UCE211049ADual Mode UMTS / GSM Cellular Mobile Radio with Bluetooth

User Guide 103P Introduction Thank.you.for.purchasing.SoftBank.103P. ◦  Read.this.guide.thoroughly.beforehand.for.proper.usage. ◦ Accessible.services.may.vary.by.service.area,.subscription,.etc. SoftBank.103P.is.compatible.with.both.3G.and.GSM.network.technologies. Note ◦  Unauthorized.copying.of.any.part.of.this.guide.is.prohibited. ◦  Guide.content.is.subject.to.change.without.prior.notice. ◦ Efforts.have.been.made.to.ensure.the.accuracy.and.clarity.of.this.guide..Please.contact.SoftBank.Customer. Support,.General.Information.( Z P.9-22).about.unclear.or.missing.information. 1-1 Contents Getting.Started Getting.Started Contents...........................................................1-1 Package.Contents.............................................1-2 Using.This.Guide...............................................1-2 USIM.Card.Installation.....................................1-4 Charging.Battery..............................................1-5 microSD.Card.Installation................................1-6 Parts.&.Functions..............................................1-7 Basic.Operations...............................................1-9 Display............................................................1-11 Handset.Menus...............................................1-12 Handset.Security............................................1-14 Mobile.Manners.............................................1-15 Text.Entry Entering.Text.....................................................2-1 Editing.Text.......................................................2-4 Calling Emergency.Calls...............................................3-1 Voice.Calls........................................................3-1 Video.Calls........................................................3-2 International.Calls............................................3-3 Answer.Phone..................................................3-5 Optional.Services.............................................3-6 Phone.Book......................................................3-9 Messaging Basics................................................................4-1 Customizing.Handset.Address..........................4-2 Sending.S!.Mail.&.SMS.....................................4-3 Receiving.Messages.........................................4-4 PC.Mail.............................................................4-6 Internet Getting.Started................................................5-1 Accessing.Internet............................................5-2 Bookmarks.&.Saved.Pages...............................5-3 Internet.Settings..............................................5-4 Connectivity Infrared.............................................................6-1 Bluetooth ® ........................................................6-3 External.Devices...............................................6-5 Camera.&.Imaging Before.Using.Camera........................................7-1 Capturing.phots................................................7-4 Recording.Videos..............................................7-5 Other.Camera.Functions...................................7-6 Others Digital.TV..........................................................8-1 Picture.Album...................................................8-4 Appendix Handset.Data.Backup.......................................9-1 Software.Update..............................................9-2 Troubleshooting................................................9-3 Safety.Precautions............................................9-5 Handling.Precautions.....................................9-12 Copyrights......................................................9-16 Specific.Absorption.Rate.(SAR)......................9-18 Specifications.................................................9-19 Support...........................................................9-19 . 1-2 Getting.Started Package Contents  Handset.(103P)  Battery.(PMBAS1)  クイックスタート . (Japanese)  お願いとご注意 .(Japanese)  保証書 . (Japanese) Note ⿟ Use SoftBank Mobile specified AC Charger (sold separately) to charge Battery. ⿟ For more information about AC Charger and accessories, please contact SoftBank Customer Support, General Information ( Z P.9-22). ⿟ 103P accepts microSD or microSDHC Card (not included). Purchase one to use related functions ( Z P.1-6, P.9-1). Using This Guide Before.reading.on,.please.make.note.of.the.following: ⿟ SoftBank 103P is referred to as "handset" or "103P." ⿟ "microSD Card" and "microSDHC Card" are referred to as "microSD Card." ⿟ Screenshots, etc. are for reference. Actual handset windows, menus, etc. may differ. ⿟ Key icons are simplified. ⿟ Most operation descriptions begin in Standby. ⿟ Pressing a key for more than one second is described as "Press and hold." 1-3 Getting.Started Guide.Symbols Softkeys Press.the.corresponding.key.to.execute.the.function.or.operation. indicated.at.the.bottom.of.Display. Example: Multi.Selector Use.Multi.Selector.to.select.items,.navigate.menus,.etc..In.this. guide,.Multi.Selector.operations.are.indicated.as.shown.below. >z Up ?z Up/Down Xz . Up/Down/ Left/Right Cz Down Vz Left <z Left/Right *z Center Nz Right LeftRight Up DownCenter Japanese.Functions.&.Services When."(Japanese)".appears.in.a.title,.Japanese.ability.is.required. to.use.full.range.of.the.function.or.service. 1-4 Getting.Started USIM Card Installation ⿟ Always turn off handset power before removing Battery ( Z P.1-5). ⿟ USIM PINs: Z P.1-17 Inserting 1 With IC chip down, insert USIM Card Removing 1 Slide out USIM Card gently Notch Important ⿟ USIM Card is the property of SoftBank Mobile. ⿟ Return USIM Card to SoftBank Mobile upon service cancellation. ⿟ USIM Card will be reissued for a fee if lost or damaged. ⿟ If USIM Card/handset with USIM Card installed is lost or stolen, contact SoftBank Customer Support or SoftBank Mobile Global Call Center ( Z P.9-22). ⿟ Back up USIM Card files. SoftBank Mobile is not liable for l…

Text truncated - open the document above for the full version.

