80-9358-0004-020 Rev 3 5800ADAEZ2 Wireless Wall Switch Transmitter Installation Instructions Installation Sequence: 1. Slide connectors on RF transmitter board onto COM and NO tabs on switch. 2. See 5800 installation instructions for programming details for switch and RF transmitter board. Copyright © 2025, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited. Warnings: - This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that my cause undesired operation. - Changes or modifications not expressly approved could void authority to operate the equipment. Product Certification Numbers: FCC ID: U4A5800ADAEZ2 IC: 6982A-5800ADAEZ2 HVIN: 5800ADAEZ2 Notice: - This device contains license-exempt transmitter(s) / receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of this device.

Date: September 9, 2025 Attention: Application Examiner RE: Certification designating a U.S. agent for service of process pursuant to 47 CFR part 2.911(d)(7) of the FCC rules To Whom It My Concern: This letter is to certify that ASSA ABLOY Inc. (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part 2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FDD ID designed below. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission- related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name: Contact Name: Address: Telephone No.: Email: FCC ID: Applicant FRN: ASSA ABLOY Inc. James W Forte 110 Sargent Drive, New Haven, CT 06511 203-821-5788 [email protected] U4A5800ADAEZ2 0016550824 Jim Forte Regulatory Compliance Project Manager

Date: September 9, 2025 Attention: Application Examiner RE: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47CFR parts 2.903 and 2.911(d)(5)(ii) of the FCC rules Applicant: ASSA ABLOY Inc FCC ID: U4A5800ADAEZ2 To Whom It My Concern: ASSA ABLOY Inc. (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part 2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant of 47 CFR part 1.50002 and required by 47 CFR part 2.911(d)(5)(ii) of the FCC rules. Applicant further certifies that no Cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment wit h integrated Kaspersky Lab, inc. (or any of its successors and assignees) cybersecurity or anti-virus software is installed in the equipment being certified. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change to the status identified above. Jim Forte Regulatory Compliance Project Manager

Date: August 22, 2025 Attention: Application Examiner RE: Request for Confidentiality Applicant: ASSA ABLOY Inc. FCC ID: U4A5800ADAEZ2 To Whom It My Concern: Permanent Confidentiality Request is hereby submitted by ASSA ABLOY Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: •Schematics •Detailed Block Diagrams •Detailed Operational / Functional Description Rationale for request for confidentiality: ASSA ABLOY Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have any questions or need further information, please contact the undersigned. Sincerely, Jim Forte Regulatory Compliance Project Manager

© ASSA ABLOY. All rights reserved 1 Norton Rixson FCC ID U4A5800ADAEZ2 Back view of board Front view of board Antenna

Label - 5800 FCC TRANSMITTER BOARD 80-9310-0591-020 Rev 3 Rev. Eng. Description 1 tommcn ECN 25-0240 New Label Copyright © 2025, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited. 80-9310-0591-020 11-253 www.nortonrixson.com 1-877-974-2255 3/8” NOTES: 1. MATERIAL: 3M 7872 2.0 MATTE SILVER POLYESTER THERMAL TRANSFER W/ PERMANENT ADHESIVE. 2. COLOR: 1 BLACK PRINT ON WHITE MATERIAL. 3. POSITION OF TEXT FOR REFERENCE ONLY. 4. FONT TO BE 4PT MINIMUM. 5/8” ACTUAL SIZE NOT TO SCALE FCC ID:U4A5800ADAEZ2 IC: 6982A-5800ADAEZ2 HVIN: 5800ADAEZ2 80-9310-0591-020 R3 2 tommcn Removed ‘-’ from FCC ID FCC ID:U4A5800ADAEZ2 IC: 6982A-5800ADAEZ2 HVIN: 5800ADAEZ2 80-9310-0591-020 R3 3 tommcn Change size of label; updated text per review FCC ID:U4A5800ADAEZ2 IC: 6982A-5800ADAEZ2 HVIN: 5800ADAEZ2 80-9310-0591-020 R3 For Reference: Location of label on Transmitter Board REVDATE TEMPLATE NUMBER

