V7TAC19AC1200 Dual Band Gigabit WiFi Router

Modem WPS/RST POWER IPTV/3 WAN 2 1 WPS/RST POWER IPTV/3 WAN 2 1 II. Connect your devices to the new router III. Set up the new router for internet access Tenda_XXXXXX I. Connect your router Internet Or Ethernet cable Ethernet cable Ethernet cable WPS/RST POWER IPTV/3 WAN 2 1 Dual Band Gigabit WiFi Router Quick Installation Guide AC19/AC23 (AC23 is used for illustration in this guide) If you want to copy the PPPoE user name and password from your original router, start from Step 1. Otherwise, start from Step 2. Step 1: Import your PPPoE user name and password from your original router. 1. Power on your original and new routers. 2. Connect the WAN port of the original router to a LAN port (port 1, 2, 3, and IPTV/4 for AC19; port 1, 2, IPTV/3 for AC23) of the new router using an Ethernet cable. 3. When the WAN and LAN LED indicators of the new router turn solid on for 3 seconds after blinking fast, the PPPoE user name and password are imported to your new router successfully. 4. Remove the original router. Ethernet cable Power Power New router Original router WAN Step 2: Connect your new router to the internet. Power WAN Ethernet jack 1. Power on the new router. 2. Connect the WAN port of the new router to the LAN port of your modem or the Ethernet jack using an Ethernet cable. The WAN LED indicator lights on. Method 1: Connect your WiFi-enabled device (such as a smart phone) to the new router’s WiFi network using the SSID labeled on the bottom of the router. There is no WiFi password by default. Method 2: Connect your wired device (such as a computer) to a LAN port (port 1, 2, 3, and IPTV/4 for AC19; port 1, 2, PTV/3 for AC23) of the router using an Ethernet cable. The LAN LED Iindicator lights up. 1. Start a web browser on a device that has connected to the router, and visit tendawif i.com. 2. Click Start.3. The router detects your internet connection type automatically. Set required parameters and click Next. • Wireless router * 1 • Power adapter * 1 • Ethernet cable * 1 • Quick installation guide * 1 Package contents For product or function details, please visit www.tendacn.com tendawif i.com 4 . Customize your WiFi name (SSID), WiFi password and the login password as needed, and click Next. Done. If you cannot log in to the web UI of the router, refer to Q1 in FAQ. Tip The WiFi password is used to connect to the WiFi network, and the login password is used to log in to the web UI of the router. Note Tips Quick Setup Wizard Start Tenda Router WiFi Settings Tenda_XXXXXX WiFi password of 8-32 characters Not Required Set the WiFi password as the login password of the admin account. Not Required Login password of 5-32 characters Next Skip Next Please select your connection type. As detected, your connection type may be: PPPoE ISP Password: Connection Type: ISP User Name: Import PPPoE user name and password from the original router. Enter the user name from your ISP . Enter the password from your ISP . PPPoE You’re all set! You can now connect to Tenda_XXXXXX To change settings of other features,click the "More" button below. More Jack, ports and buttons WPS: Press the button of the router for 1 to 3 seconds. Within 2 minutes, enable the WPS function of the other WPS-supported device to establish a WPS connection. Reset: When the SYS LED indicator blinks, hold the button down for about 8 seconds, release it when all the LED indicators blink once. DescriptionJack/Port/Button Power jack. Used to connect to the included power adapter. POWER