[email protected]> <[email protected]> LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 - Show quoted text - Reply Reply to all Forward Invite gina.lo to Gmail Reply "gina.lo" to tim.dwyer show details Jul 4 (2 days ago) http://mail.google.com/mail/?ik=2a69a1bf8a&view=cv&...13999c554b070e4&ww=1131&cvap=4&qt=&zx=zrlqi-529vpd (1 of 4)7/6/2007 10:13:36 AM http://mail.google.com/mail/?ik=2a69a1bf8a&view=cv&search=inbox&th=113999c554b070e4&ww=1131&cvap=4&qt=&zx=zrlqi-529vpd Dear Sir, Please see the revised user manual. We asked FCC to change the client's address. When we get the revised address, we'll sent mail to you. Before changing the client's address, please don' t issue the certification. Thank you. Best Regards, Gina gina.lo 2007/07/04 11:41 AM <[email protected]> Re:LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 - Show quoted text - <[email protected]> 2007/07/04 10:47 AM "Seven Chen" <[email protected]> <[email protected]> LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 WUB1700SA3-A User Manual Revised 0704.pdf 1077K View as HTML Download Reply Reply to all Forward Invite gina.lo to Gmail Reply from Tim Dwyer <[email protected]> hide details Jul 4 (2 days ago) to "gina. lo" <[email protected]> date Jul 4, 2007 5:28 PM subject Re: Re:LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 mailed-by gmail.com Dear Gina, I will wait to send the application for certification until I hear from you. In the meantime, the manual should also include some additional advice to the user like in the examples I sent. The certification grant will include a condition statement similar to the following one. Please do not delete anything, but this statement should be added to what is in the revised manual you sent. This device has been tested for compliance with FCC RF Exposure (SAR) limits in a typical laptop computer configuration and can be used in desktop or laptop computers with side mounted USB slots. Use in other portable or handheld products like PDA or similar devices has not been verified and may not be in compliance with RF exposure rules. Use in these devices is prohibited. Best regards, http://mail.google.com/mail/?ik=2a69a1bf8a&view=cv&...13999c554b070e4&ww=1131&cvap=4&qt=&zx=zrlqi-529vpd (2 of 4)7/6/2007 10:13:36 AM http://mail.google.com/mail/?ik=2a69a1bf8a&view=cv&search=inbox&th=113999c554b070e4&ww=1131&cvap=4&qt=&zx=zrlqi-529vpd Tim Dwyer - Show quoted text - gina.lo 2007/07/04 11:41 AM <[email protected]> Re:LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 <tim.dwyer@ccsemc. com> 2007/07/04 10:47 AM "Seven Chen" < [email protected]> <[email protected] > LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 Reply Forward Reply from "gina.lo" <[email protected]> hide details 11:38 pm (9 hours ago) to [email protected] date Jul 5, 2007 11:38 PM subject Re:Re: Re:LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 Dear Sir, Please see the revised report. We get the revised address today. Thank you. Best Regards, Gina gina.lo 2007/07/05 09:10 AM [email protected]@ccsemc Re: Re:LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 ----- gina.lo/ccsemc 2007/07/05 09:17 AM ----- http://mail.google.com/mail/?ik=2a69a1bf8a&view=cv&...13999c554b070e4&ww=1131&cvap=4&qt=&zx=zrlqi-529vpd (3 of 4)7/6/2007 10:13:36 AM http://mail.google.com/mail/?ik=2a69a1bf8a&view=cv&search=inbox&th=113999c554b070e4&ww=1131&cvap=4&qt=&zx=zrlqi-529vpd "Tim Dwyer" <Timothy_Dwyer@ieee. org> [email protected] 2007/07/05 05:28 AM "gina.lo" < [email protected]> Re: Re:LanReady Technologies Inc., FCC ID: SCD030001, Assessment NO.: AN07T6960, Notice#1 - Show quoted text - gina.lo 2007/07/04 11:41 AM < tim.dwyer@cc…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 70607003 Date of Issue: June 25, 2007 Page 1 Total Page: 4 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT

