TW4AT1332.4GHz Wireless Camera

Please read this manual carefully and thoroughly before any attempt to install and operate this product and retain it for your future reference. User's Manual Swift HitchTM English Portable Wireless Camera System with Infrared Night Vision Model: SH01 TABLE OF CONTENTS INTRODUCTION 1~3 Notice Restrictions Maintenance Warranty Approval Information 1 3 3 2 1 EU Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. PRODUCT 4~5 Package Contents Feature Locations 4 5 SPECIFICATIONS 9 TROUBLESHOOTING 10 FIRST TIME USAGE 6~8 Using the Camera 7~8 8 Night Vision 6~7 Charging the Camera and Receiver INTRODUCTION Thank you for your interest and support in our product and purchasing this wireless camera kit. This product eel confident that you will be pleased with the quality and features of this product. The camera features one CMOS image sensor and a transmitting module to capture the image and transmit them wirelessly. The receiver features a receiving module to receive and display the camera image on a color (LCD) - liquid crystal display. works at ISM-2.4GHz frequency band, which could be legally used worldwide without permission. We f This product has a one year limited warranty with an affective date that begins the date of purchase. Refer to the troubleshooting guide at the end of this manual for help. Contact the phone number provided in that section for any additional support. Please retain proof of purchase receipt for verification. Any attempted disassembly of the product will void the warranty. Do not return defective product to the retailer. Notice Warranty Notice: This product may cause interferences with other wireless equipment that operates at 2.4GHz ISM band. Please turn off one of the equipments to eliminate the interference. Product Assurance: This camera will emit electromagnetic wave, just like other wireless products. But its transmitting power is less than other wireless products such as mobile phones. The 2.4GHz wireless camera meets wireless frequency security standards and recommended indexes while working. These standards and indexes are certificated by academic organization and represent the cogitative research of the scientific workers who continuously explore and annotate the involved fields. So we believe that our products are safe for customers. 1 1 2 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and the receiver. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Changes and modification not expressly approved by the manufacturer or registrant of this equipment can void your authority to operate this equipment under Federal Communications Commissions rules. All our products meet the requirements of approval FCC , and are granted the FCC certification. They are authorized to bear FCC mark. Approval Information FCC 1. DO NOT use this product to violate one's privacy. Monitoring one's activities without consent is illegal and this product is not designed and manufactured for such purpose; 2. DO NOT put this product near any medical equipment. Radio waves might potentially cause breakdown of electrical medical equipment. So this product should be placed at least 1 foot away from any heart pacemaker. Radio waves might potentially influence heart pacemaker and lead to respiratory disturbance; 3. DO NOT use this product for any illegal activities. We shall not be responsible for any consequences of illegal acts committed by the user. Restrictions 1. Do not shake or strike the product; 2. Keep it dry and dustless and avoid exposing it to direct sunlight; 3. Do not place product near any magnetic objects; 4. Avoid putting the product in places where the constantly changed temperature or humidity occurs; 5. Keep product away from heat sources such as electric heater; 6. Do not use the camera near aggressive chemicals; 7. Do not use this camera near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool and the like; 8. Do not use the camera in the places which are enclosed by metal. The surrounding metal like lifter, cabin, may shield the electromagnetic wave, and result in failure of signal reception; 9. Please obey the local government's environment protection policy; 10. Please turn off the power when left unused; 11. Do not disassemble or repair the camera or receiver; doing so might cause damages to the product. And also VOID THE WARRANTY. Maintenance 3 PRODUCT Package Contents This package comes with the following items. Please check whether they are all included in the packaging box, if one or some is missing, contact the retailer for replacement. 4 ① ④⑤⑥ ⑦ ②③ ① ② ③ ④ ⑤ ⑥ ⑦'s Manual 2.4GHz Wireless Camera×1 2.4GHz Wireless Receiver×1 Lithium Battery for R…

Text truncated - open the document above for the full version.