WPS/RST WAN 1/2 IPTV/3 Used to start the WPS negotiation process, or to reset the router. Used to connect this router to the internet. They are LAN ports used to connect to the wired devices such as computers or switches. By default, it is a LAN port. If the IPTV function of the router is enabled, it serves only as an IPTV port used to connect to a set-top box. WPS: Press the button of the router for 1 to 3 seconds. Within 2 minutes, enable the WPS function of the other WPS-supported device to establish a WPS connection. Reset: When the SYS LED indicator blinks, hold the button down for about 8 seconds, and release it when all the LED indicators blink once. LED indicators LED indicator SYS StatusDescription Solid on Blinking O WAN LAN WiFi T Solid on Blinking O Solid on Fast blinking for twice O Solid on Fast blinking Slow blinking O The router works properly, but fails to connect to the internet. The system is faulty. The WAN port is connected properly, but no data is being transmitted Data is being transmitted over the WAN port. The WAN port is disconnected or improperly connected. At least one LAN port is connected properly. A new wired device is connected to the router. No device is connected to any LAN port of the router properly. At least the 2.4 GHz or 5 GHz WiFi network is enabled. Data is being transmitted wirelessly. The router is performing WPS negotiation. Both 2.4 GHz and 5 GHz WiFi networks are disabled. This LED is reserved. The router is starting. If the indicator still lights solid on after the router completes startup, it indicates that the router is connecting to the internet successfully. CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Operations in the 5.15-5.25GHz band are restricted to indoor use only. This equipment should be installed and operated with minimum distance 20cm between the device and your body. The mains plug is used as disconnect device, the disconnect device shall remain readily operable. NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modications to this equipment. (2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable. Declaration of Conformity Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the radio equipment type AC23 is in compliance with Directive 2014/53/EU. The full text of…

Text truncated - open the document above for the full version.

         !!""#$%&   '(  )**)  +" , - !  "  "   ,    ,   -. "  / + 0"0 !, + +  . , 12  !!"" (3 "+ +)"- !  4   + '  , +   ,  "   ! ..,    !" + +!!  "   ' +. !5"6 ! +7( ) 5"6 8 !!"  .  9)**1 ! +:  & -  ,.!" +   ); !< ! &2=7 ); :   9 *9*$*($*9  ,      &    +   + > >>>>>>>>> ?@ABCD EFGDHBIJKLBMN@LOPPQRRSKTQAK@U VWXYZ[\Z]]^_`ab_cd_edf\gh_dd][idj[khd\l[\_edga_e[\ ^mdigndh_o

          !"##$%&'(&"% !"##&))&"% *+$&,#%( -$(."&/(&"% 0&1&)&"%2 -,, &'(&"% 3"'))&%4 5%'. 6789 :; % <& ) =" !" $#>&2 <0 ?@A7B CDEDE FEGFEDH  I JK  K   3$)$ %( (" 34,.) LAM796 % AM79N "O (. PQRRSTTSQUVT WXYZT [\] P^_^W^` aUb c'(&" % L99?d>ed7e "O (. "# "O f%O"#(&"% -'(2 g +$)() '"%O&%(& &(h O" (. O" "g& %4 ,"$'()i !! f 0 <" %# jklmnop mnop " (. ,"$'( )(( >"12 g +$)( (.( (. O" "g&%4 &%O"#(&"% > .  '"%O& %(& q *r.&>&() s"%4tu# !"%O&%(& &(h c."(tu# !"%O&%(& &(h c."(tu# !"%O&%(& &(h 0h) *r(% 3."(") f%(% 3."(") 5 "'; 0&4# c'.#(&') u)( c($, 3."(") vTZwVT xaUXaY 3() s&)( u$% y, :,(&"% 0)'&,(&"%) u. " %4t(# '"%O&%(& &(h r.&>&() '"%(&% "$ ( )'() % ,",&(h &%O"#(&"% (.( '"$  > "O >%O&( (" "$ '"#,(&(")M u. ). "(t(# '"%O&%(& &(h "% (. >)&) "O %)$&%4 (.( >$)&%)) )%)&(&1 &%O"#(&"% #&%) '"%O&%(& $%(& (. '($ #;(&%4 "O "$ %g 1&'M fO h"$ .1 %h +$)(&"%)2 , ) O O (" '"%('( # ( (. )) )."g% > "gM c&%'  h2

