Please read this manual thoroughly before any attempt to install and operate this product and retain it for your future reference. User's Manual 2.4GHz Wireless Transceiver Signal relay station Model:870VL English TABLE OF CONTENTS INSTALLATION & USAGE Usage1 Installation Usage2 7 INTRODUCTION 1~4 Notice Approval Information (FCC/CE) 1 2~3 8 EU Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. 7~10 PRODUCT 5~6 Package Contents Feature Locations 6 5 5 Adapter SPECIFICATIONS 11 TROUBLESHOOTING 12 Transfer approach Channel set Receiver Mode Setup Restrictions Maintenance 4 4 Channel Setup 10 10 9 8 7 INTRODUCTION Thank you for purchasing our car back view monitor. This product eel confident that you will be pleased with the quality and features of this product. The product is made of alloyed shell and special weather-proof enclosure that protect it against power and water sprays. It passed the IP65 testing. The product offers a new solution and experience for drivers. Drivers can check the back situations through the camera mounted on the rear car, and does not need to look back and forth. This product is only for accessorial reminding tool, thus we will not take any responsibility for resulting accident. Please read the manual thoroughly before using, and following the instruction accordingly. works at ISM-2.4GHz frequency band, which could be legally used worldwide without permission. We f Notice Notice: This product may cause interferences with other wireless equipment that operates at 2.4GHz ISM band. Please turn off one of the equipments to eliminate the interference. Product Assurance: This camera will emit electromagnetic wave, just like other wireless products, however, its transmitting power is less than other wireless products such as mobile phones. The 2.4GHz wireless camera meets wireless frequency security standards and recommended indexes while working. These standards and indexes are certificated by academic organization and represent the cogitative research of the scientific workers who continuously explore and annotate the involved fields. So we believe that our products are safe for customers. 1 All our products meet the requirements of approval FCC or CE, and are granted the FCC or CE certification. They are authorized to bear FCC or CE mark. Approval Information 2 FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and the receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and FCC Radiation Exposure Statement 3 This product complies with standards including Low Voltage Device Directive 2006/95/EC; EMC Directive 2004/108/EC and R&TTE Directive 1999/5/EC. It passed the subject tests by the authority concerned and is authorized to bear CE mark. CE (2) this device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment marketed in USA is restricted by firmware to only operate on 2.4G channel 1-11. Channel 1. DO NOT use this product to violate one's privacy. Monitoring one's activities without consent is illegal and this product is not designed and manufactured for such purpose; 2. DO NOT put this product near any medical equipment. Radio waves might potentially cause breakdown of electrical medical equipment. So this product should be placed at least 1 feet away from any heart pacemaker. Radio waves might potentially influence heart pacemaker and lead to respiratory disturbance; 3. DO NOT use this product for any illegal activities. We will not be responsible for any consequences of illegal acts committed by the user. Restrictions 1. Ensure the sufficient ventilation space is available; 2. Do not shake or strike the product; 3. Keep it dry and dustless and avoid exposing it to direct sunlight; 4. Do not place product near any magnetic objects; 5. Avoid putting the product in places where the constantly changed temperature or humidity occurs; 6. Keep product awa…