8-1 Digital TV ⿟ Digital TV is available only in Japan. ⿟ USIM Card removal disable Digital TV. Initial.Setup Main.Menu. 4 .TV. 4 .Channel.Setting 1 Select.Area 7 Select a region 7 Select a prefecture 7 YES . ■ Automatic.Channel.Setup If manual setup fails, try automatic channel setup. ＞ In Step 1, Automatic 7 YES 7 After channel search, YES 7 Enter title Using.Channel.List From Main.Menu. 4 .TV. 4 .Channel.List . ■ Set.Channels ＞ Select a Channel List ⿟ Select a channel to access the station. . ■ Delete.Channel.List ＞ Highlight a Channel List 7 S [Menu]. 7 Delete 7 YES ⿟ Selected Channel List cannot be deleted. Watching.TV ⿟ Set channels beforehand ( Z Left). 1 1 ⿟ To switch Portrait/Landscape View: F 2 Select a channel Direct.Channel.Access Q – O G (Channel 10) P (Channel 11) H (Channel 12) Previous/Next.Channel <z Channel.Search Press and hold <z ⿟ To stop: A [Cancel] or K 3 To end TV, L 7 End.TV Others 8-2 Others Indicators ⿟ Screenshots provided for reference only. ItemDescriptionOperation ●❶ Image —— ●❷ Captions —— ●❸ Data Broadcast —— ●❹ Data Broadcast Mode Data Broadcast Mode off Data Broadcast Mode on 1 [To.TV]/[To.DBC] 2 ●❺ Off timer( Z P.8-3) — ●❻ ECO Mode( Z P.8-3) — ●❼ Channel ( Z P.8-1) ⿟ When multiple programs are available in the same broadcasting station, "service number/total numbers" appears. — ●❽ Signal Strength Level Strong ←――――→ Weak Out of range — ●❾ Receiving Captions —— ● Volume — ⿟ Adjust volume: ?z 1 ⿟ Mute/Resume: K 1 ● Program Title — J or A 3 ● Recorder Status 1 Recording Timer Set( Z P.8-3) ● Display/Caption 2 Display: ON/OFF/Large Caption: ON/OFF J (Each key press toggles settings.) ● Indicator/Caption 3 Indicators: ON/OFF Caption: Upper position/Lower position/OFF J (Each key press toggles settings.) 1 Only when Data Broadcast Mode is off 2 Only in Portrait View 3 Only in Landscape View ❶   ❼ ❽❾ Indicator Display ❷❺❻  ❶ ❷ ❸   ❻❼ ❽ ❾ ❹ ❺  8-3 Others Functions.while.Viewing.TV From While TV is active,. cS [Menu] . ■ Set.Main/Sub.Sound ＞ Settings 7 Sound 7 Main/sub.sound 7 Select an item . ■ Set.Power.Saving.Mode ＞ Settings 7 ECO.Mode 7 YES . ■ Off.Timer ＞ Settings 7 Off.timer 7 Select a time or OFF . ■ View.Key.Guide ＞ Key.guide Recording/Playing.Programs ⿟ Recordings are saved to microSD Card. Recording.Current.Program 1 Activate TV (Data Broadcast Mode off) 7 *z [Record] appears, and recording starts. 2 *z [Stop] to end recording Program is automatically saved. . ■ Capture.Screenshots ＞ Activate TV (Data Broadcast Mode off) 7 Press and hold F Playing.Recorded.Programs Main.Menu. 4 .Data.Folder. 4 .TV. 4 .Video 1 Select a video Playback starts. 2 K to stop playback Timer Main.Menu. 4 .TV 1 Timer.Watching or Timer.Recording 2 A [New] 7 Select an item ⿟ Set a channel, date and time to start and end viewing/recording a program. 3 A [Finish] 7 For Timer.Recording, YES or YES (confirm.once) 9-1 Handset Data Backup Back.up.Phone.Book,.Calendar,.Tasks,.Messages,.Notepad,.and. Bookmarks,.etc..to.microSD.Card;.restore.files.after.accidental.. loss/alteration. ⿟ microSD Card Installation: Z P.1-6 Backing.up.to.microSD.Card Main.Menu. 4 .Tools. 4 .microSD.Backup. 4 .Refer.Data 1 Highlight a category 7 S [Menu] 7 Copy.to.microSD. ( 7 For Bookmarks, select an item) 2 Enter Phone Password 7 YES . ■ One.File.Backup ＞ Open a file. 7 S [Menu]. 7 Copy.to.microSD 7 YES Restoring.from.microSD.Card Main.Menu. 4 .Tools. 4 .microSD.Backup. 4 .Refer.Data 1 Select a category 2 .Restore.One.Item Select a file 7 Highlight an item 7 S [Menu] 7 Add.to.phone .Restore.One.File Highlight a file 7 S [Menu] 7 Add.to.phone or Overwrite.to.phone 7 Enter Phone Password .Restore.All.Files S [Menu] 7 Add.all.to.phone or Overwr..all.to.ph.. 7 Enter Phone Password 3 YES Note ⿟ Note that Overwrite.to.phone or Overwr..all.to.ph. erases all files of same category on handset. ⿟ Data backed up in other SoftBank handsets may not be restored in 103P depending on type and size. All.Data.Backup/Restoration Back.up/restore.handset.data.