Report No.: 1912C171 Page 2 of 10 Report No.: 1912C171 Page 3 of 10 Report No.: 1912C171 Page 4 of 10 Report No.: 1912C171 Page 5 of 10

AC19V1.0英文铜版纸 10043388 AC19V1.0 01 78.3*42.4mm 78.3mm AC2100 Dual Band Gigabit WiFi Router IP Address: 192.168.0.1 Input: 12V 2A FCC ID: V7TAC19 www.tendacn.com Made in China Model: AC19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 黑色100

Report No.: 1912C171 Page 6 of 10 2.4G &5G Ant.1 5G Ant.2 2.4G Ant.2 & 5G Ant.3 & 2.4G RX Ant.3 5G Ant.4 Report No.: 1912C171 Page 7 of 10 Report No.: 1912C171 Page 8 of 10 Report No.: 1912C171 Page 9 of 10 Report No.: 1912C171 Page 10 of 10

Report No.: BTL-FCCP-3-1912C171 Page 1 of 5 FCC RF EXPOSURE REPORT FCC ID: V7TAC19 Project No. : 1912C171 Equipment : AC2100 Dual Band Gigabit WiFi Router Brand Name : Tenda Test Model : AC19 Series Model : N/A Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Dec. 25, 2019 Date of Test : Dec. 27, 2019 ~ Feb. 21, 2020 Issued Date : Mar. 02, 2020 Report Version : R00 Test Sample : Engineering Sample No.: DG2019122549 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chay Cai Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-3-1912C171 Page 2 of 5 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Mar. 02, 2020 Report No.: BTL-FCCP-3-1912C171 Page 3 of 5 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: For 2.4G: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Dipole N/A 4 2 N/A N/A Dipole N/A 4 Note: This EUT supports CDD, and all antennas have the same gain, (1) For Non-Beamforming function, Directional gain = G ANT +Array Gain, where Array Gain is as follows: For power spectral density measurements, N ANT = 2, N SS = 1. So Directional gain = G ANT + Array Gain = G ANT + 10 log (N ANT / N SS ) dB =4+10log(2/1)dBi=7.01. Then, the power density limit is 8-(7.01-6) = 6.99. For power measurements, Array Gain = 0 dB (N ANT ≤ 4), so the Directional gain=4. (2) For Beamforming function, Beamforming Gain: 3 dB So Directional gain = 3+4=7. Then, the output power limit is 30-(7-6) = 29. For 5G: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Dipole N/A 4 2 N/A N/A Dipole N/A 4 3 N/A N/A Dipole N/A 4 4 N/A N/A Dipole N/A 4 Note: This EUT supports CDD, and all antennas have the same gain, (1) For Non-Beamforming function, Directional gain = G ANT +Array Gain, where Array Gain is as follows: For power spectral density measurements, N ANT = 4, N SS = 1. So Directional gain = G ANT + Array Gain = G ANT + 10 log (N ANT / N SS ) dB =4+10log(4/1)dBi = 10.02. Then, the UNII-1 power spectral density limit is 17-(10.02-6) = 12.98. the UNII-3 power spectral density limit is 30-(10.02-6) = 25.98. For power measurements, Array Gain = 0 dB (N ANT ≤ 4), so the Directional gain=4. (2) For Beamforming function, Beamforming Gain: 6.00 dB. So Directional gain = 4+6=10. Then, the UNII-1 and UNII-3 output power limit is 30-(10-6) = 26, Report No.: BTL-FCCP-3-1912C171 Page 4 of 5 The worst case for 3TX as follow: For 2.4G: For Non Beamforming: Operating Mode TX Mode 1TX 2TX IEEE 802.11b V (Ant. 1) - IEEE 802.11g V (Ant. 1) - IEEE 802.11n(HT20) - V (Ant. 1+ Ant. 2) IEEE 802.11n(HT40) - V (Ant. 1+ Ant. 2) For Beamforming: Operating Mode TX Mode 2TX IEEE 802.11n(HT20) V (Ant. 1+ Ant. 2) IEEE 802.11n(HT40) V (Ant. 1+ Ant. 2) For 5G: For Non Beamforming: Operating Mode TX Mode 1TX 4TX IEEE 802.11a V (Ant. 4) - IEEE 802.11n (HT20) - V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11n (HT40) - V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11ac(VHT20) - V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11ac(VHT40) - V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11ac(VHT80) - V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) For Beamforming: Operating Mode TX Mode 4TX IEEE 802.11n (HT20) V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11n (HT40) V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11ac(VHT20) V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11ac(VHT40) V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) IEEE 802.11ac(VHT80) V (Ant. 1+Ant. 2+Ant. 3+Ant. 4) Report No.: BTL-FCCP-3-1912C171 Page 5 of 5 2. TEST RESULTS For 2.4GHz_Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. AVG Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4 2.5119 22.74 187.9317 0.09396 1 Complies For 2.4GHz_ Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. AVG Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 7 5.0119 18.93 78.1628 0.07797 1 Complies For 5GHz UNII-1_Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4 2.5119 26.15 412.0975 0.20604 1 Complies For 5GHz UNII-1_Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 10 10.0000 25.88 387.2576 0.77082 1 Complies For 5GHz UNII-3_Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4 2.5119 28.37 687.0684 0.34352 1 Complies For 5GHz UNII-3_Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 10 10.0000 25.99 397.1915 0.79059 1 Complies For the max simultaneous transmission MPE: Power Density (S) (mW/cm 2 ) Power Density (S) (mW/cm 2 ) Total Limit of Power Density (S) (mW/cm 2 ) Test Result 2.4GHz 5GHz 0.09396 0.79059 0.88455 1 Complies Note: The calculated d…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-1912C171 Page 1 of 172 FCC Radio Test Report FCC ID: V7TAC19 This report concerns: Original Grant Project No. : 1912C171 Equipment : AC2100 Dual Band Gigabit WiFi Router Brand Name : Tenda Test Model : AC19 Series Model : N/A Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Dec. 25, 2019 Date of Test : Dec. 27, 2019 ~ Feb. 21, 2020 Issued Date : Mar. 06, 2020 Report Version : R00 Test Sample : Engineering Sample No.: DG2019122549 for conducted, DG2020010715 for radiated. Standard(s) : FCC Part15, Subpart E(15.407) ANSI C63.10-2013 FCC KDB 789033 D02 General UNII Test Procedures New Rules v02r01 FCC KDB 662911 D01 Multiple Transmitter Output v02r01 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chay Cai Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-2-1912C171 Page 2 of 172 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture‟s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL‟s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer‟s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-1912C171 Page 3 of 172 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 8 2 . GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF EUT 9 2.2 TEST MODES 12 2.3 PARAMETERS OF TEST SOFTWARE 14 2.4 DUTY CYCLE 16 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 18 2.6 SUPPORT UNITS 18 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 19 3.1 LIMIT 19 3.2 TEST PROCEDURE 19 3.3 DEVIATION FROM TEST STANDARD 19 3.4 TEST SETUP 20 3.5 EUT OPERATION CONDITIONS 20 3.6 TEST RESULTS 20 4 . RADIATED EMISSIONS TEST 21 4.1 LIMIT 21 4.2 TEST PROCEDURE 22 4.3 DEVIATION FROM TEST STANDARD 22 4.4 TEST SETUP 23 4.5 EUT OPERATION CONDITIONS 24 4.6 TEST RESULTS - 9 KHZ to 30 MHZ 24 4.7 TEST RESULTS - 30 MHz TO 1000 MHz 24 4.8 TEST RESULTS - ABOVE 1000 