V7TAC7V3AC1200 Smart Dual-Band WiFi Router

New router Step 2: Connect your router tothe upstream device. Step 1: Migrate your PPPoE user name and password from your original router Connect your router If you want to replace your original router connected to the internet with a PPPoE user name and password, start from Step 1. Otherwise, start from Step 2. Original Router 1. Power on the new router. 2. Connect the WAN port of the new router to the LAN port of your modem or the Ethernet jack using an Ethernet cable. Then the WAN LED indicator lights on. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. The device is for indoor usage only. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment should be installed and operated with minimum distance 2 5cm between the device and your body. RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment. User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic equipment. Operating Temperature: 0 °C - 40 °C Operating Humidity: (10% - 90%) RH, non-condensing CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Operations in the 5.15-5.25GHz band are restricted to indoor use only. This equipment should be installed and operated with minimum distance 20cm between the device and your body. The mains plug is used as disconnect device, the disconnect device shall remain readily operable. NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. (2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable. Declaration of Conformity Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the radio equipment type AC7 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.tendacn.com/en/service/download-cata-101.html Operate Frequency: 2.4G: EU / 2400-2483.5 MHz (CH1-CH13) 5G: EU / 5150-5250 MHz (CH36-CH48) EIRP Power (Max.): 2.4 GHz: 19.86 dBm 5 GHz: 22.96 dBm Software Version: V15.03.06.XX Caution: Adapter Model: BN052-A09009E/BN052-A09009B Manufacture: SHENZHEN HEWEISHUN NETWORK TECHNOLOGY CO., LTD. Input: 100 - 240 V AC, 50/60 Hz, 0.3 A Output: 9V DC, 1A : DC Voltage Ethernet cable Connect your wireless devices to the router's WiFi network using the SSID labeled on the bottom of the router. There is no WiFi password by default. Connect to your devices Tenda_XXXXXX Connect your wired devices to port 1, 2 or 3/IPTV of the router using Ethernet cables. The LAN LED indicator lights on. Setting Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operating frequency: 2412-2462MHz, 5150-5250MHz, 5725-5850MHz NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. (2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable. Copyright © 2019 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders. Specifications are subject to change without notice. FAQ LED indicatorsJack, ports and buttons Q1:I
cannot
log
in
to
the
web
UI
of
the
router
after
entering
tendawifi.com,
what
should
I
do? A1: Try the following solutions and log in again: Ensure that your Ethernet cable with internet connectivity is plugged into the WAN port of the router rather than a LAN port. Ensure that your WiFi-enabled device is connected to the router's SSID. Ensure that your computer is connected to port 1, 2 or 3/IPTV of the router properly by an Ethernet cable. And it is set to Obtain an IP address automatically and Obtain DNS server address automatically. Ensure that tendawifi.com is entered correctly, or try logging by 192.168.0.1. Replace the web browser. Reset the router. Q2: I cannot access the internet afte…

Text truncated - open the document above for the full version.

         !!""#$%&   '(  )**)  +" , - !  "  "   ,  .   ,    -/ "  0 + 1"1 !, + +  / , 23  !!"" (4 "+ +)"- !  5   + '  , +   ,  "   ! //,    !" + +!!  "   ' +/ !6"7 ! +8( ) 6"7 9 !!"  /  ):**$2 ! & -  ,/!" +   8 !; ! &3<8 8<( =   : *:*$*>$:?  ,      &    +   + @ @@@@@@@@@ ABCDEF GHIFJDKLMNDOPBNQRRSTTUMVSCMBW XYZ[\]^\__`abcdaefagfh^ijaff_]kfl]mjf^n]^agficag]^ `ofkipfjaq

