UCE111045AUMTS Cellular Mobile Radio with RFID

P-03D INSTRUCTION MANUAL ’11.11 Thank you for selecting the “P-03D”. Read this manual befor e use to correctly operate your P-03D. For Using This Manual ⿠Note that “P-03D” is referred to as “FOMA terminal” in this manual. ⿠Most operating procedures and displays in this manual are shown with the default settings of the “Black” handset. Further, displays and illustrations shown in this manual ar e for reference. The actual ones might differ. ⿠P-03D Handset (With Warranty and Back Cover P55) ⿠Battery Pack P23 ⿠Instruction Manual (Japanese version) ⿠See page 102 for optional items that support this FOMA terminal. About manual of P-03D The operating procedures for the P-03D are also published as in “使いかたガイド (Guide)” on - screen manual installed onto your FOMA terminal, and “Instruction Manual (Detailed V ersion)” as a PDF . (In Japanese only) ◆ “Instruction Manual” (this manual)◆ Description of the displayed content and operating procedures for basic functions ◆“使いかたガイド (Guide)” (installed onto your FOMA terminal)◆ Description of the outline and operations of frequently used functions From the P-03D m ▶ 便利ツール (Tool) ▶ 使いかたガイド (Guide) ※ This function is available in Japanese mode only. ◆“Instruction Manual (Detailed Version)” (PDF)◆ From a PC, download detailed information about all the functions and the operating pr ocedures. (In Japanese only) http://www.nttdocomo.co.jp/support/tr ouble/manual/ download/index.html ※ Note that the URL and published contents may be modified without notice. Basic Package ⿠Desktop Holder P49 1 ※It is prohibited to copy all or part of this manual without permission. ※The instructions contained in this manual may be changed without notice. Contents Introduction ▶ P.1～ FOMA Terminal ································2 What You can Do with P-03D ···········3 P art Names and Functions ··············4 Precautions ······································7 Handling Precautions ····················16 Waterproof Performance ···············19 Basic Operation ▶ P.24～～ Before Using ···················································24 Screen Explanation ········································29 Character Entry ··············································37 Sound/Scr een Setting ····································39 Lock/Security ··················································44 Connect ▶ P.49～～ Call Telephone ················································49 Mail ··································································57 Phonebook ·····················································62 Search ▶ P.64～～ i - mode/Full Browser ·······································64 i - Channel ·························································67 Map/GPS ························································68 Enjoy ▶ P.71～～ Camera ····························································71 1Seg ································································74 Music ·······························································78 i - α ppli/i - Widget ···············································80 i - motion/Movie ···············································82 More Convenient ▶ P.83～～ Osaifu - Keitai ···················································83 i - concier ··························································84 Convenient T ools ············································85 Data Management ··········································89 Others ▶ P.94～～ Support ···························································94 Appendix ·······················································103 2 Introduction FOMA Terminal ⿠P-03D supports W - CDMA system. ⿠Because the FOMA terminal uses radio waves, you cannot use it in places where the radio waves do not reach, where they are weak even outdoors, such as inside tunnels, basements, or buildings, or out - of - service area. You might not be able to operate the FOMA terminal even when you are in a place with a fi ne view such as in a high - rise building or apartment. Note that you ma y experience interruption of calls even if the three antennas respond to a strong radio wave, and you remain without moving to use the FOMA terminal. ⿠Since the FOMA terminal uses radio waves as the medium of telecommunication, calls may be tapped by a third party. However, the W - CDMA system automatically supports tapping prevention, so your conversation will be incomprehensible to the third par ty, because it is recognized as mere noise. ⿠The FOMA terminals change your voice into digital signals and send them to the other party. In places where the radio waves are weak, the digital signals may not be converted correctly, and in such a case, the voice may sound different from the actual one. ⿠The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS. Neither DOCOMO nor the certifi ers as listed herein make any representation and warranty as for the security in the use of SSL/TLS. In the event that the user shall sustain damage or loss due to the use of SSL/TLS, neither DOCOMO nor