TW4BT5012.4 Ghz Wireless Camera

Please read this manual carefully and thoroughly before any attempt to install and operate this product and retain it for your future reference. User's Manual 2.4GHz Color Wireless Camera Kit Night Vision MODEL:501LA English TABLE OF CONTENTS INTRODUCTION 1~3 Notice Restrictions Maintenance Approval Information (FCC/CE) 1 3 3 1~2 PRODUCT 4~7 Package Contents Feature Locations Adapter 4 5-6 7 SPECIFICATIONS17 TROUBLESHOOTING18 INSTALLATION & USAGE 8~16 Installation Locate the Receiver Fix the Camera 8~10 Camera Channel Setup Night Vision 11 12 12 Receiver Mode Setup 13~16 EU Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. 10-11 INTRODUCTION Thank you for purchase this wireless camera kit. This product eel confident that you will be pleased with the quality and features of this product. The camera builds in one CMOS image sensor and one transmitting module transmits the captured image wirelessly. works at ISM-2.4GHz frequency band, which could be legally used worldwide without permission. We f Notice: This product may cause interferences with other wireless equipment that operates at 2.4GHz ISM band. Please turn off one of the equipments to eliminate the interference. Product Assurance: This camera will emit electromagnetic wave, just like other wireless products, however, its transmitting power is less than other wireless products such as mobile phones. The 2.4GHz wireless camera meets wireless frequency security standards and recommended indexes while working. These standards and indexes are certificated by academic organization and represent the cogitative research of the scientific workers who continuously explore and annotate the involved fields. So we believe that our products are safe for customers. 1 All our products meet the requirements of approval FCC or CE, and obtained the FCC or CE certification. They are authorized to bear FCC or CE mark. Approval Information Notice FCC This product complies with standards including Low Voltage Device Directive 73/23/EEC; EMC Directive 89/336/EEC and R&TTE Directive 1999/5/EC. It passed the subject tests by the authority concerned and is authorized to bear CE mark. CE 2 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and the receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation changes and modification not expressly approved by the manufacturer or registrant of this equipment can void your authority to operate this equipment under Federal Communications Commissions rules. 1. DO NOT use this product to violate one's privacy. Monitoring one's activities without consent is illegal and this product is not designed and manufactured for such purpose; 2. DO NOT put this product near any medical equipment. Radio waves might potentially cause breakdown of electrical medical equipment. So this product should be placed at least 1 feet away from any heart pacemaker. Radio waves might potentially influence heart pacemaker and lead to respiratory disturbance; 3. DO NOT use this product for any illegal activities. We will not be responsible for any consequences of illegal acts committed by the user. Restrictions 1. Ensure the sufficient ventilation space is available; 2. Do not shake or strike the product; 3. Keep it dry and dustless and avoid exposing it to direct sunlight; 4. Do not place product near any magnetic objects; 5. Avoid putting the product in places where the constantly changed temperature or humidity occurs; 6. Keep product away from heat sources such as electric heater; 7. Do not use the camera near aggressive chemicals; 8. Do not use this camera near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool and the like; 9. Do not use the camera in the places which are enclosed by metal. The surrounding metal like lifter, cabin, may shield the electromagnetic wave, and result in failure of signal reception; 10. Please obey the local government's environment protection policy; 11. Please turn off the power when left unused; 12. Do not disassemble or repair the camera or receiver; doing so might cause damages to the product. Maintenance 3 ① 2.4GHz Wireless Camera ×1 ② 2.4GHz Wireless Receiver ×1 ③ ×1 ④ Adapter for Camera (DC 8V) ×1 ⑤ Adapter for Receiver (DC 5V) ×1 ⑥ AV Cable Base Charger × 1 ⑦ Mounting Hardware × 1 ⑧ Earphone × 1 ⑨ Li-battery × 2 User’s Manual × 1 This package comes with the following items. Please check whether they are all included in the packaging box, if any item is missing, contact the retailer for replacement. Package Contents PRODUCT Note: The pictures may vary from the actual objects. 4 ①②③ ⑤ ⑥ ⑧⑦ ④ Pleas…

Text truncated - open the document above for the full version.

