841P User Guide Introduction Thank you for purchasing SoftBank 841P. ◦. . For proper handset use, read User Guide (this guide). ◦ Accessible services may vary by service area, subscription, etc. SoftBank 841P is compatible with both 3G and GSM network technologies. Note ◦. .. Unauthorized copying of any part of this guide is prohibited. ◦ ... Guide content is subject to change without prior notice. ◦ . Efforts have been made to ensure the accuracy and clarity of this guide. Please contact SoftBank Mobile Customer Center, General Information ( Z P.17-30) about unclear or missing information. i Content Search Function/Service Name Search Index Z P.16-22 Contents Z P.vi Objective Search Objective Search Z P.ii Index Z P.16-22 Function Search Overview Z P.iv Contents Z P.vi Using Your Handset Function List Z P.16-2 Display Z P.1-8 Guide Organization Contents Z P.vi Section Contents Z Chapter Top Pages Solving Problems Troubleshooting Z P.16-8 W arranty & Service Z P.16-29 Getting Started Call 1 2 Text Entry Phone Book 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Digital TV Camera News/Entertainment Media Player Managing Files Connectivity Handset Security Tools Messaging Internet S! Appli Settings 17 Appendix ii Objective Search Confirming & Using My Number & My Mail Address Customizing Handset Settings Mastering Basics Fun Stuff My Phone Number Confirm your phone number on handset in Standby without navigating menus. My Number: Z P.1-24 My Mail Address Customized address may reduce spam. Customizing Handset Address: Z P.12-3 Setting Ringtones Set Chaku-Uta ® , Chaku-Uta Full ® or Ringtone Flash ® files as ringtones. Ringtones: Z P.15-2 Downloading Tunes & Tones Download music (Chaku-Uta Full ® ) files from mobile websites . Downloading Music: Z P.7-3 Learning Your Handset Learn key assignments, and navigate menus to select & execute functions . Handset Menus: Z P.1-16 Parts & Functions: Z P.1-4 Making Mobile Calls Use voice telephony or enjoy video telephony with compatible mobiles . Voice Calls: Z P.2-2 Video Calls: Z P.2-6 Watching One Seg Digital TV Enjoy One Seg digital TV. Set channels in adv ance to view shows . Digital TV: Z P.5-1 Media Player Download music/video files from websites via Media Player directly . Media Player: Z P.7-1 iii Sending Your Contact Info Save mail address and other details; send to compatible devices wirelessly . Account Details: Z P.4-14 Messaging Multiple Recipients Enter multiple mail addresses/numbers to send a message to all at one time . Sending Messages: Z P.12-4 Add/Edit/Delete Address: Z P.12-9 Sending Files Wirelessly Send files or your own mail address sa ved in Ac count De tails vi a In frared tr ansmission to ot her co mpatible de vices. Infrared: Z P.4-14 Customizing Standby Display Add wallpaper, set clock size/position or set calendar to appear in Standby . Wallpaper: Z P.8-7 Display: Z P.15-4 Customizing Key Settings Set frequently used functions to keys. Keypad: Z P.15-6 Using Shortcuts to Functions Access shortcuts to frequently used functions in Standby . Standby Window: Z P.1-19 Mastering Text Entry Methods Enter text for Messaging functions or to add/edit Phone Book entry items . Text Entry: Z P.3-1 Using Messaging Services Send short or long text messages. Attach image/sound files , etc. to S! Mail. Messaging: Z P.12-1 Feeling Mail: Z P.12-5 Graphic Mail: Z P.12-6 Accessing the Mobile Internet Access Mobile Internet sites via Yahoo! Keitai to browse sites or download files. Yahoo! Keitai: Z P.13-2 Playing Games Download and install S! Appli Games via Y ahoo! K eitai. S! Appli: Z P.14-1 Getting News (Japanese) Set up S! Quick News to view a variety of information contents . S! Quick News: Z P.6-5 Camera & Video Camera Pictures: Z P.5-5 Videos: Z P.5-6 iv Overview 841P Features SoftBank Mobile Features Useful Features PC-related Functions One Touch Guide Access One Touch Guide for instructions to k ey oper ations (opening messages/mail folder , viewing calendar or using Speed Dial, etc). Z P.11-12 Simple Mode Use