V7TA301V2Wireless N300 Universal Range Extender

Wireless N300 Universal Range Extender I Wireless N300 Universal Range Extender II Copyright Statement i s the regi stered tradem ark of Shenzhen Tenda Technol ogy Co., Ltd. Al l the products and product nam es m enti oned herein are the trademark s or registered trademark s of thei r respecti ve hol ders. C opyright of the whol e product as i ntegration, i ncl uding i ts accessori es and software, bel ongs to Shenzhen Tenda Technology Co., Ltd. N o part of this publ ication can be reproduced, tr ansmi tted, transcri bed, stored in a retrieval system , or transl ated i nto any language in any form or by any m eans wi thout the pri or wri tten permi ssi on of Shenzhen Tenda Technol ogy C o., Ltd. If you would like to know m ore about our product inf ormati on, please vi si t our websi te at http://www.tendacn.com. Disclaimer of Warranties Pictures, images and product specifi cati ons herein are f or references onl y. To improve i nternal design, operati onal f unction, and/or reli abil i ty, Tenda reserves the right to mak e changes to the products described i n this docum ent wi thout obl igati on to notify any person or organi zation of such revisions or changes. Tenda does not assume any l iabil i ty that may occur due to the use or applicati on of , the product or ci rcui t l ayout(s) descri bed herei n. Every eff ort has been made i n the preparati on of this docum ent to ensure accuracy of the contents, but all statem ents, i nform ation and recommendati ons i n this document do not consti tute the warranty of any ki nd, express or im pli ed. Wireless N300 Universal Range Extender III Preface Thank you for purchasing Tenda wi reless range extender. This guide appli es to A300/A301. As they share many simi lari ti es i n many aspects, here we take A300 for exampl e. Bef ore confi guring i t, please read thi s user gui de caref ull y. Conventions Note: Inform ati on yo u need to pay attention to. Ti p: Addi tional i nf ormati on to hel p you save time or resources. Technical Support Website: http://www.te ndacn.com Techni cal Support: [email protected] .cn Telephone: (86 755) 2765 7180 Email : sal [email protected] .cn Sk ype: tendasz YouTube: Tendasz1999 Wireless N300 Universal Range Extender IV Contents C h ap t er 1 Pro d u ct O v erv iew ........................................................................ 1 1.1 Pac k age C onte nts ................................................................................. 1 1.2 G ettin g to Kno w Yo ur W ir eles s R ange Ex t ender ..................................... 1 LED ........................................................................................................ 2 Por t & Button .......................................................................................... 2 Label ...................................................................................................... 2 1.3 Pos it ion Your W ir eless R ang e Ex ten der ................................................. 2 C h ap t er 2 In t ern et C o n n ect ion Set u p .......................................................... 4 2.1 H ar d war e I ns tall ati on ............................................................................ 4 2.2 C onf igur e the R ange E x tender ........................................................... 4 Method One: Setup by Web-bas ed Mana gem e nt Pag e .............................. 4 Method Two: Setup by Button .................................................................. 7 2.3 Internet C onn ec tio n Setu p ..................................................................... 8 C onf igur e IP ............................................................................................ 8 W eb Logi n ............................................................................................... 8 2.4 Ver if y In ter net C o n nec tion .................................................................. 10 2.5 J oin Your W ir eles s C onnec tio n ............................................................ 11 W in7 O S ............................................................................................... 11 W indo ws X P O S .................................................................................... 13 C h ap t er 3 Ad v an ced S et t in g s .................................................................... 15 3.1 W izar d ................................................................................................ 15 3.2 S ys t em Status .................................................................................... 15 3.3 W ir eles s ............................................................................................. 16 3.3.1 W ir eles s Bas ic S ettings................................................................. 16 3.3.2 W ir eles s Sec ur it y .......................................................................... 17 3.3.3 Ac c es s C ontr ol ............................................................................. 18 3.3.4 W ir eles s C onnec tion S tatus ........................................................... 20 3.4 T ools .................................................................................................. 20 3.4.1 T im e Settin gs ............................................................................... 20 3.4.2 U p gr ade ....................................................................................... 21 3.4.3 B ack up/R es tor e ............................................................................ 22 3.4.4 R es tor e to F ac tor y D ef ault ............................................................ 22 3.4.5 C h ange Pas s w or d ......................................................................... 23 3.4.6 S ys lo g .......................................................................................... 24 3.4.7 R e boot ......................................................................................... 24 C h ap t er 4…

