1 Wireless Regulations Radio, EMC and Safety Regulations This device complies with part 15 of the Federal CommunicationsCommision (FCC) rules and with RSS-210 of the Industry Canada (IC). Operation is subject to the following conditions:(1) This device may not cause harmful interference, and(2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to co mply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Ru les. These limits are designed to provide reasonable protection against harmful interf erence in a residential installation. This equipment generates, uses and can radiate ra dio frequency energy and, if not installed and used in accordance with the instructio ns, may cause harmful interference to radio communications. However, there is no guaran tee that interference will not occur in a particular installation. If this equipment do es cause harmful interference to radio or television reception, which can be determined by turning the equi pment off and on, the user is encouraged to try to correct the in terference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. The user is cautioned that changes or mo difications not expressly approved by T&D Corporation, could void the user's authority to operate the equipment.

TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50 TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50 TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50 TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50 TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50

Reviewed by: FCC ID: SRDRTR50 FCC Pt. 15.249 CERTIFICATION TEST REPORT (Part 15 Low Power Transceiver, Rx Verified (DXT)) Quality Manager Test Report S/N: Test Dates: EUT Type: 0611281065.SRD January 26 - 31, 2007 Wireless Communication Port Page 20 of 24 © 2007 PCTEST Engineering Laboratory, Inc. REV 3.10BT 01/09/07 EXHIBIT A – LABELING REQUIREMENTS Per 15.19; Docket 95-19 The label shall be permanently affixed at a conspicuous location on the device; instruction manual or pamphlet supplied to the user and be readily visible to the purchaser at the time of purchase. However, when the device is so small wherein placement of the label with specified statement is not practical, only the trade name and FCC ID must be displayed on the device per Section 15.19(b)(2). Please see attachment for FCC ID label and label location. Figure A-1. FCC ID Label Figure A-2. FCC DoC Label Figure A-3. FCC ID Label Location

TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50 TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50 TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50 TandD FCC ID: SRDRTR50 EUT Photographs © 2007 PCTEST Lab. Wireless Communication Port Model: RTR-50

Reviewed by: FCC ID: SRDRTR50 FCC Pt. 15.249 CERTIFICATION TEST REPORT (Part 15 Low Power Transceiver, Rx Verified (DXT)) Quality Manager Test Report S/N: Test Dates: EUT Type: 0611281065.SRD January 26 - 31, 2007 Wireless Communication Port Page 1 of 24 © 2007 PCTEST Engineering Laboratory, Inc. REV 3.10BT 01/09/07 Applicant Name: Date of Testing: TandD Corporation January 26 - 31, 2007 5652-169 Sasaga Test Site/Location: Matsumoto, Nagano PCTEST Lab. Columbia, MD, USA 399-0033 Japan Test Report Serial No.: 0611281065.SRD FCC ID: SRDRTR50 APPLICANT: TandD Corporation Model(s): RTR-50 EUT Type: Wireless Communication Port Frequency Range: 902.28 – 927.053 MHz FCC Classification: FCC Part 15 Low Power Transceiver, Rx Verified (DXT) FCC Rule Part(s): Part 15 Subpart C (15.249) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC PART 15.249 Certification Reviewed by: FCC ID: SRDRTR50 FCC Pt. 15.249 CERTIFICATION TEST REPORT (Part 15 Low Power Transceiver, Rx Verified (DXT)) Quality Manager Test Report S/N: Test Dates: EUT Type: 0611281065.SRD January 26 - 31, 2007 Wireless Communication Port Page 2 of 24 © 2007 PCTEST Engineering Laboratory, Inc. REV 3.10BT 01/09/07 TABLE OF CONTENTS FCC PART 15.249 MEASUREMENT REPORT...................................................................................3 1.0 INTRODUCTION......................................................................................................................................4 1.1 EVALUATION PROCEDURE..................................................................................................................... 4 1.2 SCOPE....................................................................................................................................................... 4 1.3 PCTEST TEST LOCATION........................................................................................................................ 4 2.0 PRODUCT INFORMATION .....................................................................................................................5 2.1 EQUIPMENT DESCRIPTION..................................................................................................................... 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS.................................................................................. 5 3.0 DESCRIPTION OF TEST ........................................................................................................................6 3.1 CONDUCTED EMISSIONS........................................................................................................................ 6 3.2 RADIATED EMISSIONS ............................................................................................................................ 7 4.0 ANTENNA REQUIREMENTS ..................................................................................................................8 5.0 TEST EQUIPMENT CALIBRATION DATA..............................................................................................9 6.0 TEST RESULTS ....................................................................................................................................10 6.1 20DB BANDWIDTH MEASUREMENT .....................................................................................................11 6.2 RADIATED FUNDAMENTAL MEASUREMENTS .................................................................................... 13 6.3 RADIATED HARMONIC MEASUREMENTS............................................................................................ 14 6.4 RADIATED SPURIOUS MEASUREMENTS ............................................................................................ 15 6.5 LINE-CONDUCTED TEST DATA............................................................................................................. 17 7.0 CONCLUSION .......................................................................................................................................19 EXHIBIT A – LABELING REQUIREMENTS .......................................................................................................20 EXHIBIT B – TEST SETUP PHOTOGRAPHS ...................................................................................................21 EXHIBIT C – EUT INTERNAL PHOTOGRAPHS ...............................................................................................22 EXHIBIT D – EUT EXTERNAL PHOTOGRAPHS ..............................................................................................23 EXHIBIT E – USER’S MANUAL .........................................................................................................................24 Reviewed by: FCC ID: SRDRTR50 FCC Pt. 15.249 CERTIFICATION TEST REPORT (Part 15 Low Power Transceiver, Rx Verified (DXT)) Quality Manager Test Report S/N: Test Dates: EUT Type: 0611281065.SRD January 26 - 31, 2007 Wireless Communication Port Page 3 of 24 © 2007 PCTEST Engineering Laboratory, Inc. REV 3.10BT 01/09/07 MEASUREMENT REPORT FCC Part 15.249 A. § 2.1033 General Information APPLICANT: TandD Corporation APPLICANT ADDRESS: 5652-169 Sasaga Matsumoto, Na…
