V7TCP3Security Pan/Tilt Camera 1080P

This guide is applicable to the Ethernet port version and non-Ethernet port version of Security Pan/Tilt Camera. The Ethernet port version is used for illustration unless otherwise specified. FAQ AppearancePackage contentsAdd the camera to TDSEE App Q1. What should I do when I failed to add the camera? A1. Try the following solutions: — Ensure that the router is connected to the internet successfully. — The Security Pan/Tilt Camera only supports 2.4 GHz Wi-Fi network. When adding the Security Pan/Tilt Camera, you need to connect the smartphone to a 2.4 GHz Wi-Fi network. — Do not hide the Wi-Fi network of the router when adding the Security Pan/Tilt Camera (After adding the Wi-Fi network successfully, you can hide the Wi-Fi network). — Confirm whether the LED indicator of the camera blinks blue quickly. If not, please reset the camera and configure it again. Reset method: Hold down the Reset button for about 5 seconds and release it when the LED indicator blinks blue quickly or you hear a prompt tone. The Security Pan/Tilt Camera is reset successfully. Q2. What should I do when the video preview is not smooth? A2. Try the following solutions: — Check if the Wi-Fi network of the router is smooth. — Move the router closer to the camera. — When previewing the video with cellular data, make sure that the internet connection of the smartphone is smooth. — Auto, Fluent, and HD are supported for video preview. By default, it is Auto. You can adjust the video clarity according to the internet status. Q3. How to store the video? A3. Try the following solutions: Method 1: Install the Micro SD card to the camera. By default, the camera's recording mode is Alarm Recording, which can be set to All-day Recording through TDSEE App. Method: Run TDSEE App, choose the Security Pan/Tilt Camera on the home page, then tap Settings( in the upper right corner)→ Recording Settings, choose All-day Recording. Method 2: Subscribe Cloud Storage Service on TDSEE App. Method: Run TDSEE App, choose the camera on the home page, and then tap Cloud Storage in the lower left corner. You can enjoy free cloud storage service (7-days loop detection recording) for 3 months upon the first activation. ① Power on the camera. The LED indicator lights solid red after the camera is powered on. When the LED indicator blinks blue quickly, it indicates the camera is waiting to connect to a 2.4 GHz Wi-Fi network. Camera x 1Power adapter x 1 Quick installation guide x 1 For product or function details, please go to www.tendacn.com to download the user guide. Anchor x 2 (Height: 6.6 mm, Inner diameter:2.4 mm, Length:26.4 mm) Screw x 2 (BA3 x 25 mm, Head diameter:6.0 mm) Base x 1 Installation template x 1 Tips: Before adding your camera, please ensure that the router is connected the internet successfully and the filter function is disabled. Internet Router ② Download the TDSEE onto your mobile device by searching for TDSEE in the App Store or Google Play or by scanning the QR code. QR code ③ Run the TDSEE App and follow the instructions to complete user registration. Enter the Home page, tap the Add a device or the upper right corner of the home page . ④ Scan the QR code on the bottom of the camera, and follow the instructions in the App. Micro SD Reset Microphone Speaker Power port Micro SD card slot Reset button LED indicator LED indicator Ethernet port Reset button Micro SD card slot Solid red: Initializing and starting. Blinking red slowly: Disconnected from a 2.4 GHz Wi-Fi network. Blinking red quickly: Connecting to a 2.4 GHz Wi-Fi network. Solid blue: Connected to a 2.4 GHz Wi-Fi network. Blinking blue slowly: Upgrading. Blinking blue quickly: Waiting to connect to a 2.4 GHz Wi-Fi network. 10/100Mbps auto-negotiation Ethernet port, used for connecting the router, switch, etc. Hold down the Reset button for about 5 seconds and release it when the LED indicator blinks blue quickly or you hear a prompt tone. The camera is reset successfully. Turn the lens upward, then you can see it. Ethernet port LANPWR LANPWR 十 Quick Installation Guide Security Pan/Tilt Camera CP6&CP3 This guide is applicable to the Ethernet port version and non-Ethernet port version of Security Pan/Tilt Camera. The Ethernet port version is used for illustration unless otherwise specified. Quick Installation Guide Security Pan/Tilt Camera CP6&CP3 Or Install the device The camera supports desktop, ceiling and wall installations. This guide takes ceiling installation as an example. ①② ③④ — Please make sure the ceiling is strong enough to withstand three times the weight of the camera and base. — You may need a hammer drill, a drill bit, a screwdriver, and a ladder for the installation. Please prepare them by yourself. After finishing the ceiling installation, in order to facilitate monitoring, you need to adjust the camera installation status. Methods: Run the TDSEE App. Choose the camera on the home page, and tap Settings （ in the upper right corner）> Video Flip-over, choose Camera UP-side Down. Ceiling Buckle Slot Installation template Anchor Screw Base Drill bit diameter: 6 mm Hole depth: 28-32 mm Tips: CE Mark Warning Declaration of Conformity This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. This equipment should be installed and operated with minimum distance 20cm between the device and your body. The mains plug is used as disconnect device, the disconnect device shall remain readily operable. NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. (2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable. Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the radio equipment type CP6 is in compliance with Directive 2014/53/EU. Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the radio equipment type CP3 is in complianc…

