U4A-YRIZW1USPush Button and Touch Screen Deadbolt Locks

ASSA ABLOY Inc.

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Apr 06, 2014
Application Purpose: Original Equipment
Date of Application: Apr 06, 2014
Equipment Note: Push Button and Touch Screen Deadbolt Locks
Frequency Range: 908.42000000 - 908.42000000
Company: ASSA ABLOY Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: U4A-YRIZW1US IC: 6982A-YRIZW1US FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 14-0099 Manufacturer: Assa Abloy Inc. Models: YRD110-ZW-US, YRD120-ZW-US Manual P/N AYRD-110-INST-FUL Rev A x4 x2 x3 2-3/8" position UP 2-3/4" position UP Press Pull O optional x4 Installing Latch & Strike Plate 1 Bolt must be in retracted (unlocked) position. Note horizontal orientation of mechanism. ! Installing Keypad Escutcheon 2 Outside of DoorInside of Door Bolt must be in retracted (unlocked) position. Note horizontal orientation of mechanism. ! x2 Installing Interior Mounting Plate 3 Attaching the Cable Assembly 4 x3 Installing Interior Escutcheon 5 Testing Operation Handing the Lock Bolt must be in retracted (unlocked) position before installing batteries. ! Installing Cover 6 Press . Press . Enter new Master PIN code (4-8 digits). Press to complete. Yale Real Living™ Installation and Programming Instructions Preparing Door After entering the Master PIN code, press any key to complete handing. Key Free Push Button Deadbolt B1L with WAVE ® #8-32 x 5/16’’ Machine screws #7 wood & #8-32 machine x 20mm Combination screws M6x47mm Long through bolt Congratulations, you've installed the Yale Real Living™ Key Free Push Button Deadbolt B1Lwith ! Turn sheet over for Programming Instructions to customize your product. WAVE ® Programming Instructions Press Enter Master PIN code Press Enter User number to be created (1-100)*. Enter 4-8 digit PIN code "Unlock" Master PIN Code Setting M M User PIN Code Registration Register Delete Advanced Lock Settings Audio Mode N/A All Code Lockout Mode Network Setting Join the network Enable Enable Disable Exit the network Disable User Number (UN) 1~100: with network module 12 U Automatic Re-lock Enable Disable One Touch Locking Enable Disable Feature Programming Through Menu Mode Using Master PIN code* *The Master PIN code must be registered prior to any other programming of the lock. Handing the Lock For quiet areas, select Disable (3) in Audio Mode. 1. Enter the 4-8 digit Master PIN code followed by the key. 2. Enter digit corresponding to the function to be performed followed by the key. Note: If the lock is connected to a network controller, it is recommended that it is programmed through the centralized user interface (PC or hand-held device) to ensure communication between the lock and the controller unit. Programming Troubleshooting * When batteries are replaced, Network locks have a real time clock that will be set through the User Interface (UI); it is recommended to verify correct date and time particularly those locks operating under Daylight Saving Time (DST). Symptom Suggested Action Lock does not respond – door is open and accessible. • Press each keypad button for response when pressed. • Check batteries are installed and oriented correctly (polarity) in the battery case. • Check batteries are in good condition; replace batteries* if discharged. • Check to see if cable is fully connected and not pinched. • Batteries may be completely discharged. • Apply 9V battery to terminals below the keypad for backup power option. Unit chimes to indicate code acceptance, but the door will not open. • Check to see if there is another locking device on the door. • Check the door gaps for any foreign objects between door and frame. • Check that the cable is firmly connected to the PC board. Unit operates to allow access, but will not automatically re-lock. • Check to see if Auto Re-lock Mode is enabled. • If low battery indicator is lit (see below), change batteries*. PIN codes will not register. • PIN codes must consist of 4 to 8 digits to register. • The same PIN code cannot be used for multiple users. • Registration/management of PIN codes is set by the authority of the Master Code. • Contact the Master user. • User codes must be entered within 5 seconds or the process will have to be restarted. • Check mark or gear cannot be used as part of the Upon entering a PIN code and pressing the (*) key, the lock gives a series of beeps, flashes red & blue LEDs 7 times, and does not unlock. • All Code Lockout Mode is enabled. • Only the Master can enable/disable All Code Lockout Mode. • Contact the Master user. Upon entering a PIN code and pressing the (*) key, there are different tones. • Check to see if the lock is set to All Code Lockout Mode. • Setting/managing All Code Lockout Mode is done through Master Code only. Contact the Master user. The unit operates, but it makes no sound. • Enable Audio Mode. The unit displays inter- mittent RED flashes. • This is the Low Battery indicator alerting that it is time to replace the batteries. Replace all four (4) batteries* with new AA Alkaline batteries. Upon entering a PIN code and pressing the (*) key, the unit responds with a series of beeps and the keypad flashes three times. • The digits entered were incorrect or incomplete. Re-enter the correct code followed by the check mark (*) key. All Code Lockout Mode: This feature is enabled by the Master code. When enabled, it restricts all user (except Master) PIN code access. When attempting to enter a code while the unit is in Lockout, the Status Indicator flashes RED (8 times); the keypad flashes as well. Audio Mode: Choosing Disable (3) in Audio mode shuts off the code confirmation tone play-back for use in quiet areas. Audio mode is enabled or disabled through feature programming by the Master code. Automatic Re-lock Time: After a successful unlock, the unit will automatically re-lock after a default of thirty (30) seconds. Re-lock time is adjustable** from 10-180 seconds. Low Battery: When battery power is low, the Status Indicator flashes RED. If battery power is completely lost, use the 9Volt battery override. To use the 9V battery override apply 9V battery, in either direction, to terminals below the keypad for backup power option. Wake …

