SRDRTR5WData Collector

2006.04 16007024040 User ' s Manual Thank you for purchasing our product. Carefully read this instruction manual- before using this unit. #OPYRIGHT4$#ORPORATION!LLRIGHTSRESERVED RTR-RTR-5W5W Ū ɡNotices about this User's Manual In order to properly use this product, please carefully read this manual before using. T&D Corporation accepts no responsibility for any malfunction of and/or trouble with this product or with your computer that is caused by the improper handling of this product and will deem such trouble or malfunction as falling outside the conditions for free repair outlined in the attached warranty. -All rights of this Userȧs Manual belong to T&D Corporation. It is prohibited to use, duplicate and/or arrange a part or whole of this Userȧs Manual without the permission of T&D Corporation. -Microsoft ® and Windows ® are registered trademarks of Microsoft Corporation USA and are binding in the USA and all other countries. -Company names and product names are trademarks or registered trademarks of each company. -Specifi cations, design and other contents outlined in this manual are subject to change without notice. -On screen messages in this manual may vary slightly from the actual messages. Please notify the shop where you purchased this product or T&D Corporation of any mistakes, errors or unclear explanations in this manual. T&D Corporation accepts no responsibility for any damage or loss of income caused by the use of our product. -This product has been designed for private or industrial use only. It is not for use in situations where strict safety precautions are necessary such as in connection with medical equipment, whether directly or indirectly. -We are not responsible for any malfunction or trouble caused by the use of our product or by any problem caused by the use of measurement results of our unit. Please be fully aware of this before using our product. -Some of our products, which come under the category of strategic goods in foreign trade law, need the permission of the Japanese government to be exported outside of Japan. -Please read the warranty and provisions for free repair carefully. ŪŪ Software User's Agreement ɡEscape Clauses -T and D Corporation does not guarantee the operation of ThermoRecorder for Windows -T and D Corporation shall not accept any responsibility for any damage whether direct or indirect that results from the usage of ThermoRecorder for Windows. -Specifi cations of ThermoRecorder for Windows may be subject to change and service may be terminated without advance notice to the user. In such a case, T&D Corporation shall not be responsible for any damages, whether direct or indirect, from the inability to use RTR-5W for Windows. -T and D Corporation has no obligation to correct any defects found in Thermo Recorder for Windows. ɡCopyright -All copyrights for RTR-5W for Windows, including all of the programs and all related documents, are the sole property of T and D Corporation -The reprinting or redistribution for commercial purposes whether in part or in whole, in magazines or as a part of any product is strictly forbidden without the expressed consent of T&D Corporation. Any inquires concerning commercial redistribution should be directed to the Sales Department of T&D Corporation. -Please do not attempt to make any changes or modifi cations to RTR-5W for Windows. *RTR-5W consists of the following applications: [RTR-5W for Windows], [Network Settings Utility], [Temperature /Humidity Graph], [Multi-Scale Graph], [Event Viewer] and [RTR-5W web Viewer] ŪŪŪ Safety Precautions and Instructions To ensure safety be sure to obey all of the following warnings. The following items should be strictly obeyed for the safe usage of this unit, and for protecting yourself and other people from bodily harm and/or damage to property.Before using make sure to carefully read, understand and follow the safety rules and precautions for our products as outlined below. ɡExplanation of Symbols Explanation of Warning Symbols Warning These entries are actions that absolutely under no circumstance should be taken. The taking of such an action may cause serious personal physical damage or death. Caution These entries are actions that if taken may lead to physical injury or damage to persons or things. Explanation of Picture Symbols Denotes an important warning or caution. Inside or near the symbol will appear another symbol giving details. Denotes a forbidden action. Inside or near the symbol will appear another symbol giving details. Denotes an action that you must take. Inside or near the symbol will appear another symbol giving details.(Ex: Unplug power plug from outlet) Ūŷ ! Warnig Do not take apart, repair or modify the main unit. This may cause fi re or electrocution. When installing and using this product, make sure to follow all warnings and directions from your computer manufacturer. Be careful of igniting fi re. If water or a foreign body enters into this unit, immediately unplug the AC adaptor and stop using. Continued use may cause fi re or electrocution. Do not use this unit in wet or humid places, such as a bathroom. It may cause a fi re or other trouble including malfunction. Store main units, AC adaptors, and LAN cables out of the reach of children. Touching them may result in injury and it is dangerous if they are dropped. If any smoke or strange smells are emitted from the unit, immediately pull out the AC adaptor and cease using it. Continued use may cause fi re or electrocution. Do not drop the unit, or expose the unit to a strong impact. If that happens, immediately unplug the AC adaptor and stop using it. Continued use may cause fi re or electrocution. Make sure to periodically remove dust and dirt from the AC adaptor plug. If dust is allowed to accumulate on the plug, moisture may cause poor insulation and result in fi re. Do not unplug the AC adaptor with wet hands. This may cause electrocution. ŷ We are not responsible for any damage…

