TW4LR255Wireless Camera Receiver

English User's Manual 2.4GHz Wireless Remote Control Camera Kit Model: 601LD 2.4GHz Wireless Camera BT601 2.4GHz Wireless Receiver LR255 Please read this manual carefully and thoroughly before any attempt to install and operate this product and retain it for your future reference. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. EU Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. TABLE OF CONTENTS INTRODUCTION 1~3 Notice 1 Approval Information ( FCC/CE) 1~2 Restrictions 3 Maintenance 3 PRODUCT 4~6 Package Contents 4 Feature Locations 5 Adapter 6 INSTALLATION & USAGE 7~10 Installation 7~8 Receiver Remote Control Function 9 Channel Looping Setup 10 SPECIFICATIONS 11 TROUBLESHOOTING 12 INTRODUCTION Thank you for your interest and support in our product and purchasing this wireless camera kit. This product works at ISM-2.4GHz frequency band, which could be legally used worldwide without permission. We f eel confident that you will be pleased with the quality and features of this product. The camera features one CMOS image sensor and a transmitting module to capture the image and transmit them wirelessly. The receiver features a receiving module to receive and output AV signals. Notice Notice: This product may cause interferences with other wireless equipment that operates at 2.4GHz ISM band. Please turn off one of the equipments to eliminate the interference. Product Assurance: This camera will emit electromagnetic wave, just like other wireless products. But its transmitting power is less than other wireless products such as mobile phones. The 2.4GHz wireless camera meets wireless frequency security standards and recommended indexes while working. These standards and indexes are certificated by academic organization and represent the cogitative research of the scientific workers who continuously explore and annotate the involved fields. So we believe that our products are safe for customers. Approval Information All our products meet the requirements of approval FCC or CE, and are granted the FCC or CE certification. They are authorized to bear FCC or CE mark. 1 FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and the receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Changes and modification not expressly approved by the manufacturer or registrant of this equipment can void your authority to operate this equipment under Federal Communications Commissions rules. CE This product complies with standards including Low Voltage Device Directive 73/23/EEC; EMC Directive 89/336/EEC and R&TTE Directive 1999/5/EC. It passed the subject tests by the authority concerned and is authorized to bear CE mark. 2 Restrictions 1. DO NOT use this product to violate one's privacy. Monitoring one's activities without consent is illegal and this product is not designed and manufactured for such purpose; 2. DO NOT put this product near any medical equipment. Radio waves might potentially cause breakdown of electrical medical equipment. So this product should be placed at least 1 feet away from any heart pacemaker. Radio waves might potentially influence heart pacemaker and lead to respiratory disturbance; 3. DO NOT use this product for any illegal activities. We shall not be responsible for any consequences of illegal acts committed by the user. Maintenance 1. Ensure the sufficient ventilation space is available; 2. Do not shake or strike the product; 3. Keep it dry and dustless and avoid exposing it to direct sunlight; 4. Do not place product near any magnetic objects; 5. Avoid putting the product in places where the constantly changed temperature or humidity occurs; 6. Keep product away from heat sources such as electric heater; 7. Do not use the camera near aggressive chemicals; 8. Do not use this camera near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool and the like; 9. Do not use the camera in the places which are enclosed by metal. The surrounding metal like lifter, cabin, may shield the electromagnetic wave, and result in failure of signal reception; 10. Please obey the local government'…

Text truncated - open the document above for the full version.

SHENZHEN AEE TECHNOLOGY CO. LTD 1/F., BLDG. B TSINGHUA HI-TECH PARK, NORTHERN HI-TECH INDUSTRIAL PARK, NANSHAN DISTRICT, SHENZHEN, P.R.C AmericanTCB, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 Subject: Request for Confidentiality FCC ID: TW4LR255 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards Tom Lee Manager of Test Department Shenzhen Aee Technology Co. Ltd.