Text truncated - open the document above for the full version.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: U4A-YRIZW1US IC: 6982A-YRIZW1US FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 14-0099 Manufacturer: Assa Abloy Inc. Models: YRD110-ZW-US, YRD120-ZW-US Manual P/N AYRD-120-INST-FUL Rev A x4 x2 x3 2-3/8" position UP 2-3/4" position UP Press Pull O optional x4 Installing Latch & Strike Plate 1 Bolt must be in retracted (unlocked) position. Note horizontal orientation of mechanism. ! Installing Touchscreen Escutcheon 2 Outside of DoorInside of Door Bolt must be in retracted (unlocked) position. Note horizontal orientation of mechanism. ! x2 Installing Interior Mounting Plate 3 Attaching the Cable Assembly 4 x3 Installing Interior Escutcheon 5 Testing Operation Handing the Lock Installing Cover 6 Press . Press . Enter new Master PIN code (4-8 digits). Press to complete. Preparing Door Bolt must be in retracted (unlocked) position before installing batteries. ! After entering the Master PIN code, press any key to complete handing. #8-32 x 5/16’’ Machine screws #7 wood & #8-32 machine x 20mm Combination screws M6x47mm Long through bolt Yale Real Living™ Installation and Programming Instructions Key Free Touchscreen Deadbolt T1L with WAVE ® Congratulations, you've installed the Yale Real Living™ Key Free Touchscreen Deadbolt T1L with ! Turn sheet over for Programming Instructions to customize your product. WAVE ® Programming Instructions Press Enter Master PIN code Press Enter User number to be created (1-100)*. Enter 4-8 digit PIN code "Unlock" Master PIN Code Setting M M User PIN Code Registration Register Delete Advanced Lock Settings Audio Mode N/A All Code Lockout Mode Network Setting Join the network Enable Enable Disable Exit the network Disable User Number (UN) 1~100: with network module 12 U Automatic Re-lock Enable Disable One Touch Locking Enable Disable Feature Programming Through Menu Mode Using Master PIN code* *The Master PIN code must be registered prior to any other programming of the lock. Handing the Lock For quiet areas, select Disable (3) in Audio Mode. 1. Enter the 4-8 digit Master PIN code followed by the key. 2. Enter digit corresponding to the function to be performed followed by the key. Note: If the lock is connected to a network controller, it is recommended that it is programmed through the centralized user interface (PC or hand-held device) to ensure communication between the lock and the controller unit. Programming Troubleshooting * When batteries are replaced, Network locks have a real time clock that will be set through the User Interface (UI); it is recommended to verify correct date and time particularly those locks operating under Daylight Saving Time (DST). Symptom Suggested Action Lock does not respond – door is open and accessible. • Press each touchscreen key for response when pressed. • Check batteries are installed and oriented correctly (polarity) in the battery case. • Check batteries are in good condition; replace batteries* if discharged. • Check to see if cable is fully connected and not pinched. • Batteries may be completely discharged. • Apply 9V battery to terminals below the touchscreen for backup power option. Unit chimes to indicate code acceptance, but the door will not open. • Check to see if there is another locking device on the door. • Check the door gaps for any foreign objects between door and frame. • Check that the cable is firmly connected to the PC board. Unit operates to allow access, but will not automatically re-lock. • Check to see if Auto Re-lock Mode is enabled. • If low battery indicator is lit (see below), change batteries*. PIN codes will not register. • PIN codes must consist of 4 to 8 digits to register. • The same PIN code cannot be used for multiple users. • Registration/management of PIN codes is set by the authority of the Master Code. • Contact the Master user. • User codes must be entered within 20 seconds or the process will have to be restarted. • Check mark or gear cannot be used as part of the Upon entering a PIN code and pressing the key, the lock gives a series of beeps, flashes red 7 times, and does not unlock. • All Code Lockout Mode is enabled. • Only the Master can enable/disable All Code Lockout Mode. • Contact the Master user. Upon entering a PIN code and pressing the key, there are different tones. • Check to see if the lock is set to All Code Lockout Mode. • Setting/managing All Code Lockout Mode is done through Master Code only. Contact the Master user. The unit operates, but it makes no sound. • Enable Audio Mode. The unit displays inter- mittent RED flashes. • This is the Low Battery indicator alerting that it is time to replace the batteries. Replace all four (4) batteries* with new AA Alkaline batteries. Upon entering a PIN code and pressing the key, the unit responds with a series of beeps and the touchscreen flashes three times. • The digits entered were incorrect or incomplete. Re-enter the correct code followed by the check mark (*) key. Lock does not respond – door is locked and inaccessible. PIN code. Press Press Press STOP 0:20 Press Press Press Definitions Creating Master PIN Code 1 Press Press Enter 4-8 digit Master PIN Code. Press Creating User PIN Codes 2 Master PIN code must be created first. *Max User Codes = 100 Unlocking Door with PIN Code 3 Enter PIN Press Resetting Lock to Factory Default Factory Default Settings Settings Factory Default Master PIN Code Registration required* Automatic Re-lock Disabled One Touch Locking Enabled AudioEnabled Automatic Re-lock Time **30 Seconds Wrong Code Entry Limit **5 Times Shutdown Time**60 Seconds **Adjustable through a Z-Wave controller. ® *The Master PIN code must be registered prior to any other programming of the lock. When lock is reset to factory defaults all user codes (including the Master PIN code*) are deleted and all programming features are reset to original default settings (see "Fac…