Text truncated - open the document above for the full version.

ijij ɡUsing Mail via LAN 242 7 㧔㧕 3-40#LIENT 3-403ERVER 㧔㧕 (5" 0# 㧔㧕 Ԙ ԙ 0/0 OR )-!03ERVER 㧔㧕 ԛ Ԛ -AIL"OX ӱ The RTR-5W accesses the SMTP server and sends mail to the server. Ӳ The SMTP server delivers the mail sent from the RTR-5W according to the address to a POP server. ӳ The POP server receives the delivered mail from the SMTP server and stores it in the appropriate mailbox for that mail address. ӴYour computer accesses the POP server where the mail is stored and receives mail in the computer 's mailbox. NOTE: Please take note that when you are using a LAN to send and get warning mail, it is necessary to have set up a SMTP server (for sending) and a POP or IMAP server (for receiving) in the network. ɡSending Internet Mail ! L .@/: ! U ABC ! _ DEF ! i GHI ! t JKL ! y MNO PQRS TUV WXYZ ! ! Þ ß HILD @p 㩅㩆 2OUTER 㧔㧕 Ԙ -AIL -ODEM 242 7 㧔㧕 3-40#LIENT 0# 㧔㧕 3-40SERVER 㧔SMTP++++COM㧕 ).4%2.%4 0ROVIDER 0/0 OR )-!0 3ERVER 㧔POP++++NEJP㧕 ԛ Ԛ -AIL "OX ԙ ӱThe RTR-5W, via a router or provider, accesses an SMTP server that exists on the Internet and sends mail to the SMTP server. ӲThe SMTP server delivers the mail sent from the RTR-5W, according to the address, to a POP server. ӳThe POP server receives the delivered mail from the SMTP server and stores it in the appropriate mailbox for that mail address. ӴYour computer accesses the POP server where the mail is stored and receives mail in the computerȧs mailbox. NOTE: In order to connect to the Internet, please make the necessary router (LAN) settings. ijĴ Installation Install the provided software. - Is Windows ® operating properly? If Windows ® is not operating properly, ȶRTR-5W for Windowsȷmay not be installed correctly or it may not operate properly. - Please quit all other applications. If other programs are open, please close and quit all of them, making sure to quit all Quick Start programs such as a virus checker. *To install [RTR-5W for Windows], it is necessary to have Administrator rights (Computer Administrator) for the computer in which you wish to install it. ȁ 1. Open Windows ® . 2. Place the accompanying CD-ROM into your CD-ROM drive. In a few seconds, the £Install Program¤ window will appear. *If that window does not automatically open, please open it by double clicking the CD- ROM icon in £My Computer¤ on your desktop. Or, if after double clicking the CR-ROM drive, the fi le appears in the CD-ROM folderȂ double click on the "start.exe" icon. [Execute] button Click ijĵ 3. Select ȶRTR-5W for Windows¤ and click the [Execute] button to start the installation. 4. Continue the installation by following the directions as they appear. 