Compliance Certification Services Inc. Report No.: 70607003 Date of Issue: June 25, 2007 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 70607003 Date of Issue: June 25, 2007 Page 3 Rev.00 Compliance Certification Services Inc. Report No.: 70607003 Date of Issue: June 25, 2007 Page 4 Rev.00

Walsin Technology Corporation Introduction of RFANT5220110A2T Aug. 2006
 W WW W



 W WW W






                                                              L L T T C C C C M M u u l l t t i i L L a a y y e e r r C C h h i i p p A A n n t t e e n n n n a a - - B B r r o o a a d d B B a a n n d d T T y y p p e e For ISM Band 2.4GHz Application




Surface Mounted Devices with a small dimension of 5.2 x 2.0 x 1.1 mm 3 meet future miniaturization trend.
Embedded and LTCC (Low Temperature Co-fired Ceramic) technology is able to future integrate with system design as well as beautifying the housing of final product.
High Stability in Temperature / Humidity Change                            Item Specification Central frequency 2.450 GHz (Note-1) Gain 0 ~ 2 dBi VSWR 2 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50W Maximum Input Power 5 Watts for 5 minutes Operation Temperature -40̓C ~ +85̓C *Note 1. Central Frequency should be defined after customers’ application approval.                  Bluetooth Wireless LAN HormRF ISM band 2.4GHz applications.                         Outline of 2.4GHz Chip Antenna        CONTACT INFORMATION For more information, please contact with Walsin Technology Corporation. Tel : 886-3-475-8711 Fax : 886-3-475-5197 E mail : [email protected] Web Site : http://www.passivecomponent.com Specification subject to change without prior notice. Test Board Insertion Loss (S11) Patent Pending L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm A = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm  L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm A = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm       W T C W T C B B        W T C W T C B B