Text truncated - open the document above for the full version.

Cover Letter(s)

Americas Division 110 Sargent Drive New Haven, CT 06511 USA Phone: +1 203 821-5714 Fax: +1 203 603-5981 Email: [email protected] Steven Pfalzgraf Applications Engineer March 5, 2014 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: U4A-YRIZW1US to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC ID: U4A-YRIZW1US listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Steven Pfalzgraf Applications Engineer

Cover Letter(s)

Americas Division 110 Sargent Drive New Haven, CT 06511 USA Phone: +1 203 821-5714 Fax: +1 203 603-5981 Email: [email protected] Steven Pfalzgraf Applications Engineer March 5, 2014 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST Gentlemen: ASSA ABLOY Inc. respectfully requests confidentiality of certain materials provided with the submission of the YRD110-ZW-US, and YRD120-ZW-US respectively under FCC ID: U4A- YRIZW1US in accordance with FCC Regulations 0.459. The confidentiality request applies to any and all schematics, engineering drawings and bills of material contained in this filing and included in the following files. ASSA ABLOY Documents: 14-0099 – Schematics.pdf 14-0099 – System Block Diagram.pdf 14-0099 – Theory of Operation.pdf The YRD110-ZW-US and YRD120-ZW-US have been developed at considerable effort and expense by ASSA ABLOY Inc. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. Sincerely, Name:Steven PfalzgrafSignature: Title:Applications EngineerDate: March 5, 2014

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 March 31, 2014 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: U4A-YRIZW1US To Whom It May Concern: The following application is submitted on behalf of our client, Assa Abloy Inc., for evaluation of their models YRD110-ZW-US and YRD120-ZW-US for certification under FCC Part 15.249. Models YRD110-ZW-US and YRD120-ZW-US are electromechanical deadbolt locks, where the user can interact with the lock by using the touchscreen/pushbuttons on the outside escutcheon, a few buttons and a thumbturn on the inside escutcheon, and/or by sending Z-Wave RF commands to it using the proper Z- Wave controller. The only difference between the two models is that one has a pushbutton interface, and the other has a touchscreen interface on the front escutcheon. All other functionality is the same. The YRD110-ZW-US and YRD120-ZW-US were both tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

