Pro9 Headset System Installation Manual page 2 This guide specifies how the Pro9 headset system should be installed and commissioned. The LEDs on the base and headset use a sequence of colours, flashes and pulses to indicate the status of the system and the item, which are explained in this guide. CONTENTS Preface page 3 Introduction page 3 What’s in the box page 3 Tools, cabling and equipment required page 3 Installation procedure page 4 Appendix A Installing Pro9 system using existing cabling to page 10 connect the base station to the DTM located in the order point (Q-P9NTB x2) Appendix B Installing Pro9 system using existing cabling to page 11 connect the base station to the DTM located in the building (Q-P9JB x2) Appendix C Pro9 auxiliary connections (Q-P9ACB) page 12 Appendix D Pro9 repeaters (Q-P9REP) page 13 Appendix E Pro9 table service (Q-P9BSTS) page 14 Appendix F Connecting a computer to Pro9 base station page 15 Appendix G Connecting a computer to Pro9 base station page 16 using a wireless adaptor Appendix H Setting up Pro9 as dual lane/tandem configuration page 18 (Q-P9BSDL) Appendix I Recording a ‘Pull forward’ message page 20 Trouble shooting page 22 Manufacturer’s notes page 24 Headset transition table page 25 Regulatory notices page 26 Pro9 system components page 27 page 3 Preface Quail Digital Pro9 is a wireless headset system designed to facilitate order-taking in the drive-thru lane of a quick service restaurant. Team members wearing wireless headsets communicate with customers through a remote order point containing a microphone and speaker which activate on arrival of their vehicle at the post. Headset users can communicate with the customers, and on a private channel, with each other. The system uses the internationally approved DECT telephony standard and specification for transmission. Page 27 of this manual lists the components parts of the system. The sale, installation and support of the product is undertaken by organisations and individuals known to or appointed by Quail Digital. Introduction This manual is aimed at the technician level reader who is expected to be familiar with all safety precautions relevant to the use of electrical equipment. The Pro9 system differs from other drive-thru headset systems as it is digital all the way from the order point to the headset. This improves audio quality, clarity and acts as a shield from external interference. If you are unfamiliar with Quail Digital products, you are encouraged to watch our training films on this product before you start the installation, and to follow the installation steps in the order presented in this guide. Quail Digital uses direct burial Cat5 cable for the link between the order post and the base station and always recommends that solution. Proprietary or recommended cables used by other headset suppliers have been tested with Pro9 and can be used if already in the ground (subject to testing). What’s in the box • Pro9 Headset (Q-P9HS) (optional items) • Pro9 Base Station (Q-P9BS) • Pro9 Repeater (Q-P9RP) • Pro9 Charger (Q-P9CH) • Pro9 accessory kit • Pro9 Drive-Thru Module (Q-P9DTM) - Junction Box (Q-P9JB) • Pro9 Speaker & enclosure (Q-P9SPK) - Auxiliary Connection Box (Q-P9ACB) • Pro9 Microphone & enclosure (Q-P9MIC) - Network Termination Box (Q-P9NTB) • Acoustic foam (Q-P9FOAM) Tools, cabling and equipment required • Small terminal flat blade screwdriver • Cat5 patch lead • Cordless drill • Cat5 cable tester • Tape measure • Direct burial specification Cat5 cable • Spirit level • RJ45 connectors (up to 4) • Marker pen • Multimeter • Cable strippers/diagonal side cutters • Stepladder • Cat5 cable crimping tool • Laptop or phone for setup page 4 Installation procedure Step 1 The 8-port charger, power supply and metal hanger are in the box (Q-P9CH). Wall mount the charger in the manager’s office or other secure location close to a power socket using the template provided in the box. There are two key slots on the rear for mounting and one screw hole under the cap in the third battery slot from the left on the bottom battery row to secure the charger to the wall. Plug in the power supply lead to the charger feeding the cable through the securing gates. Attach the hanging bar before mounting to the wall. Step 2 Plug the power supply into a mains socket. The power LED bottom right will illuminate RED. Insert each battery into a slot. The individual LEDs will be solid red when charging and turn solid green when fully charged. On occasion new batteries may get warm during charging. If this happens, the LED will go out and charging will stop to protect the battery until it cools down, this is normal. Step 3 Remove the microphone (Q-P9MIC) and speaker (Q-P9SPK) from their boxes. The microphone is positioned against the top grill of the order point. Use the silver pre-drilled mounting bracket to fix securely where you can. There should be no gap between the face of the microphone and the grill, and the grill should have as many holes as illustrated in the diagram. If it doesn’t, consider drilling more holes to maximise the effectiveness of microphone. Step 4 Place the acoustic foam provided around the microphone to provide extra acoustic protection. Step 5 Use the same procedure as in Step 3 above to mount the speaker against the lower grill; it does not require the acoustic foam. Figure 1 - Pro9 charger Figure 2 - Order point assembly Drive-Thru Module Speaker Microphone Step 6 You now fit the Drive-Thru Module (Q-P9DTM) into to the order point using the flanges and four screws. If the DTM does not fit or cannot be mounted in the order point, go to Step 10. Step 7 Next install a single length of direct burial Cat5 cable from the DTM in the order point, through the existing underground conduit(s) to the likely location of the base station (Q-P9BS) in the kitchen area. Then, using your crimping tool, terminate both ends of the cable with RJ45 plugs, remembering to fit waterproof connection cover pro…

Text truncated - open the document above for the full version.