Text truncated - open the document above for the full version.

                   !!"" #$%&'()**)+",-!"" ,   ,         - ."/+ 0"-"  + ., 1 2 !!"" (3"++) " -!4+' , +  ,      " !.., '+.!5"6!"++! ! "!+7()"   8! !". ,89 )*%*8 ,.!"+  8( 8($ 8($  8($ !: ! & 2 ;7 8(   <    =* =)$*($*%  ,        & +  +

            !" "#$%&%!$' !""%''%!$ (#)!%*%!$$+,#%!$%,%'%!$   !$-%$% %./0#'1%$122%&%!$-!&%-%&%!$!- 3456 7  89:;9<=>>?@ AB>C?=;DEFGH<=IDEFGJ?K>LAM?NNC;;C?=O;P9QA;RSALA:ATU:AV9A;&!$-%$% "$!-%$-!"%!$&&!"2$.%$1)%'22%&%!$'!#%$W!X  Y!&Z%1" [&)"%&' \2%!$'&%2%!$ ]^[&)"%&' _^Y!&Z%1" `^\2%$'&%2%!$    6)W!," %'&!$%$'&'$2!2%.%$-!"%!$$!&#'!"%.'! )2#W%&^6)2#W%&%'&!'#!-)'"%'".W)"-#!)22%&$$2!,% #$a#'%-%W $-%'!%'&!"2%!'^  6)22%&$#$'$')2#'#$![&%!$^]_5!-)/#'b%'&!'#!-)%' 22%&%!$$&&!"2$.%$1!&#"$%!$X%$!W"W-!)!-)c$ -!)%'22%&%!$^  3%'!##$'$%$1)"'#"$'2!'b 3W-!"$ &!'2!$$&#%$1)&%-%&%!$,%X2!&''&$$!W1$'&!$-%$% !&#"$'$)%'%$-!"%!$X%W,%W-!2#W%&,%X!$&)1$!-0#%2"$ #)!%*%!$%'%''#^  [%1$#  [)$d#

          ! " #$%&"'%&"(&")*(&!%"+,+-.!+/,()/ *#01234(5&6"/7887' 9")$:!  %;  <<445#  = #$ =>(4!7828= ( #!=6!=61"!=61,!=61% (?#(  (  *44@ <A4!=6!=61"!=61,!=61%444 B4C<445 <<# +4  4<</   )#D8D7/ 86/82 "#$. (4#201EFF1DE0FE8G2 &14#H/ $#