          !"##$%&'(&"% !"##&))&"% *+$&,#%( -$(."&/(&"% 0&1&)&"%2 -,, &'(&"% 3"'))&%4 5%'. 6789 :; % <& ) =" !" $#>&2 <0 ?@A7B CDEDE FGFDHI  J KL  L   3$)$ %( (" 34,.) MAN796 % AN79O "P (. QRSSTUUTRVWU XYZ[U \]^ Q_`_X_a bVc d'(&" % M99?e>fe7f "P (. "# "P g%P"#(&"% -'(2 h +$)() '"%P&%(& &(i P" (. P" "h& %4 ,"$'()j !! g 0 <" %# klmnolkp nol " (.  ,"$'( )(( >"12 h +$)( (.( (. P" "h&%4 &%P"#(&"% > .  '"%P& %(& q *r.&>&() s"%4tu# !"%P&%(& &(i d."(tu# !"%P&%(& &(i d."(tu# !"%P&%(& &(i 0i) *r(% 3."(") g%(% 3."(") 5 "'; 0&4# d'.#(&') u)( d($, 3."(") vU[wWU xbVYbZ 3() s&)( u$% y, :,(&"% 0)'&,(&"%) u. " %4t(# '"%P&%(& &(i r.&>&() '"%(&% "$ ( )'() % ,",&(i &%P"#(&"% (.( '"$  > "P >%P&( (" "$ '"#,(&(")N u. ). "(t(# '"%P&%(& &(i "% (. >)&) "P %)$&%4 (.( >$)&%)) )%)&(&1 &%P"#(&"% #&%) '"%P&%(& $%(& (. '($ #;(&%4 "P "$ %h 1&'N gP i"$ .1 %i +$)(&"%)2 , ) P P (" '"%('( # ( (. )) )."h% > "hN

        !"# $%# &#'# "#  (")(*) +  ( #  ,-. /01212324315  677 8,09:;<7:9=  >? @/ABCDE/F0<7:   GHI  JKLKMNOPHQQ RSTUNVTHSWPHQQTWWTHS XRVYHMTZNVTHSNSL[\NORNVTHS]T\TWTHS ^_`abNcONSLdTOOWeHNL PHORQfTNgd]  GHh YHQiVdNjPHSUKMSg  hK gkl[mnl[mG[m]XG[PlmbobpqPbrgoG]rLKUONMKVYNVVYTW[sGtJPPi]I 9:;<7:9=uvwxyz{|}~x€vw‚ƒwvx„…z‚|†wzwz‡wzˆ‰Š‹Œ~z~v~„xŽ…xz‚†xyiS NLLTVTHSrGYK‘MK’RKSUjWKOKUVTHS‘KNVRMKTWLTWNfOKLfj‘TMQ“NMK‘HMLK\TUKWQNMcKLVH VYK sk”PNSNLNrJHM]Gk•NMVH‘VYTWLK\TUKgHSOjUYNSSKOW–ˆ––“TOOfKRWKLTSmHMVY XQKMTUNgPHRSVMjUHLKWKOKUVTHSTWLTWNfOKLr  kYH ROLjHRYN\KNSj’RKWVTHSWHMUHQQKSVWMK—NMLTS—VYTWQNVVKMg•OKNWKYN\KQjfKWV NVVK SVTHSr  kTSU KMKOjg   tkT— SKL˜  mNQ K”GTVOKI™š›œž›Ÿ œ¡¢œ››£ PHQ•NSjIkl[mnl[mG[m]XG[PlmbobpqPbrgoG]r XLLMKWWI¤ˆ¥JOHHMgGH“KM[`gmHr–¦¦–gnYHS—WYNSjRNSeHNLgmNSWYNS]TWVMTUVg kYKSZYKSgPYTSNga–¥¦a§ GKOI¥¤ˆ^aaˆ§^¤a^¦ ̈¥ JN©I¥¤¤ˆ^aaˆ§^¤a^–^¥ [ˆdNTOIUKMVªVKSLNrUS

AC7V3.0-TDE01铜版贴 AC7V3.0 10042713 103*40mm FCC
ID:
V7TAC7V3 注意：需要通过耐磨试验、耐腐试验要求（包括生产打印区域） label location

Report No.: 1911C209 Page 6 of 8 2.4G Ant.1 5G Ant.2 2.4G Ant.2 5G Ant.1 Report No.: 1911C209 Page 7 of 8 Report No.: 1911C209 Page 8 of 8