5. After installation has been completed,ȶRTR-5W for Windowsȷwill be registered in the Window's [Start] Menu. ijĶ Using the Network Settings Utility ɡHow to Open From the list of programs in the Window's Start Menu, click on "RTR-5W for Windows"-Network Settings Utility. ɡUsing Help For details about how to use the software, please see the explanations in the Software Help Menu. By clicking on [Help] in the Menu Bar and then [How to Use Network Settings Utility] you can click on one of the tabs [Contents] or [Keyword] to search for the topic or term you are unsure about or have questions about. [Contents] By clicking on one of the topics listed, you can fi nd detailed information for that subject. [Keyword] By selecting a Keyword in the Keyword list, and clicking the [Display] button at the bottom, a detailed explanation will appear. * By clicking the help button in a dialog box, an explanation for that dialog box will appear. ijķ ɡNetwork Settings Utility Functions The Network Settings Utility contains the following functions: Network Initialization Settings After purchasing a RTR-5W unit, the fi rst step is to make all Network Initialization Settings including assigning an IP Address and a Subnet Mask. Detailed Network Settings The reception of RTR-5W settings and more detailed network settings can be made here. IN the SNTP settings, it is possible to make settings so that the RTR-5W clock settings can be automatically received from NTP server.Clock settings can be made directly using [RTR- 5W for Windows] software, but if an RTR-5W is rebooted (restarted) the clock settings will be initialized. However, by making settings to enable the SNTP server it is possible to have the clock automatically reset to the current time upon rebooting. NOTE: Please open the Network Settings Utility from only one computer at a time in the same network (same broadcast domain). If you open the Network Settings Utility on multiple computers in the same network, it may not work properly. ȶMENUȷ -[Menu] - [Login History] If you wish to disable the History Function, select [Login History] ɨ [OFF]. -[Menu] - [Clear Login History] Use this to erase the entire login history. -[Menu] - [Communication Time Settings] It is possible to change the communication time for all types of communication depending on your network environment. ijĸ Network Initialization Settings To connect an RTR-5W to a network, it is necessary to enter an IP Address and Subnet Mask that are appropriate for your network. NOTE: Please note, that upon purchase, all RTR-5W units are set with the same IP address. To make IP address changes, connect one unit at a time and carry out the changes.Do not connect more than one unit with the same address to the network at the same time. 1. Connect the RTR-5W to the same network as to which the computer you have opened [Network Settings Utility] is connected to. 2. Click on theȶNetwork InitializationȷTab and then click on the [Search] button. After clickingȂthe search results will be shown in about 5 seconds. *The factory default settings for RTR-5W are as follows: IP Addressȇ"192.168.1.200"ȂSubnet Maskȇ "255.255.0.0". The MAC address is written on a sticker on the back of the RTR-5W unit . [Change Settings] button [Search] button Con…

Text truncated - open the document above for the full version.

