SHENZHEN TENDA TECHNOLOGY CO.,LTD. Add: 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Tel: 86-755- 27657098Fax: 866-755 -27657178 E- mail: [email protected] Date: 2023-03-23 To: FEDERAL COMMUNI CATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Declaration Subject: FCC ID:V7TA23 declaration of frequency bands restriction Dear Sir o r M adam: We, SHENZHEN TENDA TECHNOLOGY CO.,LTD., hereby decla re that our product AX1500 Wi-Fi 6 Range Extender, Model Number: A23 have the a bility to work in 2.4G and 5G 4 frequency bands : 5150 MHz~5250 MHz,5250 MHz~5350MHz,5470 MHz~5725 MHz, 5725 MHz~5850 MHz. For the purpose of marketing, the frequency of t he product sold i n U.S. a re programmed and locked to work only in 5150 MHz~5250 MHz ,5725 MHz~5850 MHz, The other frequency bands5250 MHz~5350MHz,5470 MHz~5725 MHz are disabled by firmware in factory. The end user or any other parties cannot have the capability to activate the other frequency ba nds. We applied for testing only freque ncy bands : 2412~2462 MHz,5150 MHz~5250 MHz,5725 MHz~5850 MHz MHz for th e U nited States this time . And for the chipset RTL8832BR,which supports IEEE 802.11a/b/g/n/ac/ax mode, but for this product, only 5G wifi upport 802.11ax mode(5G 802.11ax mode not support OFDMA) , 2.4G wifi not support 802.11ax, which was disabled by software. Please contact me if y ou have any question. Signature: Printed Name: Shen Yue Title: Engineer

       !"# $%# &## "#  '"(')( *  ' # ++, -+ +,-+-.#/-++,-+-- 0#')(1( #)   &2-3,.454+54'54''5 (("(#('  ((    677897:7;<=>8778?  #(,,,  &  @@AB B  @@ BB  %('*#(' # C#%#(' 'C'"'  -2+ #D# @'"&# %0E'#@,2  &F ((" (#(' (#(0 (" &2-3,.454+54'54''5'' !   BG - ,  HIJKLIJ KMJKNOMJPIKQRQSTPQUVRMNU4W(#XX')# (Y5)('F'"(#((Z%'X0 (F ')#%( '*#(' '""%!(;9=<7W)CYZ%'X0 (X'E'(F0)'C' !#  Z%'X0 (#%('*#(' X%"%# ((")(' ,.F( %"  HIJKLIJ KMJKNOMJPIKQRQSTPQUVRMN4W(#XX')# (Y5)('F'"(#(#"F(#(F (F'' ! F(#XX')#(' (#XX')# ('" (' ('F' ( C '"(#"#  ('($ X%)' ! W)CYZ%'X0 (  ' )$      '! #(%   (#)([ "  % '( !'  0X# $#0\ ""     \   !"# $%# &## "# '"(')( *  ' #++,

       !"   #$%&'(&'('  )#) *+,,-./.+-+,, ..+- 012345$42$ )6$70$42#464842 '9+$:7$ ,47782$  270;<4$=,# &>  ?%8$42$;8@$3  474 .#%A/'  B)-C B)-/)-#/)B-+*+DE+ =*/#  F1GG74H$IH34?481$=$82?1 $2?1?4742?1$GG74H$42=/ $/H1272J=.H   $ 48203 84$    $ ?238364H2?G32H88?231$<263?3H .# B)-CB)-/)-# /)B-+*+DE+ =*/# F1GG74H$I$HHG82;$4$4$$?2327881$ 2J$3$?313$1$83;4$ $77;$3:4$ 4;G23$42231H2H708422? $J2; ;48842(37$ G32H 44627641K04G;   / $/H1272J=.H   $$HHG8=$82?1 $2?1?4742?1$GG74H$42= 12<74 $422?1 84$   $?238364H2?G32H88?231$<263?3H  .#   #84$    .?23;$42% 2;G$J-$;%  / $/H1272J=.H  388% L99D$76 4J2?. 083J= L 4 $8 -%  &&'' &&L /7 % >>(&>  );$47%;4J4 10M $08 H2; 4 <J G34 $;%,4J4B0 4$03%  B)-C B)-/)-#/)B-+*+DE+ =*/#   %>(L7223=/2N3)'=-2  && =C1281$J0$2$ =-$81$#4834H=151= 14$ 9 L&9 /7%L>(99(>9& L$O%L>>(99(>9 L )(;$47%H3M $ H 4 <J G34 $;%1E0 4$03%

