V7TAH302Wireless N300 High Power Universal Range Extender

Wireless Range Extender I AH302 II Copyright Statement i s the regi stered tradem ark of Shenzhen Tenda Technol ogy Co., Ltd. Al l the products and product nam es m enti oned herein are the trademark s or registered trademark s of thei r respecti ve hol ders. C opyright of the whol e product as i ntegration, i ncl uding i ts accessori es and software, bel ongs to Shenzhen Tenda Technology Co., Ltd. N o part of this publ ication can be reproduced, tr ansmi tted, transcri bed, stored in a retrieval system , or transl ated i nto any language in any form or by any m eans wi thout the pri or wri tten permi ssi on of Shenzhen Tenda Technol ogy C o., Ltd. If you would like to know m ore about our product inf ormati on, please vi si t our websi te at http://www.tendacn.com. Wireless N300 High Power Universal Range Extenda III Disclaimer of Warranties Pictures, images and product specifi cati ons herein are f or references onl y. To improve i nternal design, operati onal f unction, and/or reli abil i ty, Tenda reserves the right to mak e changes to the products described i n this docum ent wi thout obl igati on to notify any person or organi zation of such revisions or changes. Tenda does not assume any l iabil i ty that may occur due to the use or applicati on of , the product or ci rcui t l ayout(s) descri bed herei n. Every eff ort has been made i n the preparati on of this docum ent to ensure accuracy of the contents, but all statem ents, i nform ation and recommendati ons i n this document do not consti tute the warranty of any ki nd, express or im pli ed. Wireless N300 High Power Universal Range Extenda IV Preface Thank you f or purchasing Tenda wi rel ess range extender. Before conf iguri ng it, please read this user gui de carefull y. Conventions Note: Inform ati on yo u need to pay attention to. Ti p: Addi tional i nf ormati on to hel p you save time or resources. Technical Support Website: http://www.te ndacn.com Email : [email protected] .cn Sk ype: tendasz YouTube: Tendasz1999 Hotl ine: 1-800-570-5892 (USA) (061) 1300787922 (Australi a) (044)197-780-6119 (U K) (0852)36120883 (HongKong) (064) 800787922 (New Zeal and) Wireless N300 High Power Universal Range Extenda V Contents C h a p t e r 1 P r o d u c t O v e r v i e w ............................................................................... 1 1 P a c k a g e C o n t e n t s ............................................................................................. 1 2 G e t t i n g t o K n o w Y o u r W i r e l e s s R a ng e E x t e n d e r .................................................. 1 L E D .................................................................................................................. 1 I n t e r f a c e s a n d B u t t o n s ..................................................................................... 2 L a b e l ............................................................................................................... 3 3 P o s i t i o n Y o u r W i r e l e s s R a n g e E x t e n d e r .............................................................. 3 C h a p t e r 2 I n t e r n e t C o n n e c t i o n S e t u p ................................................................... 4 1 P r e p a r a t i o n ...................................................................................................... 4 2 H a r d w a r e I n s t a l l a t i o n ....................................................................................... 4 3 S e t u p b y B u t t o n ................................................................................................ 5 4 I n t e r n e t C o n n e c t i o n S e t u p ................................................................................ 6 C o n f i g u r e I P ..................................................................................................... 6 C o n f i g u r e t h e w i r e l e s s r a n g e e x t e n d e r L o g i n ..................................................... 6 5 V e r i f y I n t e r n e t C o n n e c t i o n .............................................................................. 11 6 J o i n Y o u r W i r e l e s s C o n n e c t i o n ........................................................................ 14 W i n 7 O S ......................................................................................................... 14 W i n d o w s X P O S .............................................................................................. 16 C h a p t e r 3 A d v a n c e d S e t t i n g s ............................................................................. 18 1 W i z a r d ........................................................................................................... 18 2 S y s t e m S t a t u s ................................................................................................. 18 3 W i r e l e s s ......................................................................................................... 18 3 . 1 W i r e l e s s B a s i c S e t t i n g s ............................................................................. 18 3 . 2 W i r e l e s s S e c u r i t y ...................................................................................... 20 3 . 3 A c c e s s C o n t r o l .......................................................................................... 21 3 . 4 W i r e l e s s C o n n e c t i o n S t a t u s ....................................................................... 22 4 T o o l s .............................................................................................................. 23 4 . 1 T i m e S e t t i n g s ........................................................................................... 23 4 . 2 U p g r a d e ................................................................................................... 23 4 . 3 B a c k u p / R e s t o r e ...............................................…

Text truncated - open the document above for the full version.

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Wireless N300 High Power Universal Range Extender Model Name AH302 Brand Name Tenda Applicant SHENZHEN TENDA TECHNOLOGY CO., LTD. Address Tenda Industrial Park, No. 34-1, Shilong Rd., Shiyan Town, Bao’an District, Shenzhen, P.R.China 518108 Standard(s) FCC Part 15, Subpart B: 2012 ANSI C63.4 -2009 Report(s) NEI-FCCE-1-1312C082 The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

Neutron Engineering Inc. Project No.: 1312C082 Page 2 of 7 Neutron Engineering Inc. Project No.: 1312C082 Page 3 of 7 Neutron Engineering Inc. Project No.: 1312C082 Page 4 of 7

Neutron Engineering Inc. Project No.: 1312C082 Page 5 of 7 Neutron Engineering Inc. Project No.: 1312C082 Page 6 of 7 Neutron Engineering Inc. Project No.: 1312C082 Page 7 of 7