ĸij ɡErase Selected Channel Data : From the [Tools] Menu 1. Put a check on the channel number you wish to erase. 2. Click the [OK] button to complete the deletion. [OK] button Check ĸĴ ɡSet Vertical Axis Display Range: From the [Tools] Menu It is possible to set the upper and lower values of the vertical axis scale for each channel. NOTE: - In this case, the data graph lines may under certain circumstances stick out of the graph. - Settings for the upper limit must be lower than 40,000 and settings for the lower limit must be higher than –40,000. 1. Put a check next to <Fixed> for the channel you wish to make settings for. Make all settings same as Ch. 1 \ OK ^ button Check <Fixed> and enter the desired numerical values. 2. Enter the Upper and Lower Limits. 3. Click the [OK] button to fi nish the setting process. ĸĵ ȺMake all settings same as Ch. 1Ȼ If you have chosen fi xed values for Ch.1 and put a check next to [Make all settings same as Ch. 1], the settings will become the same for all other channels whether that channel has been set to ȨFixedȩ or ȨAutoȩ. ɡScale / Unit Conversion: From [Tools] Menu It is possible to make settings for the conversion of units and scales for each channel of downloaded data. 1. Select to use 2 voltage points to convert the scale or to use the conversion equation of y=Ax+B. Conversion Info [OK] button ȶDesignate by 2 pointsȷ ȶy=Ax+Bȷ 2. Make settings for the conversion equation and unit. 3. Click the [OK] button to fi nish the setting process. ȺConversion InfoȻ The currently set conversion equation and the character array of the current unit will be displayed. By stands for the value after conversion and x is the voltage input directly from the sensor. ĸĶ ɡChange Graph Colors : From the [Tools] Menu 1. Click the channel number or item for which you wish to make changes. If you wish to change the color: click the appropriate button to view the color selection samples. If you wish to change the type of line: click the [Line Type] button to view the line type selections. If you wish to make changes to the width of the lines: In the image preview display, fi rst click on a channel number button to select the channel and then each click of the ɣ button will make that channelȧs line wider and each click of the ɥ button will make it thinner. ȴColor Sampleȵ ȴChange Line Typeȵ [Close] button Image Preview memo [Channel No.] button [Default] button *If you wish to make changes to the graph colors, line types, or line widths, click on the [Channel No.] button fi rst and then click on the topic you wish to make changes to. ĸķ 2. After confi rming the color in the image preview display, click the [Close] button to complete the changes. *By clicking the [Default] button, you will return to the color settings to the Default settings. Ⱥ memo Ȼ Here it is possible to save one pattern of settings for use in the display and one for use when printing . 1. Select [Display] or [Print]. 2. Click the [Save] button to save the settings. For Display For Printing [Load] button [Save] button By clicking the [Load] button, you can call up a saved pattern. ĸĸ Operating the Graph Display ɡReturning to Original Size Return from zooming in on one part of data to the original whole graph size. ɡZoom out step by step Return by regular steps from zooming in on one part of data to show larger ranges of data. ĸĹ How to Operate the Event Viewer ɡHow to Open From the list of programs in the Window’s Start Menu, click on "RTR-5W for Windows" - "Event Viewer" ɡUsing Help For details about how to use the software, please see the explanations in the Software Help Menu. -In the Menu Bar, click [Help] - [Search by Topic], then click on one of the tabs [Contents], [Index], or [Search] to search for the topic or term you are unsure about or have questions about. [Contents] By clicking on one of the topics listed, you can fi nd detailed information for that subject. [Index] By selecting a Keyword in the Keyword list, and clicking the [Display] button at the bottom, a detailed explanation will appear. [Search] Enter the keyword you wish to search for and click the [List Topics] button. All topics that contain the keyword will be displayed. By selecting a topic and clicking the [Display] button at the bottom, a detailed explanation will appear. - By clicking the help button in a dialog box, an explanation for that dialog box will appear - In the Graph Window, by clicking on the in the toolbar, you can have short explanations appear the next time you click on a menu, an icon, or anything in the main window. ĸĺ ɡEvent Viewer Display Part Names and Functions With Event Viewer you can view Recorded Event Time Data in a List (up to 64 channels), Print the List, or Save as Text File. ӱ Ӳ Ӵ ӳ ӵ ӱMenu Bar Menus are lined up which contain various commands. They are used to view data or to make settings for the various functions in each menu. ɪIcon: View only rising edge data This includes when there was a simultaneous occurrence of rising and falling. ɫ Icon: View only falling edge data.This includes when there was a simultaneous occurrence of rising and falling. ɪɫ Icon: View all Data ӲToolbar Buttons appear for frequently used commands. ӳButton for Moving Vertical Axis Click the arrow buttons to move up or down. ӴScroll Bar By dragging the Scroll Bar you can move up and down to the desired position. ӵɪ/ɫ/ɪɫ View ɪrising (Lo to Hi) waves, ɫ falling (Hi to Lo) waves, or ɪɫboth types Ĺı Change the Event Viewer Method of Display ɡShift Display: From the [View] Menu or the Toolbar You can shift the display to view either by the recorded date/time or by the elapsed time from the last recorded data. Recorded Date Display Elapsed Time Display ɡShift Descending / Ascending: From the [View] Menu or the Toolbar You can shift the display to view the recorded data either from the newest to the oldest or from the oldest to the newest. ĹIJ ɡFile Info: From the [View] Menu View fi le info about data in the currently displayed d…

