UCE111037AUMTS Cellular Mobile Radio with RFID

P-04C INSTRUCTION MANUAL ’11.5 Thank you for selecting the “docomo STYLE series P-04C”. Read this manual befo re use to correctly operate your P-04C. For Using This Manual ⿠Note that “P-04C” is referred to as “FOMA terminal” in this manual. ⿠Most operating procedures and displays in this manual are shown with the default settings of the “White” handset. Further, displays and illustrations show n in this manual are for reference. The actual ones might differ. ⿠Most operating pro cedures and displays in this manual are described when the FOMA terminal is in Normal Style. See page 34 for the operations in Viewer Style (Touch panel). ⿠P-04C Handset (With Wa rranty and Back Cover P49) ⿠Battery Pack P23 ⿠Instruction Manual (Ja panese version) ※ A CRYSTAL TOUCH PEN is provided as a free gift to users who purch ase a special model. ⿠See page 10 2 for optional items that support this FOMA terminal. About manual of P-04C The operating procedures for the P-04C are also published as in “ (Guide)” on - scre en manual installed onto your FOMA terminal, and “Instruction Manual (Detailed Ve rsion)” as a PDF. (In Japanese only) “Instruction Manual” (this manual) Description of the displayed content and operating pro cedures for basic functions “ (Guide)” (installed onto your FOMA terminal) Description of the outline and operations of frequently used functions From the P-04C m (Tool) (Guide) This function is available in Japanese mode only. “Instruction Manual (Detailed Version)” (PDF) Fro m a PC, download detailed information about all the functions and the operating procedures. (In Japanese only) ( http://www. nttdocomo.co.jp/support/trouble/manual/ download/index.html) ※ Note that the URL and published contents may be modified without notice. Basic Package ⿠Touch Pen P01 ※ ⿠Desktop Holder P45 1 ※It is prohibited to copy all or part of this manual without permission. ※The instructions contained in this manual may be changed without notice. Contents Introduction ▶ P.1～ FOMA Terminal ································2 What You can Do with P-04C ···········3 Part Names and Functions ··············4 Styles ···············································6 P recautions ······································7 Handling P recautions ····················16 Waterproof Performance ···············19 Basic Operation ▶ P.24～～ Before Using ···················································24 Screen Explanation ········································29 Character Entry ··············································39 Sound/Scr een Setting ····································41 Lock/Security ··················································46 Connect ▶ P.51～～ Call Telephone ················································51 Mail ··································································59 Phonebook ·····················································64 Search ▶ P.66～～ i - mode/Full Browser ·······································66 i - Channel ·························································69 Map/GPS ························································70 Enjoy ▶ P.73～～ Camera ····························································73 1Seg ································································76 Music ·······························································80 i - α ppli/i - Widget ···············································82 i - motion/Movie ···············································84 More Convenient ▶ P.85～～ Osaifu - Keitai ···················································85 i - concier ··························································86 Convenient T ools ············································87 Data Management ··········································90 Others ▶ P.95～～ Support ···························································95 Appendix ·······················································103 Index ·····························································115 2 Introduction FOMA Terminal ⿠P-04C supports W - CDMA system. ⿠Because the FOMA terminal uses radio waves, you cannot use it in places where the radio waves do not reach, where they are weak even outdoors, such as inside tunnels, basements, or buildings, or out - of - service area. You might not be able to operate the FOMA terminal even when you are in a place with a fi ne view such as in a high - rise building or apartment. Note that you ma y experience interruption of calls even if the three antennas respond to a strong radio wave, and you remain without moving to use the FOMA terminal. ⿠Since the FOMA terminal uses radio waves as the medium of telecommunication, calls may be tapped by a third party. However, the W - CDMA system automatically supports tapping prevention, so your conversation will be incomprehensible to the third par ty, because it is recognized as mere noise. ⿠The FOMA terminals change your voice into digital signals and send them to the other party. In places where the radio waves are weak, the digital signals may not be converted correctly, and in such a case, the voice may sound different from the actual one. ⿠The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS. Neither DOCOMO nor the certifi ers as listed herein make any representation and warranty as for the security in the use of SSL/TLS. In the event that the user shall sustain damage or loss due to the use of SSL/TLS, neither DOCOMO nor the certifi ers shall be responsible for any such damage or loss. Certifi ers: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc., and Go Daddy, Inc. ⿠This FOMA terminal supports FOMA Plus - Area and FOMA High - Speed Area. ⿠The FOMA terminal can be used only via the FOMA network provided by DOCOMO and in DOCOMO ’ s roaming area. ⿠You are advised that you make separate notes of information (such as Phonebook entries, sche…

Text truncated - open the document above for the full version.