(Phone.Book,.Calendar,.Messages,. Notepad,.Bookmarks).all.at.once. Main.Menu. 4 .Tools. 4 .microSD.Backup. 4 .Backup/Restore 1 Select an item 7 Enter Phone Password 7 YES Note ⿟ Data backed up in 103P cannot be restored in other handsets. Appendix Appendix 9-2 Software Update Check.for.103P.software.updates.and.download.as.required. ⿟ Transmission fees do not apply to updates (including checking for updates, downloading and rewriting). ⿟ Fully charge Battery beforehand. Even if appears, low battery message may appear. In this case, charge Battery until Notification Light/Charging Indicator goes out. ⿟ Select a place where signal is strong and stable. ⿟ Other functions are unavailable during update. ⿟ Software Update does not affect Phone Book entries, files saved in Data Folder or other content, but it is recommended that you create a backup of any important information and data (note that some files cannot be copied). SoftBank Mobile is not liable for damages resulting from loss of data, information, etc. ⿟ Do not remove Battery/USIM Card during the update. Update will fail. ⿟ Software Update failure may disable handset. Contact SoftBank Customer Support, Customer Assistance ( Z P.9-22). Main.Menu. 4 .Settings. 4 .Phone.Settings. 4 .Software.Update. 4 .Software.Update 1 A [Yes] 7 Follow onscreen instructions After download is complete, handset automatically restarts and update begins. When update is complete, Software.has.been.successfully.updated. appears. Handset restarts, then Information appears. Entire process takes approximately 60 seconds. Update.Results When Information Window appears, Software.Updt..Result ⿟ When Information Window does not appear, Main.Menu 4 Settings 4 Phone.Settings 4 Software Update 4 Update.Results Scheduled.Update SoftBank Mobile sends update notice via SMS; read and change preset update schedule as needed. Confirmation appears at scheduled time. Press *z or wait a while for update to start. Note ⿟ If handset does not power on a…

Text truncated - open the document above for the full version.

103P FCC ID Label and Location 103P FCC ID Label and Location103P FCC ID Label and Location103P FCC ID Label and Location -FCC ID label -FCC ID label-FCC ID label-FCC ID label Battery Area : Battery Area :Battery Area :Battery Area : Battery is placed in Battery is placed inBattery is placed inBattery is placed in rear side of the phone rear side of the phonerear side of the phonerear side of the phone Label Area : Label Area :Label Area :Label Area : This outline drawing This outline drawingThis outline drawingThis outline drawing shows the label in shows the label inshows the label inshows the label in position within the position within theposition within theposition within the battery compartment. battery compartment.battery compartment.battery compartment. The label is visible to The label is visible toThe label is visible toThe label is visible to the user at the point of the user at the point ofthe user at the point ofthe user at the point of sale prior to fitting the sale prior to fitting thesale prior to fitting thesale prior to fitting the USIM, battery pack and USIM, battery pack andUSIM, battery pack andUSIM, battery pack and cover covercovercover (Rear View) (Rear View)(Rear View)(Rear View) -Label location -Label location-Label location-Label location ① Model Name ① Model Name① Model Name① Model Name ② Color ② Color② Color② Color ③ ID for JATE ③ ID for JATE③ ID for JATE③ ID for JATE ④ ID for TELEC ④ ID for TELEC④ ID for TELEC④ ID for TELEC ⑤ Production Year & Month ⑤ Production Year & Month⑤ Production Year & Month⑤ Production Year & Month ⑥ Bar Code of IMEI ⑥ Bar Code of IMEI⑥ Bar Code of IMEI⑥ Bar Code of IMEI ⑦ ⑦ ⑦ ⑦ IMEI IMEIIMEIIMEI( (((Production Serial Number Production Serial NumberProduction Serial NumberProduction Serial Number） ））） ⑧ Operator Name ⑧ Operator Name⑧ Operator Name⑧ Operator Name FCC ID:UCE211049A FCC ID:UCE211049AFCC ID:UCE211049AFCC ID:UCE211049A ① ② ⑤ ⑥ ⑦ ③ ④ ⑧