simplified menus limiting to only basic functions . Z P.1-21 Yahoo! Keitai Access Mobile Internet sites via Yahoo! Keitai to browse sites or download files. Z P.13-2 Graphic Mail Create HTML messages; select font color/size, background; insert images . Z P.12-6 Phone Book/ S! Addressbook Back-up Save Phone Book entries; back up handset entries on Server , etc. Z P.4-1, P.4-11 Camera/Video Capture still images or record videos with appro ximately two mega pixel camera. Z P.5-5, P.5-6 PC Site Browser View PC-based websites on handet. Z P.13-5 Data Back-up/Management Transfer data between handset and PC for back-up and editing. Z P.9-5 v Magnifying Loupe Use handset camera to view enlarged image, etc. Z P.5-8 3G High Speed 841P supports HSDPA (High Speed Downlink P acket Access) that provides high-speed web browsing and downloads of Music/video files . S! Information Channel/ Weather (Japanese) Subscribe to content and periodically receive update information. Set Weather Indicator to check weather forecast in Standby . Z P.6-2 Calendar & Alarm Add events by time/date and set Event Alarms to help manage your schedule . Z P.11-2, P.11-6 e-Book Viewer/BookSurfing ® (Japanese) Download e-media, like e-books, e-comics, and e-photobooks on 841P . Z P.6-6 Media Player Play handset/microSD Card music/video files; stream media via Yahoo! K eitai. Z P.7-1 S! Quick News (Japanese) Add news headlines, weather forecasts, etc. via S! Quick News List to scroll across Standby Window. Z P.6-5 Voice Recorder Record your voice or voice memos. View Blind 841P protects private information from prying eyes . Z P.1-24 Z P.11-9 microSD Card Extend handset internal memory or back-up handset files , etc. Z P.8-13 vi Contents Contents ..............................................vi Package Contents ..............................viii Using This Guide ................................viii Safety Precautions ..............................xii Handling Precautions .........…

Text truncated - open the document above for the full version.

6-1 6 Camera Before Using Camera ............................................6-2 Image File Formats .....................................................................6-2 Notes .........................................................................................6-2 Camera ......................................................................................6-2 Camera Display Indicators ...........................................................6-3 Pictures/Videos .....................................................6-5 Capturing Still Images.................................................................6-5 Recording Videos ........................................................................6-6 Functions Available while Shooting .............................................6-6 Viewing Saved Images .........................................6-8 Magnifying Loupe.................................................6-8 6-2 Camera 6 Before Using Camera 841P features approximately Two Mega Pixel CMOS Auto-focus Camera capable of capturing still images and videos. Image File Formats Still images/videos are saved to Data Folder. Image TypeFile FormatSave Location Still imagesJPEG (.jpg)Pictures (Data F older) VideosMPEG-4 (.3gp) Videos (Data F older) ⿟ To save to Memory Card: Z P.5-3 Notes ⿟ Remove dust/debris from lens cover with a soft cloth. ⿟ Handset movement may blur images especially in dark places; hold handset firmly . ⿟ Capturing/saving images immediately after handset has been left in a hot place may affect image quality . ⿟ Exposing lens to direct sunlight may affect image quality. ⿟ While Camera is active, Notification Light/Charging Indicator illuminates or flashes . Notification Light/Charging Indicator cannot be turned off . Shutter Click ⿟ Shutter click sounds at fixed volume even in Manner Mode. ⿟ To change shutter click sound: Z P.15-15 Camera Press F in Standby to activate Camera, or press S in Picture Preview Window to activate Video Camera; press and hold F in