FCCID:TW4AT133 AT132

FCC ID: TW4AT133 Report No.: 061018FIA01 1 FCC TEST REPORT REPORT NO.: 061018FIA01 MODEL NO.: AT132 RECEIVED: Oct. 31, 2006 TESTED: Oct. 31 ~ Nov. 13, 2006 ISSUED: Nov. 13, 2006 APPLICANT: SHENZHEN AEE TECHNOLOGY CO., LTD ADDRESS: 1/F., Blog. B, Tsinghua Hi-Tech Park, Northern Hi-Tech Industrial Park, Nanshan District, Shenzhen, P. R. C ISSUED BY: ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan rd., 201103, Shanghai, China This test report consists of 29 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. ADT (Shanghai) Corporation. V 1.0 FCC ID: TW4AT133 Report No.: 061018FIA01 2 Table of Contents 1 CERTIFICATION............................................................................................ 3 2 SUMMARY OF TEST RESULTS...................................................................... 4 2.1 MEASUREMENT UNCERTAINTY................................................................... 5 3 GENERAL INFORMATION............................................................................. 6 3.1 GENERAL DESCRIPTION OF EUT................................................................. 6 3.2 DESCRIPTION OF TEST MODES................................................................... 6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..................................... 8 3.4 DESCRIPTION OF SUPPORT UNITS............................................................. 9 4 EMISSION TEST......................................................................................... 10 4.1 CONDUCTED EMISSION MEASUREMENT.................................................. 10 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................. 10 4.1.2 TEST RESULTS........................................................................................... 10 4.2 RADIATED EMISSION MEASUREMENT....................................................... 11 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................... 11 4.2.2 TEST INSTRUMENTS.................................................................................. 12 4.2.3 TEST PROCEDURE.................................................................................... 13 4.2.4 DEVIATION FROM TEST STANDARD........................................................... 13 4.2.5 TEST SETUP.............................................................................................. 14 4.2.6 EUT OPERATING CONDITIONS................................................................... 14 4.2.7 TEST RESULTS........................................................................................... 15 4.3 BAND EDGES MEASUREMENT................................................................... 25 4.3.1 LIMITS OF BAND EDGES MEASUREMENT.................................................. 25 4.3.2 TEST INSTRUMENTS.................................................................................. 25 4.3.3 TEST PROCEDURE.................................................................................... 25 4.3.4 DEVIATION FROM TEST STANDARD........................................................... 25 4.3.5 EUT OPERATING CONDITION..................................................................... 25 4.3.6 TEST RESULTS........................................................................................... 26 5 APPENDIX - INFORMATION ON THE TESTING LABORATORY..................... 29 FCC ID: TW4AT133 Report No.: 061018FIA01 3 1 CERTIFICATION PRODUCT: 2.4G wireless camera BRAND NAME: AEE MODEL NO.: AT132 APPLICANT: SHENZHEN AEE TECHNOLOGY CO., LTD TESTED: Oct. 31 ~ Nov. 13, 2006 TEST ITEM: ENGINEERING SAMPLE STANDARDS: 47 CFR Part 15, Subpart C (Section 15.249), ANSI C63.4-2003 The above equipment has been tested by ADT (Shanghai) Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. TECHNICAL ACCEPTANCE : , DATE:NOV. 13, 2006 (Bright Tong) Engineering Supervisor APPROVED BY : , DATE: NOV. 13, 2006 (Wallace Pan) Director of Operations FCC ID: TW4AT133 Report No.: 061018FIA01 4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Paragraph Test Type ResultRemark 15.207 Conducted Emission Test N/A Radiated Emission Test (Mode A1, Channel 1, 30 ~ 1000 MHz) PASS Minimum passing margin is –27.22 dB at 905.42 MHz Radiated Emission Test (Mode A2, Channel 1, 30 ~ 1000 MHz) PASS Minimum passing margin is –8.92 dB at 95.55 MHz Radiated Emission Test (Mode B1, Channel 1, 30 ~ 1000 MHz) PASS Minimum passing margin is –21.89 dB at 369.27 MHz Radiated Emission Test (Mode B2, Channel 1, 30 ~ 1000 MHz) PASS Minimum passing margin is –4.84 dB at 96.60 MHz Radiated Emission Test (Mode A1, Channel 1, Above 1 GHz) PASS Minimum passing margin is –1.58 dB at 2413.4 MHz Radiated Emission Test (Mode A1, Channel 3, Above 1 GHz) PASS Minimum passing margin is –3.62 dB at 2450.6 MHz Radiated Emission Test (Mode A1, Channel 4, Above 1 GHz) PASS Minimum passing margin is –2.18 dB at 2468.5 MHz Radiated Emission Test (Mode A2, Channel 1, Above 1 GHz) PASS Minimum passing margin is –1.09 dB at 2413.2 MHz Radiated Emission Test (Mode A2, Channel 3, Above 1 GHz) PASS Minimum passing margin is –3.87 dB at 2450.6 MHz 15.249 Radiated Emission Test (Mode A2, Channel 4, Above 1 GHz) PASS Minimum passing margin is –2.32 dB at 2468.3 MHz 15.249 Band Edge Measurement PASS Meet the requirement of limit FCC ID: TW4AT133 Report No.: …

Text truncated - open the document above for the full version.

Test mode A1 & B1 Test mode A2 & B2