© ASSA ABLOY. All rights reserved 1 Norton Rixson FCC ID U4A5800ADAEZ2 Back view of board Front view of board Antenna

ASSA ABLOY Inc RF Exposure Exhibit SCOPE OF WORK EMC TESTING – Transmitter Board, Model: ADA1012 REPORT NUMBER 106183429MPK-003 ISSUE DATE September 09, 2025 REVISED DATE February 06, 2026 PAGES 9 DOCUMENT CONTROL NUMBER Non-Specific Radio Report Shell Rev. December 2017 MPK © 2017 INTERTEK Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for ASSA ABLOY Inc on the ADA1012 Page 2 of 9 RF Exposure Exhibit (Portable devices) Report Number: 106183429MPK-003 Project Number: G106183429 Report Issue Date: September 09, 2025 Revised Date: February 06, 2026 Product Designation: Model Tested: FCC ID: IC: Transmitter Board ADA1012 U4A5800ADAEZ2 6982A-5800ADAEZ2 to 47CFR 2.1093 RSS-102 Issue 6 for ASSA ABLOY Inc Tested by: Client: Intertek 1365 Adams Court Menlo Park, CA 94025 USA ASSA ABLOY Inc 110 Sargent Dr New Haven, CT 06511 USA Report prepared by: Report reviewed by: Kenneth Tutor / EMC Project Engineer Minh Ly / EMC Team Lead This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. REPORT NUMBER: 106183429MPK-003 Issued: September 09, 2025 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for ASSA ABLOY Inc on the ADA1012 Page 3 of 9 Report No. 106183429MPK-003 Equipment Under Test: Transmitter Board Model(s) Tested: ADA1012 Applicant: ASSA ABLOY, Inc Contact: Tommy McNally Address: 110 Sargent Dr New Haven, CT 06511 Country: USA Email: [email protected] Applicable Regulation: 47CFR 2.1093 RSS-102 Issue 6 REPORT NUMBER: 106183429MPK-003 Issued: September 09, 2025 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for ASSA ABLOY Inc on the ADA1012 Page 4 of 9 TABLE OF CONTENTS 1.0 RF Exposure Summary.................................................................................................................. 5 2.0 RF Exposure Limits ....................................................................................................................... 5 3.0 Test Results (Portable Configuration) ......................................................................................... 6 4.0 Document History .......................................................................................................................... 9 REPORT NUMBER: 106183429MPK-003 Issued: September 09, 2025 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for ASSA ABLOY Inc on the ADA1012 Page 5 of 9 1.0 RF Exposure Summary Test Reference FCC Reference Industry Canada Result Radio frequency Radiation Exposure Evaluation 47 CFR§2.1093 RSS-102 Issue 6 Complies 2.0 RF Exposure Limits 2.1 FCC Limits According to FCC KDB 447498 D01 v06, at frequency 315 MHz and separation distance of ≤ 5 mm the equation and threshold in section 4.3.1 must be applied to determine the SAR exclusion. The SAR exclusion threshold is determined by the following formula (KDB 447498 D01 Section 4.3.1(a)) 2.2 Industry Canada Limits According to RSS-102 sec. 6.3, at frequency 315MHz and separation distance of ≤ 5 mm SAR Exemption limit is ≤ 32 mW. REPORT NUMBER: 106183429MPK-003 Issued: September 09, 2025 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for ASSA ABLOY Inc on the ADA1012 Page 6 of 9 3.0 Test Results (Portable Configuration) 3.1 Classification 1. For purposes of this section, a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Per the applicant, ASSA ABLOY Inc, the AD1012 is not intended to be worn on the body; however, the user may be within 20cm of the device during transmission. 3.2 EIRP calculations The Transmitter Board consists of a 315 MHz radio. Note: The 315MHz radio complies with Field Strength limits of 47 CFR FCC Part 15 sub part 15.231 as per test Report # 106183429MPK-001. 3.3 Maximum RF Power Frequency (MHz) Average FS @ 3m (dBμV/m) EIRP (dBm) EIRP (mW) Note 315 69.91 -25.35 0.00292 FS measurements were taken from Report #106183429MPK-001. REPORT NUMBER: 106183429MPK-003 Issued: September 09, 2025 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for ASSA ABLOY Inc on the ADA1012 Page 7 of 9 3.4 RF Exposure Calculation for Transmitter Board 3.4.1 RF Exposure calculation for FCC KDB 447498 D01 v06 According to FCC KDB 447498 D01 v06, at frequency 315 MHz and separation distance of ≤ 5 mm, SAR test exclusion threshold limit is less than 3 for 1-g SAR. Maximum Average Field Strength measured = 69.91dBμV/m or -25.35dBm or 0.00292mW (from Report #106183429MPK-001). According to MICRF112 chip datasheet, the maximum output power of 10dBm was used for calculation as worse-case power. This value was provided by the client and may affect compliance. Intertek does not claim compliance for values other than those shown. No duty cycle was considered. According to KDB 447498 D01 Section 4.3.1 the SAR test exclusion condition is based on source-based time-averaged maximum conducted output power, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The SAR exclusion threshold is determined by the following fo…