              ! "   #$%&#'$()'$ ' '$&#'$ *&+*,+ #!$-#!$ #*$' . ./ ! ../.0 '1 ../. 2'* ,!+3+!$',$ 455 6789:;<=>8<:? '+! //""/"    @@ABB @@ B B )+#*-'+*$ '$ C')'+*$ *C*&*$ D". 'E'$ @*& ' )2F*' @ /D )FG!,+  %!$+ )+#*-'+*$  #2 *+ 2'( ,$,!$ H!          !!F( ')+#*-!& #*$' !+*I*,'+*$ B  + J$%%)'$K + ',+ $ *+& F!#'I *$ ' 2'++!& !'+*$% + 'LL*,'+*$ I M)*L2!$+ ')+#*-'+*$ *$,)*$% +#! &*%$*$% I ' ,)2!$+& !'+*$% + +#!&! 2'++!&  ',+& ,'*! )+ F( #*$' !+*I*,'+*$ B  + J$%%)'$K $ ) F!#'I & #' #'C! +#! &'2! !II!,+ '& )  $ ',+*$ H! +#! )$!&*%$! #!!F( ,!+*I( +#'+ ! '! $+ &)FG!,+ + ' !$*' I I!!' F!$!I*+& +#'+ *$,)!&  F!$!I*+& L)&)'$+ + !,+*$ ." I +#! $+*)% F)&! ,+ I 0 / A   / #*& ') +#*-'+*$ *& C'* )$+* I)+#! *++!$ $+*,! I2 +#! 'LL*,'$+ *$,!! ( )& *!$+N& &*%$'+)! O*$+! '2! #!$ )! *+! $%*$!!

        !! "#$%"&#'(&#& &#%"&#)%*)+* "#,"#")#&-!-. --. -!/&0--.- 1&)+*2*#&+# 344456789:6;8<=>?;@5A8B<;856 &*.!. ! .    CCD EE CC E E (*"),&*)#&# F&(&*)#)F)%)# G -&H&#C)%& (1I)&C.!G (IJ+*#K )#*)&)*'L(%*$&)#$&MM)+&*)#K+*)K)+&*)#KEN. E#&++&#+ )*" +*)#%!G-&#!G-/K*"11)%%)#O%(%P      Q"I'L(%*%#$*1+#K)#*)&*&*1#*K)#K1&*)# &++1M&#')#$ *")%&MM)+&*)#&%(*)#I RS+H )&$&1 R +"1&*)+% RM&*)#%+)M*)# R T DE E D EE NE "&IF1& *)&%+#*&)#MM)*&'&#+#K)#*)&)#K1&*)##*+(%*1&)'&%**" M(I)+"M( I)+)%+%(K*"%1&*)&%MF)%(#J(%*)K)I#K)*%*)*%+1M*)*%)#*" 1&H* )#+' )$#&*( U)#*#&1 "#( )* #$)#

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS AntennaChain 0 AntennaChain 1

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230206415-00A Page 70 of 70 5. RF EXPOSURE EVALUATION 5.1 Applicable Standard According to §1.1307(b)(3)(i) (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). P th is given by: 5.2 Measurement Result Operation Modes Frequency (MHz) Distance (mm) P th Maximum Conducted Power including Tune-up Tolerance (dBm) Antenna Gain (dBi) ERP (P) (dBm) ERP (P) (mW) Exemption (mW)(dBm) WLAN 2.4G 2412-2462 200 3060 34.86 23 7.1 27.95 623.73 Compliant WLAN 5G 5150-5250 200 3060 34.86 23 7.0 27.85 609.54 Compliant 5725-5850 200 3060 34.86 25 7.8 30.65 1161.45 Compliant Note: Antenna gain includes bearmforming gain. The Maximum Conducted Power including Tune-up Tolerance was declared by manufacturer. WLAN 2.4G and 5G can`t transmit simultaneously. Result: The device compliant the Exemption at 20cm distances. ===== END OF REPORT =====