        !"#$""!  %&'()*)+,*-,*.  /'&0'12 3'45672'389:;%2<  =>?@ABCDA?EFGHIDJHIDKIDLMKI=HDNONPQ=NRSOKLR MTTUEVVFWXYZ[>>USK>\EUI]SD>R^__^SJ`>BaV`ABCbABc>ATSDABV`ABLdVeUdfeSG`EBg`EBS=`dBA LEf[AUEe`A eF  hU>TbfeTEV fUd@ed>BFGEfbUdeChABiKd[e=A?EUA^_Y_h KC@ETEVdaBAed>BF=h]S=h]XDS=h]XOS=h]XH jUABTFKEBTA Z==kLFlmK=h]  2n<80%22'n5+o++p6nnq'15'362r  912&4<893'5'n'8&69265365%qn'3   st<910%u' %2<v1'5&69254'7%43627&0'%1&0946w%&692;n'%5'3929&0'56&%&'&9892&%8&15 &0%2x<91o   628'4'n<     yz"{!|} }}}}}}}}}}}}}}}}}}}}}}} ~|y€{ |‚ƒ„……„ƒ…„†‡‚ ˆ| !"‰"Š

Report No.: 2101C171 Page 2 of 12 Report No.: 2101C171 Page 3 of 12 Report No.: 2101C171 Page 4 of 12 Adapter: BN073-A09009U Report No.: 2101C171 Page 5 of 12

Label location

Report No.: 2101C171 Page 6 of 12 Report No.: 2101C171 Page 7 of 12 Report No.: 2101C171 Page 8 of 12 Report No.: 2101C171 Page 9 of 12 Report No.: 2101C171 Page 10 of 12 Report No.: 2101C171 Page 11 of 12 Report No.: 2101C171 Page 12 of 12 Antenna

Report No.: BTL-FCCP-2-2101C171 Page 1 of 3 FCC RF EXPOSURE REPORT FCC ID: V7TCP3 Project No. : 2101C171 Equipment : Security Pan/Tilt Camera 1080P Brand Name : Tenda Test Model : CP3 Series Model : CP3-N, CP3-L, CP3-H Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Jan. 19, 2021 Date of Test : Jan. 20, 2021 ~ Mar. 01, 2021 Issued Date : Mar. 08, 2021 Report Version : R00 Test Sample : Engineering Sample No.: DG2021012014 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Peggy Zhu Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-2-2101C171 Page 2 of 3 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Mar. 08, 2021 Report No.: BTL-FCCP-2-2101C171 Page 3 of 3 1. TEST FACILITY The test facilities used to collect the test data in this report is at the location of No.3,Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. BTL's Test Firm Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Internal N/A 2 Note: The antenna gain is provided by the manufacturer. 3. TEST RESULTS Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2 1.5849 23.77 238.2319 0.07515 1 Complies Note: The calculated distance is 20 cm. End of Test Report