Text truncated - open the document above for the full version.

Norton Rixson January 27 th , 2026 5800 RF TX, Rev 7 PN: 41-5800-0012 Antenna Construction Report Public 1.0 Antenna Design The antenna for PN 41-5800-0012, also referred to as “5800 RF TX”, was designed based on Micrel/Microchip’s design notes to go with the MICRF112 integrated circuit. These documents are being sent with this document for reference: a. TX112PCB_Layout.doc b. TX112_ANT_DIM_TOP.pdf c. TX112_ANT_DIM_BOT.pdf These describe the layout of the antenna, and where the ground plane should stop. There is an example layout of the RF IC and associated components, which was used as a reference, but some changes were made, since the components used and the components in the example were not one-to-one. Figure 1: Excerpt from TX112PCB_Layout.doc Norton Rixson January 27 th , 2026 5800 RF TX, Rev 7 PN: 41-5800-0012 Antenna Construction Report Public 2.0 41-5800-0012 Antenna Details The PCBA for the 41-5800-0012 is a four layer PCBA. However, all traces and planes, except the antenna traces, stop before the antenna region, as specified by the MICRF112 antenna recommendations, as can be seen in Figure 2. Also visible in Figure 2, is the actual dimensions of the 41-5800-0012 board. Figure 2: 41-5800-0012 Layout, Viewed in Altium Figure 3 shows the layer stackup for the PCB. In the antenna region, the Ground and Power layers have been removed. This means the total dielectric thickness between the top and botton traces is approximately 55.6mils +/-13%. Both the top and bottom antenna traces are 1oz copper. Norton Rixson January 27 th , 2026 5800 RF TX, Rev 7 PN: 41-5800-0012 Antenna Construction Report Public Figure 3: 41-5800-0012 Layer Stackup The upward protrusion of the planes to the left of the antenna starts 191mils (4.85mm) away and is outside the current loop of the antenna. The dimensions of the plane, nearest the antenna, can be see in Figure 4. Figure 4: Dimensions of Plane Protrusion, Near Antenna Norton Rixson January 27 th , 2026 5800 RF TX, Rev 7 PN: 41-5800-0012 Antenna Construction Report Public Finally, exact dimensions of the antenna were used from the dimensions in the referenced documents TX112_ANT_DIM_TOP.pdf and TX112_ANT_DIM_BOT.pdf (included with this package, and referenced in Figure 5 and Figure 6). The layout of the RF circuit and board dimensions varies. Figure 5: Antenna Layout – Top Layer Norton Rixson January 27 th , 2026 5800 RF TX, Rev 7 PN: 41-5800-0012 Antenna Construction Report Public Figure 6: Antenna Layout – Bottom Layer

EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 Page 1 of 25 TEST REPORT Report Number: 106183429MPK-001 Project Number: G106183429 Report Issue Date: August 28, 2025 Revised Date: February 05, 2026 Testing performed on the Transmitter Board Model Number: AD1012 FCC ID: U4A5800ADAEZ2 IC: 6982A-5800ADAEZ2 to FCC Part 15 Subpart C (15.231) Industry Canada RSS-210 Issue 11 For ASSA ABLOY Inc Test Performed by: Test Authorized by: Intertek 1365 Adams Court Menlo Park, CA 94025 USA ASSA ABLOY Inc 110 Sargent Dr New Haven, CT 06511 USA Prepared by: Date: AUGUST 28, 2025 Kenneth Tutor Reviewed by: Date: AUGUST 28, 2025 Minh Ly This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 Page 2 of 25 Report No. 106183429MPK-001 Equipment Under Test: Transmitter Board Model Number: ADA1012 Applicant: ASSA ABLOY, Inc Contact: Tommy McNally Address: 110 Sargent Dr New Haven, CT 06511 Country: USA Tel. Number: +1 (704) 233-1516 Email: [email protected] Applicable Regulation: FCC Part 15 Subpart C (15.231) Industry Canada RSS-210 Issue 11 Date of Test: April 18, 2025 to February 4, 2026 We attest to the accuracy of this report: Kenneth Tutor EMC Engineer Minh Ly EMC Team Leader EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 Page 3 of 25 TABLE OF CONTENTS 1.0 Summary of Tests ....................................................................................................................... 4 2.0 General Description ................................................................................................................... 5 2.1 Product Description ............................................................................................................ 5 2.2 Related Submittal(s) Grants ................................................................................................ 6 2.3 Test Methodology ............................................................................................................... 6 2.4 Test Facility ......................................................................................................................... 6 2.5 Measurement Uncertainty ................................................................................................. 6 3.0 System Test Configuration ......................................................................................................... 7 3.1 Justification ......................................................................................................................... 7 3.2 Block Diagram of Test Setup ............................................................................................... 7 3.3 Justification ......................................................................................................................... 9 3.4 Software Exercise Program ................................................................................................. 9 3.5 Mode of Operation during test ........................................................................................... 9 3.6 Modifications required for Compliance. ............................................................................. 9 3.7 Additions, deviations, and exclusions from standards ....................................................... 9 4.0 Measurement Results .............................................................................................................. 10 4.1 Field Strength of Fundamental and Spurious Radiated Emission ............................................ 10 4.2 Occupied Bandwidth ................................................................................................................ 17 4.3 Deactivation Testing ................................................................................................................ 19 5.0 List of Test Equipment .............................................................................................................. 20 6.0 Document History .................................................................................................................... 21 Appendix A. Duty Cycle Correction Factor Calculation .......................................................................... 22 EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 Page 4 of 25 1.0 Summary of Tests TEST FCC REFERENCE ISED REFERENCE RESULTS Field Strength of Fundamental and Spurious Emissions §15.231 (b), §15.205 RSS-210, Issue 11 §A.1.3 Complies Occupied Bandwidth §15.231 (c) RSS-210, Issue 11 §A.1.4 Complies Deactivation Testing §15.231(a) RSS-210, Issue 11 §A.1.2 Complies Antenna requirement §15.203 RSS-Gen Issue 5 §6.8 Complies 1 Line Conducted Emissions §15.207 RSS-Gen Issue 5 §7.2 Not Applicable 2 1 EUT utilizes an internal Antenna. 2 EUT is battery operated. EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 Page 5 of 25 2.0 General Description 2.1 Product Description ASSA ABLOY Inc suppl…

Text truncated - open the document above for the full version.

EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 TEST SETUP PHOTOGRAPH Radiated Emission, 9kHz – 30MHz EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 Radiated Emission, 30MHz – 1GHz EMC Report for ASSA ABLOY Inc on the AD1012 File: 106183429MPK-001 Radiated Emission, 1GHz – 4GHz