Antenna Passive Test Report 页1 Antenna Passive Test Report Test Information Product Name A23 V1.0 Product stage prototype Product image Antenna Passive Test Report 页2 Product Name A23V1.0 Antenna encoded Test Category Antenna passive test Test location S parameter (laboratory) Radiation parameter (Barron test) Test date 2021-06-22 Tester Xiao Pengcheng Test environment temperature ： 24°C-28°C relative humidity ： 56%-58% atmospheric pressure ： 100kPa-101kPa Test items Normal temperature electrical performance ：□ √ E A Return loss A□ √E A gainA□ √E A directional diagram A□ √E A Port isolation A□ √E A productiveness Test basis Test report, see attached test drawings Test Conclusion The antenna radiation parameters and S parameters meet the requiremen and the antenna matches well Antenna Passive Test Report 页3 Normal temperature electrical performance test results order number Inspection items units Performance index requirements Inspection results senten ce Sample No.: 1 frequency range MHz 2400 -2500 /5150-5850 2400 -2500 /5150-5850 OK 2 Gain dBi 3/5 2410 3.5 OK 2450 4.1 OK 2500 4.1 OK 5150 4.0 OK 5500 5.1 OK 5850 4.8 OK 3 Isolation degree dB ≤- 15 2410 -24 OK 2450 -21 OK 2500 -21 OK 5150 -20 OK 5500 -25 OK 5850 -23 OK 4 Return loss dB ≤- 10 2410 -14 OK 2450 -14 OK 2500 -17 OK 5150 -25 OK 5500 -17 OK 5850 -15 OK 5 productiveness / ≥60% 2410 86% OK 2450 92% OK 2500 95% OK 5150 71% OK 5500 81% OK 5850 79% OK Antenna Passive Test Report 页4 3Ddirectional diagram XOY_PLANE XOZ PLANE 2450MHz Antenna Passive Test Report 页5 3Ddirection al diagram XOY_PLANE XOZ PLANE 5150MHz 5850MHz Vertical plane radiation field pattern Horizontal radiation field pattern Antenna Passive Test Report 页6 S11 antenna1 frequency 2412MHz-2500 MHz/5150MHz-5850MHz Antenna Passive Test Report 页7 S22 antenna2 frequency 2412MHz-2500 MHz/5150MHz-5850MHz S21（Isolation degree） antenna1/2 frequency 2412MHz-2500 MHz/5150MHz-5850MHz

TEST REPORT Applicant: SHENZHEN TENDA TECHNOLOGY CO.,LTD. Address: 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 FCC ID: V7TA23 Product Name: AX1500 Wi-Fi 6 Range Extender Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230206415-00A Date Of Issue: 2023/3/24 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230206415-00A Page 2 of 70 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230206415-00A Page 3 of 70 CONTENTS T EST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 DOCUMENT REVISION HISTORY .......................................................................................... 5 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 8 1.2.1 EUT Operation Condition: ............................................................................................................................. 8 1.2.2 Support Equipment List and Details .............................................................................................................. 8 1.2.3 Support Cable List and Details ...................................................................................................................... 8 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 9 1.3 MEASUREMENT UNCERTAINTY ........................................................................................................ 10 2. SUMMARY OF TEST RESULTS .......................................................................................... 11 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 12 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 12 3.1.1 Applicable Standard ..................................................................................................................................... 12 3.1.2 EUT Setup.................................................................................................................................................... 13 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 13 3.1.4 Test Procedure ............................................................................................................................................. 14 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 14 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 15 3.2.1 Applicable Standard ..................................................................................................................................... 15 3.2.2 EUT Setup.................................................................................................................................................... 15 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 16 3.2.4 Test Procedure ............................................................................................................................................. 16 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 16 3.3 MINIMUM 6 DB BANDWIDTH: .............................................................................................…