Report No.: BTL-FCCP-1-2101C171 Page 1 of 105 FCC Radio Test Report FCC ID: V7TCP3 This report concerns: Original Grant Project No. : 2101C171 Equipment : Security Pan/Tilt Camera 1080P Brand Name : Tenda Test Model : CP3 Series Model : CP3-N, CP3-L, CP3-H Applicant : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Manufacturer : SHENZHEN TENDA TECHNOLOGY CO.,LTD Address : 6-8 Floor, Tower E3, No. 1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052 Date of Receipt : Jan. 19, 2021 Date of Test : Jan. 20, 2021 ~ Mar. 01, 2021 Issued Date : Mar. 12, 2021 Report Version : R00 Test Sample : Engineering Sample No.: DG2021012014 for conducted, DG2021020749 for radiated. Standard(s) : FCC Part15, Subpart C (15.247) ANSI C63.10-2013 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Peggy Zhu Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-1-2101C171 Page 2 of 105 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2101C171 Page 3 of 105 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 12 2.4 DUTY CYCLE 13 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 2.6 SUPPORT UNITS 14 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 15 3.1 LIMIT 15 3.2 TEST PROCEDURE 15 3.3 DEVIATION FROM TEST STANDARD 15 3.4 TEST SETUP 16 3.5 EUT OPERATION CONDITIONS 16 3.6 TEST RESULTS 16 4 . RADIATED EMISSIONS TEST 17 4.1 LIMIT 17 4.2 TEST PROCEDURE 18 4.3 DEVIATION FROM TEST STANDARD 18 4.4 TEST SETUP 19 4.5 EUT OPERATION CONDITIONS 20 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 20 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 20 4.8 TEST RESULTS - ABOVE 1000 MHZ 20 5 . BANDWIDTH TEST 21 5.1 LIMIT 21 5.2 TEST PROCEDURE 21 5.3 DEVIATION FROM STANDARD 21 5.4 TEST SETUP 21 Report No.: BTL-FCCP-1-2101C171 Page 4 of 105 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 21 5.6 TEST RESULTS 21 6 . MAXIMUM OUTPUT POWER TEST 22 6.1 LIMIT 22 6.2 TEST PROCEDURE 22 6.3 DEVIATION FROM STANDARD 22 6.4 TEST SETUP 22 6.5 EUT OPERATION CONDITIONS 22 6.6 TEST RESULTS 22 7 . CONDUCTED SPURIOUS EMISSIONS 23 7.1 LIMIT 23 7.2 TEST PROCEDURE 23 7.3 DEVIATION FROM STANDARD 23 7.4 TEST SETUP 23 7.5 EUT OPERATION CONDITIONS 23 7.6 TEST RESULTS 23 8 . POWER SPECTRAL DENSITY TEST 24 8.1 LIMIT 24 8.2 TEST PROCEDURE 24 8.3 DEVIATION FROM STANDARD 24 8.4 TEST SETUP 24 8.5 EUT OPERATION CONDITIONS 24 8.6 TEST RESULTS 24 9 . MEASUREMENT INSTRUMENTS LIST 25 10 . EUT TEST PHOTO 27 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 31 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 34 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 39 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 42 APPENDIX E - BANDWIDTH 91 APPENDIX F - MAXIMUM OUTPUT POWER 96 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 98 Report No.: BTL-FCCP-1-2101C171 Page 5 of 105 Table of Contents Page APPENDIX H - POWER SPECTRAL DENSITY 103 Report No.: BTL-FCCP-1-2101C171 Page 6 of 105 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Mar. 08, 2021 R01 Modified the comments of TCB. Mar. 12, 2021 Report No.: BTL-FCCP-1-2101C171 Page 7 of 105 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.247) Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emissions APPENDIX G PASS -…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2101C171 Page 100 of 105 Test Mode TX G Mode Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: BTL-FCCP-1-2101C171 Page 101 of 105 Test Mode TX N-20M Mode Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: BTL-FCCP-1-2101C171 Page 102 of 105 Test Mode TX N-40M Mode Bandedge-CH03 Bandedge-CH09 CH03 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH09 – 10th Harmonic of the fundamental frequency Report No.: BTL-FCCP-1-2101C171 Page 103 of 105 APPENDIX H - POWER SPECTRAL DENSITY Report No.: BTL-FCCP-1-2101C171 Page 104 of 105 Test Mode TX B Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -6.21 8 Complies 06 2437 -6.10 8 Complies 11 2462 -5.44 8 Complies CH01 CH06 CH11 Test Mode TX G Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -10.36 8 Complies 06 2437 -7.49 8 Complies 11 2462 -8.54 8 Complies CH01 CH06 CH11 Report No.: BTL-FCCP-1-2101C171 Page 105 of 105 Test Mode TX N-20M Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -9.02 8 Complies 06 2437 -6.55 8 Complies 11 2462 -6.40 8 Complies CH01 CH06 CH11 Test Mode TX N-40M Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -10.42 8 Complies 06 2437 -10.43 8 Complies 09 2452 -10.72 8 Complies CH03 CH06 CH09 End of Test Report

Report No.: BTL-FCCP-1-2101C171 Page 27 of 105 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-2101C171 Page 28 of 105 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-1-2101C171 Page 29 of 105 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-1-2101C171 Page 30 of 105 Radiated Emissions Test Photos Above 1 GHz