Compliance Certification Services Inc. Report No.: 70607003-SF FCC ID: SCD030001 Date of Issue: June 25, 2007 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 25 Rev. 00 ANSI/IEEE Std. C95.1-1992 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC TEST REPORT For USB Dongle b/g Model: WUB1700SA3-A Trade: LanReady Issued to LanReady Technologies Inc. 4F, No. 337, Sinhu 2nd Rd., Neihu District, Taipei City 114, Taiwan (R.O.C.) Issued by Compliance Certification Services Inc. No. 11, Wugong 6th Rd., Wugu Industrial Park, Taipei Hsien 248, Taiwan. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 70607003-SF Date of Issue: June 25, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. EUT DESCRIPTION ..................................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC .................5 3. DOSIMETRIC ASSESSMENT SYSTEM ................................................................................5 3.1 MEASUREMENT SYSTEM DIAGRAM .........................................................................6 3.2 SYSTEM COMPONENTS.................................................................................................7 4. EVALUATION PROCEDURES ...............................................................................................9 5. MEASUREMENT UNCERTAINTY ......................................................................................13 6. EXPOSURE LIMIT ..................................................................................................................14 7. TYPICAL COMPOSITION OF INGREDIENTS FOR LIQUID TISSUE PHANTOMS .15 8. MEASUREMENT RESULTS..................................................................................................16 8.1 SYSTEM PERFORMANCE CHECK..............................................................................16 8.2 TEST LIQUID CONFIRMATION...................................................................................17 8.3 EUT TUNE-UP PROCEDURES AND TEST MODE.....................................................18 8.4 SAR MEASUREMENTS RESULTS...............................................................................19 9. EUT PHOTOS ...........................................................................................................................22 10. EQUIPMENT LIST & CALIBRATION STATUS................................................................23 11. FACILITIES..............................................................................................................................24 12. REFERENCES ..........................................................................................................................24 13. ATTACHMENTS......................................................................................................................25 Compliance Certification Services Inc. Report No.: 70607003-SF Date of Issue: June 25, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product USB Dongle b/g Trade Name LanReady Model Number WUB1700SA3-A Model Discrepancy N/A Frequency Range 802.11b: 2400 ~ 2483.5 MHz 802.11g: 2400 ~ 2483.5 MHz Max. O/P Power: (Conducted/Peak) 802.11b: 17.51 dBm 802.11g: 19.22 dBm Max. SAR (1g): 802.11b: 0.362 W/kg 802.11g: 0.300 W/kg Modulation Technique 802.11b: Direct Sequence Spread Spectrum(DSSS) 802.11g: Orthogonal Frequency Division Multiplexing (OFDM) Antenna Specification Antenna type: Chip antenna Host 1 SONY, Model: VGN-S44TP, SN: 28198080 8100339 Remark: The sample selected for test was prototype that approximated to production product and was provided by manufacturer. Compliance Certification Services Inc. Report No.: 70607003-SF Date of Issue: June 25, 2007 Page 5 Rev. 00 3. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC The US Federal Communications Commission has released the report and order “Guidelines for Evaluating the Environmental Effects of RF Radiation", ET Docket No. 93-62 in August 1996 [1]. The order requires routine SAR evaluation prior to equipment authorization of portable transmitter devices, including portable telephones. For consumer products, the applicable limit is 1.6 mW/g for an uncontrolled environment and 8.0 mW/g for an occupational/controlled environment as recommended by the ANSI/IEEE standard C95.1-1992 [6]. According to the Supplement C of OET Bulletin 65 “Evaluating Compliance with FCC Guide-lines for Human Exposure to Radio frequency Electromagnetic Fields", released on Jun 29, 2001 by the FCC, the device should be evaluated at maximum output power (radiated from the antenna) under “worst-case” conditions for normal or intended use, incorporating normal antenna operating positions, device peak performance frequencies and positions for maximum RF energy coupling. 4. DOSIMETRIC ASSESSMENT SYSTEM These measurements were performed with the automated near-field scanning system DASY4 from Schmid & Partner Engineering AG (SPEAG). The system is based on a high precision robot (working range greater than 0.9 m) which positions the probes with a positional repeatability of better than ± 0.02 mm. Special E- and H-field probes have been developed for measurements close to material discontinuity, the sensors of which are directly loaded with a Schottky diode and connected via highly resistive lines to the data acquisition unit. The SAR measurements were conducted with the dosimetric probe EX3DV3-SN: 3531 (manufactured by SPEAG), designed in the classical triangular configuration and optimized for dosimetric evaluation. The probe has been calibrated according to the procedure with acc…

Text truncated - open the document above for the full version.