Text truncated - open the document above for the full version.

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the BTL EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Wireless N300 Universal Range Extende r Model Name A301 Brand Name Tenda Applicant SHENZHEN TENDA TECHNOLOGY CO.,LTD Address 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Standard(s) FCC Part 15, Subpart B: 2014 ANSI C63.4-2014 Report(s) BTL-FCCE-1-1509C314 The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory BTL INC. B1, No. 37, Lane 365, YangGuang St., Nei-hu District, Taipei City 114, Taiwan. TEL:+886-2-2657-3299 FAX:+886-2-2657-3331

RV-0000000 Project No.: 1509C314 Page 2 of 1 5 RV-0000000 Project No.: 1509C314 Page 3 of 1 5 RV-0000000 Project No.: 1509C314 Page 15 of 1 5

RV-0000000 Project No.: 1509C314 Page 4 of 1 5 RV-0000000 Project No.: 1509C314 Page 5 of 1 5 RV-0000000 Project No.: 1509C314 Page 6 of 1 5 RV-0000000 Project No.: 1509C314 Page 7 of 1 5 RV-0000000 Project No.: 1509C314 Page 8 of 1 5 RV-0000000 Project No.: 1509C314 Page 9 of 1 5 RV-0000000 Project No.: 1509C314 Page 10 of 1 5 RV-0000000 Project No.: 1509C314 Page 11 of 1 5 RV-0000000 Project No.: 1509C314 Page 12 of 1 5 RV-0000000 Project No.: 1509C314 Page 13 of 1 5 RV-0000000 Project No.: 1509C314 Page 14 of 1 5

FCC RF EXPOSURE REPORT FCC ID: V7TA301V2 Project No. : 1509C314 Equipment : Wireless N300 Universal Range Extender Model : A301 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Manufacturer Model Name Antenna TypeConnector Gain(dBi) 1 Tenda N/A Dipole N/A 2.25 2 Tenda N/A Dipole N/A 2.25 TEST RESULTS EUT： Wireless N300 Universal Range Extender Model Name : A301 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.25 1.6788 22.79 190.1078 0.063525831 Complies 2.25 1.6788 22.59 181.5516 0.060666701 Complies 2.25 1.6788 21.61 144.8772 0.048411701 Complies EUT： Wireless N300 Universal Range Extender Model Name : A301 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.25 1.6788 22.03 159.5879 0.053327401 Complies 2.25 1.6788 24.43 277.3320 0.092672391 Complies 2.25 1.6788 21.15 130.3167 0.043546211 Complies EUT： Wireless N300 Universal Range Extender Model Name : A301 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.25 1.6788 23.90 245.4709 0.082025781 Complies 2.25 1.6788 26.26 422.6686 0.141237611 Complies 2.25 1.6788 23.72 235.5049 0.078695591 Complies EUT： Wireless N300 Universal Range Extender Model Name : A301 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-40M MODE_Total /CH03, CH06, CH09 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.25 1.6788 22.09 161.8080 0.054069251 Complies 2.25 1.6788 26.15 412.0975 0.137705211 Complies 2.25 1.6788 22.34 171.3957 0.057273061 Complies Note: the calculated distance is 20 cm.