Standby to activate Magnifying Loupe ( Z P.5-8). Note ⿟ Alternatively, Main Menu 4 Camera 4 Camera, Video Camera or Magnifying Loupe . ⿟ Camera is not available when battery is low. ⿟ Incoming calls, Alarm and low battery cancel Camera. Captured images/ recorded videos are saved. ⿟ When left in preview window for three minutes, Camera is canceled and previous window returns . Camera 6-3 Camera 6 Camera Display Indicators ⿟ Images shown below are for reference only. ■ Picture Preview Window ⿟ Press P to open key assignment guide. ItemDescriptionOperation ❶ Save to Phone Memory Card Q ❷ Size UXGA SXGA VGA QVGA QQVGA Wallpaper W ❸ Quality Super Fine Fine Normal E ❹ Multi Shot ( Z P.5-5) Multi Shot R Night Mode ( Z P.15-15) Night Mode Y ❺ Self-Timer ( Z P.5-6) 5 seconds 10 seconds T ❻ White Balance ( Z P.15-15) Automatic Fine Cloudy Light Bulb I ❼ Focus Setting ( Z P.15-15) Auto Focus Close-up Scenery ❽ Focus Guide ( Z P.5-6)Adjust focus automatically– ❾ Effect ( Z P.15-15)Normal/Sepia/Monochrome/Negative U  Auto Focus LockLock focus on the subject to set Auto Focus Lock  ZoomIndicate zoom level (Level 1 to 25) to zoom in/ to zoom out ⿟ Long press: continuous zoom  BrightnessAdjust brightness (Level -2 to +2) H Brighter/ G darker ❶ ❽ ❾   ❷❸❹❺❻ ❼ 6-4 Camera 6 ■ Video Preview Window ⿟ Press P to open key assignment guide. ❶ ❽❾ ❷ ❸❹❺ ❻ ❼ ItemDescriptionOperation ❶ Save to Phone Memory Card Q ❷ Quality / Super Fine / Fine / Normal E ⿟ Available only when Recording Time is set to Extended Video. ❸ Recording Time Attach to S! Mail Extended Video W ❹ Self-Timer ( Z P.5-6) 5 seconds 10 seconds T ❺ White Balance ( Z P.15-16) Automatic Fine Cloudy Light Bulb I ❻ Focus Setting ( Z P.15-16) Close-up Scenery ❼ Effect ( Z P.15-16)Normal/Sepia/Monochrome/Negative U ❽ ZoomIndicate zoom level (Level 1 to 25) to zoom in/ to zoom out ⿟ Long press: continuous zoom ❾ BrightnessAdjust brightness (Level -2 to +2) H Brighter/ G darker 6-5 Camera 6 Pictures/Videos ⿟ Confirm battery strength ( Z P.1-9) and available memory ( Z P.15-15, P.15-16) before recording. When battery is low , video cannot be recorded. Capturing Still Images 1 Press F to activate Camera 2 Frame subject 3 [Shoot] to capture the image Camera automatically focuses on subject before capturing image . Shutter click sounds at fixed volume . 4 [Save] ⿟ To return to preview window without saving the image: K 5 L to exit Return to Standby. Note ⿟ Data Folder opens when Phone memory becomes full. Delete files; image is automatically saved. ⿟ If save location is set to Memory Card and memory becomes full, image is saved to Phone memory automatically . Picture Preview Window Continuous Shooting Capture a succession of 15 still images automatically with a single press. ⿟ Picture size is fixed to QVGA (240x320). ⿟ When Multi Shot is ON, Night Mode is set to OFF automatically. 1 In Picture Preview Window, R 2 Frame subject 7 [Shoot] ⿟ Image thumbnails appear. ⿟ To stop shooting halfway: K ⿟ To return to preview window without saving the image: S [Delete] 7 Go to Step 1 3 To view captured images, to select an image Full-size image appears. ⿟ to toggle full-size images. 4 When Viewing a Full-size Image A [Save All] or [Save] ⿟ Press [Save] to save the full-size image. When Viewing Thumbnailed Images A [Menu] 7 Save All Pictures or Save This One Only 6-6 Camera 6 Recording Videos 1 F 7 S to activate Video Camera 2 Frame subject 3 [Record] to start recording Tone sounds. 4 [Stop] to end recording Tone sounds. ⿟ Recording stops automatically at maximum recording time . ⿟ To return to preview window without saving the image: S [Back] ⿟ To review: Playback 5 To save the video, select Save to Data Folder 6 L to exit Return to Standby. Note ⿟ If Phone memory becomes full, Data Folder opens. Delete files; image is automatically saved. ⿟ If save location is set to Memory Card, file is saved to Memory Card automatically. To delete the saved file , select Delete. Video Preview Window Functio…

Text truncated - open the document above for the full version.