Panasonic Mobile Communications Development of Europe limited Willoughby Road, Bracknell, Berkshire, RG12 8FP Tel: +44 (0) 1344 862444 Fax: +44 (0) 1344 706796 VAT Reg No. GB787451290 Web: http:Panasonic.net/pmc Registered in England No. 4188880 Panasonic Mobile Communications Development of Europe Limited 22nd March 2011 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom Subject: Certification Application FCC ID: UCE111037A It is requested that the following information is held Confidential on behalf of Panasonic Mobile Communications Development of Europe Ltd., on the confidentiality basis outlined below: 1. Permanent Confidentiality (FCC Rules Part 0.459 refers). Exhibit Category Exhibit Filenames Schematic Diagrams P-04C Schematics.pdf Parts list (BOM) P-04C BOM.pdf Block Diagrams P-04C UMTS RF Block Diagram.pdf P-04C RFID Block Diagram.pdf Operational Descriptions * P-04C UMTS RF Product Specification.pdf P-04C RFID Operational Description.pdf Tune up Information P-04C RF Calibration Spec.pdf The above information contains trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjust benefits to its competitors. The applicant understands that pursuant to rule 0.457d, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. * The Operational Descriptions contain proprietary information relating to the device implementation used. This information is not customarily released to the public. continued........

P PPP- ---04 040404Ｃ Ｃ Ｃ Ｃ FCC ID Label and Location FCC ID Label and LocationFCC ID Label and LocationFCC ID Label and Location -FCC ID label -FCC ID label-FCC ID label-FCC ID label Battery Area : Battery Area :Battery Area :Battery Area : Battery is placed in Battery is placed inBattery is placed inBattery is placed in rear side of the phone rear side of the phonerear side of the phonerear side of the phone Label Area : Label Area :Label Area :Label Area : This outline drawing This outline drawingThis outline drawingThis outline drawing shows the label in shows the label inshows the label inshows the label in position within the position within theposition within theposition within the battery compartment. battery compartment.battery compartment.battery compartment. The label is visible to The label is visible toThe label is visible toThe label is visible to the user at the point of the user at the point ofthe user at the point ofthe user at the point of sale prior to fitting the sale prior to fitting thesale prior to fitting thesale prior to fitting the USIM, battery pack and USIM, battery pack andUSIM, battery pack andUSIM, battery pack and cover covercovercover (Rear View) (Rear View)(Rear View)(Rear View) -Label location -Label location-Label location-Label location ① Operator Name ① Operator Name① Operator Name① Operator Name ② Model Name ② Model Name② Model Name② Model Name ③ Color ③ Color③ Color③ Color ④ ID for JATE ④ ID for JATE④ ID for JATE④ ID for JATE ⑤ ID for TELEC ⑤ ID for TELEC⑤ ID for TELEC⑤ ID for TELEC ⑥ Production Year & Month ⑥ Production Year & Month⑥ Production Year & Month⑥ Production Year & Month ⑦ Bar Code of IMEI ⑦ Bar Code of IMEI⑦ Bar Code of IMEI⑦ Bar Code of IMEI ⑧ ⑧ ⑧ ⑧ IMEI IMEIIMEIIMEI( (((Production Serial Number Production Serial NumberProduction Serial NumberProduction Serial Number） ））） FCC ID:UCE111037A FCC ID:UCE111037AFCC ID:UCE111037AFCC ID:UCE111037A 機器名称 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: NTT docomo P-04C FCC ID: UCE111037A To: FCC Part 15.225: 2010 Subpart C Test Report Serial No: RFI-RPT-RP80807JD05A This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: Checked By: A. Henriques Signature: Date of Issue: 04 March 2011 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP80807JD05A VERSION 1.0 ISSUE DATE: 04 MARCH 2011 Page 2 of 22 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP80807JD05A VERSION 1.0 ISSUE DATE: 04 MARCH 2011 RFI Global Services Ltd Page 3 of 22 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 5 2.4. Deviations from the Test Specification 5 3. Equipment Under Test (EUT) ....................................................................................................... 