Text truncated - open the document above for the full version.

FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 5 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 3 EQUIPMENT UNDER TEST 3.1 Photo documentation of the EuT RTR-5W External Photo Front view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 6 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Rear view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 7 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Side view left FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 8 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Side view right FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 9 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Top view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 10 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Bottom view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 18 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 Power Supply Unit External Photo

FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 11 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Rear view of open cover FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 12 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Front view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 13 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 5WK49266 Internal Photo Rear view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 14 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Front view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 15 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Rear view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 16 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Front view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 17 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Rear view PCB

FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 1 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 EMI -- T E S T R E P O R T Test Report No. : T30654-00-04HU 10. April 2006 ______________________________________________________________________________________________ Date of issue Type / Model Name : RTR-5W Product Description : Data Collector Applicant : T&D CORPORATION Address : 5652-169 Sasaga Matsumoto City NAGANO 399-0033 Japan Manufacturer : T&D CORPORATION Address : 5652-169 Sasaga Matsumoto City NAGANO 399-0033 Japan Licence holder : T&D CORPORATION Address : 5652-169 Sasaga Matsumoto City NAGANO 399-0033 Japan Test Result according to the standards listed in clause 1 test standards: POSITIVE The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test DAT-P-207/05-00 laboratory. FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 2 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 Contents 1 TEST STANDARDS 3 2 SUMMARY 4 3 EQUIPMENT UNDER TEST 5 3.1 PHOTO DOCUMENTATION OF THE EUT 5 3.2 POWER SUPPLY SYSTEM UTILISED 19 3.3 SHORT DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) 19 4 TEST ENVIRONMENT 20 4.1 ADDRESS OF THE TEST LABORATORY 20 4.2 ENVIRONMENTAL CONDITIONS 20 4.3 STATEMENT OF THE MEASUREMENT UNCERTAINTY 20 4.4 MEASUREMENT PROTOCOL FOR FCC, VCCI AND AUSTEL 20 5 TEST CONDITIONS AND RESULTS 22 5.1 CONDUCTED EMISSIONS 22 5.2 RADIATED POWER OF THE FUNDAMENTAL WAVE 26 5.3 SPURIOUS EMISSIONS (MAGNECTIC FIELD) 9 KHZ – 30 MHZ 29 5.4 RADIATED EMISSIONS (ELECTRIC FIELD) 30 MHZ – 40 GHZ 31 5.5 EMISSION BANDWIDTH 38 5.6 BAND EDGE TEST 43 5.7 ANTENNA APPLICATION 47 5.8 RECEIVER CONDUCTED DISTURBANCES 0.15 - 30 MHZ 48 5.9 RECEIVER SPURIOUS EMISSIONS (MAGNECTIC FIELD) 9 KHZ – 30 MHZ 52 5.10 RECEIVER RADIATED EMISSIONS (ELECTRIC FIELD) 30 MHZ - 40 GHZ 54 6 USED TEST EQUIPMENT AND ACCESSORIES 57 FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 3 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 1 TEST STANDARDS The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C - Intentional Radiators (October 01, 2004) Part 15, Subpart C, Section 15.249 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725- 5875 MHz, and 24.0-24.25 GHz Part 15, Subpart C, Section 15.35(c) Correction for Pulse Operation (Duty Cycle) Part 15, Subpart C, Section 15.203 Antenna requirement Part 15, Subpart C, Section 15.204 External radio frequency power amplifiers and antenna modifications Part 15, Subpart C, Section 15.209(a) Radiated emissions, general requirements ANSI C63.4-2003, Section 13.1.7 Occupied bandwidth measurements FCC Rules and Regulations Part 15 Subpart B - Unintentional Radiators (October 01, 2004) FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 4 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 2 SUMMARY GENERAL REMARKS: The frequency range was scanned from 9 kHz to 9500 MHz. All emissions not reported in this test report were more than 10 dB below the specified limit. FINAL ASSESSMENT: The equipment under test fulfills the EMI requirements cited in clause 1 test standards. Date of receipt of test sample : acc. to storage records Testing commenced on : 08. March 2006 Testing concluded on : 10. March 2006 Checked by: Tested by: Klaus Gegenfurtner Dipl.-Ing.(FH) Manager: Radio Group Huber Markus FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 5 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 3 EQUIPMENT UNDER TEST 3.1 Photo documentation of the EuT RTR-5W External Photo Front view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 6 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Rear view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 7 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Side view left FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 8 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Side view right FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 9 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Top view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 10 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W External Photo Bottom view FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 11 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Rear view of open cover FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 12 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Front view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 13 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 5WK49266 Internal Photo Rear view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 14 of 57 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 RTR-5W Internal Photo Front view PCB FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-04HU, page 15 of 57 Ohmstrasse 2-…