： , # # ， N 24X10mm2525 25# 10. S M501L000011-

FCC ID: TW4BT501 Report No.: 061212FIA01 1 FCC TEST REPORT REPORT NO.: 061212FIA01 MODEL NO.: BT501 RECEIVED: Dec. 8, 2006 TESTED: Dec. 8 ~ Dec. 20, 2006 ISSUED: Dec. 20, 2006 APPLICANT: SHENZHEN AEE TECHNOLOGY CO., LTD ADDRESS: 1/F., Blog. B, Tsinghua Hi-Tech Park, Northern Hi-Tech Industrial Park, Nanshan District, Shenzhen, P. R. C ISSUED BY: ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan Rd., 201103, Shanghai, China This test report consists of 31 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. ADT (Shanghai) Corporation. V 1.0 FCC ID: TW4BT501 Report No.: 061212FIA01 2 Table of Contents 1 CERTIFICATION .....................................................................................................3 2 SUMMARY OF TEST RESULTS.............................................................................4 2.1 MEASUREMENT UNCERTAINTY ..........................................................................4 3 GENERAL INFORMATION .....................................................................................5 3.1 GENERAL DESCRIPTION OF EUT........................................................................5 3.2 DESCRIPTION OF TEST MODES..........................................................................6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .........................................8 3.4 DESCRIPTION OF SUPPORT UNITS....................................................................9 4 EMISSION TEST...................................................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................10 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .....................................10 4.1.2 TEST INSTRUMENTS ..........................................................................................10 4.1.3 TEST PROCEDURE .............................................................................................10 4.1.4 TEST SETUP ........................................................................................................ 11 4.1.5 EUT OPERATING CONDITIONS.......................................................................... 11 4.1.6 TEST RESULTS ....................................................................................................12 4.2 RADIATED EMISSION MEASUREMENT .............................................................14 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ..........................................14 4.2.2 TEST INSTRUMENTS ..........................................................................................15 4.2.3 TEST PROCEDURE .............................................................................................16 4.2.4 DEVIATION FROM TEST STANDARD .................................................................16 4.2.5 TEST SETUP ........................................................................................................17 4.2.6 EUT OPERATING CONDITIONS..........................................................................17 4.2.7 TEST RESULTS ....................................................................................................18 4.3 BAND EDGES MEASUREMENT ..........................................................................28 4.3.1 LIMITS OF BAND EDGES MEASUREMENT .......................................................28 4.3.2 TEST INSTRUMENTS ..........................................................................................28 4.3.3 TEST PROCEDURE .............................................................................................28 4.3.4 DEVIATION FROM TEST STANDARD .................................................................28 4.3.5 EUT OPERATING CONDITION ............................................................................28 4.3.6 TEST RESULTS ....................................................................................................29 5 APPENDIX - INFORMATION ON THE TESTING LABORATORY ........................31 FCC ID: TW4BT501 Report No.: 061212FIA01 3 1 CERTIFICATION PRODUCT: 2.4G wireless camera BRAND NAME: AEE MODEL NO.: BT501 APPLICANT: SHENZHEN AEE TECHNOLOGY CO., LTD TESTED: Dec. 8 ~ Dec. 20, 2006 TEST ITEM: ENGINEERING SAMPLE STANDARDS: 47 CFR Part 15, Subpart C (Section 15.249), ANSI C63.4-2003 The above equipment has been tested by ADT (Shanghai) Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. TECHNICAL ACCEPTANCE : , DATE:DEC. 20, 2006 (Bright Tong) Engineering Supervisor APPROVED BY : , DATE: DEC. 20, 2006 (Wallace Pan) Director of Operations FCC ID: TW4BT501 Report No.: 061212FIA01 4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Paragraph Test Type ResultRemark 15.207 Conducted Emission Test (Mode A1) PASS Minimum passing margin is –22.32dB at 25.248MHz Radiated Emission Test (Mode A1, Below 1GHz) PASS Minimum passing margin is –11.43dB at 31.44MHz Radiated Emission Test (Mode A2, Below 1GHz) PASS Minimum passing margin is –10.91dB at 31.44MHz Radiated Emission Test (Mode B1, Below 1GHz) PASS Minimum passing margin is –4.26dB at 252.50MHz Radiated Emission Test (Mode B2, Below 1GHz) PASS Minimum passing margin is –8.45dB at 31.45MHz Radiated Emission Test (Mode A1, Above 1GHz) PASS Minimum passing margin is –3.96dB at 4869.60MHz 15.249 Radiated Emi…

Text truncated - open the document above for the full version.

CE (Test mode A1, Powered by adapter, Daylight) RE (Test mode A1, Powered by adapter, Daylight) CE (Test mode B1, Powered by battery, Daylight)