MHz 24 5 . BANDWIDTH TEST 25 5.1 LIMIT 25 5.2 TEST PROCEDURE 25 5.3 DEVIATION FROM STANDARD 25 Report No.: BTL-FCCP-2-1912C171 Page 4 of 172 Table of Contents Page 5.4 TEST SETUP 25 5.5 EUT OPERATION CONDITIONS 25 5.6 TEST RESULTS 25 6 . MAXIMUM OUTPUT POWER TEST 26 6.1 LIMIT 26 6.2 TEST PROCEDURE 26 6.3 DEVIATION FROM STANDARD 26 6.4 TEST SETUP 26 6.5 EUT OPERATION CONDITIONS 26 6.6 TEST RESULTS 26 7 . POWER SPECTRAL DENSITY TEST 27 7.1 LIMIT 27 7.2 TEST PROCEDURE 27 7.3 DEVIATION FROM STANDARD 27 7.4 TEST SETUP 27 7.5 EUT OPERATION CONDITIONS 27 7.6 TEST RESULTS 27 8 . FREQUENCY STABILITY MEASUREMENT 28 8.1 LIMIT 28 8.2 TEST PROCEDURE 28 8.3 DEVIATION FROM STANDARD 28 8.4 TEST SETUP 28 8.5 EUT OPERATION CONDITIONS 28 8.6 TEST RESULTS 28 9 . MEASUREMENT INSTRUMENTS LIST 29 10 . EUT TEST PHOTOS 31 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 35 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 40 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1 GHZ 45 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 48 APPENDIX E - BANDWIDTH 123 APPENDIX F - CONDUCTED OUTPUT POWER 132 Report No.: BTL-FCCP-2-1912C171 Page 5 of 172 Table of Contents Page APPENDIX G - POWER SPECTRAL DENSITY 154 APPENDIX H - FREQUENCY STABILITY 170 Report No.: BTL-FCCP-2-1912C171 Page 6 of 172 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Mar. 06, 2020 Report No.: BTL-FCCP-2-1912C171 Page 7 of 172 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart E(15.407) Standard(s) Section Test Item Test Result Judgement Remark 15.207 15.407(b) AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.407(b) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.407(a) 15.407(e) Spectrum Bandwidth APPENDIX E PASS ------ 15.407(a) Maximum Output Power APPENDIX F PASS ------ 15.407(a) Power Spectral Density APPENDI…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-1912C171 Page 115 of 172 Orthogonal Axis X Test Mode UNII-3_TX AC (VHT40) Mode 5795 MHz Horizontal REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 116 of 172 Orthogonal Axis X Test Mode UNII-3_TX AC (VHT40) Mode 5795 MHz Horizontal REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 117 of 172 Orthogonal Axis X Test Mode UNII-3_TX AC (VHT80) Mode 5775 MHz Vertical REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 118 of 172 Orthogonal Axis X Test Mode UNII-3_TX AC (VHT80) Mode 5775 MHz Vertical REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 119 of 172 Orthogonal Axis X Test Mode UNII-3_TX AC (VHT80) Mode 5775 MHz Horizontal REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 120 of 172 Orthogonal Axis X Test Mode UNII-3_TX AC (VHT80) Mode 5775 MHz Horizontal REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 121 of 172 The worst case of simultaneous transmission: Test Mode: TX B Mode 2437+AC 20 Mode 5825MHz Vertical REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 122 of 172 Test Mode: TX B Mode 2437+AC 20 Mode 5825MHz Horizontal REMARKS: (1) Measurement Value = Reading Level + Correct Factor. (2) Margin Level = Measurement Value - Limit Value. Report No.: BTL-FCCP-2-1912C171 Page 123 of 172 APPENDIX E - BANDWIDTH Report No.: BTL-FCCP-2-1912C171 Page 124 of 172 Test Mode UNII-1_TX A Mode_Ant.4 Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 36 5180 28.90 17.10 40 5200 37.19 19.80 48 5240 37.05 19.50 CH36 CH40 CH48 Test Mode UNII-1_TX N (HT20) Mode_Ant.4 Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 36 5180 22.39 17.90 40 5200 24.59 17.90 48 5240 22.09 17.90 CH36 CH40 CH48 