Report No.: BTL-FCCP-3-1911C209 Page 1 of 5 FCC RF EXPOSURE REPORT FCC ID: V7TAC7V3 Project No. : 1911C209 Equipment : AC1200 Smart Dual-Band WiFi Router Brand Name : Tenda Test Model : AC7 Series Model : N/A Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Dec. 05, 2019 Date of Test : Mar. 15, 2020 ~ Apr. 10, 2020 Issued Date : Apr. 29, 2020 Report Version : R00 Test Sample : Engineering Sample No.:DG2019110753 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-3-1911C209 Page 2 of 5 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Apr. 29, 2020 Report No.: BTL-FCCP-3-1911C209 Page 3 of 5 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: For 2.4GHz Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Dipole N/A 5 2 N/A N/A Dipole N/A 5 Note: This EUT supports CDD, and all antennas have the same gain, so, 1) For Non Beamforming, Directional gain=G ANT +Array Gain. For output power measurements, Array Gain=0 (N ANT ≤ 4), so the Directional gain=5. For power spectral density measurements, Array Gain=10log(N ANT /N SS ) dB, so the Directional gain=5+10log(2/1)=8.01. So, the power spectral density limit is 8-(8.01-6)=5.99. 2) For Beamforming, Beamforming Gain: 3dB. So the Directional gain=3+5=8. So the output power limit is 30-(8-6)=28. For 5GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Dipole N/A 5 2 N/A N/A Dipole N/A 5 Note: This EUT supports CDD, and all antennas have the same gain, so, 1) For Non Beamforming, Directional gain=G ANT +Array Gain. For output power measurements, Array Gain=0 (N ANT ≤ 4), so the Directional gain=5. For power spectral density measurements, Array Gain=10log(N ANT /N SS ) dB, so the Directional gain=5+10log(2/1)=8.01. So, the UNII-1 power spectral density limit is 17-(8.01-6)=14.99, the UNII-3 power spectral density limit is 30-(8.01-6)=27.99. 2) For Beamforming, Beamforming Gain: 3dB. So the Directional gain=3+5=8. So the output power limit is 30-(8-6)=28. Report No.: BTL-FCCP-3-1911C209 Page 4 of 5 Table for Antenna Configuration: For 2.4GHz: Non Beamforming: Operating Mode TX Mode 1TX 2TX IEEE 802.11b V (Ant. 2) - IEEE 802.11g V (Ant. 2) - IEEE 802.11n (HT20) - V (Ant. 1 + Ant. 2) IEEE 802.11n (HT40) - V (Ant. 1 + Ant. 2) Beamforming: Operating Mode TX Mode 2TX IEEE 802.11n (HT20) V (Ant. 1 + Ant. 2) IEEE 802.11n (HT40) V (Ant. 1 + Ant. 2) For 5GHz: Non Beamforming: Operating Mode TX Mode 1TX 2TX IEEE 802.11a V (Ant.1) - IEEE 802.11n (HT20) - V (Ant. 1 + Ant. 2) IEEE 802.11n (HT40) - V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT20) - V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT40) - V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT80) - V (Ant. 1 + Ant. 2) Beamforming: Operating Mode TX Mode 2TX IEEE 802.11n (HT20) V (Ant. 1 + Ant. 2) IEEE 802.11n (HT40) V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT20) V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT40) V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT80) V (Ant. 1 + Ant. 2) Report No.: BTL-FCCP-3-1911C209 Page 5 of 5 2. TEST RESULTS For 2.4GHz Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 5 3.1623 29.93 984.0111 0.39640 1 Complies For 2.4GHz Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 8 6.3096 27.94 622.3003 0.50018 1 Complies For 5GHz UNII-1 Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 5 3.1623 26.4 436.5158 0.17585 1 Complies For 5GHz UNII-3 Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 5 3.1623 25.79 379.3150 0.15280 1 Complies For 5GHz UNII-1 Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 8 6.3096 26.43 439.5416 0.35329 1 Complies For 5GHz UNII-3 Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 8 6.3096 25.78 378.4426 0.30418 1 Complies For the max simultaneous transmission MPE: Power Density (S) (mW/cm 2 ) Power Density (S) (mW/cm 2 ) To t a l Limit of Power Density (S) (mW/cm 2 ) Test Result 2.4GHz 5GHz 0.50018 0.35329 0.85347 1 Complies Note: The calculated distance is 25 cm. End of Test Report