17-1 17 Appendix Function List .......................................................17-2 Troubleshooting ..................................................17-8 Warning Signs ........................................................................17-10 Software Update ..............................................17-10 Updating Software Manually ...................................................17-10 Updating Softw are Automatically ............................................17-11 Key Assignments ...............................................17-12 Symbol List .......................................................17-13 Character Code List ..........................................17-14 Weather Indicator List ......................................17-19 Memory List ......................................................17-20 Specifications ...................................................17-21 Index .................................................................17-22 Warr anty & Service ...........................................17-29 Warranty ................................................................................17-29 After-Sales Service ..................................................................17-29 Customer Service..............................................17-30 17-2 Appendix 17 Function List From Main Menu, press key corresponding to a menu number for direct access. ( Z P.1-17) Example: To select S! Mail Settings in Messaging menu: 1 first column 0 second column 3 third column Q (Messaging) 7 P (Settings) 7 E (S! Mail Settings) Messaging Menu Number/Function NamePage 1Messaging – 1Incoming Mail P.12-12 2Create New S! Mail P.12-4 3Retrieve New P.12-17 4Drafts P.12-18 5Templates P.12-6 6Sent Messages P.12-18 7Unsent Messages P.12-18 8Server Mail Bo x – 1Mail List P.12-17 2Delete Server Mail All P.12-18 9Create New SMS P.12-8 0Settings – 1Custom Mail Address P.12-3 2Universal Settings P.15-18 3S! Mail Settings P.15-19 4SMS Settings P.15-21 e Memory Status – 1Phone P.12-3 2USIM P.12-3 Yahoo! (Yahoo! Keitai) Menu Number/Function NamePage 2Yahoo!– 1Yahoo! K eitai P.13-3 2Bookmarks P.13-8 3Saved P ages P.13-8 4Web SearchP .13-3 5Enter URL – 1Direct Entry P.13-4 2URL History List P.13-4 6History P.13-4 7PC Site Browser – 1Homepage P.13-5 2Bookmarks P.13-8 3Saved P ages P.13-8 4Web SearchP .13-5 5Enter URL P.13-5 6History P.13-5 7Yahoo! K eitai P.13-3 8PC Site Browser Settings P.15-21 8Settings – 1Font Size P.15-21 2Scroll Unit P.15-21 3Downloads P.15-21 4Memory Manager P.15-22 5Security P.15-22 6Initialized Browser P.15-23 7Reset Defaults P.15-23 17-3 Appendix 17 S! Appli Menu Number/Function NamePage 3S! Appli – 1S! Appli List – Tab 1 Phone P.14-2 Tab 2 Memory Card P.14-2 2S! Appli Settings – 1Volume P.15-23 2Display Backlight P.15-23 3Vibr ation P.15-23 4Auto Suspend Timer P.15-23 5Synchronize Memory Card P.15-23 3Information P.14-2 News/Ent. (News/Entertainment) Menu Number/Function NamePage 4News/Ent. – 1S! Information Channel/W eather – 1What's New? P.6-3 