U4A-SCYICLS2Microprocessor Controlled Networked Locks

ASSA ABLOY Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Apr 18, 2011
Application Purpose: Original Equipment
Date of Application: Apr 17, 2011
Equipment Note: Microprocessor Controlled Networked Locks
Frequency Range: 13.56000000 - 13.56000000
Company: ASSA ABLOY Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: U4A-SCYICLS2 IC: 6982A-SCYICLS2 FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0071.W06.11.A Manufacturer: Assa Abloy, Inc. Model: P1-IM/IKM Manual A8032D 12/10 Copyright 2010, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. PASSPORT 1000 Mortise Lock Installation Instructions P1 PRELIMINARY 1-800-810-WIRE • www.sargentlock.com • A8078A Copyright © 2010, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited. 10/10/10 Warning ! 1 Observe precautions for handling electrostatic sensitive devices. 1 2 3 4 5 6 7 Table of Contents Warning ...................................................................................2 General Description .................................................................3 Hardware Specifications .........................................................3 Electronic Specifications .........................................................3 Installation Wiring Overview ...................................................3 Installation Wiring ...................................................................4 Parts Breakdown .....................................................................7 Installation Instructions ..........................................................7 Operational Check ................................................................17 8 9 Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Warning SARGENT Mfg. Co. v.P Series locksets utilizing a door position switch (DPS) are not rated for, or intended for use in life safety applications. FCC This equipment has been tested and found to comply with the limits for a Class A digital device, pur- suant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Industry Canada: The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. This Class A digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. Operation is subject to the following two conditions: (1) this device may not cause harm- ful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Cet appareillage numérique de la classe A répond à toutes les exigences de l’interférence canadienne causant des règlements d’équipement. L’opération est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer l’interférence nocive, et (2) ce dispositif doit accepter n’importe quelle interférence reçue, y compris l’interférence qui peut causer l’opération peu désirée. PRELIMINARY 12/15/10 1-800-810-WIRE • www.sargentlock.com • A8032D 3 Copyright © 2010, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited. Passport 1000 Series P1 PoE Mortise Lock Installation Wiring Overview 5 General Description 2 Hardware Specifications 3 • Inside lever retracts latch • Locks furnished for 1-3/4” doors only • Grade 1; UL Listed • Outside lever controlled by any combination of keypad, magnetic keypad, iCLASS, prox (prox- imity) reader, or mechanical cylinder • Complete locksets with on-board memory • Magnetic swipe standard with optional 125 kHz Proximity Reader (specify PRX-), 13.56 MHz reader (specify IKM-), and/or keypad (specify KP-) • ADA Compliant • Easily retrofits existing Passport 1000 door preps (cylindrical locks) • Latch 1/2” standard 3/4” throw fire-rated double doors (optional) (41- prefix) • Guarded latch • Outside lever is unlocked through access control credentials only Electronic Specifications 4 • 2,400 users per lock; 10,000 event audit trail • Multiple time zone and holiday access scheduling • Centralized lock management • Real time door status monitoring • First-In unlock configuration, either by time or by user (selectable) • Lock down capable • Input Power: PoE Class 2 Device, as defined by IEEE 802.3af, requires up to 7 watts over structured cabling • Uses existing Magstripe keycards (track 2) • Magnetic Stripe Card Coercivity: HiCo (4000 Oersted) or LoCo (300 Oersted) • Supports HID 125 kHz prox or 13.56 MHz iCLASS credentials (26 - 39 bit); supports CSN reads for other common 13.56 MHz cards, including MiFare, DesFire, and Felica The SARGENT Passport Series v.P1 cylindrical lock is available with either an HID® Prox 125 kHz or 13.56 MHz iCLASS® technology reader. It utilizes existing infrastructure and IEEE 802.3af PoE (Power over Ethernet) providing access control with Magnetic swipe and optional Proximity Reader and/or Keypad, as well as detailed audit capabilities- technology as a proven alternative to traditional access control installations. The v.P1 is a self-contained microproces- sor-controlled access control product with non-volatile memory. It uses the existing network cable to communicate with access control systems. The v.P1 lock holds a total of 2…