Report No.: BTL-FCCP-1-1911C209 Page 1 of 118 FCC Radio Test Report FCC ID: V7TAC7V3 This report concerns: Original Grant Project No. : 1911C209 Equipment : AC1200 Smart Dual-Band WiFi Router Brand Name : Tenda Test Model : AC7 Series Model : N/A Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Dec. 05, 2019 Date of Test : Mar. 15, 2020 ~ Apr. 10, 2020 Issued Date : May 06, 2020 Report Version : R01 Test Sample : Engineering Sample No.: DG2019110753 for conducted and radiated, DG2019110752 for adaptivity and receiver blocking. Standard(s) : FCC Part15, Subpart C (15.247) ANSI C63.10-2013 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-1-1911C209 Page 2 of 118 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-1911C209 Page 3 of 118 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 8 2 . GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF EUT 9 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 13 2.4 DUTY CYCLE 14 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 15 2.6 SUPPORT UNITS 15 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 16 3.1 LIMIT 16 3.2 TEST PROCEDURE 16 3.3 DEVIATION FROM TEST STANDARD 16 3.4 TEST SETUP 17 3.5 EUT OPERATION CONDITIONS 17 3.6 TEST RESULTS 17 4 . RADIATED EMISSIONS TEST 18 4.1 LIMIT 18 4.2 TEST PROCEDURE 19 4.3 DEVIATION FROM TEST STANDARD 19 4.4 TEST SETUP 20 4.5 EUT OPERATION CONDITIONS 21 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 22 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 22 4.8 TEST RESULTS - ABOVE 1000 MHZ 22 5 . BANDWIDTH TEST 23 5.1 LIMIT 23 5.2 TEST PROCEDURE 23 5.3 DEVIATION FROM STANDARD 23 5.4 TEST SETUP 23 Report No.: BTL-FCCP-1-1911C209 Page 4 of 118 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 23 5.6 TEST RESULTS 23 6 . MAXIMUM OUTPUT POWER TEST 24 6.1 LIMIT 24 6.2 TEST PROCEDURE 24 6.3 DEVIATION FROM STANDARD 24 6.4 TEST SETUP 24 6.5 EUT OPERATION CONDITIONS 24 6.6 TEST RESULTS 24 7 . CONDUCTED SPURIOUS EMISSIONS 25 7.1 LIMIT 25 7.2 TEST PROCEDURE 25 7.3 DEVIATION FROM STANDARD 25 7.4 TEST SETUP 25 7.5 EUT OPERATION CONDITIONS 25 7.6 TEST RESULTS 25 8 . POWER SPECTRAL DENSITY TEST 26 8.1 LIMIT 26 8.2 TEST PROCEDURE 26 8.3 DEVIATION FROM STANDARD 26 8.4 TEST SETUP 26 8.5 EUT OPERATION CONDITIONS 26 8.6 TEST RESULTS 26 9 . MEASUREMENT INSTRUMENTS LIST 27 10 . EUT TEST PHOTO 29 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 33 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 38 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 43 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 46 APPENDIX E - BANDWIDTH 97 APPENDIX F - MAXIMUM OUTPUT POWER 102 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 108 Report No.: BTL-FCCP-1-1911C209 Page 5 of 118 Table of Contents Page APPENDIX H - POWER SPECTRAL DENSITY 115 Report No.: BTL-FCCP-1-1911C209 Page 6 of 118 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Apr. 29, 2020 R01 Modified the comments of TCB. May 06, 2020 Report No.: BTL-FCCP-1-1911C209 Page 7 of 118 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.247) Standard(s) Section Test Item Test ResultJudgment Remark 15.207 AC Power Line Conducted EmissionsAPPENDIX APASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX EPASS ------ 15.247(b)(3) Maximum Output Power APPENDIX FPASS ------ 15.247(d) Conducted Spurious Emissions…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-1911C209 Page 34 of 169 10. EUT TEST PHOTOS AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-2-1911C209 Page 35 of 169 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-2-1911C209 Page 36 of 169 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-2-1911C209 Page 37 of 169 Radiated Emissions Test Photos Above 1 GHz