2History P.6-3 3Register/Cancel P.6-2 4Get Latest Contents P.6-2 5Mi ssed Ev ent se ttings(S! In formation Ch annel) P.6-2 6Weather Indicator P.6-3 2S! Quick News – 1S! Quick News List P.6-5 2Settings P.15-17 3BookSurfing P.6-6 4e-Book Viewer P.6-6 Camera Menu Number/Function NamePage 5Camera – 1Camera P.5-5 2Video Camer a P.5-6 3Bar Code Reader P.11-10 1Scan BarcodesP .11-10 2Saved Data ListP .11-11 4Magnifying Loupe P.5-8 Media (Media Player) Menu Number/Function NamePage 6Media– 1Audio– 1AllP.7-5 2MusicP.7-5 3Ring SongP .7-5 4PlaylistP.7-5 5Display Playback ScreenP .7-5 6Playback ModeP .7-7 7Download MusicP .7-3 8Music SearchP .7-3 2Video– 1AllP.7-6 2Video F olderP.7-6 3PlaylistP.7-6 4Display Playback Screen– 5Playback ModeP.7-7 6Download VideosP .7-3 17-4 Appendix 17 Tools Menu Number/Function Name Page 7Tools– 1AlarmsP.11-6 2CalendarP.11-2 3CalculatorP.11-7 4NotepadP.11-8 5Count Down TimerP.11-9 6Answer Phone– 1Message ListP .2-13 2SettingsP.2-12 7Voice RecorderP .11-9 8Bar Code ReaderP.11-10 1Scan BarcodesP .11-10 2Saved Data ListP .11-11 9Software Update– 1Software UpdateP .16-10 2Regular UpdatesP.16-11 3Update ResultP .16-11 0One Touch Guide– 1Display New MessagesP .11-12 2CalendarP.11-12 3Speed DialP.11-12 4Simple ModeP .11-12 5Set as WallpaperP .11-12 6Private MenuP .11-12 7View BlindP .11-12 8MannerP.11-12 9Magnifying LoupeP .11-12 0Create New Phone BookP .11-12 70 e KeyguardP.11-12 r DriveP.11-12 Yahoo! K eitai Menu*P .11-12 Create Message*P .11-12 Key Customization*P .11-12 * Direct access unavailable 17-5 Appendix 17 Data Folder Menu Number/Function Name Page 8Data Folder– 1Pictures– Tab 1Phone P.8-2 T ab 2Memory CardP .8-2 Tab 3Digital Camer aP.8-2 2Ring Songs·Tones– Tab 1Phone P.8-2 T ab 2Memory CardP .8-2 3S! Appli– Tab 1Phone P.8-2 T ab 2Memory CardP.8-2 4Music– Tab 1Phone P.8-2 T ab 2Memory CardP .8-2 5Videos– Tab 1Phone P.8-2 T ab 2Memory CardP .8-2 Tab 3Video Camer aP.8-2 6Books– Tab 1Phone P.8-2 T ab 2Memory CardP.8-2 7TemplatesP .8-2 8Flash(R)– Tab 1Phone P.8-3 T ab 2Memory CardP .8-3 9Other Documents– Tab 1Phone P.8-3 T ab 2Memory CardP .8-3 80Memory Status– 1Phone P.8-3 2Memory CardP .8-3 Infrared Menu Number/Function Name Page 9Infrared– 1Infrared ON/OFFP .9-3 2Send Account DetailsP .9-3 3Send All Phone BookP .9-4 Bar Code (Bar Code Reader) Menu Number/Function Name Page e Bar Code– 1Scan Barcodes P.11-10 2Saved Data List P.11-11 17-6 Appendix 17 Phone Menu Number/Function Name Page Phone – 1Phone Book P.4-6 2Create New Entry P.4-3 3Mail & Call Log– T ab 1 All Calls/All Mails LogsP .2-10, P .12-15 Tab 2 Incoming/Receive LogsP.2-10, P.12-15 Tab 3 Outgoing/Send LogsP .2-10, P .12-15 4Group P.4-5 5Account Details P.1-24, P .4-14 6One Touch K ey– 1One Touch KeyP.4-8 2Speed Dial P.4-8 7S! Addressbook Back-up – 1Start Sync P.4-12 2Auto Sync Settings P.4-13 3Sync Log P.4-13 8Memory Manager – 1Copy All from USIM P.4-10 2Copy All to USIM P.4-10 3Delete All (Phone) P.4-10 4Delete All (USIM) P.4-…

Text truncated - open the document above for the full version.