Report No.: BTL-FCCP-2-1912C171 Page 125 of 172 Test Mode UNII-1_TX N (HT40) Mode_Ant.4 Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 38 5190 42.30 36.40 46 5230 65.39 37.00 CH38 CH46 Report No.: BTL-FCCP-2-1912C171 Page 126 of 172 Test Mode UNII-3_TX A Mode_Ant.4 Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 149 5745 15.79 22.20 500 Complies 157 5785 16.35 22.30 500 Complies 165 5825 15.80 22.40 500 Complies CH149 CH157 CH165 Test Mode UNII-3_TX N (HT20) Mode_Ant.4 Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 149 5745 15.80 23.60 500 Complies 157 5785 15.79 23.90 500 Complies 165 5825 15.80 24.00 500 Complies CH149 CH157 CH165 Report No.: BTL-FCCP-2-1912C171 Page 127 of 172 Test Mode UNII-3_TX N (HT40) Mode_Ant.4 Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 151 5755 32.80 36.80 500 Complies 159 5795 32.80 36.60 500 Complies CH151 CH159 Report No.: BTL-FCCP-2-1912C171 Page 128 of 172 Test Mode UNII-1_TX AC (VHT20) Mode_Ant.4 Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 36 5180 22.45 17.80 40 5200 22.10 17.80 48 5240 21.49 17.80 CH36 CH40 CH48 Test Mode UNII-1_TX AC (VHT40) Mode_Ant.4 Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 38 5190 41.30 36.20 46 5230 70.70 36.80 CH38 CH46 Report No.: BTL-FCCP-2-1912C171 Page 129 of 172 Test Mode UNII-1_TX AC (VHT80) _Ant.4 Channel Frequency (MHz) 26 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 42 5210 80.60 75.20 CH42 Report No.: BTL-FCCP-2-1912C171 Page 130 of 172 Test Mode UNII-3_TX AC (VHT20) Mode_Ant.4 Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 149 5745 15.75 20.30 500 Complies 157 5785 17.00 19.10 500 Complies 165 5825 15.89 20.00 500 Complies CH149 CH157 CH165 Test Mode UNII-3_TX AC (VHT40) Mode_Ant.4 Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 151 5755 35.30 36.40 500 Complies 159 5795 35.30 36.40 500 Complies CH151 CH159 Report No.: BTL-FCCP-2-1912C171 Page 131 of 172 Test Mode UNII-3_TX AC (VHT80) _Ant.4 Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Emission Bandwidth (MHz) 6 dB Bandwidth Min. Limit (kHz) Result 155 5775 74.20 75.20 500 Complies CH155 Report No.: BTL-FCCP-2-1912C171 Page 132 of 172 APPENDIX F - CONDUCTED OUTPUT POWER Report No.: BTL-FCCP-2-1912C171 Page 133 of 172 Non-Beamforming Test Mode UNII-1_TX A Mode_Ant.4 Channel Frequency (MHz) Conducted Output Power (dBm) Duty Factor Conducted Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 36 5180 21.89 0.51 22.40 30.00 1.00 Complies 40 5200 23.05 0.51 23.56 30.00 1.00 Complies 48 5240 22.55 0.51 23.06 30.00 1.00 Complies Test Mode UNII-3_TX A Mode_Ant.4 Channel Frequency (MHz) Conducted Output Power (dBm) Duty Factor Conducted Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 149 5745 22.88 0.51 23.39 30.00 1.00 Complies 157 5785 23.14 0.51 23.65 30.00 1.00 Complies 165 5825 23.51 0.51 24.02 30.00 1.00 Complies Report No.: BTL-FCCP-2-1912C171 Page 134 of 172 Test Mode UNII-1_TX N (HT20) Mode_Ant. 1 Channel Frequency (MHz) Conducted Output Power (dBm) Duty Factor Conducted Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 36 5180 14.54 0.58 15.12 30.00 1.00 Complies 40 5200 14.76 0.58 15.34 30.00 1.00 Complies 48 …

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1912C171 Page 28 of 117 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-1912C171 Page 29 of 117 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-1-1912C171 Page 30 of 117 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-1-1912C171 Page 31 of 117 Radiated Emissions Test Photos Above 1 GHz