the certifi ers shall be responsible for any such damage or loss. Certifi ers: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc., and Go Daddy, Inc. ⿠This FOMA terminal supports FOMA Plus - Area and FOMA High - Speed Area. ⿠You are advised that you make separate notes of information (such as Phonebook entries, schedule events, memos, record messages, voice memos) stored in the FOMA terminal and keep them in a safe place. Note that we cannot be held responsible for the unlikely event of loss of the stored content due to a malfunction, repair, change of your model, or other mishandling of the FOMA terminal. ⿠You are advised to save y our important data on the microSD card. If you have a personal computer, you can transfer and save data such as Phonebook entries, mail messages, schedule events, and others on t…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: NTT-DoCoMo P-03D FCC ID: UCE111045A To: FCC Part 15.225: 2011 Subpart C Test Report Serial No: RFI-RPT-RP83567JD01B This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: Checked By: Ian Watch Signature: Date of Issue: 12 October 2011 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP83567JD01B VERSION 1.0 ISSUE DATE: 12 OCTOBER 2011 Page 2 of 23 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP83567JD01B VERSION 1.0 ISSUE DATE: 12 OCTOBER 2011 RFI Global Services Ltd Page 3 of 23 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 5 2.4. Deviations from the Test Specification 5 3. Equipment Under Test (EUT) ....................................................................................................... 6 3.1. Identification of Equipment Under Test (EUT) 6 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 7 3.5. Support Equipment 8 4. Operation and Monitoring of the EUT during Testing ............................................................... 9 4.1. Operating Modes 9 4.2. Configuration and Peripherals 9 5. Measurements, Examinations and Derived Results ................................................................ 10 5.1. General Comments 10 5.2. Test Results 11 5.2.1. Receiver/Idle Mode AC Conducted Spurious Emissions 11 5.2.2. Receiver/Idle Mode Radiated Spurious Emissions 14 5.2.3. Transmitter Fundamental Field Strength 16 5.2.4. Transmitter Radiated Spurious Emissions 17 5.2.5. Transmitter Band Edge Radiated Emissions 19 5.2.6. Transmitter 20 dB Bandwidth 20 5.2.7. Transmitter Frequency Stability (Temperature & Voltage Variation) 21 6. Measurement Uncertainty .......................................................................................................... 22 Appendix 1. Test Equipment Used ................................................................................................ 23 TEST REPORT SERIAL NO: RFI-RPT-RP83567JD01B VERSION 1.0 ISSUE DATE: 12 OCTOBER 2011 Page 4 of 23 RFI Global Services Ltd 1. Customer Information Company Name: Panasonic Mobile Communications Development of Europe Ltd. Address: Panasonic House Willoughby Road Bracknell Berkshire RG12 8FP United Kingdom TEST REPORT SERIAL NO: RFI-RPT-RP83567JD01B VERSION 1.0 ISSUE DATE: 12 OCTOBER 2011 RFI Global Services Ltd Page 5 of 23 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.225 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Radio Frequency Devices) - Section 15.225 Specification Reference: 47CFR15.107 and 47CFR15.109 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart B (Radio Frequency Devices) - Sections 15.107 and 15.109 Specification Reference: 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Intentional Radiators) - Section 15.209 Site Registration: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 06 September 2011 to 05 October 2011 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.107(a) Receiver/Idle Mode AC Conducted Spurious Emissions Part 15.109 Receiver/Idle Mode Radiated Spurious Emissions Part 15.225(a)(b)(c)(d) Transmitter Fundamental Field Strength Part 15.209(a), 15.225(d) Transmitter Radiated Spurious Emissions Part 15.209(a), 15.225(c)(d) Transmitter Band Edge Radiated Emissions Part 2.1049 Transmitter 20 dB Bandwidth Part 15.225(e) Transmitter Frequency Stability (Temperature & Voltage Variation) Key to Results = Complied = Did not comply 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP83567JD01B VERSION 1.0 ISSUE DATE: 12 OCTOBER 2011 Page 6 of 23 RFI Global Services Ltd 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: NTT DoCoMo Model Name or Number: P-03D IMEI: 357979040014460 Hardware Version Number: Revision C Software Version Number: ACPU: 01.05.001 CCPU: 18.10.18.02 FCC ID: UCE111045A Brand Name: NTT DoCoMo Description: Battery Model Name or Number: P23 Brand Name: NTT DoCoMo Description: AC Charger Model Name or Number: FOMA AC Adapter 01 Brand Name: NTT DoCoMo Description: DC Charger Model Name or Number: FOMA DC Adapter 01 Brand Name: NTT DoCoMo Description: Data cable Model Name or Number: FOMA USB Cable with Charge Function Brand Name: NTT DoCoMo Description: Personal Hands Free Headset Model Name or Number: Earphone set 01 (stereo) E…