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: V7TAH302 Project No. : 1312C082 Equipment : Wireless N300 Hi gh Power Universal Range Extender Model : AH302 Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD. Address : Tenda Industrial Park, No.34-1, Shilong Rd., Shiyan Town, Bao'an District, Shenzhen, P.R. China 518108 According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) Length Note 0 Tenda Q5102 Dipole N/A 4.94 80mm TX/RX 1 Tenda Q5108 Dipole N/A 4.94 195mm TX/RX Neutron Engineering Inc. TEST RESULTS EUT： Wireless N300 High Power Universal Range Extender Model Name : AH302 Temperature： 24 °C Relative Humidity: 60 % Pressure： 1016 hPa Test Voltage : AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.94 3.1189 22.19 165.5770 0.102789881 Complies 4.94 3.1189 24.23 264.8500 0.164418381 Complies 4.94 3.1189 22.65 184.0772 0.114274771 Complies EUT: Wireless N300 High Power Universal Range Extender Model Name : AH302 Temperature: 24 °C Relative Humidity: 60 % Pressure: 1016 hPa Test Voltage : AC 120V/60Hz Test Mode : TX G MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.94 3.1189 25.01 316.9567 0.196766141 Complies 4.94 3.1189 26.82 480.8393 0.298504151 Complies 4.94 3.1189 26.23 419.7590 0.260585571 Complies Neutron Engineering Inc. EUT: Wireless N300 High Power Universal Range Extender Model Name : AH302 Temperature: 24 °C Relative Humidity: 60 % Pressure: 1016 hPa Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE /CH01, CH06, CH11 ANT0+ANT1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.94 3.1189 24.57 286.4178 0.177807621 Complies 4.94 3.1189 28.27 671.4289 0.416821751 Complies 4.94 3.1189 26.21 417.8304 0.259388291 Complies EUT: Wireless N300 High Power Universal Range Extender Model Name : AH302 Temperature: 24 °C Relative Humidity: 60 % Pressure: 1016 hPa Test Voltage : AC 120V/60Hz Test Mode : TX N-40M MODE /CH03, CH06, CH09 ANT 0+ANT 1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.94 3.1189 22.66 184.5015 0.114538201 Complies 4.94 3.1189 27.83 606.7363 0.376660751 Complies 4.94 3.1189 25.23 333.4264 0.206990481 Complies Note: The calculated distance is 20 cm.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 1 of 128 FCC Radio Test Report FCC ID: V7TAH302 This report concerns (check one): Original Grant Class II Change Issued Date : Jan. 24, 2014 Project No. : 1312C082 Equipment : Wireless N300 High Power Universal Range Extender Model Name : AH302 Applicant : SHENZHEN TENDA TECHNOLOGY CO., LTD. Address : Tenda Industrial Park, No. 34-1, Shilong Rd., Shiyan Town, Bao’an District, Shenzhen, P.R.China 518108 Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Dec. 09, 2013 Date of Test: Dec. 09, 2013~ Jan. 23, 2014 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 2 of 128 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 3 of 128 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 TEST PROCEDURE 20 4.2.3 DEVIATION FROM TEST STANDARD 20 4.2.4 TEST SETUP 21 4.2.5 EUT OPERATING CONDITIONS 22 4.2.6 EUT TEST CONDITIONS 22 4.2.7 TEST RESULTS (9K~ 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 31 5 . BANDWIDTH TEST 60 5.1 APPLIED PROCEDURES 60 5.1.1 TEST PROCEDURE 60 5.1.2 DEVIATION FROM STANDARD 60 5.1.3 TEST SETUP 60 5.1.4 EUT OPERATION CONDITIONS 60 5.1.5 EUT TEST CONDITIONS 60 5.1.6 TEST RESULTS 61 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 4 of 128 Table of Contents Page 6 . MAXIMUM OUTPUT POWER TEST 73 6.1 APPLIED PROCEDURES / LIMIT 73 6.1.1 TEST PROCEDURE 73 6.1.2 DEVIATION FROM STANDARD 73 6.1.3 TEST SETUP 73 6.1.4 EUT OPERATION CONDITIONS 73 6.1.5 EUT TEST CONDITIONS 73 6.1.6 TEST RESULTS 74 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 77 7.1 APPLIED PROCEDURES / LIMIT 77 7.1.1 TEST PROCEDURE 77 7.1.2 DEVIATION FROM STANDARD 77 7.1.3 TEST SETUP 77 7.1.4 EUT OPERATION CONDITIONS 77 7.1.5 EUT TEST CONDITIONS 77 7.1.6 TEST RESULTS 78 8 . POWER SPECTRAL DENSITY TEST 108 8.1 APPLIED PROCEDURES / LIMIT 108 8.1.1 TEST PROCEDURE 108 8.1.2 DEVIATION FROM STANDARD 108 8.1.3 TEST SETUP 108 8.1.4 EUT OPERATION CONDITIONS 108 8.1.5 EUT TEST CONDITIONS 108 8.1.6 TEST RESULTS 109 9 . MEASUREMENT INSTRUMENTS LIST 123 10 . EUT TEST PHOTO 125 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 5 of 128 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1312C082 Original Issue. Jan. 24, 2014 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 6 of 128 1. CERTIFICATION Equipment : Wireless N300 High Power Universal Range Extender Brand Name : Tenda Model Name : AH302 Applicant : SHENZHEN TENDA TECHNOLOGY CO., LTD. Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD. Address : Tenda Industrial Park, No. 34-1, Shilong Rd., Shiyan Town, Bao’an District, Shenzhen, P.R.China 518108 Date of Test : Dec. 09, 2013~ Jan. 23, 2014 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1312C082) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 7 of 128 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Standard(s) Section Test Item Judgment Remark FCC 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious …

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 125 of 128 10. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 126 of 128 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 127 of 128 Radiated Measurement Photos 30~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1312C082 Page 128 of 128 Radiated Measurement Photos Above 1000MHz