17-16 Appendix 17 17-17 Appendix 17

17-18 Appendix 17 17-19 Appendix 17 Weather Indicator List ⿟ Indicators and categories are subject to change without notice . Weather Clear (day) Clear (night) Cloudy Rain Snow Thunderstorm - Chance of Precipitation 0%-100% Later Occasionally Pollen Level Low Moderate High Very High Cherry Blossom Blossoms Opening Near Full Bloom Peak Bloom Past Peak Fall F oliage No Color Moderate Color Peak Color Past Peak UV Level Low Moderate High Very High Typhoon Formed Approaching Severe Other Information Heavy Rain Storm Winds Notifications 17-20 Appendix 17 Memory List Data Folder Up to 1000 items/approx. 31 MB (Including pre-installed data) ⿟ Shared with Notepad/S! Appli List (One S! Appli corresponds to three to six items .) Schedule Events Up to 100 items Phone BookUp to 1000 items Messaging (SMS and S! mail combined) Incoming Mail Up to 1000 items/appro x. 5 MB Dr afts/ Sent Messages/ Unsent Messages Up to 500 items/appro x. 5 MB Yahoo! Keitai Saved Pages [Yahoo! Keitai] Up to 20 items/750 KB [PC Site Browser] Up to 20 items/1150 KB Bookmarks [Yahoo! Keitai] Up to 100 items (Including pre-installed data) [PC Site Browser] Up to 100 items URL History [Yahoo! Keitai] URL Entry: Up to 20 items URL Access: Up to 100 items* [PC Site Browser] URL Entry: Up to 20 items URL Access: Up to 100 items* Cache [Yahoo! Keitai] 750 KB [PC Site Browser] 1150 KB * The number of sav able items v aries depending on URL length. 17-21 Appendix 17 Specifications 841P Weight (including battery)120 g* Dimensions (closed)50 x 108 x 17.9 mm* Standby Time 3G430 hours* GSM340 hours* Talk Time 3G230 minutes* Video Call100 minutes* GSM250 minutes* TV Reception Time4 hours* Charging Time AC Charger150 minutes* In-Car Charger150 minutes* Maximum Output 3G0.25 W GSM2.0 W * Approximate v alue ⿟ Values above were calculated with battery installed. ⿟ Talk Time is an average measured with a new, fully charged battery, with stable signals . ⿟ Standby Time is an average measured with a new, fully charged battery, with handset closed without calls or oper ations, in Standby with stable signals. ⿟ TV-Reception Time is an average measured using earphone/microphone, with stable signals . ⿟ Talk Time and Standby Time may vary by environment (battery status, temperature , etc.). ⿟ Talk Time and Standby Time may decrease when an S! Appli is active. Battery Voltage3.7 V Battery TypeLithium-ion Capacity920 mAh Dimensions45 x 5.4 x 37 mm* * Approximate v alue ⿟ Specifications subject to change without notice. 17-22 Appendix 17 Numerics 3D Pictograms ....................................12-16 Settings ..........................................15-18 3G ...........................................................2-9 B Background Music ..................................7-5 Backlight Display ..............................................15-6 Keys ..................................................15-6 S! Appli ...........................................15-23 Video Calls ......................................15-14 Backup Memory Card ....................................8-15 S! Addr ess Back-up ..........................4-11 Bar Code Reader .................................11-10 Basic Operations (Internet) ..................13-6 Battery ..................................................1-10 Battery Strength Indicator ...................1-11 Bookmarks ............................................13-8 Books folder ...........................................8-2 BookSurfing ® ..........................................6-6 Brightness Camera ...............................................5-3 Display ..............................................15-6 Video Camer a .....................................5-4 Browser (Initializing) ..........................15-23 A AC Charger ...........................................1-13 Access History PC Site ..............................................13-5 Yahoo! K eitai ....................................13-4 