Text truncated - open the document above for the full version.

FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 22 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 5 TEST CONDITIONS AND RESULTS 5.1 Conducted emissions For test instruments and accessories used see section 6 Part A 4. 5.1.1 Description of the test location Test location: Shielded Room S2 5.1.2 Photo documentation of the test set-up 5.1.3 Description of Measurement The final level, expressed in dBμV, is arrived at by taking the reading directly from the EMI receiver. This level is compared directly to the FCC Limit or to the CISPR limit, which is equivalent to the Australian AS 3548 limit. To convert between dBμV and μV, the following conversions apply: dBμV = 20(log μV) μV = Inverse log(dBμV/20) Conducted emissions on the 50 Hz and/or 60 Hz power interface of the EuT are measured in the frequency range of 150 kHz to 30 MHz. The measurements are performed using a receiver, which has CISPR characteristic bandwidth and quasi-peak detection, and a Line Impedance Stabilization Network (LISN), with 50Ω/50 μH (CISPR 16) characteristics. Table top equipment is placed on a non-conducting table 80 centimeter’s above the floor and is positioned 40 centimeter’s from the vertical ground plane (wall) of the screen room. If the minimum passing margin appears to be less than 20 dB with a peak mode measurement, the emissions are remeasured using a tuned receiver with quasi-peak and average detection and recorded on the data sheets. FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 26 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 5.2 Radiated power of the fundamental wave For test instruments and accessories used see section 6 Part CPR 2. 5.2.1 Description of the test location Test location: OATS1 Test distance: 3 metres 5.2.2 Photo documentation of the test set-up FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 29 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 5.3 Radiated emissions (electric field) 30 MHz – 40 GHz For test instruments and accessories used see section 6 Part SER 2, SER 3. 5.3.1 Description of the test location Test location: OATS1 Test location: Anechoic Chamber A2 Test distance: 3 metres 5.3.2 Photo documentation of the test set-up FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 30 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 FCC ID:SRDRTR5W mikes-testingpartners gmbh File No. T30654-00-00HU, page 36 of 54 Ohmstrasse 2-4 x 94342 Strasskirchen Tel.:+49(0)9424-94810 x Fax:+49(0)9424-9481240 Rev. No. 1.1 5.4 Emission Bandwidth For test instruments and accessories used see section 6 Part MB. 5.4.1 Description of the test location Test location: Shielded Room S4 5.4.2 Ph…

Text truncated - open the document above for the full version.