SHENZHEN AEE TECHNOLOGY CO. LTD 1/F., BLDG. B TSINGHUA HI-TECH PARK, NORTHERN HI-TECH INDUSTRIAL PARK, NANSHAN DISTRICT, SHENZHEN, P.R.C Date: 28 August 2006 AmericanTCB, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 To whom it may concern: We, the undersigned, hereby authorize the Shenzhen office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS SZ, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS SZ on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS SZ as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Tom Lee Manager of Test Department Shenzhen Aee Technology Co. Ltd. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 13, 2006 RE: Shenzhen Aee Technology Co., Ltd. FCC ID: TW4LR255 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram should show the frequencies of all oscillators in the TX portion of the device (CFR 2.1033(a)(5)). Please update. 2) The RF transmitter module appears to show a subshield over a portion of the circuits. FCC expects photographs to also show what is under the subshield portions. Please update. 3) This device appears to be labeled with a DoC logo as well. Please note that that use of the DoC logo should be justified. Although this device may contain a RX, the RX portion defaults to Verification since the TX portion is Certified (see 15.101(b)). Additionally it does not appear that this attached to a PC. Please justify or correct as necessary. 4) Schematics of the TX circuitry portion of the device have not been provided. Please provide. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

LABEL LOCATION

Compliance Certification Services (Shenzhen) Inc. Report No: SZ060824B06-RP FCC ID: TW4LR255 Date of Issue: September 05, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 26 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For 2.4G Receiver Model: LR255 Trade Name: AEE Prepared for SHENZHEN AEE TECHNOLOGY CO., LTD 1/F., BLDG.B, TSINGHUA HI-TECH PARK, NORTHERN HI-TECH INDUSTRIAL PARK, NANSHAN DISTRICT, SHENZHEN, P.R.C Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 5, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No: SZ060824B06-RP FCC ID: TW4LR255 Date of Issue: September 05, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION.............................................................................................................. 5 3.2 EUT EXERCISE......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES.................................................................................................. 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 6 3.5 DESCRIPTION OF TEST MODES................................................................................................. 6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES.............................................................................................................................. 8 5.2 EQUIPMENT............................................................................................................................. 8 5.3 LABORATORY ACCREDITATIONS AND LISTING....................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT.............................................................................................. 9 6.2 SUPPORT EQUIPMENT.............................................................................................................. 9 7. FCC PART 15.231 REQUIREMENTS...................................................................................... 10 7.1 20 DB BANDWIDTH .......................................................................................................... 10 7.2 LIMIT OF TRANSMISSION TIME.............................................................................................. 12 7.3 DUTY CYCLE ..................................................................................................................... 14 7.4 RADIATED EMISSIONS........................................................................................................... 18 7.5 POWERLINE CONDUCTED EMISSIONS.................................................................................... 23 Compliance Certification Services (Shenzhen) Inc. Report No: SZ060824B06-RP FCC ID: TW4LR255 Date of Issue: September 05, 2006 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: SHENZHEN AEE TECHNOLOGY CO., LTD 1/F., BLDG.B, TSINGHUA HI-TECH PARK, NORTHERN HI-TECH INDUSTRIAL PARK, NANSHAN DISTRICT, SHENZHEN, P.R.C Equipment Under Test: 2.4G Receiver Trade Name: AEE Model: LR255 Date of Test: August 24-September 04, 2006 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and Part 15.231. The test results of this report relate only to the tested sample identified in this report. Approved by: Tested By: Henry Ding Reviewed By: Harris Lai / General Manager Eric Wong / Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC. Compliance Certification Services (Shenzhen) Inc. Report No: SZ060824B06-RP FCC ID: TW4LR255 Date of Issue: September 05, 2006 Page 4 Rev. 00 2. EUT DESCRIPTION Product 2.4G Receiver Trade Name AEE Model Number LR255 Model Difference N/A Power Supply RX: DC6V powered by the battery or DC9V powered by the adapter Frequency Range 915 MHz Antenna Designation Dipole Antenna Remark: This submittal(s) (test report) is intended for FCC ID: TW4LR255 filing to comply with Section 15.207, 15.209 and 15.231 of the FCC Part 15, Subpart C Rules. Compliance Certification Services (Shenzhen) Inc. Report No: SZ060824B06-RP FCC ID: TW4LR255 Date of Issue: September 05, 2006 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4: 2003 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2…

Text truncated - open the document above for the full version.

Compliance Certification Services (Shenzhen) Inc. Report No: SZ060824B06-RP FCC ID: TW4LR255 Date of Issue: September 05, 2006 Page 25 Rev. 00 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP LINE CONDUCTED EMISSION TEST Compliance Certification Services (Shenzhen) Inc. Report No: SZ060824B06-RP FCC ID: TW4LR255 Date of Issue: September 05, 2006 Page 26 Rev. 00 RADIATED EMISSION TEST