External Photos

ID Label/Location Info

Internal Photos

Test Report

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: U4A-YRIZW1US IC: 6982A-YRIZW1US FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Report Number: 14-0099.W06.1A Manufacturer: Assa Abloy Inc. Model(s): YRD110-ZW-US, YRD120-ZW-US Test Begin Date: March 18, 2014 Test End Date: March 18, 2014 Report Issue Date: March 31, 2014 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 14 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1GENERAL .............................................................................................................................................. 3 1.1PURPOSE............................................................................................................................................ 3 1.2PRODUCT DESCRIPTION..................................................................................................................... 3 1.3TESTMETHODOLOGY ANDCONSIDERATIONS................................................................................... 3 2TEST FACILITIES ................................................................................................................................ 4 2.1LOCATION......................................................................................................................................... 4 2.2LABORATORYACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS.................................................. 4 2.3RADIATEDEMISSIONSTESTSITEDESCRIPTION................................................................................ 5 2.3.1Semi-Anechoic Chamber Test Site ........................................................................................... 5 2.3.2Open Area Tests Site (OATS) ................................................................................................... 6 2.4CONDUCTEDEMISSIONSTESTSITEDESCRIPTION............................................................................ 7 3APPLICABLE STANDARD REFERENCES ..................................................................................... 7 4LIST OF TEST EQUIPMENT.............................................................................................................. 8 5SUPPORT EQUIPMENT ...................................................................................................................... 9 6EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ............................................................ 9 7SUMMARY OF TESTS ....................................................................................................................... 10 7.1ANTENNAREQUIREMENT–FCC15.203......................................................................................... 10 7.2POWERLINECONDUCTEDEMISSIONS–FCC15.207;ICRSS-GEN7.2.4 ...................................... 10 7.320DB/99%BANDWIDTH–FCC15.215;ICRSS-GEN4.6............................................................. 10 7.3.1Measurement Procedure ........................................................................................................ 10 7.3.2Measurement Results.............................................................................................................. 10 7.4FUNDAMENTALFIELDSTRENGTH–FCC15.249(A);ICRSS-210A2.9(A) .................................... 12 7.4.1Measurement Procedure ........................................................................................................ 12 7.4.2Measurement Results.............................................................................................................. 12 7.5RADIATEDSPURIOUSEMISSIONS–FCC15.249(A)(D)(E);ICRSS-210A2.9(A)(B) ....................... 13 7.5.1Measurement Procedure ........................................................................................................ 13 7.5.2Measurement Results.............................................................................................................. 13 7.5.3Sample Calculation: ............................................................................................................... 14 8CONCLUSION ..................................................................................................................................... 14 Model(s): YRD110-ZW-US, YRD120-ZW-US FCC ID: U4A-YRIZW1US IC: 6982A-YRIZW1US ACS Report: 14-0099.W06.1AAdvanced Compliance SolutionsPage 3 1GENERAL 1.1Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210 for Certification. 1.2Product description Models YRD110-ZW-US and YRD120-ZW-US are electromechanical deadbolt locks, where the user can interact with the lock by using the touchscreen/pushbuttons on the outside escutcheon, a few buttons and a thumbturn on the inside escutcheon, and/or by sending Z-Wave RF commands to it using the proper Z-Wave controller. The lock features include but are not limited to user pin codes, user schedules, automatic (using a small motor) and manual operation of the deadbolt locally and/or remotely, logging lock events locally, reporting events and/or status to a controller over RF, etc. The product consists of the outside escutcheon (where the keypad/touchscreen is), the main/inside escutcheon, and the deadbolt assembly. All components and circuits related to RF communications are on the PCB of the main escu…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

James Forte(Senior Product Compliance Engineer)

[email protected]2038215788Fax: 2034985600

Test Firm

Advanced Compliance Solutions, Inc.Randy Abernathy

[email protected]770-831-8048Fax: 770-831-8598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	908.42 MHz - 908.42 MHz	-

Confidentiality

Long Term