6 3.1. Identification of Equipment Under Test (EUT) 6 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 7 3.5. Support Equipment 8 4. Operation and Monitoring of the EUT during Testing ............................................................... 9 4.1. Operating Modes 9 4.2. Configuration and Peripherals 9 5. Measurements, Examinations and Derived Results ................................................................ 10 5.1. General Comments 10 5.2. Test Results 11 5.2.1. Receiver/Idle Mode AC Conducted Spurious Emissions 11 5.2.2. Receiver/Idle Mode Radiated Spurious Emissions 13 5.2.3. Transmitter Fundamental Field Strength 15 5.2.4. Transmitter Radiated Spurious Emissions 16 5.2.4. Transmitter Radiated Spurious Emissions 16 5.2.5. Transmitter Band Edge Radiated Emissions 18 5.2.6. Transmitter 20 dB Bandwidth 19 5.2.7. Transmitter Frequency Stability (Temperature & Voltage Variation) 20 6. Measurement Uncertainty .......................................................................................................... 21 Appendix 1. Test Equipment Used ................................................................................................ 22 TEST REPORT SERIAL NO: RFI-RPT-RP80807JD05A VERSION 1.0 ISSUE DATE: 04 MARCH 2011 Page 4 of 22 RFI Global Services Ltd 1. Customer Information Company Name: Panasonic Mobile Communications Development of Europe Ltd. Address: Panasonic House Willoughby Road Bracknell Berkshire RG12 8FP United Kingdom TEST REPORT SERIAL NO: RFI-RPT-RP80807JD05A VERSION 1.0 ISSUE DATE: 04 MARCH 2011 RFI Global Services Ltd Page 5 of 22 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.225 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart C (Radio Frequency Devices) - Section 15.225 Specification Reference: 47CFR15.107 and 47CFR15.109 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart B (Radio Frequency Devices) - Sections 15.107 and 15.109 Specification Reference: 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart C (Intentional Radiators) - Section 15.209 Site Registration: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 16 February 2011 to 25 February 2011 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.107(a) Receiver/Idle Mode AC Conducted Spurious Emissions Part 15.109 Receiver/Idle Mode Radiated Spurious Emissions Part 15.225(a)(b)(c)(d) Transmitter Fundamental Field Strength Part 15.209(a), 15.225(d) Transmitter Radiated Spurious Emissions Part 15.209(a), 15.225(c)(d) Transmitter Band Edge Radiated Emissions Part 2.1049 Transmitter 20 dB Bandwidth Part 15.225(e) Transmitter Frequency Stability (Temperature & Voltage Variation) Key to Results = Complied = Did not comply 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP80807JD05A VERSION 1.0 ISSUE DATE: 04 MARCH 2011 Page 6 of 22 RFI Global Services Ltd 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: NTT docomo Model Name or Number: P-04C IMEI: 355098040018090 Hardware Version Number: Rev C Software Version Number: B-D11SW1-01.01.004 D11SW1_Cv48091406 FCC ID: UCE111037A Brand Name: NTT docomo Description: Battery Model Name or Number: P23 Brand Name: NTT docomo Description: AC Charger Model Name or Number: FOMA AC Adapter 01 for Global use / MAS-BH0008-A 002 Brand Name: NTT docomo Description: DC Charger Model Name or Number: FOMA DC Adapter 02 Brand Name: NTT docomo Description: Charge/USB Data cable Model Name or Number: FOMA USB Cable with Charge Function 02 Brand Name: NTT docomo De…