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Softbank S21CS1 FCC ID: UCE211049A To: FCC Part 15.247: 2011 Subpart C Test Report Serial No: RFI-RPT-RP87154JD01B V2.0 Version 2.0 Supersedes All Previous Versions This Test Report Is Issued Under The Authority Of John Newell, Group Quality Manager: Checked By: Steven White Signature: Date of Issue: 31 May 2012 The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by RFI Global Services Ltd. is under licence. Other trademarks and trade names are those of their respective owners. This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP87154JD01B V2.0 VERSION NO. 2.0 ISSUE DATE: 31 MAY 2012 Page 2 of 51 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP87154JD01B V2.0 VERSION NO. 2.0 ISSUE DATE: 31 MAY 2012 RFI Global Services Ltd Page 3 of 51 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) ....................................................................................................... 7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 8 3.5. Support Equipment 9 4. Operation and Monitoring of the EUT during Testing ............................................................. 10 4.1. Operating Modes 10 4.2. Configuration and Peripherals 10 5. Measurements, Examinations and Derived Results ................................................................ 11 5.1. General Comments 11 5.2. Test Results 12 5.2.1. Receiver/Idle Mode AC Conducted Spurious Emissions 12 5.2.2. Receiver/Idle Mode Radiated Spurious Emissions 15 5.2.3. Transmitter AC Conducted Spurious Emissions 19 5.2.4. Transmitter 20 dB Bandwidth 22 5.2.5. Transmitter Carrier Frequency Separation 26 5.2.6. Transmitter Number of Hopping Frequencies and Average Time of Occupancy 29 5.2.7. Transmitter Maximum Peak Output Power 31 5.2.8. Transmitter Radiated Emissions 36 5.2.9. Transmitter Band Edge Radiated Emissions 41 6. Measurement Uncertainty .......................................................................................................... 49 Appendix 1. Test Equipment Used ................................................................................................ 50 TEST REPORT SERIAL NO: RFI-RPT-RP87154JD01B V2.0 VERSION NO. 2.0 ISSUE DATE: 31 MAY 2012 Page 4 of 51 RFI Global Services Ltd 1. Customer Information Company Name: Panasonic Mobile Communications Development of Europe Ltd. Address: Panasonic House Willoughby Road Bracknell Berkshire RG12 8FP United Kingdom TEST REPORT SERIAL NO: RFI-RPT-RP87154JD01B V2.0 VERSION NO. 2.0 ISSUE DATE: 31 MAY 2012 RFI Global Services Ltd Page 5 of 51 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Intentional Radiators) - Section 15.247 Specification Reference: 47CFR15.107 and 47CFR15.109 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart B (Unintentional Radiators) - Sections 15.107 and 15.109 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Intentional Radiators) - Sections 15.207 and 15.209 Site Registration: FCC: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 23 April 2012 to 18 May 2012 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.107(a) Receiver/Idle Mode AC Conducted Emissions Part 15.109 Receiver/Idle Mode Radiated Spurious Emissions Part 15.207 Transmitter AC Conducted Emissions Part 15.247(a)(1) Transmitter 20 dB Bandwidth Part 15.247(a)(1) Transmitter Carrier Frequency Separation Part 15.247(a)(1)(iii) Transmitter Number of Hopping Frequencies and Average Time of Occupancy Part 15.247(b)(1) Transmitter Maximum Peak Output Power Part 15.247(d) & 15.209(a) Transmitter Radiated Emissions Part 15.247(d) & 15.209(a) Transmitter Band Edge Radiated Emissions Key to Results = Complied = Did not comply TEST REPORT SERIAL NO: RFI-RPT-RP87154JD01B V2.0 VERSION NO. 2.0 ISSUE DATE: 31 MAY 2012 Page 6 of 51 RFI Global Services Ltd 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP87154JD01B V2.0 VERSION NO. 2.0 ISSUE DATE: 31 MAY 2012 RFI Global Services Ltd Page 7 of 51 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name:…