Date/Time: 6/13/2007 9:24:33 AM Test Laboratory: Compliance Certification Services Inc. D2450V2 SN-728 Body DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:728 Communication System: CW2450; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.96 mho/m; ε r = 51.9; ρ = 1000 kg/m 3 Phantom section: Flat Section Air Temperature:25.0 deg C;Liquid Temperature:24.0 deg C Area Scan Find Secondary Maximum Within 2dB and with a peak SAR value greater than 0.0012W/kg DASY4 Configuration: z Probe: EX3DV3 - SN3531; ConvF(7.88, 7.88, 7.88); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 8/23/2006 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Pin=250mW,d=10mm/Area Scan (6x6x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 14.1 mW/g Pin=250mW,d=10mm/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 94.9 V/m; Power Drift = -0.033 dB Peak SAR (extrapolated) = 28.1 W/kg SAR(1 g) = 13.4 mW/g; SAR(10 g) = 6.14 mW/g Maximum value of SAR (measured) = 19.1 mW/g Pin=250mW,d=10mm/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 19.5 mW/g Page1 Page2 Date/Time: 6/13/2007 1:02:38 PM Test Laboratory: Compliance Certification Services Inc. 802.11b Tip Touched mode Sony Host DUT: WUB1700SA3-A; Type: USB Dongle b/g; Serial: N/A Communication System: IEEE 802.11b WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.94 mho/m; ε r = 51.9; ρ = 1000 kg/m 3 Phantom section: Flat Section Air Temperature:25.0 deg C;Liquid Temperature:24.0 deg C Area Scan Find Secondary Maximum Within 2dB and with a peak SAR value greater than 0.0012W/kg DASY4 Configuration: z Probe: EX3DV3 - SN3531; ConvF(7.88, 7.88, 7.88); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 8/23/2006 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Middle CH, Rate=1M/Area Scan (5x6x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.245 mW/g Middle CH, Rate=1M/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 12.4 V/m; Power Drift = -0.020 dB Peak SAR (extrapolated) = 0.459 W/kg SAR(1 g) = 0.181 mW/g; SAR(10 g) = 0.073 mW/g Maximum value of SAR (measured) = 0.285 mW/g Page1 Page2 Date/Time: 6/13/2007 1:21:00 PM Test Laboratory: Compliance Certification Services Inc. 802.11g Tip Touched mode Sony Host DUT: WUB1700SA3-A; Type: USB Dongle b/g; Serial: N/A Communication System: IEEE 802.11g WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.94 mho/m; ε r = 51.9; ρ = 1000 kg/m 3 Phantom section: Flat Section Air Temperature:25.0 deg C;Liquid Temperature:24.0 deg C Area Scan Find Secondary Maximum Within 2dB and with a peak SAR value greater than 0.0012W/kg DASY4 Configuration: z Probe: EX3DV3 - SN3531; ConvF(7.88, 7.88, 7.88); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 8/23/2006 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Middle CH, Rate=6M/Area Scan (6x6x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.247 mW/g Middle CH, Rate=6M/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 15.6 V/m; Power Drift = -0.159 dB Peak SAR (extrapolated) = 0.643 W/kg SAR(1 g) = 0.260 mW/g; SAR(10 g) = 0.108 mW/g Maximum value of SAR (measured) = 0.402 mW/g Page1 Page2 Date/Time: 6/13/2007 4:01:23 PM Test Laboratory: Compliance Certification Services Inc. 802.11b Bottom Flat Touched mode Sony Host DUT: WUB1700SA3-A; Type: USB Dongle b/g; Serial: N/A Communication System: IEEE 802.11b WLAN; Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2412 MHz; σ = 1.91 mho/m; ε r = 52; ρ = 1000 kg/m 3 Phantom section: Flat Section Air Temperature:25.0 deg C;Liquid Temperature:24.0 deg C Area Scan Find Secondary Maximum Within 2dB and with a peak SAR value greater than 0.0012W/kg DASY4 Configuration: z Probe: EX3DV3 - SN3531; ConvF(7.88, 7.88, 7.88); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 8/23/2006 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Low CH, Rate=1M/Area Scan (5x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.474 mW/g Low CH, Rate=1M/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 8.28 V/m; Power Drift = -0.039 dB Peak SAR (extrapolated) = 0.611 W/kg SAR(1 g) = 0.362 mW/g; SAR(10 g) = 0.185 mW/g Maximum value of SAR (measured) = 0.482 mW/g Low CH, Rate=1M/Z Scan (1x1x26): Measurement grid: dx=20mm, dy=20mm, dz=4mm Maximum value of SAR (measured) = 0.098 mW/g Page1 Page2 Date/Time: 6/13/2007 4:42:22 PM Test Laboratory: Compliance Certification Services Inc. 802.11b Bottom Flat Touched mode Sony Host DUT: WUB1700SA3-A; Type: USB Dongle b/g; Serial: N/A Communication System: IEEE 802.11b WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.94 mho/m; ε r = 51.9; ρ = 1000 kg/m 3 Phantom section: Flat Section Air Temperature:25.0 deg C;Liquid Temperature:24.0 deg C Area Scan Find Secondary Maximum Within 2dB and with a peak SAR value greater than 0.0012W/kg DASY4 Configuration: z Probe: EX3DV3 - SN3531; ConvF(7.88, 7.88, 7.88); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 8/23/2006 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Middle…