Report No.: BTL-FCCP-1-1509C314 Page 1 of 143 FCC Radio Test Report FCC ID: V7TA301V2 This report concerns (check one): Original Grant Class II Change Project No. : 1509C314 Equipment : Wireless N300 Universal Range Extender Model Name : A301 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Sep. 28, 2015 Date of Test : Sep. 28, 2015 ~ Oct. 19, 2015 Issued Date : Oct. 20, 2015 Tested by : BTL Inc. Testing Engineer : (Niklaus Lai) Technical Manager : (David Mao) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-1-1509C314 Page 2 of 143 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-1-1509C314 Page 3 of 143 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 TEST PROCEDURE 14 4.1.3 DEVIATION FROM TEST STANDARD 14 4.1.4 TEST SETUP 15 4.1.5 EUT OPERATING CONDITIONS 15 4.1.6 EUT TEST CONDITIONS 15 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 EUT TEST CONDITIONS 19 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 19 4.2.8 TEST RESULTS (30MHZ TO 1000 MHZ) 19 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 19 5 . BANDWIDTH TEST 20 5.1 APPLIED PROCEDURES 20 5.1.1 TEST PROCEDURE 20 5.1.2 DEVIATION FROM STANDARD 20 5.1.3 TEST SETUP 20 5.1.4 EUT OPERATION CONDITIONS 20 5.1.5 EUT TEST CONDITIONS 20 5.1.6 TEST RESULTS 20 6 . MAXIMUM PEAK CONDUCTED OUTPUT POWER TEST 21 Report No.: BTL-FCCP-1-1509C314 Page 4 of 143 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 21 6.1.1 TEST PROCEDURE 21 6.1.2 DEVIATION FROM STANDARD 21 6.1.3 TEST SETUP 21 6.1.4 EUT OPERATION CONDITIONS 21 6.1.5 EUT TEST CONDITIONS 21 6.1.6 TEST RESULTS 21 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 22 7.1 APPLIED PROCEDURES / LIMIT 22 7.1.1 TEST PROCEDURE 22 7.1.2 DEVIATION FROM STANDARD 22 7.1.3 TEST SETUP 22 7.1.4 EUT OPERATION CONDITIONS 22 7.1.5 EUT TEST CONDITIONS 22 7.1.6 TEST RESULTS 22 8 . POWER SPECTRAL DENSITY TEST 23 8.1 APPLIED PROCEDURES / LIMIT 23 8.1.1 TEST PROCEDURE 23 8.1.2 DEVIATION FROM STANDARD 23 8.1.3 TEST SETUP 23 8.1.4 EUT OPERATION CONDITIONS 23 8.1.5 EUT TEST CONDITIONS 23 8.1.6 TEST RESULTS 23 9 . MEASUREMENT INSTRUMENTS LIST 24 10 . EUT TEST PHOTO 26 ATTACHMENT A - CONDUCTED EMISSION 30 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 33 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 35 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 42 ATTACHMENT E - BANDWIDTH 91 ATTACHMENT F – MAXIMUM PEAK CONDUCTED OUTPUT POWER 100 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 104 ATTACHMENT H - POWER SPECTRAL DENSITY 129 Report No.: BTL-FCCP-1-1509C314 Page 5 of 143 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-1-1509C314 Original Issue. Oct. 20, 2015 Report No.: BTL-FCCP-1-1509C314 Page 6 of 143 1. CERTIFICATION Equipment : Wireless N300 Universal Range Extender Brand Name : Tenda Model Name : A301 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Test : Sep. 28, 2015 ~ Oct. 12, 2015 Test Sample : Engineering Sample Standard(s) : FCC Part15, Subpart C: 2014 (15.247) / ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-1-1509C314) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-1-1509C314 Page 7 of 143 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C: 201…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1509C314 Page 26 of 143 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FCCP-1-1509C314 Page 27 of 143 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-1-1509C314 Page 28 of 143 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FCCP-1-1509C314 Page 29 of 143 Radiated Measurement Photos Above 1000MHz