Account Details ...........................1-24, 4-14 After -Sales Service .............................16-29 Alarms ..................................................11-6 All Reset ...............................................10-9 Alternative Picture ......................2-5, 15-14 Answer Phone .......................................2-12 Answer Time (Answer Phone) ...............2-13 Answering Calls Video Calls ..........................................2-6 Voice Calls ..........................................2-4 Any Key Answer ..................................15-11 Attachment Auto-play ........................15-19 Attachments Adding/deleting ...............................12-9 Opening/saving ..............................12-15 Audio Player ...........................................7-4 Authentication Code ..............................9-4 Auto Answer .......................................15-11 Auto Delete (Messages) ............12-3, 15-18 Auto F ocus Lock .....................................5-6 Auto Save (Camera) .................15-15, 15-16 Auto Suspend Timer (S! Appli) ...........15-23 Available Memory (Camer a) ....15-15, 15-16 A way Clock ...........................................15-8 Index 17-23 Appendix 17 C Cache Memory ......................................13-2 Calculator .............................................11-7 Calendar ...............................................11-2 Call Barring ...........................................2-19 Call Barring Passwor d...........................1-23 Call Cost .............................................15-10 Call Forwar ding ....................................2-14 Call Log .................................................2-10 Call Operations .......................................2-9 Call Settings .........................................15-9 Call Time .............................................15-10 Call W aiting ..........................................2-17 Caller ID .........................................2-2, 2-20 Camer a [Section Contents] ....…

Text truncated - open the document above for the full version.

Panasonic Mobile Communications Development of Europe limited Willoughby Road, Bracknell, Berkshire, RG12 8FP Tel: +44 (0) 1344 862444 Fax: +44 (0) 1344 706796 VAT Reg No. GB787451290 Web: http:Panasonic.net/pmc Registered in England No. 4188880 Panasonic Mobile Communications Development of Europe Limited 15 th January 2010 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom Subject: Certification Application FCC ID: UCE209025A It is requested that the following information is held Confidential on behalf of Panasonic Mobile Communications Development of Europe Ltd., on the confidentiality basis outlined below: 1. Permanent Confidentiality (FCC Rules Part 0.459 refers). Exhibit Category Exhibit Filenames Schematic Diagrams 841P Schematics.pdf Parts list (BOM) 841P BOM.pdf Block Diagrams 841P GSM_UMTS RF Block Diagram.pdf Operational Descriptions * 841P GSM_UMTS RF Product Specification.pdf Tune up Information 841P RF Calibration Spec.pdf The above information contains trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjust benefits to its competitors. The applicant understands that pursuant to rule 0.457d, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. * The Operational Descriptions contain proprietary information relating to the device implementation used. This information is not customarily released to the public. continued........

① ② ③ ⑤⑥ ⑦ ④ ⑧ ⑨ ➀ Model Name② Color③ Commodity Code④ Production Year & Month⑤ ID for JATE⑥ ID for TELEC⑦ Operator Name⑧ Bar Code of IMEI⑨ IMEI (Production Serial Number) -FCC ID Label -Label Location FCC ID:UCE209025A Label Area :This outline drawing showsthe label in position withinthe battery compartment.The label is visible to theuser at the point of saleprior to fitting the USIM,battery pack and cover.Battery Area :Battery is placed inrear side of the phone
